HP Pro Tablet 608 G1 Manual
HP Pro Tablet 608 G1
Maintenance and Service Guide
IMPORTANT! This document is intended for HP
authorized service providers only.
© Copyright 2015 HP Development Company,
L.P.
Bluetooth is a trademark owned by its
proprietor and used by HP Inc. under license.
Intel and Atom are trademarks of Intel
Corporation in the U.S. and other countries.
Windows is a trademark of the Microsoft group
of companies. SD Logo is a trademark of its
proprietor.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS
Licensing Limited. DTS, the Symbol, & DTS and
the Symbol together are registered
trademarks, and DTS Studio Sound is a
trademark of DTS, Inc. © DTS, Inc. All Rights
Reserved .
The information contained herein is subject to
change without notice. The only warranties for
HP products and services are set forth in
the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors or
omissions contained herein.
Second Edition: August 2015
First Edition: July 2015
Document Part Number: 815234-002
Product notice
This guide describes features that are common
to most models. Some features may not be
available on your tablet.
Software terms
By installing, copying, downloading, or
otherwise using any software product
preinstalled on this tablet, you agree to be
bound by the terms of the HP End User License
Agreement (EULA). If you do not accept these
license terms, your sole remedy is to return the
entire unused product (hardware and software)
within 14 days for a refund subject to the
refund policy of your place of purchase.
For any further information or to request a full
refund of the tablet, please contact your local
point of sale (the seller).
Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the tablet, do not place the
tablet directly on your lap. Do not allow a soft surface, such as pillows or rugs or clothing, to block airow.
Also, do not allow the AC adapter to come into contact with the skin or a soft surface, such as pillows or rugs
or clothing, during operation. The tablet and the AC adapter comply with the user-accessible surface
temperature limits dened by the International Standard for Safety of Information Technology Equipment
(IEC 60950-1).
iii
iv Safety warning notice
Table of contents
1 Product description ....................................................................................................................................... 1
2 External component identication .................................................................................................................. 4
3 Illustrated parts catalog ................................................................................................................................ 7
Locating the serial number and model number .................................................................................................... 7
Tablet major components ...................................................................................................................................... 8
Miscellaneous parts ............................................................................................................................................... 9
Sequential part number listing ........................................................................................................................... 10
4 Removal and replacement preliminary requirements ..................................................................................... 13
Tools required ...................................................................................................................................................... 13
Service considerations ......................................................................................................................................... 13
Plastic parts ....................................................................................................................................... 13
Cables and connectors ...................................................................................................................... 13
Grounding guidelines ........................................................................................................................................... 14
Electrostatic discharge damage ........................................................................................................ 14
Packaging and transporting guidelines .......................................................................... 15
Workstation guidelines ................................................................................ 15
5 Removal and replacement procedures ........................................................................................................... 17
Tablet component replacement procedures ....................................................................................................... 17
MicroSD card tray ................................................................................................................................................. 17
Nano SIM card tray (select models only) ............................................................................................................. 18
Back cover ............................................................................................................................................................ 18
Disconnecting the battery ................................................................................................................................... 19
WWAN module (select models only) ................................................................................................................... 21
Left speaker ......................................................................................................................................................... 23
Audio board .......................................................................................................................................................... 24
Vibration motor board ......................................................................................................................................... 26
Front-facing webcamera ..................................................................................................................................... 27
