HP Compaq nx6115 Actualización de firmware

Installing Windows 2000 on the HP Compaq Business

Notebook 6125 and 6115

Introduction......................................................................................................................................... 2

Purpose .......................................................................................................................................... 2

Audience ........................................................................................................................................ 2

System Requirements and Prerequisites................................................................................................... 2

System requirements......................................................................................................................... 2

System prerequisites ......................................................................................................................... 2

Installing the operating system and system hardware ............................................................................... 3

Preparing for installation ................................................................................................................... 3

Installing drivers and enhancements ................................................................................................... 3

Appendix A: Known anomalies ............................................................................................................ 5

Power management.......................................................................................................................... 5

Appendix B: Questions and answers..................................................................................................... 6

For more information............................................................................................................................ 7

Introduction

Purpose

This white paper provides instructions on how to successfully create a Microsoft® Windows® 2000

Professional on HP Compaq Business Notebook 6125/6115 models. The following guidelines

provide installation procedures independent of the currently installed operating system.

Audience

This white paper is for use by HP personnel and clients and describes the process for installing

Microsoft Windows 2000 Professional along with applicable HP drivers and applications.

System Requirements and Prerequisites

System requirements

Information regarding minimum hardware requirements for installing Windows 2000 Professional or

XP Professional is available at www.microsoft.com.

The supported system and subject of this white paper is the HP Compaq Business Notebook

6125/6115.

System prerequisites

IMPORANT:

Back up all user data prior to installing Microsoft Windows 2000.

You will need the following items before installing Windows 2000:

Applicable system: HP Compaq Business Notebook 6125/6115

•Microsoft Windows 2000 Professional CD, Certificate of Authenticity and documentation and

appropriate Service Pack (Service Pack 4 for Windows 2000)

•The latest HP Support Software CD containing updated drivers and deliverables described in the

section “Installation of HP Drivers and Enhancements”

Optionally, the software can be downloaded from the HP website at www.hp.com and burned onto

a CD-R or CD-RW.

•Proper OS License for each PC

IMPORANT:

Make sure you have the latest compatible version of Microsoft Windows

2000 drivers and enhancements. In addition, you must have a Microsoft

OS license for each system on which you install Windows 2000

Professional. The Windows XP Professional license allows you to use either

Windows XP Professional or Windows 2000 Professional. The Windows

2000 license is applicable to Windows 2000 only.

Note:

The HP Support Software CD is updated monthly and available through an

annual subscription or as a one-time purchase. You can also download all

files, including the most current available ROM for the platform, from the

HP website www.hp.com. See Appendix A for information on

determining the current ROM version and how to update.

Installing the operating system and system hardware

Preparing for installation

IMPORANT:

Follow the installation instructions in the order provided. Failure to

complete these steps in the proper order can result in an unsuccessful or

unstable installation.

This section provides guidelines for users who perform a clean installation of Microsoft Windows

2000 Professional.

Installing drivers and enhancements

Perform the following steps before manually installing Windows 2000 Professional:

1. Change the boot order in ROM BIOS to make the Multibay the first boot device on each system.

2. Install the OS and Service Pack (See note below).

Note:

Contact the Network Administrators to properly set up the networking

components of Microsoft Windows 2000 Professional. For installation,

refer to the Microsoft documentation provided with Windows 2000

Professional for complete installation instructions.

3. Install the latest drivers and enhancements from the HP Software Support CD or the HP website at

www.hp.com. See Table 1 for additional information.

Table 1 Minimum versions of necessary drivers and enhancements

Windows 2000 software components Version #

AMD PowerNow for Win2000 3.0.4 A

Conexant Audio Driver 1.00 A

Quick Launch Buttons Software 5.10 B

Synaptics Touchpad 7.13 J

Conexant Modem for ATI Chipset 1.00 A

ATi RS480m Video Driver and Control Panel 1.00 A

HP Wireless Assistant 1.01 A

HP Integrated module with Bluetooth wireless technology 4.00 C

HP Mobile Printing for Notebooks 3.13

TI Cardbus Driver 1.0.3.3 A

System Enhancements Disk for Windows 2000 7.00 E

InterVideo WinDVD Player 6.10 A

Broadcom WLAN Network Adapters Driver for Windows

2000

4.00 C

Broadcom WLAN Network Adapters User Interface for

Windows 2000

4.00 C

Broadcom BCM440x 10-100 Ethernet Driver 1.01 B

Broadcom NetXtreme Gigabit Ethernet PCI Express Driver 1.00 D

Note:

System Enhancements should be installed immediately after Windows

2000 has been installed. Video Driver and Audio Driver should be installed

prior to InterVideo WinDVD Player to improve video playback quality.

WLAN Network Adapters Driver should be installed prior to the WLAN

Network Adapters User Interface.

4. If you have an Internet connection, go to www.microsoft.com/windowsupdate and install the critical

patches.

Reboot the system after completing installation of Microsoft patches.

5. Reboot the system.

It is recommended that power management settings are adjusted prior to using the notebook to

prevent possible data loss.

Appendix A: Known anomalies

Power management

Anomaly: System will not enter hibernation automatically.

Description: The default power management settings under Windows 2000 do not enable

hibernation when the battery reaches a critical state.

Systems Affected: HP Compaq Business Notebook 6125/6115

Operating Systems Affected: Windows 2000

Resolution: Go to Control Panel>Power to adjust the power management settings prior to using the

notebook.

Appendix B: Questions and answers

Q .

Which operating systems are supported on the HP Compaq Business Notebook 6125/6115?

A . Windows XP Home, Windows XP Professional Edition and Windows 2000 Professional are

supported.

Can I purchase Windows 2000 Professional preinstalled on the HP Compaq 6125/6115 from

HP?

A . PC Customization Services can pre-configure 6125/6115 with Windows 2000, although

additional costs will apply. For more information, go to

http://h18000.www1.hp.com/solutions/pcsolutions/pccs.html.

Q . How do I obtain updated software components?

A . The latest software updates are available from the HP Web site at www.hp.com.

For more information

To learn more about HP business notebooks, contact your local HP sales representative or visit our

Web site at: www.hp.com/go/notebooks.

contained herein is subject to change without notice. The only warranties for

HP products and services are set forth in the express warranty statements

accompanying such products and services. Nothing herein should be construed

as constituting an additional warranty. HP shall not be liable for technical or

editorial errors or omissions contained herein.

Microsoft and Windows are U.S. registered trademarks of Microsoft

Corporation. Intel and Pentium are U.S. registered trademarks of Intel

Corporation.

XXXX-XXXXEN, 05/2005
