HITACHI INVERTER

SERVICE MANUAL

(ADJUSTMENT AND MAINTENANCE)

Model:

European Version

SJ100-002NFE to SJ100-022NFE

SJ100-004HFE to SJ100-075HFE

US Version

SJ100-002NFU to SJ100-022NFU

SJ100-004HFU to SJ100-075HFU

SJ100-037LFU

Japanese Version

SJ100-002LFR to SJ100-037LFR

SJ100-004HFR to SJ100-075HFR

After reading this manual, keep it at hand for future reference

NBS585XA

Hitachi, Ltd.

Tokyo Japan

SJ100 SERIES

INDEX

1. Pre-operation Check

1-1. Check inverter model and Manufacturing number

1-2. Check inverter parameter and motor specification

2. Measurement of The Internal Voltage Supply

3. Trouble Shoot

3-1. Error messages - Possible Cause and Remedy

3-2. Analysis of Various Operating Problems That Do Not Trigger an Trip Message

3-3. How to Initialize the Data (FACTORY SETTING)

3-4. Error Message Comparison

3-5. Other Displays

3-6. Auto tuning under high incoming voltage

4. Ambient Condition of the Frequency Inverter (Temperature, Altitude)

4-1. Required Derating in case of 50deg., 55 deg. of Ambient Temperature

4-2. Required derating toward altitude

5. Level of Each Detection

5-1. DC Bus Voltage Detection Characteristics

5.2. Output Current Detection Characteristics

5.3. Motor Temperature Detection (PTC)

5.4. Over Temperature Detection of the Frequency Inverter

6. Measurement & Replacement of Subassemblies

6-1. Insulation Measurement

6-2. Power Components Measurements

7. Maintenance and Inspection Procedure

7-1. Precautions

7-2. Measurement of Mains Voltage, Current and Power

7-3. Maintenance of Parts

7-4. If you install replacement INV at site

8. Daily Inspection and Periodical Inspection

9. Image block diagram

10. Spare parts list

10-1. parts list

10-2. I/O board compatibility

10-3. O, OI terminal adjustment procedure (C81, C82)

10-4. kW setup procedure

10-5. I/O board schematic (circuit diagram)

1-1

1-2

2-1

3-1

3-7

3-8

3-9

3-10

4-1

4-4

5-1

5-3

5-4

6-1

7-1

7-4

8-1

9-1

10-1

10-13

10-14

10-15

10-16

‑i‑

Revisions

Revisionhistorytable

No. Revision contents Date of issue Manual No.

-ⅰⅰ-

1. Pre-Operation Check

Before starting adjustment and maintenance, be sure to check the following specifications of the inverter

and the motor.

1.1 Check Inverter model and Manufacturing number (MFG No).

NE16452-6

MADE IN JAPAN

Hitachi, Ltd.

HITACHI

Model : SJ100-015NFE

HP/kW : 2 / 1.5

Input/Entree: 16.0 A

1Ph

200-240V

50,60Hz 9.3 A

3Ph

200-240V

50,60Hz

Output/Sortie: 1-360Hz 7.1 A

3Ph

200-240V

MFG No. 78H T1129670060 Date: 9708

You can find these information from the specification label which attached at the side cover of the unit.

(1) Description of the model name.

(2) Description of MFG No.

Inverter model

MFG No.

T112967 0060H87 Unique number

Production code

Revision of the inverter

Production Month

(1 - 9, 0:October, J:November, K:December)

Production year

(The unit digit of the year of grace. 7:1997, 8:1998, 9:1999, 0:2000)

1-1

EF015 HSJ100 Version number

E: European version

U: US version

R: Japanese versionSeries name Structure type

F: With operator

Input voltage class

005

004

: 7.5kW

: 5.5kW

: 4.0kW

: 3.7kW

: 3.0kW

: 2.2kW

: 1.5kW

: 1.1kW

: 0.75kW

: 0.55kW

: 0.4kW

: 0.2kW002

Applicable motor kW

L: 3 phase 200V class

N: Single/3 phase 200V class

H: 3 phase 400V class

075

055

040

037

030

022

015

011

007

1.2 Check Inverter parameter and motor specification.

[1] Inverter specifications.

