HP Part Number 5967-5277

Printed in October 1998

HP NetServer LXr 8000

Memory Upgrade Guide

ii

Notice

Hewlett-Packard makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties of

merchantability and fitness for a particular purpose. Hewlett-Packard

shall not be liable for errors contained herein or for incidental or

consequential damages in connection with the furnishing, performance, or

use of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its

software on equipment that is not furnished by Hewlett-Packard.

This document contains proprietary information that is protected by

copyright. All rights are reserved. No part of this document may be

photocopied, reproduced, or translated to another language without the

prior written consent of Hewlett-Packard Company. Information in this

document is subject to change without notice.

PentiumTM is a U.S. trademark of Intel Corporation.

Hewlett-Packard Company

Network Server Division / MS 45S-LE

Technical Communications

10955 Tantau Avenue

Cupertino, CA 95104 USA

© Copyright 1998, Hewlett-Packard Company

iii

Audience Assumptions

This guide is for the person who installs, administers, and troubleshoots

LAN servers. Hewlett-Packard Company assumes that you are qualified

to service computer equipment and trained in recognizing hazards in

products with hazardous energy levels.

v

Contents

Preface......................................................................................................1

Introduction............................................................................................1

Purpose of this Guide............................................................................2

Related Documentation.........................................................................2

Tools You Need.....................................................................................2

1 Preparing for Installation....................................................................3

Verify Contents......................................................................................3

Prepare for Installation..........................................................................5

2 Installing Memory and Memory Boards .............................................7

Memory Configuration Guidelines.........................................................7

Removing the Memory Board..............................................................18

Installing DIMMs on the Memory Board..............................................21

Removing DIMMs From the Memory Board........................................23

Replacing the Memory Board..............................................................25

3 Warranty and Support........................................................................29

Hardware Warranty.............................................................................29

HP Repair and Telephone Support.....................................................30

1

Preface

Introduction

The HP NetServer LXr 8000 is an Intel-CPU based network server that

can use up to 8 GB of memory. This memory is situated on two boards

that communicate with the rest of the NetServer via the midplane

connector.

Each memory board can hold up to 4 GB of memory, arranged in four

banks of four buffered DIMMs. These DIMMs can be 64 MB or 256

MB, 50 ns EDO memory.

The standard configuration of memory is 256 MB on the primary (right)

board, as four 64 MB DIMMs in slots J1 through J4. Add memory four

DIMMs at a time. If you use both boards, each must have the same type

and number of DIMMs in the same slots.

2

Purpose of this Guide

This guide tells how to:

• Remove and reinstall the HP NetServer LXr 8000 memory board

for a memory upgrade

• Install DIMMs in the specified interleave configuration on the

memory board

• Remove DIMMs and downsize the memory configuration

Related Documentation

The following documents describe the HP NetServer LXr 8000:

•The HP NetServer LXr 8000 Installation Guide

•HP NetServer LXr 8000 Technical Reference Card

•HP NetServer Online Documentation CD-ROM

Tools You Need

To install this accessory kit, you need the following tools:

•An anti-static service kit (3M8501/8502/8503 or equivalent).

This kit includes a static-dissipating work surface, a chassis clip

lead, and a wrist strap.

3

1 Preparing for Installation

Verify Contents

CAUTION Do not remove the DIMM from its bag until you are

ready to install it. Make sure the bag remains sealed.

The DIMM is sensitive to humidity, so desiccant has

been packed in the bag containing the DIMM. When

the DIMM has been installed and the HP NetServer is

running, it is no longer sensitive to humidity.

Unpack the shipping box and verify that you received the contents listed

below for the Memory Upgrade Kit.

The upgrade kit includes:

•Four DIMM memory modules, either 64 MB or 256 MB buffered

EDO DIMMs (50 ns)

4

Figure 1-1. EDO DIMM

NOTE Be sure to keep the bag around the DIMM sealed until

you are ready to install it.

•HP NetServer Memory Upgrade Guide (this document)
