Honeywell CS04XE Manual de usuario
Portable Evaporative Air Cooler
User Manual
Read and save these instructions before use
www.honeywellaircoolers.com
E-mail: info@honeywellaircoolers.com
POWER
SPEED
MODE
COOL
SWING
H
M
L
Model: CS04XE
1
PARTS DESCRIPTION
EN
1) Control Panel 6) Front Grill Screws
2) Louvers 7) Honeycomb Cooling Media
3) Front Grill 8) Mounting Holes
4) Water Fill Tray 9) Drain Plug
5) Water Level Indicator 10) Power Cord & Plug
POWER
SPEED
MODE
COOL
SWING
H
M
L
1
5
6
2
7
9
3
4
10
8
WARNING -- READ AND SAVE THE AIR COOLER SAFETY & MAINTENANCE GUIDE AND USER
MANUAL BEFORE USING THIS PRODUCT. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY
DAMAGE AND/ OR IMPAIR ITS OPERATION AND VOID THE WARRANTY. IN CASE THERE IS
ANY INCONSISTENCY OR CONFLICT BETWEEN THE ENGLISH VERSION AND ANY OTHER
LANGUAGE VERSION OF THE CONTENT OF THIS MATERIAL, THE ENGLISH VERSION SHALL
PREVAIL.
2
SPEED
POWER
MODE
COOL
SWING
H
M
L
USE & OPERATION
EN
CONTROL PANEL
POWER
Press the POWER button to turn the unit on. The cooler will start automatically at medium speed.
After a few seconds the speed will switch to low. To turn the unit off, press the button again.
SPEED
Press the SPEED button repeatedly to change the speed between H - M - L.
The indicator light will show the selected speed:
FUNCTION BUTTONS
MODE
Press the MODE button until the COOL indicator light is illuminated on the control panel. This
activates evaporative cooling. The water pump will operate and you will feel the cooler air after the
Honeycomb Cooling Media is completely wet. When the COOL indicator light is switched OFF, the
unit can still function in a fan only mode (without evaporative cooling).
High (H) Medium (M) Low (L)
SWING
Press the SWING button until the SWING indicator light is illuminated on
the control panel. The louvers will begin to move left to right automatically.
Vertical Air Flow - You can manually adjust the louvers to change vertical
air flow.
LOUVER
MOVEMENT
3
USE & OPERATION (CONTINUED)
EN
REMOTE CONTROL
POWER :
:
:
:
ON / OFF
Low / Medium / High
Evaporative cooling ON / OFF
Controls the motion of the louvers
SPEED
MODE
SWING
NOTE:
•
•
•
•
•
•
•
•
•
•
The remote control requires AAA (2 x 1.5V) batteries for replacement.
Open the battery compartment at the back of the remote control and insert the batteries inside.
Care must be taken to insert the batteries according to the corr ect polarity (+ / –) markings
shown inside the battery compartment.
Always point the remote control signal transmitter towards the unit when operating. Make sure
that the signal path is not obstructed.
Remove the batteries if the unit is not going to be used for an extended period of time.
Do not drop the remote control.
Do not mix different types of batteries such as alkaline, carbon-zinc, or rechargeable batteries.
Do not mix old and new batteries.
Do not recharge the battery.
Exhausted batteries are to be removed from the product and safely disposed of as per local
regulations.
Do not dispose of batteries in fire. Batteries may explode or leak.
WARNING: Caution for ingestion of the small battery. Keep away from children and animals.
4
CAUTION:
Unplug the unit from the electrical power outlet before emptying or refilling the water tank.
Open the Water Fill Door located on the front of the unit.
The Water Level Indicator is located at the front of the unit. Refill the
water tank when water level is low. Do not fill water above the "Max."
water level mark to avoid water droplets collecting on the louvers.
Check the water level in the tank before running the COOL function.
Make sure that the water in the tank is above the minimum water level
mark. Running the unit in COOL mode with inadequate water may
cause pump failure.
