Huawei HG659 Manual de usuario

Huawei HG659

Home Router for NBN™HFC

Quick Setup Guide

HeadlineHeadline

1. Setup for NBN™HFC Broadband (Cable) 2. Powering On Your Modem

Switch your modem on using the power button located on

the side. By default, your broadband settings should configure

automatically once your NBN™ service is active and your

modem is powered on for 15 minutes.

1. The Internet light on the front of your modem should be

solid green.

2. The VoIP light on the front of your modem should be solid

green if you have an active VoIP phone service and a handset

connected to the modem. See section 4 of this guide for

more details.

Please wait for a confirmation email

from us that your NBN™ HFC service is

active before getting started.

1. Connect the Power port on the back

of your modem to your power socket.

2. Using the Ethernet cable supplied,

connect the blue WAN port on the

back of the modem to the UNI-D1

port on your NBN™ Connection Box

(note that some boxes may have one

yellow LAN port to plug into instead).

3. If you wish to use your VoIP phone

service, connect your phone handset

to the Phone1 port on the back of

your modem.

4. Using an additional Ethernet cable,

you can connect your computer

to any of the 4 LAN ports on the

back of your modem. Alternatively,

follow the steps later in this guide

to connect WiFi devices such as

computers, tablets and smartphones.

NBN Connection Box

Power Socket

NBN™ HFC Gateway

Telephone

Wall Outlet

1 3 4 2

1 2

If the internet light is off

Check if you received an email from us advising that your

service is ACTIVE.

- If you have, please check section 6 of this guide to configure

the settings manually.

- If you haven’t received the email, your NBN™ connection

is not ACTIVE yet. Please check your last email from us for

advice on your connection appointment. It will include a

reference number in case you need to call with any concerns.

Headline

4. VoIP Phone Setup

Your modem’s WiFi has been pre-configured.

You’ll find the WiFi network name (SSID) and

password (WLAN Key) printed on a sticker on

the back of your modem.

1. Make sure that WiFi is enabled on your computer, tablet,

smartphone or other WiFi device.

2. View the list of available WiFi networks on your WiFi device

and select the network called WiFi-XXXX (XXXX will be 4

random alphanumeric characters).

3. Enter the WiFi password (security key) exactly as printed on

the sticker on the back of your modem.

Note: You may notice there are two WiFi networks present.

You may connect to either of these, however most devices

will only be compatible with the 2.4GHz network. See the

sticker on your modem for more network details.

3. WiFi (Wireless) Setup

By default, your VoIP phone service should

set up automatically once your NBN™ and

VoIP services are active and your modem is

online.

All you have to do is plug a handset into the Phone1 port on

the back of your modem.

If you can’t use your VoIP phone service after setting up,

please use the contact details in section 8 of this guide to

call our Support Team for assistance.

Porting your existing phone number to VoIP?

If you’ve asked us to convert your existing phone number

to a VoIP service, please allow up to 7 days after your NBN™

service is active for this porting process to complete. We’ll

send you an email to confirm when your VoIP service is

active and ready to use.

Headline Headline

SUPPORT INFORMATION

5. Modem Indicator Lights

The following table lists how the indicator lights on the front of your modem may appear

and what they mean.

Indicator Light Description Light Description

Power Steady green Your modem is powered on

WAN Steady green Your modem is connected to NBN™

Blinking green Your modem is connecting to NBN™

Internet

Off Your modem is not connected to the Internet

Steady green Your modem is connected to the Internet. No data is being transmitted

Blinking green Your modem is connected to the Internet. Data is being transmitted

WLAN Steady green Your modem has wireless enabled

Blinking green Your modem has wireless enabled. Data is being transmitted wirelessly

VoIP Steady green Your VoIP phone service is ready

Blinking green Your VoIP phone service is in use

LAN1~LAN4 Steady green The LAN port has device plugged in and turned on

Power WAN Internet WLAN VoIP LAN1 LAN2 LAN3 LAN4 USB

6. Manual setup

1. On a computer or WiFi device that’s connected to your modem, open your web browser and go to http://192.168.1.1

2. Log in with the default username and password, which are both admin. The Start Wizard should open. If it doesn’t, select

Home > Start Wizard.

3. Select Connect with user account and enter your credentials as provided in the email advising that your NBN™ HFC service is

active.

iiNet Westnet Internode

Internet account e.g. “[email protected]” e.g. “[email protected]” e.g. “[email protected]”

Password recovery iinet.net.au/password westnet.com.au/password internode.on.net/getmypassword

4. Click Next. After connecting successfully, you may wish to customize your WiFi network by following the steps in the next

section of this guide.

5. If following these manual setup instructions doesn’t get you online, please use the details in section 8 of this guide to call

our Support Team for assistance.

1. After logging into the modem settings (see steps 1-2 on

previous page) you can customize your WiFi network details as

part of the Start Wizard, or by selecting Home Network > WLAN

Settings.

2. Your modem has 2 WiFi networks which share the same

password but broadcast on different frequencies. If your

device(s) can’t connect to the latest 5GHz network, use the

2.4GHz one.

3. The 2.4/5GHz SSIDs are the names of your WiFi networks. You

can change these to anything you’d like so they’re easier to spot

in a list of WiFi networks to join.

4. If you’re in the Home Network settings (not the Start Wizard)

make sure Security mode is set to WPA-PSK+WPA2-PSK with

TKIP+AES WPA encryption.

5. The password/WPA pre-shared key/WLAN Key is the password

for your WiFi networks. Change this to something that’s hard

for others to guess but easy for you to remember. Make sure

you write down your newWiFi details, otherwise you may

need to factory reset your modem if you forget them.

6. Click Save. After changing your WiFi details, you may need to

reconnect your WiFi device(s) using the new name/password.

7. WiFi Customisation 8. Contact Support

iiNet Westnet Internode

13 22 58 1300 786 068 1300 788 233

[email protected] [email protected] [email protected]om.au

iinet.net.au/support westnet.com.au/myhelp internode.on.net/support

Available 24/7

For operating hours during public

holidays visit iinet.net.au/contact

Available 24/7

For operating hours during public

holidays visit westnet.com.au/contact

Mon-Sun 7AM-Midnight (ACST)

For operating hours during public

holidays visit internode.on.net/contact

Account management

toolbox3.iinet.net.au

Account management

myaccount3.westnet.com.au

Account management

internode.on.net/myinternode
