HP L919g Manual de usuario

User Guide

HP L717g 17” and

HP L919g 19” Flat Panel Monitors

Document Part Number: 395552-001

May 2005

This guide provides information on setting up the monitor,

installing drivers, using the on-screen display menu,

troubleshooting and technical specifications.

Enhanced for Accessibility

HP, Hewlett Packard, and the Hewlett-Packard logo are trademarks of

Hewlett-Packard Company in the U.S. and other countries.

Compaq and the Compaq logo are trademarks of Hewlett-Packard

Development Company, L.P. in the U.S. and other countries.

Microsoft, Windows, and the Windows logo are trademarks of Microsoft

Corporation in the U.S. and other countries.

All other product names mentioned herein may be trademarks of their

respective companies.

Hewlett-Packard Company shall not be liable for technical or editorial

errors or omissions contained herein or for incidental or consequential

damages in connection with the furnishing, performance, or use of this

material. The information in this document is provided “as is” without

warranty of any kind, including, but not limited to, the implied warranties

of merchantability and fitness for a particular purpose, and is subject to

change without notice. The warranties for Hewlett-Packard products are set

forth in the express limited warranty statements accompanying such

products. Nothing herein should be construed as constituting an additional

warranty.

This document contains proprietary information that is protected by

translated to another language without the prior written consent of

Hewlett-Packard Company.

ÅWARNING: Text set off in this manner indicates that failure to

follow directions could result in bodily harm or loss of life.

ÄCAUTION: Text set off in this manner indicates that failure to follow

directions could result in damage to equipment or loss of information.

User Guide

HP L717g 17” and L919g 19” Flat Panel Monitors

First Edition (May 2005)

Document Part Number: 395552-001

Contents

1 Product Features

2 Safety and Maintenance Guidelines

Important Safety Information. . . . . . . . . . . . . . . . . . . . . . 2–1

Maintenance Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . 2–2

Cleaning the Monitor. . . . . . . . . . . . . . . . . . . . . . . . . 2–3

Shipping the Monitor. . . . . . . . . . . . . . . . . . . . . . . . . 2–3

3 Setting Up the Monitor

Installing the Stand Base . . . . . . . . . . . . . . . . . . . . . . . . . 3–1

Removing the Stand Base . . . . . . . . . . . . . . . . . . . . . . . . 3–2

Selecting the Signal Connectors and Cables . . . . . . . . . . 3–3

Connecting the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . 3–4

Mounting the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–9

Locating the Rating Labels . . . . . . . . . . . . . . . . . . . . . . 3–10

4 Operating the Monitor

Software and Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1

The Information File . . . . . . . . . . . . . . . . . . . . . . . . . 4–1

The Image Color Matching File . . . . . . . . . . . . . . . . 4–2

Installing the .INF and .ICM Files . . . . . . . . . . . . . . . . . . 4–2

Installing from the CD. . . . . . . . . . . . . . . . . . . . . . . . 4–2

Downloading from the Worldwide Web . . . . . . . . . . 4–3

Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–4

Adjusting the Screen Image . . . . . . . . . . . . . . . . . . . . . . . 4–6

Using the On-Screen Display. . . . . . . . . . . . . . . . . . . . . . 4–6

User Guide iii

Contents

Selecting and Adjusting OSD Menus . . . . . . . . . . . . 4–9

Optimizing Digital Conversion . . . . . . . . . . . . . . . . 4–12

Identifying Monitor Conditions . . . . . . . . . . . . . . . . . . . 4–12

HP Display LiteSaver. . . . . . . . . . . . . . . . . . . . . . . . . . . 4–13

Installing the HP Display LiteSaver Software. . . . . 4–13

A Troubleshooting

Solving Common Problems . . . . . . . . . . . . . . . . . . . . . . . A–1

Using the Worldwide Web. . . . . . . . . . . . . . . . . . . . . . . . A–4

Preparing to call Technical Support. . . . . . . . . . . . . . . . . A–5

B Technical Specifications

L717g Flat Panel Monitor . . . . . . . . . . . . . . . . . . . . . . . . B–1

L919g Flat Panel Monitor . . . . . . . . . . . . . . . . . . . . . . . . B–4

Recognizing Preset Display Resolutions . . . . . . . . . . . . . B–6

Entering User Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . B–7

Energy Saver Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . B–7

Power Light Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . B–8

C Agency Regulatory Notices

Federal Communications

Commission Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–1

Modifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–2

Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–2

Declaration of Conformity for Products Marked with the FCC

Logo (United States Only) . . . . . . . . . . . . . . . . . . . . . . . . C–2

Materials Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–3

Canadian Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–3

Avis Canadien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–3

User Guideiv

Contents

Disposal of Waste Equipment by Users in Private Household

in the European Union . . . . . . . . . . . . . . . . . . . . . . . . . . . C–4

ENERGY STAR Compliance . . . . . . . . . . . . . . . . . . . . . C–4

Power Cord Set Requirements . . . . . . . . . . . . . . . . . . . . . C–5

D LCD Monitor Quality

and Pixel Policy

User Guide v

Contents

User Guidevi

Product Features

The Flat Panel Display has an active matrix, thin-film transistor

(TFT), liquid crystal display (LCD). The monitor features

include:

L717g Model

■ 17-inch (43.27 cm) viewable area display.