(1) Inverter specifications (Monitor mode)

Display Function name Category Screen display Initial Remarks

order Code display EU US JPN

1 Output frequency monitor Monitor d01 - - -

2 Output current monitor Monitor d02 - - -

3 Running direction monitor Monitor d03 - - -

4 Feedback data of PID

control monitor Monitor d04 - - -

5 Intelligent input terminal

condition monitor Monitor d05 - - -

6 Intelligent output terminal

condition monitor Monitor d06 - - -

7 Output frequency

converted value monitor Monitor d07 - - -

8 Trip monitor Monitor d08 - - -

9 Trip history monitor Monitor d09 - - -

(2) Inverter specifications (Basic function mode)

Display Function name Category Screen display Initial Remarks

Order Code display EU US JPN

1 Output frequency setting Set F01 0.0 0.0 0.0

2 Acceleration time 1 Set F02 10 10 10

- Acceleration time 1

(2nd setting) Set F202 10 10 10

3 Deceleration time 1 Set F03 10 10 10

- Deceleration time 1

(2nd setting) Set F203 10 10 10

4 Running direction setting Set F04 00 00 00

5 Extended function

A group setting Set A--

6 Extended function

B group setting Set B--

7 Extended function

C group setting Set C--

8 Extended function

H group setting Set H--

Note; “-“ means hidden display ;depends on 2nd setting selection.

(3) Inverter specifications (Extended function mode : A group)

Displa

yFunction name Category Screen display Initial Remarks

Order Code display EU US JPN

1 Frequency destination Set A01 01 01 00

2 Running command

destination Set A02 01 01 02

3 Base frequency Set A03 50 60 60

- Base frequency(2nd setting) Set A203 50 60 60

4 Maximum frequency Set A04 50 60 60

- Maximum frequency(2nd

setting) Set A204 50 60 60

5 External freq. setting start Set A11 000

6 External freq. setting end Set A12 000

7 External freq. setting start

rate Set A13 000

8 External freq. setting end

rate Set A14 100 100 100

9 External freq. start pattern Set A15 01 01 01

10 Time constant of the filter

of analog input Set A16 888

1-2

(3) Inverter specifications (Extended function mode : A group)

Display Function name Category Screen display Initial Remarks

Order Code display EU US JPN

11 Multi-speed 1 to 16 Set A20 - A35 0 0 Note 1

12 Jogging frequency Set A38 1.0 1.0 1.0

13 Stop mode of jogging Set A39 00 00 00

14 Torque boost mode Set A41 00 00 00

- Torque boost mode(2nd

setting) A241 00 00 00

15 Level of manual torque

boost Set A42 11 11 11

- Level of manual torque

boost (2nd setting) A242 11 11 11

16 Manual torque boost

frequency Set A43 10.0 10.0 10.0

- Manual torque boost

frequency (2nd setting) A243 10.0 10.0 10.0

17 V/f characteristics Set A44 00 00 00

- V/f characteristics(2nd

setting) A244 00 00 00

18 V-gain Set A45 100 100 100

19 Selection of DC braking Set A51 00 00 00

20 DC braking frequency Set A52 0.5 0.5 0.5

21 DC braking waiting time Set A53 0.0 0.0 0.0

22 DC braking force Set A54 000

23 DC braking time Set A55 0.0 0.0 0.0

24 Frequency upper limiter Set A61 0.0 0.0 0.0

25 Frequency lower limiter Set A62 0.0 0.0 0.0

26 Jump frequency 1-3 Set A63, A65, A67 0.0 0.0 0.0

27 Jump frequency width 1-3 Set A64, A66, A68 0.5 0.5 0.5

28 Selection of PID control Set A71 00 00 00

29 P gain Set A72 1.0 1.0 1.0

30 I gain Set A73 1.0 1.0 1.0

31 D gain Set A74 0.0 0.0 0.0

32 Scale conversion of

PID control Set A75 1.0 1.0 1.0

33 Feedback destination Set A76 00 00 00

34 Selection of AVR function Set A81 02 02 02

35 AVR voltage Set A82 230/400 230/460 200/400

36 Second acceleration time Set A92 15.0 15.0 15.0

- Second acceleration

time(2nd setting) A292 15.0 15.0 15.0

37 Second deceleration time Set A93 15.0 15.0 15.0

- Second deceleration

time(2nd setting) A293 15.0 15.0 15.0

38 Method to use 2nd

acceleration / deceleration

(Acc2 / Dec2)

Set A94 00 00 00

- Method to use 2nd

acceleration / deceleration

(Acc2 / Dec2)(2nd setting)

A294 00 00 00

39 Acc1 to Acc2 changing

frequency Set A95 0.0 0.0 0.0

- Acc1 to Acc2 changing

frequency(2nd setting) A295 0.0 0.0 0.0

40 Dec1 to Dec2 changing

frequency Set A96 0.0 0.0 0.0

- Dec1 to Dec2 changing

frequency(2nd setting) A296 0.0 0.0 0.0

41 Acceleration characteristic Set A97 00 00 00

42 Deceleration characteristic Set A98 00 00 00

Note 1; A20;0, A21;5, A22;10, A23;15,A24;20, A25;30, A26;40, A27;50, A28; 60,A29--A35;0

1-3

(4) Inverter specifications (Extended function mode : B group)

