HP Pavilion f1503 Manual de usuario

hp pavilion

f1503/f1703

15-inch/17-inch

LCD Monitor

(15-inch/17-inch Viewable Image)

User’s Guide

Notice

Important Safety Instructions

What the f1503 Monitor Offers

What the f1703 Monitor Offers

Unpacking the Monitor

Setting Up the Monitor

Installing the Drivers

Using the Monitor

Adjusting the Monitor Settings

Troubleshooting

LCD Monitor Quality and Pixel

Policy for f1503 Monitor

LCD Monitor Quality and Pixel

Policy for f1703 Monitor

Technical Specifications for the

f1503 Monitor

Technical Specifications for the

f1703 Monitor

Care and Cleaning

Environmental Information

Regulatory Information

hp pavilion f1503/f1703 LCD Monitor

Notice

2English

Notice

The information contained in the documents accompanying this

product is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to

this material, including, but not limited to, the implied warranties

of merchantability and fitness for a particular purpose.

HP shall not be liable for errors contained herein or for incidental

or consequential damages in connection with the furnishing,

performance, or use of this material.

THE WARRANTY TERMS CONTAINED IN THIS STATEMENT,

EXCEPT TO THE EXTENT LAWFULLY PERMITTED, DO NOT

EXCLUDE, RESTRICT OR MODIFY AND ARE IN ADDITION TO

ANY MANDATORY STATUTORY RIGHTS APPLICABLE TO THE

SALE OF THIS PRODUCT OR SERVICE TO YOU.

HP assumes no responsibility for the use or reliability of its software

on equipment that is not furnished by HP.

These documents contain proprietary information that is protected

by copyright. All rights are reserved. No part of these documents

may be photocopied, reproduced, or translated to another language

without the prior written consent of HP.

Hewlett-Packard Company

P.O. Box 4010

Cupertino, CA 95014-4010

USA

Hewlett-Packard is a registered trademark of Hewlett-Packard

Company in the United States of America and other

countries/regions. Other brand or product names are trademarks of

their respective holders.

hp pavilion f1503/f1703 LCD Monitor

3English

f1503 15-inch LCD

Monitor

hp pavilion f1503/f1703

15-inch/17-inch

LCD Monitor

(15-inch/17-inch Viewable Image)

User’s Guide

f1703 17-inch LCD

Monitor

hp pavilion f1503/f1703 LCD Monitor

Important Safety Instructions

4English

Important Safety Instructions

CAUTION: The lightning flash with arrowhead symbol

inside an equilateral triangle is intended to

alert the user to the presence of uninsulated,

dangerous voltage which may be of sufficient

magnitude to constitute a risk of electric shock.

WARNING: The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and servicing

instructions in the literature accompanying the

appliance.

WARNING: If you are unsure that you can lift the equipment

safely, do not try to move it without help.

WARNING: Before you connect any cables or install

the HP monitor, refer to the above safety

instructions. Also, refer to the setup poster

and the documentation included with the PC and

the video adapter to ensure this equipment is

correctly installed.

WARNING: For your safety, always connect equipment to a

three-prong, grounded wall outlet. Always use

a power cord with a properly grounded plug,

such as the one provided with the equipment, or

one in compliance with your national safety

standards. This equipment can be disconnected

from the power by removing the power cord

from the power outlet. This means the

equipment must be located close to an easily

accessible power outlet.

hp pavilion f1503/f1703 LCD Monitor

Important Safety Instructions

5English

WARNING: Use the monitor with the power adapter

supplied with your HP monitor only.

To avoid electrical shock, do not open the

monitor cover or the power adapter. There are

no user-serviceable parts inside. Only qualified

service personnel should service these parts.

Make sure the computer is turned off before

connecting or disconnecting a display

peripheral.

Working in comfort

Thank you for selecting HP monitor equipment.

To optimize your comfort and productivity, it’s important that you set

up your work area correctly and use your HP equipment properly.

With that in mind, we have developed some setup and use

recommendations based on established ergonomic principles for you

to follow.

