HP P6500 EVA Controller

Y-cable Replacement Instructions

© Copyright 2011 Hewlett-Packard Development Company, L.P.

First edition: May 2011

The information in this document is subject to change without notice.

Printed in Puerto Rico

www.hp.com

*593098-001*

About this document

For the latest documentation, go to http://www.hp.com/support/

manuals, and select your product.

The information contained herein is subject to change without notice.

The only warranties for HP products and services are set forth in the

express warranty statements accompanying such products and services.

Nothing herein should be construed as constituting an additional

warranty. HP shall not be liable for technical or editorial errors or

omissions contained herein.

WARRANTY INFORMATION

To obtain a copy of the warranty for this product, see the warranty

information website: http://www.hp.com/go/storagewarranty

Before you begin

Observe the following precautions when replacing the Y-cable:

•Ensure that the array is either operational and stable on the redundant

path for the device ports being serviced or the array has been shut

down.

•Label the replacement cable before installing it. See Labeling the re-

placement Y-cable.

NOTE:

The Y-cable is replaced as part of the troubleshooting process

to address a communication failure.

Labeling the replacement Y-cable

Before you remove the cable, label the replacement cable with the port

numbers using the label kit that shipped with the cable. Four sheets of

labels (two red and two green) contain all the port numbers you need.

Label the new cable to match the port labels on the original cable.

The replacement cable should resemble Figure 1.

Page 1

2. Port number label

1. Pull tab (may also be a release

bar)

Figure 1 Y-cable

.

Replacing a Y-cable

To ensure the replacement cable is configured the same as the original

cable, HP recommends that you replace one end at a time.

1. Remove the end of the cable that is connected to the controller port

(DP-A or DP-B) (P0 in Figure 1).

NOTE:

The cable release may be either a pull tab or a release

bar.

2. Insert the new cable head into the controller port (DP-A or DP-B).

3. Remove the end of the cable that is connected to the disk enclosure

port (P1 or P2) (cable head P1 (DP 1) in Figure 1.)

4. Insert the new cable end into the disk enclosure port (P1 or P2).

5. Remove the end of the cable that is connected to the second port

(cable head P2 (DP 2) in Figure 1.)

6. Insert the new cable end into the disk enclosure port (P1 or P2).

Verifying proper operation

Use HP P6000 Command View to verify that the device ports are

enabled.

Page 2
