Models

HP 1410-8G Switch

J9559A

HP 1410-16G Switch

J9560A

HP 1410-24G-R Switch

JG708A

HP 1410-24G Switch

J9561A

HP 1410-8 Switch

J9661A

HP 1410-16 Switch

J9662A

HP 1410-24 Switch

J9663A

HP 1410-24-R Switch

JD986B

HP 1410-24-2G Switch

J9664A

Key features

Unmanaged Gigabit Ethernet and Fast Ethernet switches

Green features for low power consumption

Fanless design for silent operation

Quality of service (QoS) support

Lifetime warranty

Product overview

HP 1410 Switch Series comprises unmanaged Gigabit Ethernet and Fast Ethernet switches designed for small businesses looking for

entry-level, low-cost networking solutions that come with a lifetime warranty. The series consists of nine models with flexible

mounting options to meet different network switching needs. All models have quality of service(QoS) support and IEEE 802.3x flow

control features that provide outstanding data efficiency. Simplified plug-and-play convenience is enabled by features such as Auto-

MDIX and auto-speed negotiation. HP has innovated and combined the latest advances in silicon technology to bring you some of the

most power-efficient switches: 1410-24G-R,1410-16 and 1410-24 models are advanced IEEE 802.3az-compliant unmanaged Gigabit

and Fast Ethernet switches. The switches come with built-in green features and a lifetime warranty, making the series the right choice

for organizations seeking a networking solution that's both economical and reliable.

Features and benefits

Quality of Service

(QoS)

IEEE 802.1p prioritisation

delivers data to devices based on the priority and type of traffic

DiffServ Code Point (DSCP) support

allows real-time traffic prioritisation based on Layer 3 TOS/DSCP parameters

Connectivity

Auto-MDIX

provides automatic adjustments for straight-through or crossover cables on all 10/100 and 10/100/1000 ports

Performance

QuickSpecs

HP 1410 Switch series

Overview

DA - 13674 Worldwide — Version 12 — December 16, 2013

Page 1

NEW Energy-efficient Ethernet support

supports new IEEE 802.3az standard; allows lower power consumption when operated with IEEE-compliant client devices in

100 Mb/s mode only (JG708A, J9662A and J9663A switches)

Half-/full-duplex auto-negotiating capability on every port

doubles the throughput of every port

NEW Jumbo frame support

allows frames up to 9216 bytes to be switched through the network (Gigabit Ethernet models)

Mini jumbo frame support

allows frames up to 2048 bytes to be switched through the network, which supports large data transfers (J9662A and J9663A

switches)

Ease of use

Unmanaged

provides plug-and-play simplicity

Comprehensive LED display with per-port indicators

provides an at-a-glance view of status, activity, speed and full-duplex operation

Flow control

helps ensure reliable communications during full-duplex operation

Auto-speed negotiation

selects individual port speed automatically depending on client capabilities without the need for manual intervention, allowing

for simple plug-and-play operation

Flexibility

Fanless design

enables quiet operation for deployment in open spaces

NEW Internal power supply

provides operation convenience and a neat operation environment (JG708A, J9561A and JD986B switches)

Warranty and support

NEW Lifetime Warranty 2.0

advance hardware replacement for as long as you own the product with next-business-day delivery (available in most countries)†

NEW Electronic and telephone support (for Lifetime Warranty 2.0)

limited 24x7 telephone support is available from HP for the first 3 years; limited electronic and business hours telephone

support is available from HP for the complete warranty period; to reach our support centres, refer to

www.hp.com/networking/contact-support

; for details on the duration of support provided with your product purchase, refer

www.hp.com/networking/warrantysummary

* HP warranty includes repair or replacement of hardware for as long as you own the product, with next business day advance

replacement (available in most countries). The disk drive included with HP AllianceOne Advanced Services and Services zl Modules, HP

Threat Management Services zl Module, HP AllianceOne Extended zl Module with Riverbed Steelhead, HP MSM765 zl Mobility Controller

and HP Survivable Branch Communication zl Module powered by Microsoft® Lync has a five-year hardware warranty. For details, refer

to the Software license and hardware warranty statements at

www.hp.com/networking/warranty

QuickSpecs

HP 1410 Switch series

Overview

DA - 13674 Worldwide — Version 12 — December 16, 2013

Page 2

Build To Order

: BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-

Shippable solution.

