About this Manual

We’ve added this manual to the Agilent website in an effort to help you support

your product. This manual is the best copy we could find; it may be incomplete

or contain dated information. If we find a more recent copy in the future, we will

add it to the Agilent website.

Support for Your Product

Agilent no longer sells or supports this product. Our service centers may be able

to perform calibration if no repair parts are needed, but no other support from

Agilent is available. You will find any other available product information on the

Agilent Test & Measurement website, www.tm.agilent.com.

HP References in this Manual

This manual may contain references to HP or Hewlett-Packard. Please note that

Hewlett-Packard's former test and measurement, semiconductor products and

chemical analysis businesses are now part of Agilent Technologies. We have

made no changes to this manual copy. In other documentation, to reduce

potential confusion, the only change to product numbers and names has been in

the company name prefix: where a product number/name was HP XXXX the

current name/number is now Agilent XXXX. For example, model number

HP8648A is now model number Agilent 8648A.

Emulation for the PowerPC

MPC500

User’s Guide

Publication number E3456-97002

July 1998

For Safety information, Warranties, and Regulatory information,

see the pages behind the index.

Emulation for the PowerPC MPC500—At a Glance

Motorola’s embedded PowerPC MPC500 microprocessors provide a

development port (also known as a debug port) that lets tools like the

HP E3456A emulation probe or the HP 16610A emulation module give

you capabilities like:

• Stopping or starting program execution.

• Setting breakpoints in the program.

• Displaying and modifying the contents of microprocessor registers.

• Displaying and modifying the contents of target system memory or I/O.

• Downloading program code to target system memory.

The HP E3456A emulation probe and the HP 16610A emulation

module require that a debug port connector be designed into your

target system (unless you have the HP E2490A analysis probe for

MPC505/509 microprocessors which has a built-in connector for the

emulation probe or emulation module).

Both the HP E3456A emulation probe and the HP 16610A emulation

module come with a target interface module (TIM) that adapts the

emulation probe or emulation module to a debug port connector in the

target system.

The emulation probe or emulation module can be controlled by a

debugger on a host computer or by the Emulation Control Interface on

an HP 16600A/16700A-series logic analysis system.

Emulation Probe

The HP E3456A emulation probe is a stand-alone unit that has its own

power supply and local area network (LAN) interface.

The HP E3456A emulation probe is typically used in situations where

only its capabilities are needed, for example, by software developers

using debuggers to debug program code. But, it can also be used along

with the HP 16600A/16700A-series logic analysis system when logic

analysis capabilities are needed.

Emulation Module

The HP 16610A emulation module is designed to be installed in

HP 16600A/16700A-series logic analysis systems. The logic analysis

system supplies the power and LAN interface.

The HP 16610A emulation module is typically used in situations where

its capabilities are needed along with the logic analysis system

capabilities, for example, by hardware designers, firmware developers,

and system integrators who are analyzing the real-time execution of a

microprocessor-based target system.

In This Book

This book describes the following products:

This book shows how to:

• Install and set up the emulation probe or emulation module.

• Connect the emulation probe/module to a target system.

• Configure the emulation probe/module for proper operation with your

target system.

• Use the emulation probe/module with debuggers.

This book also describes the specifications and characteristics of the

emulation probe/module, and it contains service information.

See Also If you’re using the Emulation Control Interface in the HP 16600A/

16700A-series logic analysis system to control the emulation probe/

module, see the logic analysis system’s on-line help.

If you’re using a high-level source debugger to control the emulation

probe/module, see the debugger’s documentation.

See also Hewlett-Packard’s logic analysis and emulation web site at:

http://www.hp.com/go/emulator

Comments on the

Documentation? Send email to documenta[email protected] (for comments only;

please contact your local HP representative if you need technical

support).

