5243-2SE Tape Drive

Installation and User’s

Guide

Abstract

This guide provides information about installing, operating, and maintaining the 5243-

2SE tape drive on HP NonStop™ telco servers. This guide is written for those who

install or maintain the 5243-2SE tape drive.

Product Version

N.A.

Supported Release Version Updates (RVUs)

This guide supports G06.29 and all subsequent G-series RVUs and H06.06 and all

subsequent H-series RVUs until otherwise indicated by its replacement publication.

Part Number Published

542757-003 July 2006

Document History

Part Number Product Version Published

542757-002 N.A. May 2006

542757-003 N.A. July 2006

Hewlett-Packard Company—542757-003

5243-2SE Tape Drive Installation

and User’s Guide

Index Figures Tables

What’s New in This Manual iii

Manual Information iii

New and Changed Information iii

About This Manual v

Notation Conventions v

1. Overview and Features

Overview 1-1

NonStop S-Series Servers 1-1

NonStop NS-Series Servers 1-1

Features 1-1

Specifications 1-1

2. Installing and Configuring the Tape Drive for the NonStop S-

Series Server

Installation 2-1

Configuration 2-4

ServerNet/DA 2-4

PMF CRU 2-4

3. Operation

Front Panel 3-1

Loading and Unloading Tape Cartridges 3-3

Inserting Tape Cartridges 3-3

Removing Tape Cartridges 3-4

Using Correct Media 3-5

Data Cartridges 3-5

Write-Protecting Cartridges 3-6

Cleaning Tape Cartridges 3-7

Handling Tape Cartridges 3-7

Contents

5243-2SE Tape Drive Installation and User’s Guide—542757-003

4. Troubleshooting

Problems With Tape Cartridges 4-1

The Tape Cartridge Is Jammed 4-1

The Tape Drive Will Not Accept the Tape Cartridge (Or Ejects It Immediately) 4-2

A. Specifications

Technical Specifications A-1

Capacity A-1

Performance A-1

Media A-1

Tape Format A-1

Power Specifications A-2

Environmental Specifications A-2

Safety and Compliance

Index

Figures

Figure 2-1. Front View of Tape Drive 2-1

Figure 2-2. Rear View of Tape Drive 2-2

Figure 2-3. View of Installed SCSI Cable and Terminator 2-3

Figure 3-1. Front View of Tape Drive 3-1

Figure 3-2. Inserting a Tape Cartridge 3-3

Figure 3-3. Ejecting a Cartridge 3-4

Figure 3-4. Write-Protecting a Cartridge 3-6

Tables

Table 2-1. SCSI Cables 2-2

Table 3-1. Tape Drive LEDs 3-2

Table 3-2. Data Cartridge Compatibility 3-5

5243-2SE Tape Drive Installation and User’s Guide—542757-003

iii

What’s New in This Manual

Manual Information

5243-2SE Tape Drive Installation and User’s Guide

Abstract

This guide provides information about installing, operating, and maintaining the 5243-

2SE tape drive on HP NonStop™ telco servers. This guide is written for those who

install or maintain the 5243-2SE tape drive.

Product Version

N.A.

Supported Release Version Updates (RVUs)

This guide supports G06.29 and all subsequent G-series RVUs and H06.06 and all

subsequent H-series RVUs until otherwise indicated by its replacement publication.

Document History

New and Changed Information

Indicated support for G-series RVUs.

Part Number Published

542757-003 July 2006

Part Number Product Version Published

542757-002 N.A. May 2006

542757-003 N.A. July 2006

What’s New in This Manual

5243-2SE Tape Drive Installation and User’s Guide—542757-003

New and Changed Information

5243-2SE Tape Drive Installation and User’s Guide—542757-003

About This Manual

Notation Conventions

Hypertext Links

Blue underline is used to indicate a hypertext link within text. By clicking a passage of

text with a blue underline, you are taken to the location described. For example:

This requirement is described under Backup DAM Volumes and Physical Disk

Drives on page 3-2.

About This Manual

5243-2SE Tape Drive Installation and User’s Guide—542757-003

Hypertext Links

5243-2SE Tape Drive Installation and User’s Guide—542757-003

1-1

1Overview and Features

This section includes:

Overview

The 5243-2SE tape drive is designed for file backup and archive applications. It

contains two independent DAT72 tape drives.

The tape drive unit mounts into a telco rack and has built-in power-on-self-test (POST)

diagnostics.

The tape drive uses DAT72 tape drives and is designed to use a 170-meter DAT72

tape cartridge. The tape drive is also backward compatible with the DDS-3 tape format.

It is not backward compatible with DDS-2 or DDS-1 tape formats. The unit is

considered a field replaceable unit (FRU) and can only be installed or replaced by

qualified personnel trained by HP.

NonStop S-Series Servers

The tape drive connects to a ServerNet/DA, IOMF2 CRU, or PMF CRU on the

NonStop S-series server by a SCSI cable.

NonStop NS-Series Servers

An M8201R Fibre Channel to SCSI router must be used to connect the tape drive to

the Fibre Channel ServerNet adapter (FCSA) on the HP NonStop NS-series server.

For more information, refer to the M8201R Fibre Channel to SCSI Router Installation

and User’s Guide and the Fibre Channel ServerNet Adapter Installation and Support

Guide.

Features

The DAT72 tape drive can store 36GB of data per DAT72 cartridge and up to 72GB of

data in compressed mode (assuming a 2:1 compression factor). The tape drive has

both read and write heads and can perform read-after-write (RAW) data checking.

Specifications

For the tape drive specifications, refer to Appendix A, Specifications.

Overview 1-1

Features 1-1

Overview and Features

5243-2SE Tape Drive Installation and User’s Guide—542757-003

1-2

Specifications
