Dolphin™ CT60

Quick Start Guide

CT60-A-EN-QS-02 Rev A

5/20

Out of the Box

Make sure that your shipping box contains these items:

• Dolphin CT60 mobile computer (Model CT60L0N or

CT60L1N)

• Rechargeable 3.85 VDC Li-ion battery

• Product documentation

If you ordered accessories for your mobile computer, verify that

they are also included with the order. Be sure to keep the original

packaging in case you need to return the mobile computer for

service.

Note: CT60L0N models do not include a WWAN radio.

Memory Card Specifications

Honeywell recommends the use of Single Level Cell (SLC)

industrial grade microSD™ or microSDHC™ memory cards with

Dolphin mobile computers for maximum performance and

durability. Contact a Honeywell sales representative for

additional information on qualified memory card options.

Mobile Computer Features

*Navigation Panel icons may vary depending on the unit type.

Scan Buttons

Microphone

Power

Button

Battery Status /

Notification LED

Good Read LED

Speaker

Touch Panel

Volume Buttons

Navigation Panel *

Note: Hand strap not shown.

Camera Lens

and Flash

Battery

Camera Button

Battery Latch

Imager

(LED / Laser Aperture)

SIM Card 1 Door

SIM Card 2 Door

(CT60L1N Model)

microSD Card

Door

Laser Safety

Label Location

I/O Connector

Speaker Port

Install a microSD Card (SD)

Note: Format the microSD card before initial use.

Note: Always power off the computer and remove the battery before

attempting to install or remove a card.

3 4

Install a microSIM Card (SIM 1)

Phone feature is available only on CT60L1N models.

On all models, when using a UICC card for NFC Secure Element

link encryption, install the card in SIM slot 1.

Note: Always power off the computer and remove the battery before

attempting to install or remove a card.

3 4

Install a Secondary microSIM Card (SIM 2)

Note: Feature available on CT60L1N Models only.

Note: Always power off the computer and remove the battery before

attempting to install or remove a card.

3 4

Install the Battery

The CT60 mobile computer ships with a Li-ion 3.85 VDC,

15.5 watt-hour battery manufactured for Honeywell

International Inc.

2 3

Charge the Mobile Computer

The CT60 mobile computer ships with a partially charged

battery. Charge the battery with a CT50 Series charging device

for a minimum of 4 hours. Using the computer while charging

the battery increases the time required to reach a full charge.

CT60 mobile computers are designed for use with the following

CT50 Series charging accessories: HomeBase, Ethernet

HomeBase, ChargeBase, NetBase, Quad Battery Charger,

Vehicle Power Adapter, Vehicle Dock, and USB Adapter.

Ensure all components are dry prior to placing the

battery in the computer. Mating wet components

may cause damage not covered by the warranty.

Assurez-vous que tous les composants sont secs

avant de placer la batterie dans l’ordinateur.

L’insertion de composants humides risque de

provoquer des dommages non couverts par la

garantie.

We recommend the use of Honeywell accessories and

power adapters. Use of any non-Honeywell

accessories or power adapters may cause damage not

covered by the warranty.

Mise en garde: Il est recommandé d'utiliser les

périphériques, les cordons d'alimentation et les

adaptateurs secteur conçus par Honeywell.

L'utilisation de tout périphérique, cordon

d'alimentation ou adaptateur secteur d'une autre

marque est susceptible de provoquer des dommages

non couverts par la garantie.

Ensure all components are dry prior to mating the

computers and batteries with peripheral devices.

Mating wet components may cause damage not

covered by the warranty.

Mise en garde: Assurez-vous que tous les composants

sont secs avant de connecter les terminaux/batteries

à des périphériques. L'insertion de composants

humides risque de provoquer des dommages non

couverts par la garantie.

We recommend use of Honeywell Li-ion battery

packs. Use of any non-Honeywell battery may result

in damage not covered by the warranty.

Nous recommandons l’utilisation de batteries Li-ion

de la marque Honeywell. L’utilisation d’une batterie

d’un autre fabricant est susceptible de provoquer des

dommages non couverts par la garantie.
