Specifications 6-1

chapte

SPECIFICATIONS

This chapter provides physical and performance specifications for the following

standard components:

■ Computer

■ Displays

■ Hard drives

■ Diskette drive

■ CD-ROM drive

■ Battery packs

■ External power

The chapter also includes:

■ System interrupts

■ System DMA

■ System I/O address

■ System memory map

6-2 Specifications

6.1 Computer

Table 6-1

Computer Specifications

U.S. Metric

Dimensions (CPU only)

Height

Depth

Width

1.1 in

9.3 in

11.8 in

3.1 cm

23.5 cm

30.0 cm

Dimensions (CPU M35EU)

Height

Depth

Width

2.1 in

9.3 in

11.8 in

5.4 cm

23.6 cm

30.0 cm

Dimensions ( M35EU only including tabs

)

Height

Depth

Width

0.9 in

9.3 in

11.8 in

2.3 cm

23.6 cm

30.0 cm

Weight (without M35EU)

With 6 cell battery 4.4 lbs. 2.0 kg

Standalone (Battery) Power Requirements

Nominal Operating Voltage (Li-Ion) 10.8 V

Maximum Operating Power (CPU only) 35.0 W

Maximum Operating Power (CPU+M35EU) 45.0 W

Integrated AC Power Requirements

Operating Voltage 100 to 240 VAC RMS

Operating Current 1.1 A RMS

Operating Frequency Range 47 to 63 Hz AC

Maximum Transient 4/50 kV

Temperature **

Operating 5 to95°F 10 to 35°C

Non-operating -4 to 140°F -20 to 60°C

Relative Humidity (non-condensing)

Operating 10 to 90%

Non-operating (tw= 38.7°C max) 5 to 90%

Altitude

Operating 0 to 10,000 ft 0 to 3.15 km

Non-operating 0 to 30,000 ft 0 to 10.14 km

Shoc

Operating 10 G, 11 ms, half sine

Non operating 240 G, 2 ms, half sine

Vibration

Operating 0.55 G, 0.25 Oct/Min sweep rate

Non-operating 1.5 G, 0.5 Oct/Min sweep rate

** Weight is for the computer with 6 cell battery pack and 12.1 inch display panel.

pplicable product safety standards specify thermal limits for plastic surfaces. This

computer operates well within the temperature ranges specified.

Specifications 6-3

6.2 Displays

Table 6-2

12.1-Inch CTFT, SVGA Display

U.S. Metric

Dimensions

Height

Width 7.24 in

9.7 in 18.4 cm

24.6 cm

Number of Colors 64K

Contrast Ratio 100:1 minimum

Pixel Resolution

Pitch

Format

Configuration

0.30 × 0.30 mm

800 × 600

RGB Stripe

Backlight Edge Lit

Character Display 80 × 25

Table 6-3

13.3-Inch CTFT, XGA Display

U.S. Metric

Dimensions

Heigh

7.9 in 20.1 cm

Width 10.6 in 26.9 cm

Number of Colors 64K

Contrast Ratio 100: 1 minimum

Pixel Resolution

Pitch

Format

Configuration

0.29 x 0.29 mm

1024 x 768

RGB Stripe

Backlight Edge Lit

Character Display 80 × 25

6-4 Specifications

6.3 Hard Drives

Table 6-4

Hard Drive Specifications

Standard Model Configurations 4-GB 6-GB

Formatted Capacity per Drive

Logical 4,099,866,624 6,495,068,160

Drive Type 65 65

Drive Height

Without frame (mm) 12.5 12.5

With frame (mm) 12.7 12.7

Drive Size

Inches 2.75 x 3.94 2.75 x 3.94

Millimeters 100.2 x 69.85 100.1 x 69.9

Transfer Rate

Media (Mb/s) 51.7 to 83.4 67.5 to 111.9

Interface (Mb/s) 16.6 16.6

Sector Interleave 1:1 1:1

Typical Seek Time (Including setting)

