Hotpoint RB525 Manual de usuario

RB525

RB526

RB533

RB536

RB632

Ranges



Owner’s Manual

Part No. 164D3333P038 Pub. No. 39-4761 7

ELECTRIC

Congratulations!

You Are Now Part of the Hotpoint Family.

Welcome to the Hotpoint family.

We’re proud of our quality products and

we are committed to providing dependable

service. You’ll see it in this easy-to-use

Owner’s Manual and you’ll hear it in the

friendly voices of our customer service

department.

Important!

Staple sales slip or cancelled

check here.

Proof of the original purchase date

is needed to obtain service under

the warranty.

Write the model and serial

numbers here.

You can find them on a label behind

the range door or behind the storage

drawer.

Best of all, you’ll experience these values

each time you use your range. That’s

important, because your new range will be

part of your family for many years. And we

hope you will be part of ours for a long

time to come.

We thank you for buying Hotpoint.

We appreciate your purchase and hope

you will continue to rely on us whenever

you need quality appliances for your home.

Hotpoint & You,

A Service Partnership.

Inside you will find many

helpful hints on how to use and

maintain your range properly.

Just a little preventive care on

your part can save you a great

deal of time and money over the

life of your range.

Read this Manual

Ask any Hotpoint appliance owner and

they will tell you we stand behind our

products with unmatched quality service.

However, did you know that most questions

result from simple problems that you can

easily fix yourself in just a few minutes?

This Owner’s Manual can tell you how.

You’ll find many answers to

common problems here.

If you review our chart of

Troubleshooting Tips first,

you may not need to call for

service at all.

Review the Section on

Troubleshooting Tips

If you do need service, you can

relax knowing help is only a

phone call away. A list of toll-free

customer service numbers is

included in the back section.

Or you can always call the

GE Answer Center®at

800.626.2000, 24 hours a day,

7 days a week.

If You Need Service

Safety Information

Anti-Tip Device . . . . . . . . . . . . .4

Safety Precautions . . . . . . . .5–7

Oven . . . . . . . . . . . . . . . . . . . . .8

Surface Cooking Units . . . . .9, 10

Operating Instructions

Using the Surface Units . . . . .11

Using the Clock

and Timer . . . . . . . . . . . . . .12, 13

Using the Oven . . . . . . . . .14, 15

Oven Thermostat . . . . . . . . . . .17

Care and Cleaning . . . . . . .18–26

Installation Instructions

Before You Begin . . . . . . . . . . .27

Prepare the Opening . . . . . . . .28

Flooring . . . . . . . . . . . . . . . . . .29

Electrical Connection . . . .29–34

Anti-Tip Bracket . . . . . . . . . . . .35

Leveling . . . . . . . . . . . . . . . . . .35

Troubleshooting Tips

Before You

Call For Service . . . . . . . . .36–38

Customer Service

Warranty . . . . . . . . . . . . . . . .39

Service Telephone

Numbers . . . . . . . . . .Back Cover

Troubleshooting TipsInstallation Instructions Customer Service

Operating InstructionsSafety Information

All ranges can tip and injury could result.

To prevent accidental tipping of the range, attach it to the

wall and floor by installing the Anti-Tip device supplied.

To check if the device is installed and engaged properly,

remove the storage drawer and inspect the rear leveling leg.

Make sure it fits securely into the slot.

If you pull the range out from the wall for any

reason, make sure the device is properly engaged

when you push the range back against the wall. If it is

not, there is a possible risk of the range tipping over

and causing injury if you or a child stand, sit or lean on

an open door.

Please refer to the Anti-Tip device information in this

manual. Failure to take this precaution could result in

tipping of the range and injury.

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

For your safety, the information in this manual must be

followed to minimize the risk of fire or explosion, electric

shock, or to prevent property damage, personal injury, or

loss of life.

Operating Instructions

Installation Instructions Safety Information

Troubleshooting TipsCustomer Service

WARNING

ANTI-TIP DEVICE

IMPORTANT SAFETY NOTICE

Fluorescent light bulbs contain mercury. If your model

has a surface light, you must recycle the fluorescent light

bulb according to local, state and federal codes.

Troubleshooting TipsInstallation Instructions Customer Service

Operating InstructionsSafety Information

Use this appliance only for its intended purpose as

described in this Owner’s Manual.

When using electrical appliances, basic safety precautions

should be followed, including the following:

■ Be sure your appliance

is properly installed

and grounded by a

qualified technician in

accordance with the

provided installation

instructions.

■ Do not attempt to

repair or replace any

part of your range

unless it is specifically

recommended in this

manual. All other

servicing should be

referred to a qualified

technician.

■ Before performing any

service, disconnect the

range power supply at

the household

distribution panel by

removing the fuse or

switching off the circuit

breaker.

■ Do not leave children

alone—children should

not be left alone or

unattended in an area

where an appliance is

in use. They should

never be allowed to sit

or stand on any part of

the appliance.

■ Do not allow anyone to

climb, stand or hang on

the door, storage

drawer or cooktop.

