HP D5970A - NetServer - LCII Manual de usuario

HP NetServer Product Line

Service Reference Guide

Volume 3

High-End

Version 1

Last Updated: February 2000

Notice

The information contained in this document is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited

to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall

not be liable for errors contained herein or for incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its software on equipment that is not

furnished by Hewlett-Packard.

This document contains proprietary information that is protected by copyright. All rights are reserved. No part

of this document may be photocopied, reproduced, or translated to another language without the prior written

consent of Hewlett-Packard Company.

Network Server Division

10955 Tantau Avenue MS-45SLE

Cupertino, CA 950140770

Audience Assumptions

The guide is for HP authorized service personnel who install, administer, and troubleshoot HP NetServers.

The Hewlett-Packard Company assumes you are qualified in the servicing of computer equipment and

trained in recognizing hazards in products with hazardous energy levels.

iii

Table of Contents

HP NetServer LX 1

Front Panel Controls 1

Covers 2

Exploded Views 5

HP NetServer LX Pro and LXe Pro Parts List 7

Footnotes 9

HP NetServer LX Keyboards 11

HP NetServer LX Power Cords 11

Mass Storage Cables 12

System Board 13

System Board Connectors 13

System Switches and Jumpers 14

Cabinet and Redundant Power Supply 15

Power Supply Status LED Display 16

Memory 16

Model A SIMMs 16

Model B SIMMs 18

DIMMs 20

Video Memory - DRAM 21

Boot Device Priority 21

Cabling Configurations 21

Hot Swap Subsystem SCSI Address Settings 24

LXe Cabling Configurations 25

LXe Hot Swap Subsystem SCSI ID Settings 27

Specifications 28

HP NetServer LXr 8000 System Information 31

System Views 31

Front Control Panel 31

Rear View 33

PCI Hot Plug Slot LEDs 34

Covers 35

Memory 35

Boot Device Priority 39

Hot Replacement of PCI Hot Plug Boards 40

Exploded Views 41

Parts List 42

I/O Baseboard 44

I/O Baseboard Jumper Settings 45

Processor Baseboard 45

Processor Baseboard Jumper Settings 46

Specifications 47

HP NetServer LXr 8500 49

System Views 49

Front View 49

Rear View 54

Covers 56

Memory 57

Single Memory Board 57

Dual Memory Boards 57

Memory Capacity 58

Boot Device Priority 59

I/O Baseboard 60

Processor Baseboard 61

Processor Baseboard Jumper Settings 62

IRQ Settings 62

PCI Hot Plug Boards 64

Exploded Views 64

Parts List 66

Specifications 68

Video Resolutions 69

BIOS Video Resolutions 69

HP NetServer LXr Pro 71

System Views 71

Front View 71

Rear View 72

Covers 73

Memory 74

Accessory Boards 76

Boot Device Priority 76

Processors 77

Exploded Views 78

Parts List 80

Keyboards 81

Power Cords 82

System Board 83

Jumper Settings 83

Specifications 84

HP NetServer LXr Pro8 87

System Views 87

Front Panel Controls 87

Power Supply Indicators 88

Rear Panel Controls, Ports, and Indicators 88

Covers 89

Satellite Chassis' Top Cover 91

Lower Board Cage 91

Memory 92

Memory Configurations for One 4 GB Memory Board 93

Memory Configurations for Two 4 GB Memory Boards 93

Boot Device Priority 95

Processor Board Configurations 95

Exploded Views 97

Parts List 101

Cables 102

Keyboards 102

System Board 103

System Switches 104

Specifications 104

Notes 107

Index 111

HP NetServer LX

Front Panel Controls

Poweron Switc

Keyboard

Switch

Control Description

Power on Switch Turns NetServer power on and off. Press once to turn it on; press

again to turn it off.

Reset Switch Resets all processors and reboots the system, as if the power was

cycled off and on, except that the mass storage devices do not power-

cycle.

Keyboard Lock Switch Prevents or allows use of the keyboard via a password.

Disk Access LED Lights whenever performing a read or write to a disk drive.

Power Supply LED See Power Supply Status LED Definition below.

Fan LED See Fan Status LED Definition below.

LCD Readout Displays the current operating status of the NetServer, and system

messages.

Front Panel Lock Locks the top cover, providing security to the components inside the

NetServer.

The mass storage devices are secured by three other locks,

one located between the front doors, and one on each hot-

swap drive cage.

CAUTION If the front panel power supply status LED indicator is lit red or yellow, look at the

LED indicators on each of the power supply modules located at the rear of the

NetServer.

Power Supply Status LED Definition

LED color One PSM Two PSMs Three PSMs

Green OK OK OK

Yellow Power cage

temperature warning Power cage

temperature warning Power cage temperature warning,

or one PSM LED indicator is red or

yellow

Red Power cage

temperature is critical,

or one PSM LED

indicator is red or

yellow

Power cage

temperature is critical,

or one PSM LED

indicator is red or

yellow

Power cage temperature is critical,

or two PSM LED indicators are red

or yellow

Cooling Fan Status LED Definition

LED Color Description

Green OK

Red One or more internal cooling fans have failed (this does not include power supply

module fans)

Covers

CAUTION Internal and external NetServer covers provide proper cooling airflow. To ensure

data integrity, all covers must be in place, regardless of the external environment

(stand-alone or rack-mounted) or temperature (e.g. air conditioned). Even at low

room temperatures, ensuring that all covers and panels are in place provides

controlled airflow and system reliability. This does not include the front doors, which

may be removed without risk.

Topcover

Lumberor

otherspacer

CAUTION Do not force the cover down onto the boards. Forcing the cover may result in

damage to the NetServer. Damage due to improper board installation is not covered

by the warranty.

Inc

Board guides
