Huawei MU509 Series Instrucciones de instalación

HUAWEI MU509 Series HSDPA LGA Module

Acceptance Inspection Guide

Issue

Date

2013-09-14

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. For

any assistance, please contact our local office or company headquarters.

Huawei Technologies Co., Ltd.

Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129, People’s Republic of China

Tel: +86-755-28780808 Global Hotline: +86-755-28560808 Website: www.huawei.com

E-mail: m[email protected]

Please refer color and shape to product. Huawei reserves the right to make changes or improvements to any

of the products without prior notice.

No part of this document may be reproduced or transmitted in any form or by any means without prior written

consent of Huawei Technologies Co., Ltd.

The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and

possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble,

decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are

prohibited by applicable laws or such actions are approved by respective copyright holders under licenses.

Trademarks and Permissions

, , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned are the property of their respective

owners.

Notice

Some features of the product and its accessories described herein rely on the software installed, capacities

and settings of local network, and may not be activated or may be limited by local network operators or

network service providers, thus the descriptions herein may not exactly match the product or its accessories

you purchase.

Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications

contained in this manual without prior notice or obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE

LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT

LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS

MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI

TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR

CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR

ANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary

governmental permits and licenses in order to export, re-export or import the product mentioned in this

manual including the software and technical data therein.

HUAWEI MU509 Series HSDPA LGA Module

Acceptance Inspection Guide

About This Document

Issue 01(2013-09-14)

Huawei Proprietary and Confidential

About This Document

Revision History

Document

Version

Date

Chapter

Description

2013-09-14

Creation

Scope

MU509-b

MU509-c

MU509-g

HUAWEI MU509 Series HSDPA LGA Module

Acceptance Inspection Guide

Contents

Issue 01(2013-09-14)

Huawei Proprietary and Confidential

Contents

1 Introduction....................................................................................................................................5

1.1 Purpose............................................................................................................................................ 5

1.2 Scope ............................................................................................................................................... 5

2 Acceptance Inspection..................................................................................................................6

2.1 Packaging Modes and Appearance ................................................................................................. 6

2.2 Label Inspection............................................................................................................................... 8

2.3 Performance Inspection ................................................................................................................. 10

2.4 Repack the Module after Inspection............................................................................................... 13

HUAWEI MU509 Series HSDPA LGA Module

Acceptance Inspection Guide

Introduction

Issue 01(2013-09-14)

Huawei Proprietary and Confidential

1 Introduction

1.1 Purpose

This document describes the methods of inspecting Huawei's shipments of MU509

series module. Customers can refer to this document when formulating inspection

guides for accepting Huawei's MU509 series module.

1.2 Scope

This guide is applicable to the acceptance inspection of Huawei's MU509 series

module. The inspection methods provided in this guide are recommendations, which

can be modified by customers if necessary.

HUAWEI MU509 Series HSDPA LGA Module

Acceptance Inspection Guide

Acceptance Inspection

Issue 01(2013-09-14)

Huawei Proprietary and Confidential

2 Acceptance Inspection

2.1 Packaging Modes and Appearance

The first-layer packages for the MU509 series module are large cartons, the

second-layer packages are medium cartons, and the third-layer packages are vacuum

bags, as shown in the following figures.

Figure 2-1 Large carton packaging

Check whether the package has serious damage or has been opened.

Check whether the number of Carton ID labels attached on the large carton is consistent

with the number of medium cartons in the large carton.

HUAWEI MU509 Series HSDPA LGA Module

Acceptance Inspection Guide

Acceptance Inspection

Issue 01(2013-09-14)

Huawei Proprietary and Confidential

Figure 2-2 Medium carton

Figure 2-3 Vacuum bag inside a medium carton

Check whether the packaging modes are consistent with those shown in the previous

figures.

The MU509 series modules are packed in vacuum bags. Check the vacuum bags for

damage and leakage.

HUAWEI MU509 Series HSDPA LGA Module

Acceptance Inspection Guide

Acceptance Inspection

Issue 01(2013-09-14)

Huawei Proprietary and Confidential

Figure 2-4 Arrangement of the modules (after the vacuum bag is removed)

Check that the arrangement of modules is consistent with that shown in Figure 2-4 .

Check that the number of modules is consistent with that labeled on the large carton.

After the vacuum bag is removed for inspection, repack the modules in a vacuum bag to

ensure the quality when the modules deliver to the customer.

2.2 Label Inspection

Figure 2-5 MU509-b label

HUAWEI MU509 Series HSDPA LGA Module

Acceptance Inspection Guide

Acceptance Inspection

Issue 01(2013-09-14)

Huawei Proprietary and Confidential

Figure 2-6 MU509-g label

Figure 2-7 MU509-c label 1

HUAWEI MU509 Series HSDPA LGA Module

Acceptance Inspection Guide

Acceptance Inspection

Issue 01(2013-09-14)

Huawei Proprietary and Confidential

Figure 2-8 MU509-c label 2

Check whether the information on the label of an MU509 series module is consistent with

the corresponding labels shown in Figure 2-5 to Figure 2-8 . There are two kinds of labels

producted. The labels shown in Figure 2-5 to Figure 2-8 are the general version. If the label

is customized, see the approval sheet.

Use a 2D barcode scanner to read the 2D barcode and check whether the number read

from the barcode is consistent with the IMEI number printed on the label.

2.3 Performance Inspection

Testing software: HyperTerminal

Testing tools: serial port or USB cable, test fixture for modules, PC

The following is the procedure:

Step 1 Use serial port or the USB cable to connect the testing PCB to the PC.

Step 2 Open Run and input the path C:\Program Files\Windows NT, and hypertrm.exe will

be displayed as shown in the following figure. Double click hypertrm.exe to run

HyperTerminal.