HP 1410-8G Switch

J9559A

8 autosensing 10/100/1000 ports

See Configuration

Note:2

HP 1410-16G Switch

J9560A

16 autosensing 10/100/1000 ports

1U - Height

See Configuration

Note:2

HP 1410-24G-R Switch

JG708A

24 autosensing 10/100/1000 ports

1U - Height

See Configuration

Note:2

HP 1410-24G Switch

J9561A

22 autosensing 10/100/1000 ports

2 dual-personality ports; either an RJ-45 10/100/1000 port or an open mini-GBIC slot

1U - Height

See Configuration

Note:1, 3

PDU Cable NA/MX/TW/JP

J9561A #B2B

C15 PDU Jumper Cord (NA/MX/TW/JP)

PDU Cable ROW

J9561A #B2C

C15 PDU Jumper Cord (ROW)

HP 1410-8 Switch

J9661A

8 autosensing 10/100 ports

See Configuration

Note:2

HP 1410-16 Switch

J9662A

16 autosensing 10/100 ports

1U - Height

See Configuration

Note:2

HP 1410-24 Switch

J9663A

24 autosensing 10/100 ports

1U - Height

See Configuration

Note:2

HP 1410-24-R Switch

JD986B

24 autosensing 10/100 ports

1U - Height

See Configuration

Note:2

QuickSpecs

HP 1410 Switch series

Configuration

DA - 13674 Worldwide — Version 12 — December 16, 2013

Page 3

HP 1410-24-2G Switch

J9664A

24 autosensing 10/100ports

2 autosensing 10/100/1000 ports

1U - Height

See Configuration

Note:2

Configuration Rules:

Note 1

The following Transceivers install into this switch:

HP X121 1G SFP LC SX Transceiver

J4858C

HP X121 1G SFP LC LX Transceiver

J4859C

HP X111 100M SFP LC FX Transceiver

J9054C

Note 2

Localization required. (See Localization Menu for list.)

Note 3

Localization (Wall Power Cord) required on orders without #B2B or #B2C (PDU Power Cord). (See

Localization Menu)

Internal or External Power Supplies(Model Dependant)

Power supplies included

Enter the following menu selections as integrated to the CTO Model X server above if order is factory built.

Transceivers

SFP Transceivers

HP X121 1G SFP LC SX Transceiver

J4858C

HP X121 1G SFP LC LX Transceiver

J4859C

HP X111 100M SFP LC FX Transceiver

J9054C

Cables

Multi-Mode Cables

HP .5m Multi-mode OM3 LC/LC FC Cable

AJ833A

HP 1m Multi-mode OM3 LC/LC FC Cable

AJ834A

HP 2 m Multimode OM3 LC/LC FC Cable

AJ835A

HP 5 m Multimode OM3 LC/LC FC Cable

AJ836A

HP 15 m Multimode OM3 LC/LC FC Cable

AJ837A

HP 30 m Multimode OM3 LC/LC FC Cable

AJ838A

HP 50 m Multimode OM3 LC/LC FC Cable

AJ839A

HP Premier Flex LC/LC OM4 2f 1m Cbl

QK732A

QuickSpecs

HP 1410 Switch series

Configuration

DA - 13674 Worldwide — Version 12 — December 16, 2013

Page 4

HP Premier Flex LC/LC OM4 2f 2m Cbl

QK733A

HP Premier Flex LC/LC OM4 2f 5m Cbl

QK734A

HP Premier Flex LC/LC OM4 2f 15m Cbl

QK735A

HP Premier Flex LC/LC OM4 2f 30m Cbl

QK736A

HP Premier Flex LC/LC OM4 2f 50m Cbl

QK737A

QuickSpecs

HP 1410 Switch series

Configuration

DA - 13674 Worldwide — Version 12 — December 16, 2013

Page 5

HP 1410-8G Switch

(J9559A)

I/O ports and slots

8 RJ-45 autosensing 10/100/1000 ports; Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or

full; 1000BASE-T: full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type

1000BASE-T)

Supports a maximum of 8 autosensing 10/100/1000 ports

Physical characteristics

Dimensions

6.14(w) x 3.8(d) x 0.96(h) in (15.6 x 9.65 x 2.45 cm)

Weight

0.74 lb (0.34 kg)

Memory and processor

4 Kb EEPROM capacity; packet buffer size: 192 KB

Mounting

Wall, desktop, and under-table mounting

Performance

100 Mb Latency

< 3.6 µs (LIFO 64-byte packets)

1000 Mb Latency

< 1.2 µs (LIFO 64-byte packets)

Throughput

11.9 Mpps (64-byte packets)

Switching capacity

16 Gbps

MAC address table size

4096 entries

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative

humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft. (3 km)

Acoustic

Power: 0 dB No fan

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

dissipation

41 BTU/hr (43.26 kJ/hr)

Voltage

100 - 240 VAC

Current

1.0 A

Maximum power rating

12 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case

theoretical maximum numbers provided for planning the infrastructure with

fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all

modules populated.

