HP StorageWorks 2/16 - SAN Switch Manual de instrucciones

release notes

hp StorageWorks

SAN Switch 2/16

Product Version: 3.0.2k

Second Edition (February 2003)

Part Number: AA-RR85B-TE

This document summarizes late-breaking and supplemental information for the SAN Switch

2/16 and SAN Switch 2/16 Power Pak models. In the event of conflicting information between

these Release Notes and other documents contained in this product release, the Release Note

content takes precedence.

For the latest version of these Release Notes and related switch documentation, access the HP

storage website at:

http://www.hp.com/country/us/eng/prodserv/storage.html

2 SAN Switch 2/16 Version 3.0.2k Release Notes

Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited to,

the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for

errors contained herein or for incidental or consequential damages in connection with the furnishing, performance,

or use of this material.

Compaq Computer Corporation is a wholly-owned subsidiary of Hewlett-Packard Company.

This document contains proprietary information, which is protected by copyright. No part of this document may be

photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard.

The information contained in this document is subject to change without notice.

Microsoft, Windows, and Windows NT are U.S. registered trademarks of Microsoft Corporation.

UNIX is a registered trademark of The Open Group.

BROCADE, the Brocade B weave logo, Brocade: the Intelligent Platform for Networking Storage, SilkWorm, and

SilkWorm Express, are trademarks or registered trademarks of Brocade Communications Systems, Inc. or its

subsidiaries in the United States and/or in other countries.

All other product names mentioned herein may be trademarks of their respective companies.

Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein. The

information is provided “as is” without warranty of any kind and is subject to change without notice. The warranties

for Hewlett-Packard Company products are set forth in the express limited warranty statements for such products.

Nothing herein should be construed as constituting an additional warranty.

Printed in the U.S.A.

SAN Switch 2/16 Version 3.0.2k Release Notes

Second Edition (February 2003)

Part Number: AA-RR85B-TE

About this Document

3SAN Switch 2/16 Version 3.0.2k Release Notes

About this Document

This section describes the content reflected in this document, including:

■Intended Audience, page 4

■Related SAN Switch 2/16 Product Documentation, page 4

■Features Summary, page 6

—If You Purchased the SAN Switch 2/16, page 6

—If You Purchased the SAN Switch 2/16 Power Pak, page 6

■Optional Upgrade, page 7

■Obtaining Optional Software License Keys from HP, page 8

■Orderable Hardware, page 9

■hp StorageWorks SAN Switch Software v3.0.2k CD, page 10

■v3.0.2k Firmware Overview, page 10

—Firmware Updates, page 10

—Excessive Error Counts, page 11

■Hardware Updates, page 11

—Verify Licenses Before Replacing Hardware, page 11

—Cables, page 11

■Compatibility, page 12

■Management Station Requirements for Running Web Tools, page 12

—Operating Systems, page 12

—Memory Requirement (Windows operating systems), page 13

—Disk Space, page 13

—Web Browsers, page 13

—Java Plug-in, page 14

■SNMP-based Management, page 14

Note: The SAN Switch 2/16 is offered in two configurations, the

2/16 and 2/16 Power Pak. These Release Notes refer to both models as the SAN

Switch 2/16, unless otherwise noted.

Intended Audience

4 SAN Switch 2/16 Version 3.0.2k Release Notes

Intended Audience

This document is intended for HP technicians and customers who purchased the

SAN Switch 2/16 and SAN Switch 2/16 Power Pak models.

Related SAN Switch 2/16 Product Documentation

The SAN Switch 2/16 kit also includes the following documents:

Note: The

SAN Switch 2/16 Installation Guide

and

Release Notes

ship in hard copy

format with the switch. With the exception of the Release Notes, all listed documents are

provided on the hp StorageWorks SAN Switch Software v3.0.2k CD, part number

AG-RR86C-BE.

■hp StorageWorks SAN Switch 2/16 Version 3.0.x Installation Guide, part

number AA-RR84B-TE

■hp StorageWorks SAN Switch 2/16 Version 3.0.2k Release Notes, part number

AA-RR85B-TE (this document)

