Huawei MU509 Series Manual

HUAWEI 30 mm x 30 mm LGA Module

Development Kit Guide

Issue

Date

2016-12-12

No part of this manual may be reproduced or transmitted in any form or by any means without prior written

consent of Huawei Technologies Co., Ltd. and its affiliates ("Huawei").

The product described in this manual may include copyrighted software of Huawei and possible licensors.

Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract,

reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by

applicable laws or such actions are approved by respective copyright holders.

Trademarks and Permissions

, , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd.

LTE is a trade mark of ETSI.

Other trademarks, product, service and company names mentioned may be the property of their respective

owners.

Notice

Some features of the product and its accessories described herein rely on the software installed, capacities

and settings of local network, and therefore may not be activated or may be limited by local network

operators or network service providers.

Thus, the descriptions herein may not exactly match the product or its accessories which you purchase.

Huawei reserves the right to change or modify any information or specifications contained in this manual

without prior notice and without any liability.

DISCLAIMER

ALL CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE

LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT

LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS

MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HUAWEI BE

LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOSS OF

PROFITS, BUSINESS, REVENUE, DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS

REGARDLESS OF WHETHER SUCH LOSSES ARE FORSEEABLE OR NOT.

THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO LIABILITY FOR PERSONAL

INJURY TO THE EXTENT APPLICABLE LAW PROHIBITS SUCH A LIMITATION) OF HUAWEI ARISING

FROM THE USE OF THE PRODUCT DESCRIBED IN THIS MANUAL SHALL BE LIMITED TO THE

AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE OF THIS PRODUCT.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and be responsible to

obtain all necessary governmental permits and licenses in order to export, re-export or import the product

mentioned in this manual including the software and technical data therein.

To better understand how we protect your personal information, please see the privacy policy at

http://consumer.huawei.com/privacy-policy.

HUAWEI 30 mm x 30 mm LGA Module

Development Kit Guide

About This Document

Issue 05 (2016-12-12)

Huawei Proprietary and Confidential

About This Document

Revision History

Document

Version

Date

Chapter

Descriptions

2011-10-20

Creation

2014-04-26

All

Updated

2015-03-16

All

Added the description of the interface

board 30X30LGADB VER.A

All

Added the description of ME209u-526

module

2.2

Updated setting up the DVK

3.3.7

Added Micro SD card interface

3.3.11

Updated test points

3.4

Updated power consumption test

2015-08-14

All

Added the description of the ME909s

series module

2016-12-12

1.2

Updated Table 1-1 Features of DVK

supported by LGAmodules

Scope

MU509 series

MC509 series

MU609

MU709 series

ME909u series

ME209u-526

HUAWEI 30 mm x 30 mm LGA Module

Development Kit Guide

About This Document

Issue 05 (2016-12-12)

Huawei Proprietary and Confidential

ME909s series

HUAWEI 30 mm x 30 mm LGA Module

Development Kit Guide

Contents

Issue 05 (2016-12-12)

Huawei Proprietary and Confidential

Contents

1 Overview................................................................................................................................6

1.1 About This Chapter..........................................................................................................................6

1.2 Feature Overview............................................................................................................................6

1.3 Introduction to the DVK...................................................................................................................8

1.4 Components of the DVK................................................................................................................11

2 Installation and Use Guide................................................................................................. 13

2.1 About This Chapter........................................................................................................................13

2.2 Setting Up the DVK.......................................................................................................................13

3 Interface Description........................................................................................................... 20

3.1 About This Chapter........................................................................................................................20

3.2 DVK Appearance...........................................................................................................................20

3.3 Interface Functions........................................................................................................................21

3.3.1 Power Interface ....................................................................................................................21

3.3.2 USB Communications Interface............................................................................................21

3.3.3 LED Indicators......................................................................................................................21

3.3.4 Audio Interface......................................................................................................................23

3.3.5 Buttons .................................................................................................................................23

3.3.6 SIM Card Interface................................................................................................................23

3.3.7 Micro SD Card Interface.......................................................................................................24

3.3.8 Antenna Interface .................................................................................................................24

3.3.9 UART Interface.....................................................................................................................24

3.3.10 DIP Switch SW601 .............................................................................................................24

3.3.11 Test Points ..........................................................................................................................26

3.4 Power Consumption Test ..............................................................................................................32

4 Acronyms and Abbreviations............................................................................................. 35

HUAWEI 30 mm x 30 mm LGA Module

Development Kit Guide

Overview

Issue 05 (2016-12-12)

Huawei Proprietary and Confidential

1 Overview

1.1 About This Chapter

This chapter provides a brief description of the 30 mm x 30 mm LGA module

development kit (DVK), including:

Feature Overview

Introduction to the DVK

Components of the DVK

1.2 Feature Overview

The 30 mm x 30 mm LGAmodule DVK supports MU509 series, MC509 series,

MU609, MU709 series, ME909u series, ME209u-526 and ME909s series module.

Table 1-1 describes the features of DVK supported by LGA modules.

Table 1-1 Features of DVK supported by LGA modules

Feature

Implementation

MC509

MU509

MU609

ME909u

MU709

ME209u-

526

ME909s

Power

Supply

220 V AC to 5 V

DC Adaptor (Micro

USB Port)

√

Add another two 3

pin-single-row

connector. One is

5 V and the other

is GND.