3URGXFW 6XSSRUWV ,QFOXGHV

+3 ($2SWLRQ

(PXODWLRQ3UREH

03& +3 ($HPXODWLRQSUREH

+3 (WDUJHWLQWHUIDFHPRGXOH7,0

+3 ($2SWLRQ

(PXODWLRQ0RGXOH

03& +3 $HPXODWLRQPRGXOH

+3 (WDUJHWLQWHUIDFHPRGXOH7,0

Contents

Emulation for the PowerPC MPC500—At a Glance

Emulation Probe 3

Emulation Module 3

In This Book

1 Installing the Emulation Probe

Overview of Installation and Setup 14

Equipment and Requirements 16

Supplied Equipment and Software 16

Additional Equipment and Software Required 17

Other Optional Equipment 18

Powering-On and Powering-Off the Emulation Probe 19

To power on the system 19

To power off the system 19

To connect the emulation probe to a power source 19

Connecting the Emulation Probe to a LAN 21

To get the IP and gateway addresses 22

To configure LAN parameters using the built-in terminal interface 23

To configure LAN parameters using BOOTP 26

To set the 10BASE-T configuration switches 28

To verify LAN communications 29

Solving LAN Communication Problems 31

If you cannot verify LAN communication 31

If you have LAN connection problems 32

If the “POL” LED is lit 33

If it takes a long time to connect to the network 33

Contents

Connecting a Terminal to the Emulation Probe’s Serial Port 34

To set the serial configuration switches 34

To connect a serial cable 35

To verify serial communications 36

Solving Serial Communication Problems 38

If you cannot verify RS-232 communication 38

If you have RS-232 connection problems with the MS Windows Terminal

program 38

Updating Emulation Probe Firmware 40

To display current firmware version information 40

To update firmware for an emulation probe 40

2 Installing the Emulation Module

Overview of Installation and Setup 44

Equipment and Requirements 46

Supplied Equipment and Software 46

Additional Equipment and Software Required 47

Installing into a Logic Analysis System 48

To install in a HP 16700A-series logic analysis system 48

To install in a HP 16600A-series logic analysis system 51

To test the emulation module 53

Installing Software 54

To install software from CD-ROM 54

Updating Emulation Module Firmware 56

To display current firmware version information 56

To update firmware using the Emulation Control Interface 56

To update firmware using the Setup Assistant 57

Contents

Preparing for a Debugger 59

To connect the logic analysis system to the LAN 59

To change the port number of an emulation module 60

To verify LAN communication with the emulation module 61

3 Connecting to a Target System

Designing the Target System for an Emulation Probe/Module 64

Target System Requirements 64

Debug Port Connection 64

SYPCR Register 67

On-Chip Flash Support 68

Fast Download 68

Making the Target System Connection 69

To connect to a target system debug port 69

To connect to the analysis probe 71

To verify communication with the target system 73

4 Configuring the Emulation Probe/Module

Entering Emulation Probe/Module Commands 77

To use the Emulation Control Interface 77

To use the built-in command interface 79

To use a debugger interface 80

Contents

Setting the MPC5xx Configuration Options 81

To configure the processor type 81

To configure the processor clock speed 82

To configure the debug port connection type 83

To configure the reset configuration word source 84

To configure the “Break In” type 84

To configure the Trigger Out BNC 85

To configure the Trigger In BNC 85

To configure the BNC break type 86

To configure restriction to real-time runs 86

Testing the Emulation Probe/Module and the Target System 87

To test memory accesses 87

To test by running a program 87

5UsingDebuggers

Setting Up Debugger Software 92

To change the port number of an emulation probe/module 93

To view logic analysis system windows next to the debugger 93

Using the Green Hills Debugger 95

To get started 95

To configure using an initialization script 98

To perform common debugger tasks 99

To send commands to the emulation probe/module 100

To view commands sent by MULTI to the emulation probe/module 100

To reinitialize the system 101

To disconnect from the emulation probe/module 101

Error conditions 101

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unidad de control de HP

HP 75000 B Series Manual de usuario

HP 13255 Manual

HP HP 70909A Manual de usuario

HP 83400 Series Manual de usuario

HP HP 81536A Manual de usuario

HP 900896-121 Guía

HP 7500 48p 1000BASE-T w/PoE+ SE Mod Instrucciones de instalación

HP 6600-A FIP-600 FlexIntfPltfrm Rtr Mod Instrucciones de montaje

HP R6000 - UPS - Lead Acid Expandable Manual de usuario

HP Synergy 480 Gen10 Manual de usuario

HP HP E1361A Manual de usuario

HP ProCurve PCM+ Agent on ONE zl Module Instrucciones de montaje

HP DESKJET 1050 Manual del producto

HP E1407A Manual de usuario

HP 70427A Manual de usuario

HP 13255 Manual

HP JG589A Instrucciones de montaje

HP 81541MM Manual del propietario

HP HPE FlexNetwork 7500 Manual de usuario

HP 13255 Manual de usuario

HP HP 81531A Manual de usuario

HP VXI E1476A Instrucciones de funcionamiento

HP JC075A Instrucciones de montaje

HP E1364A Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
