SL AT E ™

Limit Control Module

R8001L8001

INSTALLATION INSTRUCTIONS

Scan for more information

SLATE™LIMIT CONTROL MODULE 3

R8001L8001

Application

SLATE™ brings conﬁgurable safety and programmable logic

together into one single platform. The platform can easily be

customized for almost any requirement or application–offering

virtually limitless development opportunities with far less

complexity.

The R8001L8001 SLATE Limit Control Module is part of the

SLATE Combustions System. The SLATE Limit Control Module

provides the ability to bring in any type of analog signal and

create limits on either pressure or temperature without needing a

UDC Controller.

Features

• 12 limit blocks with each block monitoring any sensor or pair

of sensors

• One limit module for multiple burner controls

• 4 sensors available for Limit Block use (2 sets of redundant

safety inputs)

• Unused Analog Cells available for general purpose I/O

conﬁguration

• Redundant limit relay output

Speciﬁcations

Electrical Ratings:

See Table 3–Table 7.

Environmental Ratings

Ambient Temperature:

Operating: -20°F to +150°F (-29°C to +66°C).

Shipping: -40°F to +150°F (-40°C to +66°C).

Humidity: 95% continuous, noncondensing.

Vibration: 0.5G environment

Dimensions: See Fig. 1

Weight: 2 lb 1 oz (0.94 Kg)

432-00007—03

Approvals

Underwriters Laboratories Inc. Listed, File: MP268

IRI Acceptable

Federal Communications Commission: Part 15, Class A

Must be mounted inside a grounded metal enclosure.

Mounting

DIN Rail (See Fig. 2)

Required Components

R8001A1001 SLATE Base Controller

R8001S9001 SLATE Sub-Base Module

R8001B2001 SLATE Burner Control Module

Fig. 1.

M35382

4-19/32 (117)

7-3/32

(181)

2-11/16 (68)

Dimensions in in. (mm).

SLATE™LIMIT CONTROL MODULE 5

R8001L8001

LED Array

There are four LEDs on the front of the Limit Control Module

that provides quick identiﬁcation of the system status and any

problems that might occur. The status is broadcast to other

modules on the platform bus in case they are affected by the

inoperable modules.

The LEDs on the module are for the sensors, the inputs and

outputs, and for the Reference V.

Terminals 18 and 19 are the limit contacts.

Terminals 20 and 22 are reference voltage terminals to indicate to

the Limit Module what reference voltage it’s operating at.

LED Color Description

Power No light System does not have power

Green System has power

CPU Red No wire sheet or problem with the

wire sheet

Green Running

Fault Red Fault

No light Running

Table 1. LED Descriptions.

LED Display

The SLATE system modules have a seven-segment, three-

position LED display used for indicating the module number of

the SLATE system. The LED colors indicate the terminal state as

shown in Table 2.

Color Description

Green Terminal is on

Red Fault

No light Not in use

Table 2. Terminal LED Meanings.

632-00007—03

Select and Reset Buttons

The SLATE system modules have a Select and Reset buttons

located on the front of the module and beneath the segment

display. The Reset button is used to clear a lockout and reset the

module. The Select button is used to scroll through the segment

display information.

Installation

WARNING

Fire or Explosion Hazard

Can cause severe injury, death, or property damage.

Veriﬁcation of safety requirements must be performed

each time a control is installed on a burner to prevent

possible hazardous burner operation.

When Installing This Product

1. Read these instructions carefully. Failure to follow them could

damage the product or cause a hazardous condition.

2. Check the ratings given in the instructions and on the product

to make sure the product is suitable for your application.

3. After installation is complete, check out the product operation

as provided in these instructions.

4. The SLATE module must be mounted in an electrical

enclosure with adequate clearance for servicing, installation

and removal of modules.

SLATE™LIMIT CONTROL MODULE 7

R8001L8001

WARNING

Electrical Shock Hazard.

Can cause severe injury, death or equipment damage.

1. Disconnect the power supply before beginning installation to

prevent electrical shock and equipment damage. More than

one power supply disconnect can be involved.

Fig. 2.

M35383

Installing the Limit Control Module on the Sub-Base Module.

2. Wiring must comply with all applicable codes, ordinances and

regulations.

3. Wiring must comply with NEC Class 1 (Line Voltage) wiring.

832-00007—03

IMPORTANT

1. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance

with these instructions, may cause interference for radio

communications. It has been tested and found to comply

with the limits of a Class A computing device of part 15

of FCC rules, which are designed to provide reasonable

protection against such interference when operated in a

commercial environment. Operation of this equipment in a

residential area may cause interference; in which case, the

user, at their own expense, may be required to take whatever

measures are required to correct this interference.

2. This digital apparatus does not exceed the Class A limits for

radio noise, set out in the Radio Interfeence Regulations of

the Canadian Department of Communications.

3. For combination gas-oil burner applications, a double pole,

double throw (dpdt) fuel select switch is required.

4. Cable shield must be terminated to ground at both ends. If

shielded cable is NOT used, use three-wire twisted cable.

Wiring

WARNING

Electrical Shock Hazard.

Can cause severe injury, death, or equipment

damage.

Disconnect the power supply from the main disconnect

before beginning installation to prevent electrical shock

and equipment damage. More than one disconnect can

be required.

SLATE™LIMIT CONTROL MODULE 9

R8001L8001

Fig. 3.

M35285

LIMIT MODULE

4 SENSORS

12 LIMIT BLOCKS

2 DUAL LIMITS

SAFETY RELAY

UNIVERSAL

LOW VOLTAGE

CELL

BIAS

VREF+

FROM

POWER

LOADS

SAFETY

RELAY

LOAD

RELAY

UNIVERSAL

LOW VOLTAGE

CELL

UNIVERSAL

LOW VOLTAGE

CELL

UNIVERSAL

LOW VOLTAGE

CELL

VREF–

Wiring diagram for Limit Control Module.

10 32-00007—03

Terminal Description Rating

1Cell A (T1) See Table 4–7 for conguration options

2Cell A (T2) See Table 4–7 for conguration options

3Cell A (T3) See Table 4–7 for conguration options

4Cell A (T4) See Table 4–7 for conguration options

5Cell B (T5) See Table 4–7 for conguration options

6Cell B (T6) See Table 4–7 for conguration options

7Cell B (T7) See Table 4–7 for conguration options

8Cell B (T8) See Table 4–7 for conguration options

9Cell C (T9) See Table 4–7 for conguration options

10 Cell C (T10) See Table 4–7 for conguration options

11 Cell C (T11) See Table 4–7 for conguration options

12 Cell C (T12) See Table 4–7 for conguration options

13 Cell D (T13) See Table 4–7 for conguration options

14 Cell D (T14) See Table 4–7 for conguration options

15 Cell D (T15) See Table 4–7 for conguration options

16 Cell D (T16) See Table 4–7 for conguration options

17 Unused ---

18 Safety Relay

(dry contacts)

9.8 FLA, 58.8 LRA @ 120VAC,

4A (0.5 PF), 20A inrush @ 240VAC,

2A cont, 10A inrush @ 24VDC

19 Safety Relay

(dry contacts)

(see Terminal 18 above)

20 Vref+ 24VDC (0.1mA),

24VAC (0.1mA),

85-264VAC (0.2mA)

21 Unused ---

22 Vref- (see Terminal 20 above)

Table 3. Terminal Ratings.

Note: only one conguration option per cell is allowed for cells

congured as a Limit Block.
