HUAWEI HG532c Home Gateway

User Guide

HUAWEI TECHNOLOGIES CO., LTD.

HUAWEI HG532c Home Gateway

V100R001

User Guide

Issue 01

Date 2010-07-26

Part Number 202263

Huawei Technologies Co., Ltd. provides customers with comprehensive

technical support and service. Please feel free to contact our local office

or company headquarters.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: [email protected]

rights reserved.

No part of this document may be reproduced or transmitted in any form or by any means

without prior written consent of Huawei Technologies Co., Ltd.

The product described in this manual may include copyrighted software of Huawei

Technologies Co., Ltd and possible licensors. Customers shall not in any manner

reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse

engineer, lease, assign, or sublicense the said software, unless such restrictions are

prohibited by applicable laws or such actions are approved by respective copyright

holders under licenses.

Trademarks and Permissions

, , and

are trademarks or registered trademarks of Huawei

Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned are the property of

their respective owners.

Notice

Some features of the product and its accessories described herein rely on the software

installed, capacities and settings of local network, and may not be activated or may be

limited by local network operators or network service providers. Thus the descriptions

herein may not exactly match the product or its accessories you purchase.

Huawei Technologies Co., Ltd reserves the right to change or modify any information or

specifications contained in this manual without prior notice or obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS

REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR

CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE

SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL,

INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS,

BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and will

obtain all necessary governmental permits and licenses in order to export, re-export or

import the product mentioned in this manual including the software and technical data

therein.

Contents

1Warnings and Precautions ....................................................................... 1

2Connecting the Cables and Getting Started............................................ 4

2.1 Simple Connection .......................................................................................4

2.2 Connecting One Telephone ..........................................................................5

2.3 Getting Started .............................................................................................5

3Setting the Network-Access Parameters ................................................. 6

3.1 Configuring the ADSL uplink......................................................................6

Accessing the Network Through the Embedded PPP Dial-Up Software on

the HG532c ................................................................................................6

Accessing the Network Through the PPP Dial-Up Software on Your

Computer....................................................................................................7

3.2 Configuring the HSPA uplink ......................................................................8

3.3 Configuring the Wireless Network Connection............................................9

Setting Up a Wireless Connection Through the WPS Button.....................9

Setting Up a Wireless Connection Manually............................................10

4Configuring the HG532c......................................................................... 12

4.1 Changing the Administrator Password Used for Logging In to the

Web-Based Configuration Utility ......................................................................12

4.2 Enabling or Disabling the Wireless Network Function ..............................12

4.3 Changing the Wireless Network Name and the Access Password .............13

4.4 Changing the IP Address Used for Logging In to the Web-Based

Configuration Utility .........................................................................................13

4.5 Restoring Default Settings..........................................................................14

5FAQs......................................................................................................... 15

6Appendix.................................................................................................. 20

6.1 Indicators....................................................................................................20

6.2 Interfaces and Buttons................................................................................21

6.3 Default Settings..........................................................................................22

6.4 Technical Specifications.............................................................................22

1 Warnings and Precautions

Thank you for purchasing the HUAWEI HG532c Home Gateway (hereinafter referred

to as the HG532c).

To use the device properly and safely, read these warnings and precautions carefully

and strictly observe them during operation. Unless otherwise specified, the term

"device" refers to the device and its accessories.

Basic Requirements

zDuring storage, transportation, and operation of the device, keep it dry and prevent

it from colliding with other objects.

zDo not dismantle the device. In case of any fault, contact an authorized service

center for assistance or repair.

zWithout authorization, no organization or individual can change the mechanical,

safety, or performance design of the device.

zWhen using the device, observe all applicable laws and regulations and respect the

legal rights of other people.