√

Input voltage

range DC 4.5 V to

5.5 V (typical

value is 5.0 V)

√

Antenna

connector

GPS

√

AUX

√

HUAWEI 30 mm x 30 mm LGA Module

Development Kit Guide

Overview

Issue 05 (2016-12-12)

Huawei Proprietary and Confidential

Feature

Implementation

MC509

MU509

MU609

ME909u

MU709

ME209u-

526

ME909s

Main

√

SIM Ports

Standard SIM card

socket

√

Micro SIM card

socket

X (for

ME909u-

521)

√(for

ME909u-

523)

√

Audio Ports

PCM (3.5 mm

Audio Jack)

√

√(for

ME909u-

521)

X (for

ME909u-

523)

√

Analog

audio1(EAR

OUT/MIC1)

√

Analog audio2

(SPK OUT/MIC2)

√

Serial Ports

UART0

√

Only for

debugging

√

UART1

Only for

debugging

√

Only for

debugging

UART2

Only for

debugging

Only for

debugging

Only for

debugging

I2C and SPI

Three pins I2C

port

Reserved

Five pins SPI port

Reserved

RTC

Support a button

cell and a capacity

Reserved

USB Port

Micro USB Port

√

USB 2.0

Full Speed

High

Speed

High

Speed

High

Speed

High

Speed

High

Speed

GPIOs

Switchable pull

up/down resistors

√

Indicator

LED

Power on/off

indicator

√

UART TX/Ring

indicator 2*3

√

Reserved

CTS/RTS indicator

2*2

√

Reserved

HUAWEI 30 mm x 30 mm LGA Module

Development Kit Guide

Overview

Issue 05 (2016-12-12)

Huawei Proprietary and Confidential

Feature

Implementation

MC509

MU509

MU609

ME909u

MU709

ME209u-

526

ME909s

Module status

indicator

√

Reserved

Module mode

indicator

√

Module sleep

indicator

Reserved

√

USB insert

detection

(interface board)

√

ADC input

2 Analog inputs

Reserved

X (for

ME909u-

521)

√(for

ME909u-

523)

Reserved

√

JTAG

On interface board

√

HSIC

On interface board

Reserved

High-Speed

UART

High-Speed

UART0

√

High-Speed

UART1

√

SD card

Only for

debugging

Only for

debugging

Reserved means features DVK supports but the module does not support now.

X indicates the module does not support the feature; √indicates the module supports the feature.

For the detailed feature information, you can refer to the module's hardware guide.

In the following chapters and sections, "module" refers to the 30 mm x 30 mm LGA module;

"DVK" refers to the 30 mmx 30 mm LGAmodule development kit.

1.3 Introduction to the DVK

The DVK provides a complete solution based on the data functions of the module.

For designers who adopt the module in their designs, the DVK facilitates their

module-based programming and troubleshooting at the project development stage.

The DVK consists of two development boards. One is mother board and the other is

interface board.

HUAWEI 30 mm x 30 mm LGA Module

Development Kit Guide

Overview

Issue 05 (2016-12-12)

Huawei Proprietary and Confidential

The mother board (MD0MU609M02 VER.B) is the universal board and can be

used in all 30 mm x 30 mm LGAmodules, as shown in Figure 1-1 .

There are two interface boards (ML0ME909UM VER.B or 30X30LGADB VER.A)

for LGA modules, as shown in Figure 1-2 and Figure 1-3 . The 30 mm x 30 mm

LGA module is soldered on this board.

Table 1-2 shows the interface board and mother board for LGA modules.

Table 1-2 The interface boards and mother board for LGAmodules

Product

Interface Board

Mother Board

MU509 series

ML0ME909UM VER.B

MD0MU609M02 VER.B

MC509 series

ML0ME909UM VER.B

MU609

ML0ME909UM VER.B

ME909u-521

ML0ME909UM VER.B

ME909u-523

30X30LGADB VER.A

MU709 series

30X30LGADB VER.A

ME209u-526

30X30LGADB VER.A

ME909s series

30X30LGADB VER.A

Figure 1-1 The mother board (MD0MU609M02 VER.B)

HUAWEI 30 mm x 30 mm LGA Module

Development Kit Guide

Overview

Issue 05 (2016-12-12)

Huawei Proprietary and Confidential

Figure 1-2 The interface board (ML0ME909UM VER.B)

Figure 1-3 The interface board (30X30LGADB VER.A)

Otros manuales para MU509 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unidad de control de Huawei

Huawei

Huawei MU203 Manual de usuario

Huawei

Huawei MU739 Instrucciones de instalación

Huawei

Huawei UPS5000-E Series Manual de usuario

Huawei

Huawei UPS5000-E Series Manual de usuario

Huawei

Huawei ME309-562 Instrucciones de instalación

Huawei

Huawei SmartAX MA5600T Guía

Huawei

Huawei ME909s Series Instrucciones de instalación

Huawei

Huawei EM660C EVDO Manual de usuario

Huawei

Huawei UPS5000-E Series Manual de usuario

Huawei

Huawei MU709 Series Instrucciones de instalación

Huawei

Huawei PLC CCO01A Manual de usuario

Huawei

Huawei MG323 Instrucciones de instalación

Huawei

Huawei SmartLogger2000-10-C-JP Manual de usuario

Huawei

Huawei SmartAX MA5612 Manual de funcionamiento

Huawei

Huawei SmartAX MA5606T Especificaciones técnicas

Huawei

Huawei ME936 Instrucciones de instalación

Huawei

Huawei MU709s-2 Instrucciones de instalación

Huawei

Huawei MU509 Series Manual de usuario

Huawei

Huawei EM770 Manual de usuario

Huawei

Huawei MU509 Series Manual de usuario

Huawei

Huawei MU609 Guía del usuario

Huawei

Huawei MU609 Manual

Huawei

Huawei RRU5303 Manual de usuario

Huawei

Huawei MU609 Instrucciones de instalación

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