■

hp StorageWorks Common Software and Switch Options Version 3.0.x/4.0.x

Release Notes, part number AV-RTQUB-TE

■hp StorageWorks Fabric OS Version 3.0.x/4.0.x Reference Guide, part number

AA-RS24B-TE

■hp StorageWorks Fabric OS Procedures Version 3.0.x/4.0.x User Guide, part

number AA-RS23B-TE

■hp StorageWorks Diagnostics and System Error Messages Version 3.0.x/4.0.x

Reference Guide, part number AA-RS22B-TE

■hp StorageWorks Web Tools Version 3.0.x/4.0.x User Guide, part number

AA-RS25B-TE

■hp StorageWorks Advanced Performance Monitoring Version 3.0.x/4.0.x User

Guide, part number AA-RTS4B-TE

■hp StorageWorks ISL Trunking Version 3.0.x/4.0.x User Guide, part number

AA-RTSAB-TE

Related SAN Switch 2/16 Product Documentation

5SAN Switch 2/16 Version 3.0.2k Release Notes

■hp StorageWorks Extended Fabric Version 3.0.x/4.0.x User Guide, part

number AA-RTSDB-TE

■hp StorageWorks Fabric Watch Version 3.0.x/4.0.x User Guide, part number

AA-RTSGB-TE

■hp StorageWorks Zoning Version 3.0.x/4.0.x User Guide, part number

AA-RS26B-TE

■hp StorageWorks Remote Switch Version 3.0.x/4.0.x User Guide, part number

AA-RTS7B-TE

■hp StorageWorks QuickLoop Version 3.0.x User Guide, part number

AA-RTS1A-TE

Soft copy of the hp StorageWorks SAN Switch 2/8 Version 3.0.x Installation

Guide, part number AA-RSB6B-TE, is also provided on the CD, which is shared

with 2/8 SAN Switch products.

For the latest supported configurations, please refer to the hp StorageWorks SAN

Design Reference Guide, part number AA-RMPNF-TE, available at:

http://h18006.www1.hp.com/storage/saninfrastructure.html

Additional documentation, including white papers and best practices documents,

are available via the HP website at:

http://welcome.hp.com/country/us/eng/prodserv/storage.html

Features Summary

6 SAN Switch 2/16 Version 3.0.2k Release Notes

Features Summary

The following sections summarize the management features enabled on your

specific switch model (SAN Switch 2/16 or SAN Switch 2/16 Power Pak).

If You Purchased the SAN Switch 2/16

The SAN Switch 2/16 ships with the following features enabled:

■Web Tools—Provides a graphical user interface (GUI) to monitor and manage

the entire fabric.

■Zoning—Allows partitioning of the SAN into logical groupings of devices

that access each other.

■QuickLoop (present on the switch, but not enabled)—Allows arbitrated loops

to attach to a fabric. To enable, use the Web Tools QuickLoop Tab. Or use the

telnet qlPortEnable command.

If You Purchased the SAN Switch 2/16 Power Pak

The SAN Switch 2/16 Power Pak ships with the following features enabled, and

ready to use:

■Web Tools—Provides a graphical user interface (GUI) to monitor and manage

the entire fabric.

■Zoning—Allows partitioning of the SAN into logical groupings of devices

that access each other.

■Fabric Watch—Monitors the performance and status of HP StorageWorks

SAN switches, and alertS network managers as problems arise.

■Full Fabric—Provides Full Fabric OS.

■ISL Trunking—Using ISL trunking, high speed links ensure that

server-to-storage performance is efficient.

■Advanced Performance Monitoring—Provides a comprehensive tool for

monitoring the performance of storage devices within the network.

Optional Upgrade

7SAN Switch 2/16 Version 3.0.2k Release Notes

The following features are built into the switch firmware, but not enabled.

■QuickLoop—Allows arbitrated loops to attach to a fabric. To enable, use the

Web Tools QuickLoop Tab, or use the telnet qlPortEnable command.

■Extended Fabric—Creates a fabric interconnected at distances greater than 5

km for 2 Gb interswitch links. To enable, use the Web Tools Extended Fabrics

Tab, or use the telnet portCfgLongDistance command.

■Remote Switch—Provides a network bridge to interconnect fabrics. To

enable, use the Web Tools Extended Fabrics Tab. See the hp StorageWorks

Common Software and Switch Options Version 3.0.x/v4.0.x Release Notes for

Remote Switch limitations.

Optional Upgrade

The Power Pak Upgrade Bundle is available as a separate option for the SAN

Switch 2/16 and includes ISL Trunking, Advanced Performance Monitoring,

Extended Fabric, Remote Switch and Fabric Watch.

Note: Options purchased separately require you to obtain a license. See the next

section, “Obtaining Optional Software License Keys from HP.”

Obtaining Optional Software License Keys from HP

8 SAN Switch 2/16 Version 3.0.2k Release Notes

Obtaining Optional Software License Keys from HP

If you’ve purchased optional software, or need to reinstall software features due to

a motherboard replacement in your switch, you will need to retrieve the software

license keys from the HP Authorization Center.

Obtain software license keys as follows:

■If you have your HP Registration Number, (located on your software

entitlement certificate) go to

http://webkey.external.hp.com/welcome.asp

■If your HP Registration Number is unavailable, contact the Authorization

Center directly:

— Canada and United States, (Monday through Friday 6:00 am to 6:00 pm ,

(801) 431-1451 or (800) 861-2979.

— Asia, (Monday through Friday 9:00 am to 5:00 pm MST),

+81-03-3227-5289 or +81-3-3227-5289.

— Europe, Middle East, Africa and Netherlands (Monday through Friday

9:00 am to 6:00 pm), +31-555-384-210.

Orderable Hardware

9SAN Switch 2/16 Version 3.0.2k Release Notes

Orderable Hardware

Table 1 lists the optional hardware kits for the SAN Switch 2/16.