They could damage the

range and even tip it

over, causing severe

personal injury.

■ Do not store flammable

materials in an oven or

near the cooktop.

■

CAUTION:

Items of

interest to children

should not be stored in

cabinets above a range

or on the backsplash of

a range—children

climbing on the range

to reach items could be

seriously injured.

■ Never wear loose-fitting

or hanging garments

while using the

appliance. Be careful

when reaching for

items stored over the

range. Flammable

material could be

ignited if brought in

contact with hot surface

units or heating

elements and may

cause severe burns.

SAFETY PRECAUTIONS

■ Use only dry pot

holders—moist or

damp pot holders on

hot surfaces may result

in burns from steam.

Do not let pot holders

touch hot surface units

or heating elements.

Do not use a towel or

other bulky cloth.

■ For your safety, never

use your appliance for

warming or heating the

room.

■ Do not store or use

combustible materials,

gasoline or other

flammable vapors and

liquids in the vicinity of

this or any other

appliance.

■ Keep the hood and

grease filters clean to

maintain good venting

and to avoid grease

fires.

■ Do not let cooking

grease or other

flammable materials

accumulate in or near

the range.

■ Do not use water on

grease fires. Never pick

up a flaming pan. Turn

the controls off.

Smother a flaming pan

on a surface unit by

covering the pan

completely with a well-

fitting lid, cookie sheet

or flat tray. Use a multi-

purpose dry chemical

or foam-type fire

extinguisher.

■Flaming grease outside

a pan can be put out by

covering it with baking

soda or, if available, by

using a multi-purpose

dry chemical or foam-

type fire extinguisher.

■Flame in the oven can

be smothered

completely by closing

the oven door and

turning the oven off or

by using a multi-

purpose dry chemical

or foam-type fire

extinguisher.

WARNING!

SAFETY PRECAUTIONS

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

Operating Instructions

Installation Instructions Safety Information

Troubleshooting TipsCustomer Service

Troubleshooting TipsInstallation Instructions Customer Service

Operating InstructionsSafety Information

WHEN COOKING PORK…

When cooking pork, follow the directions exactly and always cook

the meat to an internal temperature of at least 170°F. This assures

that, in the remote possibility that trichina may be present in the

meat, it will be killed and the meat will be safe to eat.

■ Do not touch the

surface units, the

heating elements or the

interior surface of the

oven. These surfaces

may be hot enough to

burn even though they

are dark in color.

During and after use,

do not touch, or let

clothing or other

flammable materials

contact, the surface

units, areas nearby the

surface units or any

interior area of the

oven; allow sufficient

time for cooling first.

■Potentially hot surfaces

include the cooktop,

areas facing the

cooktop, oven vent

opening, surfaces near

the opening, crevices

around the oven door

and metal trim parts

above the door.

■

REMEMBER:

The inside

surface of the oven may

be hot when the door is

opened.

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

■ Stand away from

the range when

opening the oven door.

Hot air or steam which

escapes can cause

burns to hands, face

and/or eyes.

■ Do not heat unopened

food containers.

Pressure could build

up and the container

could burst, causing an

injury.

■ Keep the oven vent

unobstructed.

■ Keep the oven free

from grease buildup.

■ Place the oven shelf in

the desired position

while the oven is cool.

If shelves must be

handled when hot,

do not let pot holder

contact the heating

elements.

■ Pulling out the shelf

to the stop-lock is a

convenience in lifting

heavy foods. It is also a

precaution against

burns from touching

hot surfaces of the door

or oven walls.

■ When using cooking

or roasting bags in the

oven, follow the

manufacturer’s

directions.

■ Do not use the oven to

dry newspapers. If

overheated, they can

catch on fire.

■ Do not use the oven for

a storage area. Items

stored in an oven can

ignite.

■ Do not leave paper

products, cooking

utensils or food in the

oven when not in use.

■ For continuous-

cleaning models, do

not use oven cleaners

on any of the

continuous-cleaning

surfaces. Continuous-

cleaning surfaces can

be identified by their

rough surface finish.

WARNING!

OVEN

Operating Instructions

Installation Instructions Safety Information

Troubleshooting TipsCustomer Service

Use proper pan size—select cookware having flat bottoms

large enough to cover the surface unit heating element. The

use of undersized cookware will expose a portion of the

surface unit to direct contact and may result in ignition of

clothing. Proper relationship of cookware to surface unit will

also improve efficiency.

■ Never leave the surface

units unattended at

high heat settings.

Boilovers cause

smoking and greasy

spillovers that may

catch on fire.

■ Be sure the drip pans

and the vent duct are

not covered and are in

place. Their absence

during cooking could

damage range parts

and wiring.

■ Do not use aluminum

foil to line the drip

pans or anywhere in

the oven except as

described in this

manual. Misuse could

result in a shock, fire

hazard or damage to

the range.

■ Only certain types of

glass, glass ⁄ceramic,

earthenware or other

glazed containers are

suitable for cooktop

service; others may

break because of the

sudden change in

temperature.