Rear-facing webcamera ....................................................................................................................................... 28
System board ....................................................................................................................................................... 30
Right speaker ....................................................................................................................................................... 35
Battery and middle plate ..................................................................................................................................... 36
Outer ring ............................................................................................................................................................. 38
v
POGO pin connector ............................................................................................................................................. 40
6 Specications .............................................................................................................................................. 42
7 Using Computer Setup (BIOS) ........................................................................................................................ 43
Starting Computer Setup ..................................................................................................................................... 43
Navigating and selecting in Computer Setup ...................................................................................................... 43
Restoring factory settings in Computer Setup .................................................................................................... 44
Updating the BIOS ................................................................................................................................................ 44
Determining the BIOS version ........................................................................................................... 44
Downloading a BIOS update ................................................................................................................................ 45
8 Using HP PC Hardware Diagnostics (UEFI) ....................................................................................................... 47
Downloading HP PC Hardware Diagnostics (UEFI) .............................................................................................. 47
9 Backup and recovery .................................................................................................................................... 48
Creating recovery media and backups ................................................................................................................ 48
Creating recovery media ................................................................................................................... 48
Backing up your information ............................................................................................................. 49
Performing a system recovery ............................................................................................................................ 49
Using the Windows recovery tools .................................................................................................... 49
Changing the boot device order ........................................................................................................ 50
10 Power adapter requirements ...................................................................................................................... 51
Requirements for all countries ............................................................................................................................ 51
Requirements for specic countries and regions ................................................................................................ 51
11 Recycling .................................................................................................................................................. 53
Index ............................................................................................................................................................. 54
vi
1 Product description
Category Description
Product Name HP Pro Tablet 608 G1
Processor Intel® AtomTM x5-Z8500 Quad Core SOC B-1 4c BGA 1.36 GHz 16 EU, 2.16 GHz Burst, Type 4 QHAU
(soldered on the system board)
Graphics Integrated Gen8-LP 8 EU up to 640 MHz
Panel 7.86 inch, Quad Extended Graphics Array (QXGA) resolution (2048 x 1536) BV white light emitting
diode (WLED), Ultra-Wide Viewing Angle (UWVA), 70% cg, 450 nits (cd/m2) MIPI
Supports Active Pen and Multitouch
Memory 2 GB LPDDR3 memory, integrated onto system board, 1600 253b package (8 Gb(128
MbX32X2)*2pcs)
4 GB LPDDR3 memory, integrated onto system board, 1600 253b package (16 Gb(128
MbX32X4)*2pcs)
eMMC 4.51 (Memory HW will be 4.51 and 5.0 but SOC can only supports up to 4.51 protocol)
Storage 32 GB eMMC, integrated onto system board
64 GB eMMC, integrated onto system board
128 GB eMMC, integrated onto system board
Your tablet has read/write support for SDXC microSD cards up to 2 TB.
Audio and video Two noise cancellation microphones
Two speakers with DTS Studio Sound
8.0 MP full-frame high-denition rear-facing webcamera
2.0 MP full-frame high-denition front-facing webcamera
Supports HD audio formats
Supports headset
Sensors Accelerometer + eCompass
Gyroscope
Ambient light sensor
Haptics sensor
Proximity Sensor (WWAN Only)
Wireless networking Integrated WLAN option: Intel 7265.D2WG18V AC 2x2 + Bluetooth® 4 LE PCIe+USB SD 1216 WW
2 WLAN antennas congured with panel on all units
Near eld communication (NFC): NXP NPC100 Integrated NFC module and antennas
WWAN (SIM Module, 4 FF/nano SIM, M.2 3042 S3 module):
●HP It4211, LTE/EV-D0/HSPA+, QCOM MDM9615 Integrated GPS (North America only)
●Huawei ME906E, LTE/HSPA+, QCOM MDM9215, integrated GPS: HP lt4112 LTE/HSPA+ Gobi
4G Module (EMEA only)
1
Category Description
●Huawei MU736, HSPA+, Intel XMM6260 3G, integrated GPS: HP hs3110 HSPA+ Mobile
Broadband Module (worldwide)
Supports No WWAN/No GPS option
External expansion Integrated SDXC microSD card reader expandable up to 2 TB.