The exact input voltage and frequency rating are determined by the specific

power adaptor part number ordered. Please select the correct power adaptor

country option.

Safety

CSA 22.2 No. 60950; EN 60950/IEC 60950; UL 60950-1

Emissions

FCC Rules Part 15, Subpart B Class A

Immunity

Generic

EN 55022 CISPR 22

EN 55024, CISPR 24

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 Worldwide — Version 12 — December 16, 2013

Page 6

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency

magnetic field

IEC 61000-4-8

Voltage dips and

interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UF795E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UF796E)

1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR843E)

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR844E)

Installation with minimum configuration, system-based pricing (U4826E)

Installation with HP-provided configuration, system-based pricing (U4830E)

4-year, 4-hour onsite, 13x5 coverage for hardware (UR816E)

4-year, 4-hour onsite, 24x7 coverage for hardware (UR817E)

5-year, 4-hour onsite, 13x5 coverage for hardware (UR818E)

5-year, 4-hour onsite, 24x7 coverage for hardware (UR819E)

3 Yr 6 hr Call-to-Repair Onsite (UW386E)

4 Yr 6 hr Call-to-Repair Onsite (UW387E)

5 Yr 6 hr Call-to-Repair Onsite (UW388E)

1-year, 6 hour Call-To-Repair Onsite for hardware (HR845E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level

descriptions and product numbers. For details about services and response times in your area, please

contact your local HP sales office.

HP 1410-16G Switch

(J9560A)

I/O ports and slots

16 RJ-45 autosensing 10/100/1000 ports; Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or

full; 1000BASE-T: full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type

1000BASE-T)

Supports a maximum of 16 autosensing 10/100/1000 ports

Physical characteristics

Dimensions

8.21(w) x 4.41(d) x 1.73(h) in (20.85 x 11.2 x 4.4 cm) (1U height)

Weight

1.43 lb (0.65 kg)

Memory and processor

512 Kb flash; packet buffer size: 512 KB

Mounting

Mounts in an EIA-standard 19 in. telco rack (hardware included); wall, desktop, and under-table mounting

Performance

100 Mb Latency

< 8.0 µs (LIFO 64-byte packets)

1000 Mb Latency

< 3.6 µs (LIFO 64-byte packets)

Throughput

23.8 Mpps (64-byte packets)

Switching capacity

32 Gb/s

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 Worldwide — Version 12 — December 16, 2013

Page 7

MAC address table size

8192 entries

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative

humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft. (3 km)

Acoustic

Power: 0 dB No fan

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

dissipation

44 BTU/hr (46.42 kJ/hr)

Voltage

100 - 240 VAC

Current

1.1 A

Maximum power rating

13 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case

theoretical maximum numbers provided for planning the infrastructure with

fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all

modules populated.

The exact input voltage and frequency rating are determined by the specific

power adaptor part number ordered. Please select the correct power adaptor

country option.

Safety

CSA 22.2 No. 60950; UL 60950-1; IEC 60950-1; EN 60950-1

Emissions

FCC Rules Part 15, Subpart B Class A

Immunity

Generic

EN 55022 CISPR 22

EN 55024, CISPR 24

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency

magnetic field

IEC 61000-4-8

Voltage dips and

interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)

1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 Worldwide — Version 12 — December 16, 2013

Page 8

Installation with minimum configuration, system-based pricing (U4826E)

Installation with HP-provided configuration, system-based pricing (U4830E)

4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)

4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)

5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)

5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)

3 Yr 6 hr Call-to-Repair Onsite (UW389E)

4 Yr 6 hr Call-to-Repair Onsite (UW390E)

5 Yr 6 hr Call-to-Repair Onsite (UW391E)

1-year, 6 hour Call-To-Repair Onsite for hardware (HR848E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level descriptions

and product numbers. For details about services and response times in your area, please contact your local

HP sales office.

