Hotpoint RB525DDCC Guía del usuario

Dimensions (in inches)

Listed by

Underwriters

Laboratories

†Note: Check local codes for required breaker size.

Note: 30" Electric Ranges conform to U.L. requirements for

0" spacing from walls below countertops. Allow 1-1/2" spacing

from the side of the range to adjacent vertical walls above the

cooktop surface.

Receptacle Locations: Locally approved flexible service cord

or conduit must be used because terminals are not accessible

after range installation. See shaded area in drawing for location

of electrical outlet box. Recommended outlet locations allow

range to be installed directly against rear wall.

Installation Information: Before installing, consult installation

instructions packed with product for current dimensional data.

*Dimension from wall to front of closed oven door.

Dimension from wall to the front of closed oven

door handle is 28-1/2".

†The range may be placed with

0" clearance (flush) at the back

wall and side walls if the range

side trims extend beyond the

cabinet fronts at least 1/4".

Self-Clean models only

Amp Rating

240V 10.1

208V 8.0

Breaker Size

40 Amps†

All Hotpoint ranges are equipped

with an Anti-Tip device. The

installation of this device is an

important, required step in the

installation of the range.

RB525DD– Hotpoint®30" Free-Standing Electric Range

Specification Created 9/12

420419

Features and Benefits

• 5.0 cu. ft. oven capacity - Enough room to cook an entire meal at once

• Coil heating elements - Provide even heat and easy cleanup

• Porcelain upswept cooktop - Raised edges contain spills, while the surface is easy to

wipe clean

• Chrome drip bowls - Contain spills and remove for easy cleaning

• Two oven racks - Durable to securely hold any cookware

• Removable full-width storage drawer - Store cookware or kitchen accessories

• Element “on” indicator light - Know when an element is on

• Porcelain oven door - Scratch-resistant coating is easy to maintain

• Visor handle - Features a classic design and easy cleanability

• Standard clean oven - Smooth surface makes cleaning by hand easier

• Model RB525DDWW – White

• Model RB525DDBB – Black

• Model RB525DDCC – Bisque

RB525DD– Hotpoint®30" Free-Standing Electric Range

Specification Created 9/12

420419
