ENG-0034-T33, Rev. 003

TITLE DOCUMENT NUMBER REV

ADDENDUM, SERVICE MANUAL, UAWS

OPERATOR SHIELD INSTALLATION AW-17237 002

ARTWORK SIZE A SHEET 1 OF 1

REV AUTHORED BY DATE

S.SCHNEIDER 10/4/17

REV DRAFTED BY DATE

S.SCHNEIDER 10/4/17

PROPRIETARY INFORMATION:

The content of this document is the

exclusive property of Hologic and may

not, without prior written permission of

Hologic, be reproduced, copied or used

for any purpose whatsoever.

Artwork and Signature File for:

MAN-05397 "ADDENDUM, SERVICE MANUAL, UAWS OPERATOR SHIELD INSTALLATION"

Artwork consists of:

 Four (4) 8 ½ inch x11 inch sheet(s) attached.

Selenia Dimensions and 3Dimensions Systems

Addendum, Radiation Shield Installation

MAN-05397 Revision 002, October, 2017 Hologic, Inc. Page 1 of 4

36 Apple Ridge Road, Danbury, CT 06810 (800) 447-1856

This addendum modifies your Selenia®Dimensions®and 3Dimensions™Service Manuals

installation procedure for the longer radiation shield on the Universal Acquisition

Workstation (UAWS).

Place this addendum with your Service Manual for future reference.

1.1 Installation of Radiation Shield

Warning:

Use gloves and eye protection when handling the X-ray Shield.

Warning:

Do not handle or position the Radiation Shield alone. Two people are

required to handle and position the tempered glass shield to minimize stress

to the shield.

Caution:

The X-Ray Shield is made of tempered glass and is fragile. Use extreme care when

handling and installing the shield. When installing, the shield must be precisely

positioned and must not be flexed in any direction.

Caution:

Inspect the X-ray Shield before and after installation. Small imperfections embedded

in the glass are acceptable. Do not install the shield if cracks or chips are visible.

Caution:

Use care when cleaning the X-ray Shield to avoid excessive force and movement of

the shield.

Selenia Dimensions and 3Dimensions Systems

Addendum, Radiation Shield Installation

MAN-05397 Revision 002, October, 2017 Hologic, Inc. Page 2 of 4

36 Apple Ridge Road, Danbury, CT 06810 (800) 447-1856

New Installations

1. If not done already:

a. Power down the system and unplug the Acquisition Workstation.

b. Remove the front and rear covers of the Acquisition Workstation (see the

following figure).

c. Remove the side covers of the Acquisition Workstation (see the following figure).

Figure 1: Removing front, rear, and side covers

Selenia Dimensions and 3Dimensions Systems

Addendum, Radiation Shield Installation

MAN-05397 Revision 002, October, 2017 Hologic, Inc. Page 3 of 4

36 Apple Ridge Road, Danbury, CT 06810 (800) 447-1856

2. On the back of the workstation, remove the workstation shield bracket (item 6 in the

following figure, three screws on each side).

3. Insert the back spacer (item 1) and the back reinforcement plate (item 2).

4. Insert the shield (item 3). Two people are required for this action.

5. Insert the front reinforcement plate (item 4). Push at the bottom of the front

reinforcement plate (item 4) to ensure plate is vertical and an equal gap on either

side, then insert the front spacer (item 5).

Figure 2: Radiation shield installation

6. Install the shield bracket (item 6 in previous figure), hand tightening the screws in

the order shown (A through F) in the following figure. After hand tightening screws,

tighten 1/4 turn or enough to flatten the lock washer.

Figure 3: Shield bracket screw fastening

Selenia Dimensions and 3Dimensions Systems

Addendum, Radiation Shield Installation

MAN-05397 Revision 002, October, 2017 Hologic, Inc. Page 4 of 4

36 Apple Ridge Road, Danbury, CT 06810 (800) 447-1856

Existing Installations (Removal and Replacement)

1. If not done already:

a. Power down the system and unplug the Acquisition Workstation.

b. Remove the front and rear covers of the Acquisition Workstation (see figure

Removing front, rear, and side covers on page 2).

c. Remove the side covers of the Acquisition Workstation (see figure Removing

front, rear, and side covers on page 2).

2. Loosen the screws (items A - F in figure Shield bracket screw fasteningon page 3) and

remove the workstation shield bracket.

3. Remove the front spacer (item 5) and the front reinforcement plate (item 4) as shown

in figure Radiation shield installation on page 3. The items in steps 4 – 7 refer to this

same figure.

4. Carefully remove the current radiation shield (item 3). Two people are required for

this action.

5. (If necessary) Remove the back reinforcement plate (item 2) and the back spacer (item

1) and install replacements.

6. Lift the replacement shield (item 3) carefully and place in position in front of the back

reinforcement plate (item 2). Two people are required for this action.

7. Insert the front reinforcement plate (item 4). Push at the bottom of the front

reinforcement plate (item 4) to ensure plate is vertical and an equal gap on either

side, then insert the front spacer (item 5).

8. Install the shield bracket, hand tightening the screws in the order shown (A through

F in figure Shield bracket screw fastening on page 3). After hand tightening screws,

tighten 1/4 turn or enough to flatten the lock washer.
