Huawei HG532t Manual de usuario

HG532t Home Gateway

User Guide

HUAWEI TECHNOLOGIES CO., LTD.

HG532t Home Gateway

V100R001

User Guide

Issue 01

Date 2012-10-26

Part Number 202534

Huawei Technologies Co., Ltd. provides customers with comprehensive

technical support and service. Please feel free to contact our local office

or company headquarters.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: mobile@huawei.com

rights reserved.

No part of this document may be reproduced or transmitted in any form or by any means

without prior written consent of Huawei Technologies Co., Ltd.

The product described in this manual may include copyrighted software of Huawei

Technologies Co., Ltd and possible licensors. Customers shall not in any manner

reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse

engineer, lease, assign, or sublicense the said software, unless such restrictions are

prohibited by applicable laws or such actions are approved by respective copyright

holders under licenses.

Trademarks and Permissions

, , and

are trademarks or registered trademarks of Huawei

Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned are the property of

their respective owners.

Notice

Some features of the product and its accessories described herein rely on the software

installed, capacities and settings of local network, and may not be activated or may be

limited by local network operators or network service providers. Thus the descriptions

herein may not exactly match the product or its accessories you purchase.

Huawei Technologies Co., Ltd reserves the right to change or modify any information or

specifications contained in this manual without prior notice or obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS’’. EXCEPT AS

REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR

CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE

SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL,

INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS,

BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and will

obtain all necessary governmental permits and licenses in order to export, re-export or

import the product mentioned in this manual including the software and technical data

therein.

Contents

1 Connecting the Cables and Getting Started ........................... 1

1.1 Adjusting the Antenna ...................................................................1

1.2 Connecting Cables Using the ADSL Port ........................................1

1.3 Connecting Cables Using the USB Port ..........................................3

1.4 Getting Started .............................................................................3

2 Setting Network Access Parameters....................................... 4

2.1 Logging In to the Web-based Configuration Utility..........................4

2.2 Configuring a Dial-up Connection for Internet Access .....................5

3 Setting Up a Wireless Connection........................................... 6

3.1 Setting Up a Wireless Connection With the WPS Button ..................6

3.2 Setting Up a Wireless Connection Manually....................................7

4Using the USB Port ...................................................................... 9

4.1 Going Online Using a USB Modem ...............................................9

4.2 Accessing a Portable Storage Device Using the Samba Server........10

4.3 Accessing a Printer Using the Printer Server .................................11

5 Maintenance Guide ................................................................. 12

5.1 Changing the User Name and Password for the Web-Based

Configuration Utility.........................................................................12

5.2 Enabling or Disabling the Wireless Network Function ...................12

5.3 Changing the Wireless Network Name and Password.....................13

5.4 Changing the PIN code for your SIM card ....................................13

5.5 Restoring Default Settings ...........................................................14

6 FAQs......................................................................................... 15

7 Appendix.................................................................................. 18

7.1Indicators...................................................................................18

7.2 Ports and Buttons........................................................................20

7.3 Default Settings ..........................................................................22

7.4 Technical Specifications ..............................................................22

1 Connecting the Cables and Getting

Started

Thank you for purchasing the HG532t.

HG532t supports the ADSL broadband services and USB modem services,

and you can go online using the ADSL port or USB port.

1.1 Adjusting the Antenna

When adjusting the antenna, refer to the following direction.

1.2 Connecting Cables Using the ADSL Port

If your home has opened Asymmetric Digital Subscriber Line (ADSL)

broadband services, you can access the internet using the telephone wall jack

available in your home.

The following figure shows an example of how to connect cables using the

ADSL port. In this example, the HG532t is connected to a desktop computer, a

laptop computer, and a telephone.

1. Power adapter

2. Desktop computer

3. Laptop computer

4. Telephone

5. Splitter

6. Telephone wall jack

7. HG532t

a. Splitter MODEM port

b. Splitter PHONE port

c. Splitter LINE port

1.3 Connecting Cables Using the USB Port

The following figure shows an example of how to connect cables using the USB

port. In this example, the HG532t is connected to a desktop computer, a laptop

computer, and a telephone.

1 2

Power adapter 2.

HG532t 3.

USB modem

Desktop computer 5.

Laptop computer

1.4 Getting Started

After connecting the cables, press the On/Off button on the side of the HG532t

to power on the HG532t.

After you power on the HG532t, the Power indicator turns on, indicates that the

HG532t is working properly.

To power off the HG532t, press the On/Off button on the side panel,

and then unplug the power adapter.

2 Setting Network Access Parameters

2.1 Logging In to the Web-based Configuration

Utility

Most of the HG532t parameters are preset before delivery to meet common

home application scenarios. To check the HG532t's working status or configure

certain advanced network functions, use the web-based configuration utility.

To log in to the web-based configuration utility:

Step 1 Set up network access for your computer. Set the network connection

of your computer to obtain an IP address automatically.

Step 2 Open a web browser on your computer and ensure that the browser

does not use any proxy servers.

Using Internet Explorer 8.0 as an example to ensure no proxy servers

are used:

1. Choose Tools > Internet Options.

2. On the Connections tab of the Internet Options dialog box, click

LAN Settings.

3. In the Proxy server area, ensure that Use a proxy server for your

LAN is cleared. If Use a proxy server for your LAN is selected, clear

Use a proxy server for your LAN, and then click OK.

Step 3 Enter http://192.168.1.1 in the address bar, and then press Enter.

By default, the Dynamic Host Configuration Protocol (DHCP)

function is enabled. The HG532t then assigns an IP address to your

computer automatically. If you disable the DHCP function, please

ensure that the IP address of the computer and that of the HG532t

LAN port are in the same network segment to enable the computer to

access the web-based configuration utility.

Step 4 Enter the user name (default is user) and password (default is user) in

the Username and Password text boxes.

Step 5 Click Login.

After the system verifies your account information, the web-based configuration

utility is displayed.

2.2 Configuring a Dial-up Connection for Internet

Access

The HG532t works in routing mode by default. And the HG532t starts to set up a

dial-up connection automatically after the startup. You can access the network

after you power on your computer. You do not need to install any special dial-up

software on your computer or perform dial-up operations on your computer.

To configure the HG532t and your computer for the network access, do as

follows:

Step 1 Log in to the HG532t's web-based configuration utility.

Step 2 Choose Basic > WAN to display the WAN tab.

Step 3 In Connection type, select IP_Routed (PPP).

Step 4 In User name and Password, enter the user name and password that

are provided by your service provider, and then click Submit.

Step 5 Choose Basic > WLAN to display the WLAN tab.

Step 6 In SSID and WPA pre-shared key, set the wireless network name

and password. Use the default settings for other parameters, and then

click Submit.

For security reasons or to make the password easy to remember,

you can change the user name and password for the web-based

configuration utility. For details, see section 5.1 "Changing the User

Name and Password for the Web-Based Configuration Utility".

The default wireless network name (SSID) and password (WLAN

Key) which are printed on the label of the HG532t's rear panel are

preset before delivery. They are unique and safe. For security

reasons or to make the wireless network name and password easy

to remember, you can change them. For details, see section 5.3

"Changing the Wireless Network Name and Password".