■ 1280 × 1024 native resolution, plus full-screen support for

lower resolutions.

■ Wide viewing angle to allow viewing from a sitting or

standing position, or moving side-to-side.

■ Tilt and swivel adjustment capabilities.

■ Removable stand base and VESA 100mm mounting holes for

flexible mounting solutions.

■ Plug and play capability if supported by your system.

■ On-Screen Display (OSD) adjustments for ease of set-up and

screen optimization.

■ Software and documentation CD includes an information file

(INF), Image Color Matching file (ICM), and product

documentation.

■ Energy Saver feature for Energy Star compliance.

User Guide 1–1

Product Features

■ Compliant with the EPA ENERGY STAR regulated

specification.

L919g Model

■ 19-inch (48.19 cm) viewable area display.

■ 1280 x 1024 native resolution, plus full-screen support for

lower resolutions.

■ Wide viewing angle to allow viewing from a sitting or

standing position, or moving side-to-side.

■ Tilt and swivel adjustment capabilities.

■ Removable stand base and VESA 100mm mounting holes for

flexible mounting solutions.

■ Plug and play capability if supported by your system.

■ On-Screen Display (OSD) adjustments for ease of set-up and

screen optimization.

■ Software and documentation CD includes an information file

(INF), Image Color Matching file (ICM), and product

documentation.

■ Energy Saver feature for Energy Star compliance.

■ Compliant with the EPA ENERGY STAR regulated

specifications.

1–2 User Guide

Safety and Maintenance

Guidelines

Important Safety Information

A power cord is included with your monitor. If another cord is

used, use only a power source and connection appropriate for this

monitor. For information on the correct power cord set to use with

your monitor, refer to the “Power Cord Set Requirements” section

in Appendix C.

ÅWARNING: To reduce the risk of electric shock or damage to your

equipment, do not disable the power cord grounding feature. This

equipment is designed to be connected to a grounded (earthed)

power outlet that is easily accessible to the operator. The grounding

plug is an important safety feature.

ÅWARNING: For your safety, be sure that the power outlet you plug

the power cord into is easily accessible and located as close to the

equipment as possible. When you need to disconnect the power to

the equipment, unplug the power cord from the power outlet by

grasping the plug firmly. Never pull on the cord.

User Guide 2–1

Safety and Maintenance Guidelines

ÄCAUTION: For the protection of your monitor, as well as your

computer, connect all power cords for your computer and its

peripheral devices (such as a monitor, printer, scanner) to some form

of surge protection device such as a power strip or Uninterruptible

Power Supply (UPS). Not all power strips provide surge protection;

the power strips must be specifically labeled as having this ability.

Use a power strip whose manufacturer offers a Damage Replacement

Policy so you can replace your equipment if surge protection fails.

Maintenance Guidelines

To enhance the performance and extend the life of your monitor:

■ Do not open your monitor cabinet or attempt to service this

product yourself. Adjust only those controls that are covered

in the operating instructions. If your monitor is not operating

properly or has been dropped or damaged, contact your HP

authorized dealer, reseller, or service provider.

■ Use only a power source and connection appropriate for this

monitor, as indicated on the label/back plate of the monitor.

■ Be sure the total ampere rating of the products connected to

the outlet does not exceed the current rating of the electrical

outlet, and the total ampere rating of the products connected

to the cord does not exceed the rating of the cord. Look on the

power label to determine the ampere rating (AMPS or A) for

each device.

■ Install your monitor near an outlet that you can easily reach.

Disconnect the monitor by grasping the plug firmly and

pulling it from the outlet. Never disconnect the monitor by

pulling the cord.

■ Turn your monitor off when not in use. You can substantially

increase the life expectancy of your monitor by using a screen

saver program and turning off the monitor when not in use.

2–2 User Guide

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de HP

HP HC271 Instrucciones de instalación

HP Compaq LA2205wg Manual de usuario

HP EliteDisplay E243 Instrucciones de instalación

HP Compaq LE1851wl Instrucciones de instalación

HP Compaq LE19f Manual de usuario

HP TS 23W8H - 23" De-Branded Widescreen LCD Full HD 1080p... Cómo utilizar

HP V212a Instrucciones de montaje

HP EliteDisplay E273m Instrucciones de instalación

HP Compaq L1702 Manual de usuario

HP 82912A Manual de usuario

HP EliteDisplay E243d Instrucciones de instalación

HP 2509b Manual de usuario

HP w2007 Instrucciones de construcción

HP S1932 Manual de usuario

HP V221p Instrucciones de instalación

HP L6010 Instrucciones de uso

HP M27fw Manual

HP L7014 Manual

HP F1523 - Pavilion - 15" LCD Monitor Manual de usuario

HP LP2475w - 24" LCD Monitor Instrucciones de instalación

HP ProDisplay Manual de usuario

HP Pavilion MX704 Hoja de especificaciones

HP EliteDisplay E231 Manual de usuario

HP v216w - 21 Inch Wide LCD Monitor Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