Display Function name Category Screen display Initial Remarks

Order Code display EU US JPN

1 Selection of restart mode Set B01 00 00 00

2 Allowable UV time Set B02 1.0 1.0 1.0

3 Retry waiting time Set B03 1.0 1.0 1.0

4 Electronic thermal level Set B12 note note note Rated current of

each inverter

- Electronic thermal level

(2nd setting) Set B212 note note note Rated current of

each inverter

5 Electronic thermal

characteristics Set B13 01 01 00

- Electronic thermal

characteristics (2nd setting) Set B213 01 01 00

6 Overload restriction

operation mode Set B21 01 01 01

7 Overload restriction level Set B22 note note note Rated current

* 1.25 for each

inverter

8 Deceleration rate while

overload restriction Set B23 1.0 1.0 1.0

9 Selection of software lock Set B31 01 01 01

10 Analog meter adjustment Set B81 80 80 80

11 Start frequency adjustment Set B82 0.5 0.5 0.5

12 Carrier frequency Set B83 5 5 12

13 Data initialization or

Trip history clear Set B84 00 00 00

14 Initialization mode Set B85 01 02 00

15 Frequency converting

value Set B86 1.0 1.0 1.0

16 STOP key condition Set B87 00 00 00

17 Restart mode after FRS

invalid Set B88 00 00 00

18 Monitor contents

for OPE-J Set B89 01 01 01

19 Dynamic braking usage

ratio Set B90 00 00 00

20 Stopping mode selection Set B91 00 00 00

21 Cooling fan control

selection Set B92 00 00 00

1-4

(5) Inverter specifications (Extended function mode : C group)

Display Function name Category Screen display Initial Remarks

Order Code display EU US JPN

1 Input terminal 1 assign Set C01 00 00 00

2 Input terminal 2 assign Set C02 01 01 01

3 Input terminal 3 assign Set C03 02 16 02

4 Input terminal 4 assign Set C04 03 13 03

5 Input terminal 5 assign Set C05 18 09 09

6 Input terminal 6 assign Set C06 09 18 18

7 Input terminal 1 condition Set C11 00 00 00

8 Input terminal 2 condition Set C12 00 00 00

9 Input terminal 3 condition Set C13 00 00 00

10 Input terminal 4 condition Set C14 00 01 00 Note 1

11 Input terminal 5 condition Set C15 00 00 00

12 Input terminal 6 condition Set C16 00 00 00

13 Output terminal 11 assign Set C21 01 01 01

14 Output terminal 12 assign Set C22 00 00 00

15 FM terminal condition set C23 00 00 00

16 Function of AL terminal

setting Set C24 05 05 05

17 Output terminal 11

condition Set C31 00 00 00

18 Output terminal 12

condition Set C32 00 00 00

19 AL output terminal

condition Set C33 01 01 01

20 Level of overload signal Set C41 note note note Rated current of

each inverter

21 Arrival frequency

while acceleration Set C42 0.0 0.0 0.0

22 Arrival frequency

while deceleration Set C43 0.0 0.0 0.0

23 Level of deviation signal

under PID control Set C44 3.0 3.0 3.0

24 Analog input O adjustment Set C81 -- -- --

25 Analog input OI adjustment Set C82 -- -- --

26 Debug mode selection Set C91 00 00 00

27 Core monitor address Set C92 0000 0000 0000

28 Core monitor data Set C93 -- -- --

29 Core set address Set C94 D0001 D000 D000

30 Core set data Set C95 -- -- --

Note 1

USP function (NC) is allocated on US version and even another function such as CF1 is set, NO/NC

parameter is still the same. Therefore, please make sure the NO/NC parameter to suit the application.

1-5

(6) Inverter specifications (Extended function mode : H group)