Single Track (ms) 4 3

Average (ms) 13 (READ) 13 (READ)

Full Stroke (ms) 23 (READ) 25 (READ)

Disk Rotational Speed (RPM) 4009 4200

Physical Configuration

Cylinders 6975 8960

Data Heads 6 6

Sectors/Track 114 to 240 178 to 294

Bytes/Sector 512 512

Logical Configuration

Cylinders 7944 13,424

Heads 16 15

Sectors per Track 63 63

Bytes per Sector 512 512

Buffer Size (kB) 512 512

Specifications 6-5

6.4 Diskette Drive

Table 6-5

Diskette Drive Specifications

Diskette size 3.5-inch

High density 1.44-MB/1.2-MB

Low density 720 KB

Light None

Height 0.43-in (11 mm)

Bytes per sector 512

Sectors per Trac

High density 18 (1.44-MB)/15 (1.2-MB)

Low density 9

Tracks per Side

High density 80 (1.44-MB)/80 (1.2-MB)

Low density 80

Read/Write heads 2

Average Seek Times

Track-to-Track (high/low) 3 ms/6 ms

Average (high/low) 94 ms/174 ms

Settling Time 15 ms

Latency Average 100 ms

6-6 Specifications

6.5 Optical Disc Drive

Table 6-6

24X CD-ROM Specifications

Applicable Disc CD-ROM mode 1, mode 2

CD-Digital Audio

CD-XA mode 2 (Form 1, Form 2)

CD-I mode 2 (Form1, Form 2)

CD-I Ready

CD-Bridge

CD-WO (fixed/variable packets)

Photo CD (single/multisession)

Drive Size (cm) 1.27 x 12.8 x 12.9

Center Hole Diameter 15 mm

Disc Diameter 12 cm, 8 cm

Disc Thickness 1.2 mm

Track Pitch 1.6 µm

Laser

Beam Divergence 53.5 ±1.5 degrees

Output Power 0.24 ±0.1 mw

Type Semiconductor Laser GaA1As

Wave Length 780 nm ±25 nm at Ph-4.3 mW

Access time

Random <350 ms (150 ms typical)

Full Stroke <750 ms

Audio output level

Line Out 0.8 Vrms

Headphone None

Cache buffer 128 KB

Data transfer rate

Sustained, 24x 3600 KB/sec (outer diameter)

Sustained, single 150 KB/sec

Burst 8.3 MB/sec

Startup Time <8 seconds typical

Capacity

Mode 1, 12 cm 550 MB

Mode 2, 12 cm 640 MB

8 cm 180 MB

Specifications 6-7

6.6 External Power

The external battery charger charges the Li-Ion battery outside the computer. It may

also be used to charge spare batteries.

Table 6-7

External Battery Charger with AC Adapter

6-Cell

Power Supply (Input)

Nominal Voltage 90 to 264 VAC

Line frequency 47-63 Hz

Power Supply (Output)

Nominal Voltage +15.0 +/- 0.5 VDC

Power 35 to 40 W

Temperature

Operating 32°to 104°F

Nonoperating -4°to 185°F

Relative Humidity

Operating 10% to 90%

Nonoperating 10% to 95%

Table 6-8

Lithium-Ion (Li-Ion) Battery Pack

Parameter 6 Cell 9 Cell

Open circuit voltage (Nominal): 10.8 V 10.8 V

Capacity: 38.4 Wh 48.6 Wh

Temperature:

Charge

Storage 10oC to 40oC (50o F to 104o F)

0oC to 50oC (32o F to 122o F)

6-8 Specifications

6.7 System Interrupts

Table 6-9

Hardware Interrupts

Hardware IRQ System Function

IRQ0 Timer interrupt

IRQ1 Keyboard

IRQ2 Interrupt controller cascade

IRQ3 COM 2

IRQ4 COM 1

IRQ5 Audio

IRQ6 Diskette Drive controller

IRQ7 EPP Parallel

IRQ8 Real-Time Clock (MSIO)