HP 1410-24G-R Switch

(JG708A)

I/O ports and slots

24 RJ-45 autosensing 10/100/1000 ports; Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or

full; 1000BASE-T: full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type

1000BASE-T)

Supports a maximum of 24 autosensing 10/100/1000 ports

Physical characteristics

Dimensions

17.32(w) x 6.81(d) x 1.73(h) in (44 x 17.3 x 4.4 cm) (1U height)

Weight

6.61 lb (3 kg)

Memory and processor

1 MB flash; packet buffer size: 512 KB

Mounting

Mounts in an EIA standard 19-inch telco rack (hardware included); desktop mounting

Performance

100 Mb Latency

< 8.0 µs (LIFO 64-byte packets)

1000 Mb Latency

< 3.6 µs (LIFO 64-byte packets)

Throughput

35.7 Mpps (64-byte packets)

Switching capacity

48 Gb/s

MAC address table size

8192 entries

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative

humidity

5% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

relative humidity

5% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 16,404 ft (5 km)

Acoustic

Power: 0 dB No fan

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

dissipation

55 BTU/hr (58 kJ/hr)

Voltage

100 - 240 VAC

Current

0.3 A

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 Worldwide — Version 12 — December 16, 2013

Page 9

Maximum power rating

16 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case

theoretical maximum numbers provided for planning the infrastructure with

fully loaded PoE (if equipped), 100% traffic, all ports plugged

in, and all modules populated.

This model provides internal power supply. Please select the correct power

cord country option.

Safety

CSA 22.2 No. 60950; UL 60950-1; IEC 60950-1; EN 60950-1

Emissions

FCC Rules Part 15, Subpart B Class A

Immunity

Generic

EN 55022 CISPR 22

EN 55024, CISPR 24

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency

magnetic field

IEC 61000-4-8

Voltage dips and

interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Notes

IEEE 802.3az Energy Efficient Ethernet protocol is supported by the HP 1410-24G-R (JG708A), HP 1410-16

(J9662A) and HP 1410-24 (J9663A) Switches.

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)

1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)

Installation with minimum configuration, system-based pricing (U4826E)

Installation with HP-provided configuration, system-based pricing (U4830E)

4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)

4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)

5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)

5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)

3 Yr 6 hr Call-to-Repair Onsite (UW389E)

4 Yr 6 hr Call-to-Repair Onsite (UW390E)

5 Yr 6 hr Call-to-Repair Onsite (UW391E)

1-year, 6 hour Call-To-Repair Onsite for hardware (HR848E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level

descriptions and product numbers. For details about services and response times in your area, please

contact your local HP sales office.

HP 1410-24G Switch

(J9561A)

QuickSpecs

HP 1410 Switch series

Technical Specifications

DA - 13674 Worldwide — Version 12 — December 16, 2013

Page 10

Otros manuales para 1410 series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de HP

HP Procurve Series 4100GL Manual de usuario

HP StorageWorks 1606 - Extension SAN Switch Manual de operación y mantenimiento

HP J1473A Manual de usuario

HP StorageWorks 2/8-EL - SAN Switch Manual de usuario

HP ProCurve 3500-48 Instrucciones de montaje

HP ProCurve 5400zl Series Manual de usuario

HP FlexFabric 12900 series Manual de usuario

HP StorageWorks 8/24 Manual de usuario

HP 6125G Manual de usuario

HP AA-RSTZB-TE Manual de usuario

HP A12500 Instrucciones de montaje

HP 316095-B21 - StorageWorks Edge Switch 2/24 Manual de instrucciones

HP Aruba 8360-48Y6C v2 Instrucciones de instalación

HP Compaq Presario,Presario 1910 Manual de usuario

HP 316095-B21 - StorageWorks Edge Switch 2/24 Manual de usuario

HP AA979A - StorageWorks SAN Switch 2/8V Manual de usuario

HP 6125G Manual de usuario

HP J9661A Manual de usuario

HP 316095-B21 - StorageWorks Edge Switch 2/24 Manual de instrucciones

HP ProCurve 1600M Manual de usuario

HP A7990A - StorageWorks SAN Director 4/16 Blade... Manual de operación y mantenimiento

HP 316095-B21 - StorageWorks Edge Switch 2/24 Manual de usuario

HP J8772B Instrucciones de montaje

HP 5600-48XG-4QSFP+ series Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
