HP 6125G Manual de usuario

HP 6125 Blade Switch Series

bout the HP 6125 Blade Configuration Guides

Part number: 5998-3152

Software version: Release 2103

Document version: 6W100-20120907

Legal and notice information

No part of this documentation may be reproduced or transmitted in any form or by any means without

prior written consent of Hewlett-Packard Development Company, L.P.

The information contained herein is subject to change without notice.

HEWLETT-PACKARD COMPANY MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS

MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not be liable for errors contained

herein or for incidental or consequential damages in connection with the furnishing, performance, or

use of this material.

The only warranties for HP products and services are set forth in the express warranty statements

accompanying such products and services. Nothing herein should be construed as constituting an

additional warranty. HP shall not be liable for technical or editorial errors or omissions contained

herein.

About the HP 6125 Blade configuration guides

The HP 6125 Blade configuration guides describe the software features for the HP 6125 Blade Switch

Series, and guide you through the software configuration procedures. These configuration guides also

provide configuration examples to help you apply the software features to different network scenarios.

Confi

uration

uide Content

01 Fundamentals

Configuration Guide

Describes how to use the command line interface of the switch, log in to and set

up the switch, and use the basic management functions. This guide includes:

•CLI (command line interface overview and how to use the CLI)

•Logging in to the switch (CLI login methods such as Telnet, MIB access

through SNMP, user interface configuration, and access control)

•FTP and TFTP

•TFTP configuration

•Configuration file management

•Software upgrade

•Device management

•Automatic configuration

02 IRF Configuration Guide Describes the HP proprietary IRF technology, IRF fabric setup and configuration

procedure, restrictions and guidelines, and IRF fabric configuration procedure.

03 Layer 2—LAN Switching

Configuration Guide

Covers Layer 2 technologies and features used on a LAN switched network,

including VLAN technology, port isolation, and spanning tree. You can use

these features to divide broadcast domains, remove Layer 2 loops, isolate users

within a VLAN, remark VLAN tags, implement VLAN VPNs over the Internet,

and so on. This guide includes:

•Ethernet interface

•Loopback and null interfaces

•Bulking configuring interfaces

•MAC address table

•MAC Information

•Ethernet link aggregation

•Port isolation

•Spanning tree

•BPDU tunneling

•VLAN

•Isolate-user-VLAN

•Voice VLAN

•GVRP

•QinQ

•VLAN mapping

•LLDP

•Service loopback group

•Layer 2 forwarding

Confi

uration

uide Content

04 Layer 3—IP Services

Configuration Guide

Describes IP addressing (including static and dynamic IPv4 and IPv6 address

assignment), UDP helper, DNS, network performance optimization, ARP, and

interoperation between IPv4 and IPv6. This guide includes:

•ARP

•Gratuitous ARP

•Proxy ARP

•ARP snooping

•IP addressing

•DHCP overview

•DHCP relay agent

•DHCP client

•DHCP snooping

•BOOTP client

•IPv4 DNS

•IP performance optimization

•UDP helper

•IPv6 basics

•DHCPv6 overview

•DHCPv6 relay agent

•DHCPv6 client

•Tunneling

05 Layer 3—IP Routing

Configuration Guide

Covers the routing technologies for IPv4 and IPv6 networks of different sizes,

route filtering, route control, and policy based routing. This guide includes:

•IP routing basics

•Static routing (including default routing)

•RIP

•OSPF

•IS-IS

•BGP

•IPv6 static routing (including IPv6 default routing)

•RIPng

•OSPFv3

•IPv6 IS-IS

•IPv6 BGP

•Routing policy

•Policy-based routing

Confi

uration

uide Content

06 IP Multicast

Configuration Guide

Covers Layer 3 IPv4 multicast protocols (IGMP, PIM, MSDP, and MBGP), Layer

3 IPv6 multicast protocols (MLD, IPv6 PIM, and IPv6 MBGP), Layer 2 IPv4

multicast protocols (IGMP snooping, PIM snooping, and multicast VLAN), and

Layer 2 IPv6 multicast protocols (MLD snooping, IPv6 PIM snooping, and IPv6

multicast VLAN). This guide includes:

•Mulitcast overview

•IGMP snooping

•PIM snooping

•Multicast VLAN

•Multicast routing and forwarding

•IGMP

•PIM

•MSDP

•MBGP

•MLD snooping

•IPv6 PIM snooping

•IPv6 multicast VLAN

•IPv6 multicast routing and forwarding

•MLD

•IPv6 PIM

•IPv6 MBGP

07 ACL and QoS

Configuration Guide

Describes how to classify traffic with ACLs, and allocate network resources and

manage congestions with QoS technologies to improve network performance

and network use efficiency. You can use ACLs to help other function modules

(such as QoS and IP routing) classify or filter traffic. This guide includes:

•ACL

•QoS overview

•QoS configuration approaches

•Priority mapping

•Traffic policing, traffic shaping, and line rate

•Congestion management

•Congestion avoidance

•Traffic filtering

•Priority marking

•Traffic redirecting

•Aggregate CAR

•Class-based accounting

•QPPB

•Appendix

Confi

uration

uide Content

08 Security Configuration

Guide

Covers security features. The major security features available on the switch

include identity authentication (AAA), access security (802.1X, MAC

authentication, and port security), secure management (SSH), and attack

protection (IP source guard, ARP attack protection, and URPF). This guide

includes:

•AAA

•802.1X fundamentals

•802.1X

•EAD fast deployment

•MAC authentication

•Port security

•User profile

•Password control

•Public key

•PKI

•SSH

•SFTP

•SCP

•SSL

•TCP attack protection

•IP source guard

•ARP attack protection

•ND attack defense

•URPF

•MFF

09 High Availability

Configuration Guide

Describes high availability technologies and features available on the switch for

failure detection and failover. Failure detection technologies focus on fault

detection and isolation. Failover technologies focus on network recovery. This

guide includes:

•High availability overview

•Ethernet OAM

•CFD

•DLDP

•RRPP

•Smart Link

•Monitor Link

•VRRP

•BFD

•Track

Confi

uration

uide Content

10 Network Management

and Monitoring

Configuration Guide

Describes features that help you manage and monitor your network, for

example, manage system events, sample packets, assess network performance,

synchronize the clock for all devices with the clock in the network, and test

network connectivity. This guide includes:

•Using ping, tracert, and system debugging

•NTP

•Information center

•SNMP

•RMON

•Port mirroring

•Traffic mirroring

•NQA

•sFlow

•IPC