Ports ●Audio: headphone/microphone combo jack
●MicroSD card reader
●Nano SIM card slot
●USB Type-C (charging) port
●1x 10 Pin Magnetic connector (POGO)
Docking Portable docking
Keyboard/Mouse Support for Magnector connected soft keyboard, USB or Bluetooth connected external keyboard
and mouse
Power requirements 21 Whr, 1S2P, Lithium-polymer, non-user removable battery
15 W + USB Type-C (charging). (100% attached) (Micro USB Adapter) cable and localized cable
plug support
Operating system Preinstalled:
●Windows® 8.1 Pro 64 for Small Tablets
●Windows 8.1 Pro 64 StF MSNA (only available with equal to or less than 64 GB eMMC
Storage, not available with 128 GB eMMC Storage)
●Windows 8.1 Pro 64 StF EM (only available with equal to or less than 64 GB eMMC Storage,
not available with 128 GB eMMC Storage)
●Windows 8.1 Pro 64 for Small Tablets retail (only available with RS BUs)
●Windows Embedded 8.1 Industry Pro 64 Retail (only available with RS BUs)
●Windows 8.1 Core for Higher Education 64 ML (only available for Emerging Markets)
●Windows 10 Home 64 Chinese Market CPPP (only available for the People’s Republic of
China)
●Windows 10 Home 64 Shape the Future OS AV for Higher Education (only available for
Emerging Markets except Asia and the People’s Republic of China)
●Windows 10 Home 64 Entry Tablet + 2-in-1 Notebook (not available for Asia or the People’s
Republic of China)
●Windows 10 Home 64 Entry Tablet + 2-in-1 Notebook Chinese markets (only available for
the People’s Republic of China)
●Windows 10 Home 64 Entry Tablet + 2-in-1 Notebook Single Language (only available for
Emerging Markets)
●Windows 10 Home 64 Small Tablet + 2-in-1 Notebook (not available for Asia or the People’s
Republic of China)
●Windows 10 Home 64 Small Tablet + 2-in-1 Notebook Chinese market (only available for the
People’s Republic of China)
●Windows 10 Home 64 Small Tablet + 2-in-1 Notebook Single Language (only available for
emerging markets)
●Windows 10 Pro 64 Small Tablet + 2-in-1 Notebook
●Windows 10 Pro 64 Small Tablet + 2-in-1 Notebook (Retail—select countries)
2 Chapter 1 Product description
Category Description
●Windows 10 Pro 64 StF MSNA (only available for developed markets)
●Windows 10 Pro 64 StF MSNA (only available for emerging markets)
Web-only support:
●Windows 8.1 Enterprise
●Windows 10 Enterprise
Restore USB–for service only:
USB recovery to align with customer image, to include base operating system, language packs,
drivers, and QFE’s.
Serviceability End user replaceable parts:
●AC adapter
3
2 External component identication
Component Description
(1) Audio-out (headphone)/Audio-in (microphone)
combo jack
Connects optional powered stereo speakers, headphones,
earbuds, a headset, or a television audio cable. Also connects an
optional headset microphone. This jack does not support
optional microphone-only devices.
4 Chapter 2 External component identication
Otros manuales para Pro Tablet 608 G1
2
Tabla de contenidos
Otros manuales de Tableta de HP
HP
HP ElitePad 1000 G2 Instrucciones de uso
HP
HP Stream Manual de usuario
HP
HP Pro Tablet 610 Manual
HP
HP ArcPad Manual de usuario
HP
HP HNI72CWR Manual de usuario
HP
HP ElitePad 1000 G2 Manual de usuario
HP
HP Slate Manual de usuario
HP
HP 8 G21411 Manual
HP
HP HSTNH-K13C Manual de usuario
HP
HP ElitePad 1000 G2 Manual
HP
HP Slate 500 Instrucciones de uso
HP
HP Slate 10 Plus Manual
HP
HP Pro 8 Manual
HP
HP Tablet Manual de usuario
HP
HP ProPad 600 G1 Manual de usuario
HP
HP Elite x2 1011 G1 Manual
HP
HP Tx2 1025dx - TouchSmart - Turion X2 2.1 GHz Manual de usuario
HP
HP Compaq 8 1400 Manual
HP
HP ElitePad 1000 G2 Manual de usuario
HP
HP Pro Slate 10ee G1 Manual de usuario