These recommendations can be found in the online version of the

Working in Comfort guide, which is preloaded on the hard disk of

your HP computer. They can also be found on the HP Working in

Comfort Web site at http://www.hp.com/ergo along with other

information.

NOTE: This monitor is not intended for use in an office workspace.

hp pavilion f1503/f1703 LCD Monitor

What the f1503 Monitor Offers

6English

What the f1503 Monitor Offers

The HP f1503 monitor is a liquid crystal display (LCD) 15-inch, high

resolution, multi-synchronous color monitor. Multi-synchronous means

that the monitor can use a range of video modes. It is optimized for

use with HP computers.

The HP f1503 monitor has the following features:

• A 15-inch LCD; thin film transistor (TFT) with an anti-glare surface

• Support of video modes up to 1024 x 768 at a 75 Hz refresh rate

• Analog VGA interface connector for connecting to the computer

• True color (16 million colors)

• Adjustable pedestal for positioning the tilt and level of the monitor

screen

• Auto-adjustment of display position, clock, and phase for the VGA

interface

Slim and space

saving

Full scan TFT screen

that gives an

edge-to-edge image Anti-glare

surface

On/Off switch

Menu button

Browse buttons

Auto/Select button

hp pavilion f1503/f1703 LCD Monitor

What the f1503 Monitor Offers

7English

• An On Screen Display (OSD) manager that allows you to adjust

settings through onscreen menus

• Power-management system (VESA*standard) controlled from

suitably equipped HP computers to automatically reduce the

power consumption of the monitor

NOTE: As an ENERGY STAR®partner, HP has determined that

this product meets ENERGY STAR guidelines for energy

efficiency.

• Low power consumption: 40 W maximum

• Compliance with stringent Swedish Low Emissions guidelines

TCO ’99

• Plug and Play capability enabling the monitor to identify itself to

suitably equipped HP computers

• Slot for security lock

* VESA is the Video Electronics Standards Association.

hp pavilion f1503/f1703 LCD Monitor

What the f1703 Monitor Offers

8English

What the f1703 Monitor Offers

The HP f1703 monitor is a liquid crystal display (LCD) 17-inch, high

resolution, multi-synchronous color monitor. Multi-synchronous means

that the monitor can use a range of video modes. It is optimized for

use with HP computers.

The HP f1703 monitor has the following features:

• A 17-inch LCD; thin film transistor (TFT) with an anti-glare surface

• Support of video modes up to 1280 x 1024 at a 75 Hz

refresh rate

• Analog VGA interface connector for connecting to the computers

• True color (16 million colors)

• Adjustable pedestal for positioning the tilt and level of the monitor

screen

• Auto-adjustment of display position, clock, and phase for the VGA

interface

• An On Screen Display (OSD) manager that allows you to adjust

settings through onscreen menus

Slim and space

saving

Full scan TFT screen

that gives an

edge-to-edge image Anti-glare

surface

On/Off switch

Menu button

Browse buttons

Auto/Select button

hp pavilion f1503/f1703 LCD Monitor

What the f1703 Monitor Offers

9English

• Low power consumption: 50 W maximum

• Power-management system (VESA*standard) controlled from

suitably equipped HP computers to automatically reduce the

power consumption of the monitor

NOTE: As an ENERGY STAR partner, HP has determined that this

product meets ENERGY STAR guidelines for energy

efficiency.

• Plug and Play capability enabling the monitor to identify itself to

suitably equipped HP computers

• Slot for security lock

* VESA is the Video Electronics Standards Association.

hp pavilion f1503/f1703 LCD Monitor

Unpacking the Monitor

10 English

Unpacking the Monitor

Check for the following items. If they are missing or damaged,

consult your retailer immediately.

• 1 liquid crystal display (LCD)

• 1 power cord

• 1 DC adapter with an attached DC cable

• 1 set of speakers with a DC cable or speaker DC power adapter

• 1 video cable (VGA)

• 1 quick setup poster

• 1 warranty booklet

• 1 CD-ROM disc
