Thank you for choosing the Mobile Broadband

USB Stick. With your USB Stick, you can access

a wireless network at high speed.

Note:

This manual describes the appearance of the USB Stick, as well as the

procedures for preparation, installation, and removal. For operation details

about the management program, see the online help included in the

management program.

Getting to Know Your USB Stick

The following figure shows the appearance of the USB Stick. It is provided

only for your reference. The actual product may be different.

nUSB Connector

It connects the USB Stick to a PC.

oExternal Antenna Jack

It connects an external antenna to the USB Stick.

pIndicator

It indicates the status of the USB Stick.

zSolid: The USB Stick is powered on.

zBlinking once every 2s: The USB Stick is searching for a network or no

network is found.

zBlinking twice every 2s: The USB Stick finds a network.

zBlinking once every 0.2s: The USB Stick is transmitting data.

qStrap Hole

You can tie a strap to the USB Stick through the strap hole.

Installation/Removal Guide

The procedure for installing the management program depends on the

operating system (OS) installed on your PC. The following sections take

Windows XP as an example.

Connecting the USB Stick to a PC

Plug the USB Stick into the USB port of your PC.

Installing the USB Stick Management Program

1. Connect the USB Stick with the PC.

2. The OS automatically detects and recognizes the new hardware and

starts the installation wizard.

Note:

If the auto-run program does not respond, find the AutoRun.exe file in

the driver path. Then double-click AutoRun.exe to run the program.

3. Follow the on-screen instructions of the installation wizard.

4. After the program is installed, a shortcut icon for the management

program appears on the desktop.

Starting the Management Program

After being installed, the management program starts automatically. Then

every time the USB Stick is connected to the PC, the management

program starts automatically.

You can also double-click the shortcut icon on the desktop to start the

management program.

Removing the USB Stick

1. Double-click in the notification area. Then the Unplug or Eject

Hardware dialog box appears.

2. Select the corresponding hardware and then click Stop.

3. When the message "It is safe to remove the device" appears,

remove the USB Stick.

Uninstalling the Management Program

1. Choose Start > Control Panel > Add or Remove Programs.

2. Find the management program and click Remove to uninstall the

management program.

Note:

Exit the management program before uninstalling it.

Version: V100R001_01 Part Number: 3101****