Environmental Requirements for Using the Device

zBefore connecting and disconnecting cables, stop using the device, and then

disconnect it from the power supply. Ensure that your hands are dry during

operation.

zKeep the device far from sources of heat and fire, such as a heater or a candle.

zKeep the device far from electronic appliances that generate strong magnetic or

electric fields, such as a microwave oven or a refrigerator.

zPlace the device on a stable surface.

zPlace the device in a cool and well-ventilated indoor area. Do not expose the device

to direct sunlight.

zUse the device in an area with a temperature ranging from 0°C to 40°C.

zDo not block the openings on the device with any object. Reserve a minimum space

of 10 cm around the device for heat dissipation.

zDo not place any object (such as a candle or a water container) on the device. If any

foreign object or liquid enters the device, stop using the device immediately, power

it off, remove all the cables connected to it, and then contact an authorized service

center.

zDuring thunderstorms, power off the device, and then remove all the cables

connected to it to prevent it from getting damaged due to lightning strikes.

Precautions for Using Wireless Devices

zWhen using the device, ensure that the antenna of the device is at least 20 cm away

from all persons.

zDo not use the device where using wireless devices is prohibited or may cause

interference or danger.

zThe radio waves generated by the device may interfere with the operation of

electronic medical devices. If you are using any electrical medical device, contact

its manufacturer for the restrictions on the use of the device.

zDo not take the device into operating rooms, intensive care units (ICUs), or

coronary care units (CCUs).

Areas with Inflammables and Explosives

zDo not use the device where inflammables or explosives are stored, for example, in

a gas station, oil depot, or chemical plant. Otherwise, explosions or fires may occur.

In addition, follow the instructions indicated in text or symbols.

zDo not store or transport the device in the same box as inflammable liquids, gases,

or explosives.

Accessory Requirements

zUse only the accessories supplied or authorized by the device manufacturer.

Otherwise, the performance of the device may get affected, the warranty for the

device or the laws and regulations related to telecommunications terminals may

become null and void, or an injury may occur.

zDo not use the power adapter if its cable is damaged. Otherwise, electric shocks or

fires may occur.

zEnsure that the power adapter meets the specifications indicated on the device

nameplate.

zEnsure that the power adapter meets the requirements of Clause 2.5 in

IEC60950-1/EN60950-1 and it is tested and approved according to national or local

standards.

Safety of Children

Keep the device and its accessories out of the reach of children. Otherwise, they

may damage the device and its accessories by mistake, or they may swallow the

small components of the device, causing suffocation or other dangerous situations.

Maintenance

zIf the device is not used for a long time, power it off, and then remove all the cables

connected to it.

zIf any exception occurs, for example, if the device emits any smoke or unusual

sound or smell, stop using the device immediately, power it off, remove all the

cables connected to it, and then contact an authorized service center.

zDo not trample, pull, or overbend any cable. Otherwise, the cable may get damaged,

causing malfunction of the device.

zBefore cleaning the device, stop using it, power it off, and then remove all the

cables connected to it.

zUse a clean, soft, and dry cloth to clean the device shell. Do not use any cleaning

agent or spray to clean the device shell.

2 Connecting the Cables and Getting

Started

2.1 Simple Connection

If your telephone line is used for the broadband network access only and do not need to

use a telephone, take the following figure as a reference for connecting the cables.

1. Power adapter 2. Computer 3. Telephone jack on the wall

If the wireless network function is used on the HG532c for the network access, you do

not need to connect the network cable.

2.2 Connecting One Telephone

If your telephone line is used for both the broadband network access and a telephone

connection, take the following figure as a reference for connecting the cables.

a. MODEM interface b. PHONE interface c. LINE interface

1. Power adapter 2. Computer 3. Telephone

4. Splitter 5. Telephone jack on the wall

2.3 Getting Started

Press down the ON/OFF button on the side of the HG532c to power on the HG532c.

After you power on the HG532c, the Power indicators turns on and the ADSL indicator

blinks (for less than three minutes), which indicates that the HG532c is being activated.

After the ADSL indicator blinking, the Power and ADSL indicators keep solid on,

which indicates that the HG532c is working properly.