■ To minimize the

possibility of burns,

ignition of flammable

materials and spillage,

the handle of a

container should be

turned toward the

center of the range

without extending over

nearby surface units.

■ Always turn the surface

units off before

removing cookware.

■ Do not immerse or

soak the removable

surface units. Do not

put them in a

dishwasher.

■ When flaming foods

are under the hood,

turn the fan off. The

fan, if operating, may

spread the flame.

■ To avoid the possibility

of a burn or electric

shock, always be certain

that the controls for all

surface units are at the

OFF

position and all

coils are cool before

attempting to lift or

remove a unit.

SURFACE COOKING UNITS

Troubleshooting TipsInstallation Instructions Customer Service

Operating InstructionsSafety Information

IMPORTANT SAFETY INSTRUCTIONS.

READ ALL INFORMATION BEFORE USING.

■ Clean the cooktop with

caution. If a wet sponge

is used to wipe spills on

a hot cooktop, be

careful to avoid steam

burns.

■ Keep an eye on foods

being fried at high or

medium high heat

settings.

■ Foods for frying should

be as dry as possible.

Frost on frozen foods

or moisture on fresh

foods can cause hot fat

to bubble up and over

the sides of the pan.

■ Use little fat for

effective shallow or

deep fat frying. Filling

the pan too full of fat

can cause spillovers

when food is added.

■ If a combination of oils

or fats will be used in

frying, stir together

before heating, or as

fats melt slowly.

■ Always heat fat slowly,

and watch as it heats.

■ Use a deep fat

thermometer whenever

possible to prevent

overheating fat beyond

the smoking point.

WARNING!

SURFACE COOKING UNITS

Operating Instructions

Installation Instructions Safety Information

Troubleshooting TipsCustomer Service

REMEMBER…

Your continued health and safety are important to us.

Please read and follow this Safety Information carefully.

We want you to remain a happy and healthy part of

our family.

SAVE THESE INSTRUCTIONS

Otros manuales para RB525

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Rango de Hotpoint

Hotpoint

Hotpoint RGB524PR Guía de instalación

Hotpoint

Hotpoint RGB744 Guía de instalación

Hotpoint

Hotpoint RGB518PCH Manual de servicio

Hotpoint

Hotpoint RGB790SEP Manual de usuario

Hotpoint

Hotpoint RA720 Instrucciones originales

Hotpoint

Hotpoint HDT67V9H2CB/UK Manual de usuario

Hotpoint

Hotpoint RGC657EH Instrucciones de instalación

Hotpoint

Hotpoint RGA520EW Manual de usuario

Hotpoint

Hotpoint RA720 Instrucciones de funcionamiento

Hotpoint

Hotpoint RB790SD Manual de usuario

Hotpoint

Hotpoint RB502S Manual de usuario

Hotpoint

Hotpoint CP97SEA/HA Manual de usuario

Hotpoint

Hotpoint RB790DT Manual de usuario

Hotpoint

Hotpoint RGB532BEAAD Manual de servicio

Hotpoint

Hotpoint RGB530DEP Manual de usuario

Hotpoint

Hotpoint RGB790CEKCC - 30 Inch Gas Range Manual de usuario

Hotpoint

Hotpoint RGB533DEPBB - 30.0 Range Manual de usuario

Hotpoint

Hotpoint RB632GJ Instrucciones de instalación

Hotpoint

Hotpoint H64IL9PAA S SK Manual de usuario

Hotpoint

Hotpoint FZ G /HA Manual de usuario

Hotpoint

Hotpoint RB787DPWW - Electric Range Manual de usuario

Hotpoint

Hotpoint RGB744GEJ Instrucciones de instalación

Hotpoint

Hotpoint RGB751GEL Manual de usuario

Hotpoint

Hotpoint RGBS200DMWW Manual

Manuales populares de Rango de otras marcas

Samsung

Samsung FCQ321HTUW Manual de usuario

Kenmore

Kenmore 790.45712 Manual de usuario

Wolf

Wolf CHR CHSSR Manual de usuario

Smeg

Smeg Built-in Microwave Oven Manual de instrucciones

Zanussi

Zanussi ZCG054G Manual de usuario

Whirlpool

Whirlpool 8575985-W Manual de lista de piezas

Frigidaire

Frigidaire 316000635 Manual de usuario

GE JCSS630 Manual de usuario

Samsung

Samsung NX58M9960P series Manual de usuario

Whirlpool

Whirlpool Roper FGP305KW3 Manual de usuario

Amana

Amana ART6610 SERIES Manual de usuario

Maytag

Maytag MERH770WB Manual de usuario

Fulgor Milano

Fulgor Milano SOFIA Manual de usuario

Premier

Premier EF-4358GH Manual de usuario

Kenmore

Kenmore 790.9010 Series Manual de usuario

KitchenAid

KitchenAid KESC300 Manual de usuario

Frigidaire

Frigidaire FFEF3012LS Guía del usuario

Diamond

Diamond G65/2F4T Manual de usuario