Note: The water capacity refers to the total volume of water that can be contained within the air
cooler water tank and water distribution system. The water capacity in the tank at the “Max.” indicator
level may be lower than the actual water capacity of the air cooler.
WARNING: Do not fill water tank with dirty water or salt water. This can damage the unit and Honeycomb
media.
USE & OPERATION (CONTINUED)
EN
COOLER LOCATION
FILLING WITH WATER
Make sure to position the air cooler correctly before you set up and start using the product. Do not
move the unit from one place to another while the Unit is turned on. Please refer to the COOLER
LOCATION section of the separate Safety & Maintenance Guide.
POWER
SPEED
COOL
SWING
H
M
L
Water Fill Door
5
Move the unit to a location where the water can be drained. Remove the cap from the Drain plug
located at the bottom of the unit. Allow the tank to empty.
Refill the water tank with clean water, up to the maximum level and drain it completely.
Use a damp cloth to remove the dirt and dust from the surface of the unit. Never use corrosive
elements or chemicals to clean this product.
When the product is not in use, store the unit in a dry place out of direct sunlight.
•
•
•
•
USE & OPERATION (CONTINUED)
EN
Below are instructions on how to clean and maintain your air cooler. If the cooler will not be used for
a long period of time, please refer to the STORAGE & MAINTENANCE GUIDELINES located in the
separate Safety & Maintenance Guide.
WARNING:
Before cleaning the unit, switch the unit OFF and disconnect from the electrical socket.
CLEANING & DRAINING THE WATER TANK
6
USE & OPERATION (CONTINUED)
EN
CLEANING THE HONEYCOMB COOLING MEDIA
The appliance is supplied with a Honeycomb Cooling Media.
The Honeycomb Cooling Media is located inside the Rear Grill. See Figure 1 for instructions on
how to remove them from the unit for cleaning and maintenance.
Do not run the unit in COOL mode with stale water in the tank. You must empty the water tank
and refill with fresh water, especially if the tank has not been cleaned in a long time.
The cleaning frequency for the Honeycomb media depends on local air and water conditions.
In areas where the mineral content of water is high, mineral deposits may build up on the
Honeycomb Cooling Media and restrict air flow. Draining the water tank and refilling with fresh
water at least once a week will help reduce mineral deposits. If mineral deposits remain on the
Honeycomb Cooling Media, the media should be removed and washed under fresh water. The
media should be cleaned every two months or sooner, depending on your needs.
For best results allow the Honeycomb Cooling Media to dry after each use by turning off the cool
function 15 minutes before turning the unit off.
•
•
•
•
•
Remove all the screws from the Front Grill of the
Air Cooler.
Push down on the Latches and pull the Front Grill
away from the cooler.
Carefully slide out the Horizontal Bar from the
cooler.
Carefully pull out the Honeycomb Cooling Pad.
Replace or clean media with water and a damp
cloth as needed.
1.
2.
3.
4.
5.
Removing the Honeycomb Cooling Media:
WARNING: DO NOT operate the Air Cooler when the
Front Grill or Honeycomb Cooling Media is removed
from the Air Cooler, or if there is a loose-fitting Front
Grill or Honeycomb Cooling Media. Doing so can
cause serious injury or dangerous electrical shock.
Figure 1:
Rear Grill
Honeycomb
Cooling Media
Horizontal Bar
Latches
JMATEK Limited
Manulife Financial Centre,
Kwun Tong, Hong Kong
Phone: 85225595522
Email: [email protected]
Web: www.jmatek.com
Made in China
© 2017 JMATEK Limited. All rights reserved.
The Honeywell Trademark is used under license
from Honeywell International Inc.
Honeywell International Inc. makes no
representations or warranties with respect to this product.
This product is manufactured by Airtek Int'l Corp. Ltd.
(subsidiary of JMATEK Ltd.).