IRQ9 PCI devices

IRQ10 Unused

IRQ11 Used by PCMCIA

IRQ12 Mouse

IRQ13 Floating point error input

IRQ14 Primary IDE interface

IRQ15 Secondary IDE interface

6.8 System DMA

Table 6-10

DMA Channels

Hardware DMA System Function

DMA 0 Fast infrared or Audio controller

DMA 1 Audio controller

DMA 2 Diskette drive controller

DMA 3 EPP Parallel Port

DMA 4 Not assigned

DMA 5 Audio Controller

DMA 6 Not assigned

DMA 7 Not assigned

Specifications 6-9

6.9 System I/O Address

Table 6-11

System I/O (Port) Addresses

I/O Address (Hex) System Function (Shipping Configuration)

000 - 00F Master DMA Controller # 1

010 - 011 Force Software SMI

012 - 01F Unused

020 - 021 Peripheral Interrupt Controller # 1

022 - 024 Chipset Configuration Registers

025 - 03F Unused

040 - 043 Counter/Timer Registers

044 - 05F Unused

060 Keyboard Data

061 Port B

062 - 063 Unused

064 Keyboard Command/Status

065 - 06F Unused

070 CMOS Index Address

071 CMOS Data

072 - 073 Unused

074 Reserved

075 Unused

076 Reserved

077 - 077F Unused

080 - 08F DMA Page Registers

084 - 085 POST Code Output Port

090 - 091 Unused

092 Fast Reset Register

093 - 09F Unused

0A0 - 0A1 Interrupt Controller # 2

0A2 - 0BF Unused

0C0 - 0DF DMA Controller # 2

0E0 - 0E1 ESS Audio Configuration

0E2 - 0E5 Configuration Registers

0E6 - 0EF Unused

0F0 - 0F1 NCP Numerics Register

0F9 ESS Configuration Lock

0FA Unused

0FB ESS Configuration Unlock

0FC - 0FF Unused

100 - 101 Unused

103 - 16F Unused

Continued

6-10 Specifications

Table 6-9

Continued

I/O Address (Hex) System Function (Shipping Configuration)

170 - 177 Hard Drive Secondary Registers

178 - 1EF Unused

1F0 - 1F7 Hard Drive Primary Registers

1F8 - 1FF Unused

200 - 21F Unused

220 - 22F ESS Audio Registers (1st Possible) (Default)

230 - 23F ESS Audio Registers (2nd Possible)

240 - 24F ESS Audio Registers (3rd Possible)

250 - 25F ESS Audio Registers (4th Possible)

260 - 277 Unused

278 - 27A LPT2 and High Speed Parallel Port Registers

27B - 27F LPT2 High Speed Printer Port Registers

280 - 2F7 Unused

2F8 - 2FF Serial Control Register COM2

300 - 36F Unused

370 - 371 Reserved

372 Diskette Digital Output Register

373 Unused

374 Reserved

375 Diskette Main Status/Data Registers

376 Reserved

377 Diskette Input/Control Registers

378 - 37A LPT1 and High Speed Parallel Port Registers

37B - 37F Unused

380 - 387 Unused

388 - 38B ESS FM Synthesizer

38C - 3AF Unused

3B0 - 3BB Unused

3BC - 3BE LPT3 and High Speed Parallel Port Registers

3BF LPT1 High Speed Parallel Port Registers

3C0 - 3CD Unused

3D0 - 3DF Unused

3F0 - 3F7 Diskette Drive Controller Primary Registers

3F8 - 3FF COM1 Serial Controller Registers

400 - 4CF Unused

480 - 48F Extended DMS Registers

4D0 - CF6 Unused

CF7 Configuration/NVM Data Register

CF8 - CFB PCI Configuration Index Register

CFC - CFF PCI Configuration Index Register

D00 - FFF Unused