Display Function name Catego

ry Screen display Initial Remarks

Order Code display EU US JPN

1 Auto tuning setting Set H01 00 00 00

2 Motor data selection Set H02 00 00 00

- Motor data selection(2nd

setting) Set H202 00 00 00

3 Motor capacity setting Set H03 *3 *3 *3

- Motor capacity setting(2nd

setting) Set H203 *3 *3 *3

Motor poles setting H04 4 4 4

Motor poles setting(2nd setting) H204 4 4 4

4 Speed response setting Set H05 20 20 20

- Speed response setting(2nd

setting) Set H205 20 20 20

5 Motor stabilization constant

setting Set H06 100 100 100

- Motor stabilization constant

setting(2nd setting) Set H206 100 100 100

6 Motor constant R1 setting Set H20 *2 *2 *2

- Motor constant R1 setting(2nd

setting) set H220 *2 *2 *2

7 Motor constant R2 setting Set H21 *2 *2 *2

- Motor constant R2 setting(2nd

setting) Set H221 *2 *2 *2

8 Motor constant L setting Set H22 *2 *2 *2

- Motor constant L setting(2nd

setting) H220 *2 *2 *2

11 Motor constant Io setting H23 *2 *2 *2

- Motor constant Io setting(2nd

setting) H223 *2 *2 *2

12 Motor constant J setting H24 *2 *2 *2

- Motor constant J setting(2nd

setting) Set H224 *2 *2 *2

13 Motor constant R1(auto tuning

data) *1 H30 *2 *2 *2

- Motor constant R1(auto tuning

data,2nd setting *1 H230 *2 *2 *2

14 Motor constant R2(auto tuning

data) *1 H31 *2 *2 *2

- Motor constant R2(auto tuning

data,2nd setting *1 H231 *2 *2 *2

15 Motor constant L(auto tuning

data) *1 H32 *2 *2 *2

- Motor constant L(auto tuning

data,2nd setting *1 H232 *2 *2 *2

16 Motor constant Io(auto tuning

data) *1 H33 *2 *2 *2

- Motor constant Io(auto tuning

data,2nd setting *1 H233 *2 *2 *2

17 Motor constant J(auto tuning

data) *1 H34 *2 *2 *2

- Motor constant J(auto tuning

data,2nd setting *1 H234 *2 *2 *2

*1; don’t change the data

*2 ; factory set

*3 ; specified by the capacity of each inverter

1-6

[2] Motor specifications.

[3] Load conditions

Output voltage

Output

frequency

0Hz Hz

Motor MFG number

kWMotor output

pMotor poles

rpmMotor rated rpm

AmpsRated current

VRated voltage

HzRated frequency

AmpsStarting current

Equipment name

Torque characteristics

NmRequired torque

kgm2

Load inertia (J)

secAcceleration time

secDeceleration time

Hz to

Variable speed range

1-7/E

Otros manuales para SJ100 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Inversor de Hitachi

Hitachi

Hitachi HFC-VWS3D Series Manual de usuario

Hitachi

Hitachi NES1-OP Guía de instalación

Hitachi

Hitachi J100U2 SERIES Manual de usuario

Hitachi

Hitachi SJ-PB(T) Manual de usuario

Hitachi

Hitachi J100 E4 SERIES Manual de usuario

Hitachi

Hitachi HFC-VWS3 U SERIES, HFC-VWS3 H SERIES Manual de usuario

Hitachi

Hitachi WJ200 Series Software Manual de usuario

Hitachi

Hitachi L100 Series Manual de usuario

Hitachi

Hitachi WJ200-001SF Manual de usuario

Hitachi

Hitachi L300P-110L Manual de usuario

Hitachi

Hitachi AN060404-1 Instrucciones de instalación y funcionamiento

Hitachi

Hitachi WJ200 Series Software Manual de usuario

Hitachi

Hitachi SJ700 Series Software Manual de usuario

Hitachi

Hitachi SJ300-EL Series Guía de configuración

Hitachi

Hitachi SJ-DN2 Manual de usuario

Hitachi

Hitachi L100 Series Manual de servicio

Hitachi

Hitachi J300 Series Manual de usuario

Hitachi

Hitachi HFC-VWA2 SERIES Manual de usuario

Hitachi

Hitachi SJ700 Series Software Manual de usuario

Hitachi

Hitachi AN072803-1 Instrucciones de instalación y funcionamiento

Hitachi

Hitachi L100 Series Manual de usuario

Hitachi

Hitachi HFC-VWS3 U SERIES, HFC-VWS3 H SERIES Manual de usuario

Hitachi

Hitachi YUTAKI S COMBI Series Manual de usuario

Hitachi

Hitachi J300 Series Manual de usuario

Manuales populares de Inversor de otras marcas

Fourgroup

Fourgroup Easy Manual de usuario

Velleman

Velleman PI300M Manual de usuario

Sungrow

Sungrow SG350HX-US Manual de usuario

WilTec

WilTec 61897 Manual de usuario

SMA

SMA SUNNY BOY STORAGE 2.5 Manual de usuario

Simplicity

Simplicity LANDLORD 316 Manual de usuario

Santak

Santak SMAX 3000 Manual de usuario

ATON

ATON RA.Store-3 Manual de usuario

ZIEHL-ABEGG

ZIEHL-ABEGG FXET4AMQ Manual de usuario

Tektronix

Tektronix CFG250 Manual de usuario

Champion

Champion 200989 Manual de usuario

Vanner

Vanner 20-500 Series Manual de usuario

GE GEP Manual de usuario

Astrel Group

Astrel Group Power Reducer Guía rápida

MULTIQUIP

MULTIQUIP GDP-5H Guía

GoWISE

GoWISE PS1007 Manual de usuario

Promate

Promate PM13500D ES Manual de usuario

Mastervolt

Mastervolt WHISPER 3.5M3000 RPM Manual de usuario