* premerger HP part number

** premerger Compaq part number

Note: The hp StorageWorks SAN switch Universal Rack Mount Kit is a separate,

orderable item. See the

hp StorageWorks SAN switch Universal Rack Mount Kit

Installation Addendum

, part number AV-RU6YA-TE, supplied with the rack mount kit for

installation instructions.

Table 1: SAN Switch 2/16 Orderable Hardware

Accessory Part Number

Short wavelength SFP A6515A*or 300834-B21**

Long wavelength SFP, 10 km A6516A*or 300835-B21**

2m LC-to-LC Fibre Channel (fc) cable C7524A*

2m LC-to-LC multi-mode fc cable 221692-B21**

16m LC-to-LC fc cable C7525A*

5m LC-to-LC multi-mode fc cable 221692-B22**

50m LC-to-LC fc cable C7526A*

15m LC-to-LC multi-mode fc cable 221692-B23**

200m LC-to-LC fc cable C7527A*

30m LC-to-LC multi-mode fc cable 221692-B26**

50m LC-to-LC multi-mode fc cable 221692-B27**

2m LC-to-SC fc cable C7529A*

2m LC-to-SC multi-mode fc cable 221691-B21**

16m LC-to-SC fc cable C7530A*

5m LC-to-SC multi-mode fc cable 221691-B21**

15m LC-to-SC multi-mode fc cable 221691-B23**

30m LC-to-SC multi-mode fc cable 221691-B26**

50m LC-to-SC multi-mode fc cable 221691-B27**

SC female to SC female adapter C7534A*

2m LC male to SC male adapter kit C7534A*

hp StorageWorks SAN Switch Software v3.0.2k CD

10 SAN Switch 2/16 Version 3.0.2k Release Notes

hp StorageWorks SAN Switch Software v3.0.2k CD

The SAN Switch 2/16 ships with the latest version of the firmware installed. A

copy of the latest version of the firmware as of this date, v3.0.2k, is also contained

on the hp StorageWorks SAN Switch Software v3.0.2k CD, part number

AG-RR86C-BE. The v3.0.2k firmware is also available on the hp website at:

http://www.compaq.com/products/storageworks/hubs-and-bridges/firmwareupdate.html

v3.0.2k Firmware Overview

Firmware v3.0.2k works with HP StorageWorks 2 Gb switch models only. The

firmware will not work if loaded onto HP StorageWorks 1 Gb switch models.

Additionally, firmware release v3.0.2k provides fixes for problems associated

with v3.0.2j.

Firmware Updates

Enhancements to firmware V3.0.2k include:

■3.0.2k provides support for the hp StorageWorks MSA SAN switch 2/8.

■Fan errors no longer display after a specific interval (414 days) of run time.

■Extends name service query time to 1 second from 0.12 second.

■No longer sends PDISK to a single Arbitrated Loop Physical Address (ALPA)

on a single port on the switch.

■Supports both Microsoft Internet Explorer and Netscape Navigator Browsers.

■Commands are insensitive to letter case. For example, the command line

accepts fabricshow as well as fabricShow.

■Active Zone Configuration Warning: Web Tools now issues a warning before

disabling an active zone configuration. This lowers the risk that a Zoned

Fabric may become un-zoned. A "Confirm Zone Delete" window appears

confirming deletion of a zone. The window also notifies the user that the

specified zone member will be removed from corresponding configurations.

The user should click Yes to continue, and No to cancel the zone delete.

Otros manuales para StorageWorks 2/16 - SAN Switch

Tabla de contenidos

Otros manuales de Cambiar de HP

HP PROCURVE 2910AL Manual de usuario

HP 5920 Manual de usuario

HP bh5700 Manual de usuario

HP ProCurve 2910al-24G Manual de usuario

HP AE370A - Brocade 4Gb SAN Switch 4/12 Manual de usuario

HP 3100-8 v2 SI Manual de usuario

HP ProCurve 3500-48 Instrucciones de montaje

HP J3128A AdvanceStack 10Base-T Hub-8E Manual de instalación y funcionamiento

HP StorageWorks MSA 2/8 - SAN Switch Manual de usuario

HP ProCurve Switch 2650 Manual de usuario

HP 316095-B21 - StorageWorks Edge Switch 2/24 Manual de instrucciones

HP 5130 EI Switch Series Manual de usuario

HP StorageWorks 2/16 - SAN Switch Manual de usuario

HP ProCurve 3500-48-PoE Instrucciones de montaje

HP PS1810-8G Manual de usuario

HP 5920 Manual de usuario

HP pocurve switch 408 Manual de usuario

HP 438031-B21 - 1:10Gb Ethernet BL-c Switch Guía del usuario

HP A5920AF-24XG Instrucciones de instalación

HP 5920 Manual de usuario

HP 3100 v2 Series Manual de usuario

HP 5130-24G-4SFP+ EI Manual de usuario

HP ProCurve 2510G Series Manual de usuario

HP Procurve 2300 Manual

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
