HPRT LPQ118 Manual del operador

Quick Star Guide

LPQ118

Packing List

Standard Accessories

Printer Quick Star Guide

USB Cable

Appearance & Components

Power Cord

Rear

Insight Install the cables fastener

Front

Cable Fastener

Oponal Accessories

Serial Cable

Power Adapter

Xiamen Hanin Electronic Technology Co.Ltd.

ADD: 5F,8#,Aide Airport Industrial Park,Huli

District,Xiamen,China 361009

Tel.: +86-(0)592-5885993

Fax: +86-(0)592-5885992

Web: www.hprt.com

Printer Cover

Power Buon Feed Buon

LED Indicator

Cover Open Lever

Power Supply Receptacle

Power Switch

USB Port

Serial Port

Ethertnet Port

TPH

Paper Shields(movable)

Paper Sha

Paper Guides(movable)

Quick Star Guide

Note:Views above are for reference only, ports diﬀer by your choice.

Paper Sensor

Note:Power cord varies by local or region.

1.Press the cover open lever simultaneouly and the li up the

printer cover.

2.Hold the center of paper sha and slide upwards to pull out.

3.Pull out the paper shield.

4.Insert the media and aenon the thermosensive side

should face TPH.

Power Connecon

Media Loading

5. Put back the paper shield and then sha, and pull some

extra paper out through the paper guides.

6. Close the printer cover and tear the extera paper in the

direcon of printer.

1.Make sure the printer is power “Oﬀ”.

2.Connect the AC adapter with power interface.

3.Connect the AC adapter with power cord.

4.Plug the other side of power cord into the socket outlet.

Power Cord

AC Adapter

Varies by local

or region

Note:Windows driver installaon please see LPQ118 User Manual.
