Huawei E3531S-3 Guía de solución de problemas

Thank you for choosing the Mobile Broadband USB

Stick. With your USB Stick, you can access a wireless

network at high speed.

Note:

This manual describes the appearance of the USB Stick, as well as the procedures for

preparation, installation, and removal. For operation details about the management

program, see the online help included in the management program.

Getting to Know Your USB Stick

The following figure shows the appearance of the USB Stick. It is provided only for your

reference. The actual product may be different.

USB Connector

It connects the USB Stick to a PC.

Strap Hole

You can tie the cap and the USB Stick together by threading a strap through the strap holes,

so that the cap will not be easily lost.

Indicator

It indicates the status of the USB Stick.

Green, blinking twice every 2s: The USB Stick is powered on.

Green, blinking once every 2s: The USB Stick is registering with a 2G network.

Blue, blinking once every 2s: The USB Stick is registering with a 3G/3G+ network.

Green, solid: The USB Stick is connected to a 2G network.

Blue, solid: The USB Stick is connected to a 3G network.

Cyan, solid: The USB Stick is connected to a 3G+ network.

Off: The USB Stick is removed.

SIM Card Slot

It holds a Subscriber Identity Module (SIM) card.

microSD Card Slot

It holds a microSD card.

Getting Your USB Stick Ready

1. Slide the cover to remove it from the USB Stick.

2. Insert the SIM card and the microSD card into the corresponding card slots, as shown in

the following figure.

3. Replace the cover and click it into place.

Note:

The microSD card is an optional accessory. If it is not provided in the package, you can

buy one yourself.

Ensure that the beveled edge of the SIM card is properly aligned with that of the SIM

card slot and the microSD card is inserted according to the direction as labeled on the

microSD card slot.

Do not remove the microSD or SIM card when the card is in use. Otherwise, the card as

well as your USB Stick may get damaged and the data stored on the card may be

corrupted.

Installation/Removal Guide

The procedure for installing the management program depends on the operating system

(OS) installed on your PC. The following sections take Windows 7 as an example.

Connecting the USB Stick to a PC

Plug the USB Stick into the USB port of your PC.

Installing the USB Stick Management Program

1. Connect the USB Stick with the PC.

2. The OS automatically detects and recognizes the new hardware and starts the

installation wizard.

Note:

If the auto-run program does not respond, find the AutoRun Application in the driver path.

Then double-click AutoRun Application to run the program.

3. Follow the on-screen instructions of the installation wizard.

4. After the program is installed, a shortcut icon for the management program appears on

the desktop.

Starting the Management Program

After being installed, the management program starts automatically. Then every time the

USB Stick is connected to the PC, the management program starts automatically.

You can also double-click the shortcut icon on the desktop to start the management

program.

Removing the USB Stick

1. Click in the notification area.

2. Select the corresponding hardware and then click Safely Remove Hardware andEject

Media.

3. Remove the USB Stick after a while.

Uninstalling the Management Program

1. Choose Start > Control Panel > Uninstall a program.

2. Find the management program and double-click it to uninstall the management

program.

Note:

Exit the management program before uninstalling it.

Version: V100R001_01Part Number: 3101****
