Honeywell FocusPRO 6000 Series Manual de usuario

Wireless Remote Control

For use with RedLINK™ devices

À utiliser avec les appareils RedLINK™

Para ser utilizado con dispositivos RedLINK™

69-2054EFS-05

Operating

Manual

Operating Manual

® U.S. Registered Trademark.

US Patent No. 6,595,430; 7,114,554; 7,274,972; 7,225,054; D520,386 and other patents pending.

Read and save these instructions.

Lea y conserve estas instrucciones

Veuillez lire et conserver ces instructions

M29985

Always press touchscreen buttons with your fingertip. Never

use sharp instruments, such as a pencil or pen.

Presione siempre los botones de la pantalla táctil con la punta

del dedo. Nunca utilice objetos con punta, como lápices o

bolígrafos.

Toujours appuyer sur l’écran tactile du bout du doigt. Ne jamais

utiliser d’objets pointus, comme la pointe d’un crayon ou d’un

stylo.

To clean the screen, lock the display and use a damp cloth.

Never use abrasive cleansers.

Para limpiar la pantalla, bloquéela y utilice un paño húmedo.

Nunca utilice limpiadores abrasivos.

Pour nettoyer l’écran, verrouiller l’affichage et utiliser un linge

humide. Ne jamais employer de nettoyants abrasifs.

Wireless Remote Control

1 69-2054EFS—05

Contents

How it works .....................................................................................................................2

Quick reference ...............................................................................................................4

System settings............................................................................................................... 5

Temperature control options (one thermostat) ................................................. 6

Temperature control options (multiple thermostats)...................................... 7

Temperature “hold”........................................................................................................ 8

Screen lock/unlock........................................................................................................9

Customizing features (setup menu).................................................................... 10

Battery replacement................................................................................................... 12

In case of difficulty ..................................................................................................... 13

Limited warranty.......................................................................................................... 14

Regulatory information............................................................................................. 43

Contents

Operating Manual

69-2054EFS—05 2

How it works

If you have one thermostat, you can

move the remote control around your

home (like a mobile thermostat) to make

sure the temperature is comfortable in

the room you’re using.

If you have multiple thermostats, you

can use the remote control to display

and adjust temperatures in each room

independently. (See next page.)

Wireles

remote

control

Thermostat

Optional

outdoor

air senso

M29986

Heating/cooling

equipment

Thermostat

Wireless Remote Control

3 69-2054EFS—05

About your new thermostatHow it works

If you have only one thermostat

Temperature is measured at thermostat

or remote control, as you choose. You

can move the remote control as needed,

so the room you are using maintains a

comfortable temperature (see page 6).

If you have multiple thermostats

Temperature is measured at each

thermostat. Press TOGGLE ZONE buttons

to choose which room to display and

adjust (see page 7).

SET TO

READ TEMP FROM…

78 78

THIS DEVICE

THERMOSTAT

M28884

SET TO

TOGGLE ZONE

77 78

BEDROOM

M28885

Operating Manual

69-2054EFS—05 4

HEAT

OUTDOOR

SET TO

READ TEMP FROM…

REPLACE

BATTERY

TOGGLE ZONE

OFFCOOL

8:03

THIS DEVICE

LIVINGROOM

THERMOSTAT

SCREEN

UNLOCKED

M28883

Quick reference to display screen

System setting

Current time (set at thermostat)

Inside temperature

Note: First press of screen only

turns on backlight.

Outside temperature

(appears only if outdoor

sensor is installed)

Outside humidity

(Press to display

for 5 seconds)

If “No Signal” appears here,

check to make sure there are

fresh batteries in the thermo-

stat, and HVAC power is on.

Screen

lock/unlock

Temperature

setting

Replace battery

warning

Temperature

sensor source

(appears if you

have only one

thermostat)

Zone control

(appears only if

you have more

than one ther-

mostat)

Wireless Remote Control

5 69-2054EFS—05

System settings

Press to select Press a SYSTEM button to select:

• Heat: Thermostat controls only the heating

system.

• Cool: Thermostat controls only the cooling

system.

• Off: Heating and cooling systems are off.

Press and hold HEAT or COOL for 3 seconds

to select Auto Changeover (thermostat

automatically selects heating or cooling

depending on the indoor temperature).

In Auto Changeover mode, you can press

HEAT or COOL to display or adjust the settings

for each system.

To exit Auto Changeover mode, press and

hold HEAT or COOL for 3 seconds.

Note: The Auto Changeover option

is available only if programmed by

the system installer.

Note: Emergency Heat can only be

set at the thermostat.

Press and hold either to select AUTO CHANGEOVER

HEAT

OFFCOOL

8:03

M28886

HEAT

OFFCOOL

8:03

AUTO

M28887

Operating Manual

69-2054EFS—05 6

OUTDOOR

SET TO

READ TEMP FROM…

THIS DEVICE

THERMOSTAT

M28888

Temperature control options (one thermostat)

Display shows temperature at

selected device

Press to choose temperature

measurement device

Note: This option will not appear if you have a

zone system (more than one thermostat). In zone

systems, temperature is always measured at the

thermostats.

Both the thermostat and the remote control

have built-in temperature sensors. Press

a button to choose whether the system

responds to temperatures at the thermostat,

or at the location of the remote control.

If you use the remote control to measure

temperature, keep it in an upright position

in an area with good air circulation. Do not

place it near sources of heat or cold air. Keep

away from air ducts, direct sunlight, appli-

ances and electronic devices.

Wireless Remote Control

7 69-2054EFS—05

OUTDOOR

SET TO

TOGGLE ZONE

LIVINGROOM

M28889

Temperature control options (multiple thermostats)

Display shows temperature in

selected zone

Press to select a thermostat zone

If you have a zone system (more than one

thermostat), you can display and adjust the

temperature in each zone from the remote

control.

Press the arrow buttons until the thermo-

stat zone you want is displayed. After a short

delay, the remote will retrieve information,

then display the current temperature in that

zone.

At the remote control you can change the fol-

lowing settings for each zone independently:

• Temperature

• System setting (heat/cool)

• Temporary hold

• Permanent hold

(Fan operation and program schedules can

be changed only at the thermostat.)

Operating Manual

69-2054EFS—05 8

M28891

HEAT

DONE

CANCEL

HOLD UNTIL

10:15

PERM. HOLD

M28890

OUTDOOR

SET TO

Temperature “hold” (programmable thermostats only)

1Press to adjust temperature

2Set temporary hold time

period OR press PERM. HOLD

Press sor tto adjust the temperature.

Temporary hold:

Press sor tto set the “Hold Until” time.

When the timer expires (or when you press

CANCEL), the temperature will revert to the

setting you’ve programmed at the thermo-

stat.

Permanent hold:

Press PERM. HOLD to maintain the new tem-

perature permanently. The temperature will

remain as you set it until you press CANCEL to

revert to the setting you’ve programmed at

the thermostat.

Note: If you have a zone system (more than one

thermostat), Hold will only apply to the zone

displayed at the bottom of the screen. Scroll to

another zone to change the temperature in that

zone (see page 7).
