Huawei E5186 Manual de usuario

HOME WIRELESS

BROADBAND

Huawei E5186

YRUK

SRGD

TCNTG

 ET(de i!

BEFORE YOU

GET STARTED

Make sure you read through all the

instructions to make sure you’re up

and running in no time.

WHERE TO PUT YOUR HOME WIRELESS BROADBAND

To get the best signal, the ideal place for your

device will be near a window. Try a few different

areas until you find one with the best signal

strength.

THINGS THAT CAN AFFECT YOUR SIGNAL STRENGTH

Concrete or wooden walls can really weaken

the transmission of wireless signals, as well as

electrical appliances that project strong electric

or magnetic fields such as microwave ovens,

refrigerators and satellite antennas. Best keep

away from them.

12mm

15mm

Huawei E5186

HUAWEI E5186 USER GUIDE

(the one in your hand right now)

POWER ADAPTORNETWORK CABLE

MICRO SIM CARD

SIMPLE & EASY

TO SET UP

STEP 1 – INSERT THE SIM CARD.

Follow the 3 steps in the illustration below.

STEP 2 – CONNECT THE POWER ADAPTOR.

1. Follow the illustration to plug in the

power adaptor.

2. Turn the power switch on and the device will

start registering to the Optus network.

3. Solid blue light will appear once the service is

registered (allow a few mins)

TWO WAYS TO CONNECT YOUR DEVICES TO THE NET.

1) Ethernet Cable

Connect one end of the Ethernet Cable into any

of these 4 LAN ports. The other end simply plugs

into your device (i.e. Laptop or PC)

Note: Up to4devices can be connected using the LAN ports (1-4).

2) Wi-Fi

Here’s how to enjoy a cable free connection

to your Wi-Fi devices such as laptops, tablets

and iPods.

1) Check to make sure the Wi-Fi indicator light on

your device is on. Press the button on the side of

your device if you need to switch on Wi-Fi. (refer to

the section: GET TO KNOW YOUR DEVICE)

XXXXXXXXXXXXXXXXXX X X X X X

XXXXXXXXXXXXXXXXXXXX X X X

2) Switch on Wi-Fi on the device you wish to

connect. For help on this check your laptop/

device manual or ask the techy person in your

family.

3) Search for the Huawei Wireless Network name

on your laptop/device. The network name or

SSID can be found on the label of the back of

the device, along with your Security/Wi-Fi key

(which you’ll need too).

4) Click connect, and enter the Security/Wi-Fi Key.

You’ll now be connected to the internet!

Note: Device supports 2.4 GHz and 5 GHz Wi-Fi networks.

Tip! Some laptops have a Wi-Fi switch

that needs to be turned on before you can search for

a wireless network (usually on the side or at the top

of your key pad). If you need help with this refer to

your user manual.

HOW TO CHANGE PASSWORDS AND DEVICE

SETTINGS

If you want to change your password, check your

speeds or find more info on your wireless network,

just follow these simple steps:

1) Set up the device and connect as outlined in

this guide.

2) Enter http://192.168.8.1 into your browser

and press ‘Enter’ or ‘Go’.

3) Enter the username ‘admin’ and password

‘admin’ in the login window then log in.

•On: turned on

•Off: turned off

•Steady cyan (blue): The DEVICE is connected to

the Optus 4G Plus network.

•Steady red:

− The SIM card is not recognised or the PIN has

not been entered correctly.

− The device failed to connect to a wireless

network.

•On: Wi-Fi is on

•Blinking: WPS interconnection verification is in

progress. This process should not take longer

than 2 minutes.

•Off: Wi-Fi is switched off

•For Voice Calls (not available at this time).

101112 13 15

12345

5 – SIGNAL INDICATOR

• On: Shows network signal strength. Full lights

means a strong signal.

• Off: No network signal.

6 – MICRO SIM CARD SLOT

7 – WI-FI BUTTON

• Press and hold for 1 second to switch Wi-Fi on

and off.

8 – RESET BUTTON

• Press and hold for 3 or more seconds to restore

factory settings.

Note: Restoring to factory settings clears all changes to settings you might

have made.

9 – WPS BUTTON

• Pressing this will let you choose between the

two supported Wi-Fi Networks. Here’s how:

– Press and hold the button for one to

fiveseconds to set up a 2.4 GHz WPS

connection or

– Press and hold the button for five seconds or

more to set up a 5 GHz WPS connection.

10 – POWER BUTTON

Press this button to power the DEVICE on or off.

11 – POWER PORT

Where you connect the device’s power adapter.

12 – USB PORT

Connect to a USB storage device or USB printer.

Note:

• The device supports USB 1.1 and 2.0 storage devices in FAT16, FAT32,

ext2, and ext3 formats. Storage devices with power supply requirements

exceeding USB standards may not work properly. It is recommended that you

prepare an external power supply in these cases. The device is compatible

with samba-supported USB printers.

• This port cannot be connected to USB host devices, such as computers.

13 – TELEPHONE PORTS (RJ11)

• Thisfunctionalityisnotcurrentlyavailable.

14 – LAN PORTS (RJ45)

• Letsyouconnectyourmodemtocomputers,

switches, or other network devices.

15 – LAN4/WAN PORT (RJ45)

• Connecttocomputer,switch,orothernetwork

device. WAN functionality is not currently

available.

16 – LAN4/WAN INDICATOR

• On:Theportisconnectedtoadevice.

• Blinking:Dataisbeingtransmittedthroughthe

port.

• Off:Nodeviceisconnectedtotheport.

17 – LAN INDICATORS

• On:Theportisconnectedtoadevice.

• Blinking:Dataisbeingtransmittedthroughthe

port.

• Off:Nodeviceisconnectedtotheport.

18 – EXTERNAL ANTENNA PORTS (SMA TYPE)

• Connecttoexternalantennas(optional).

Note: Before you connect an external antenna to the device, remove the

device’s rear cover.

SUPER IMPORTANT!

• Duringthunderstormsswitchoffthedevice

and remove all cables.

• Donotuseanexternalantennaorapower

adapter that is not a standard component for

the device or is not Optus approved. Optus is

not liable for any problems that may result from

useofsuchanexternalantennaorapower

adapter. Outdoor antennas must be installed by

a licenced cabler.

• Warning:Thisequipmentwillnotworkwhen

mains power fails.

• TheModemandSIMcardforthisdeviceare

made for each other and will refuse to work

with any other device.

MOVING HOME?

Your Home Wireless Broadband service can move

with you, just give us a buzz to make sure there’s

coverage in your new location.
