Hisense RF702N4IS1 Instrucciones de montaje

RF702N4 I S1

RF715N4AS1

Contents

Safety and warning information2

Installing your new appliance 8

Description of the appliance14

Display controls16

Using your appliance 18

Cleaning and care21

Helpful hints and tips22

Troubleshooting23

Disposal of the appliance25

Safety and warning information

For your safety and correct usage, before installing and first

using the appliance, read this user manual carefully, including

its hints and warnings. To avoid unnecessary mistakes and

accidents, it is important to make sure that all people using the

appliance are thoroughly familiar with its operation and safety

features. Save these instructions and be sure that they remain

with the appliance if it is moved or sold, so that anyone using it

throughout its life, will be properly informed on its usage and

safety notices.

For the safety of life and property, keep the precautions of

these user's instructions as the manufacturer is not

responsible for damages caused by omission.

Safety for children and others who are ulnerable people

According to EN standard

This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children

without supervision.

According to IEC standard

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

Keep all packaging away from children as there is risk of

suffocation.

If you are discarding the appliance, pull the plug out of the

socket, cut the connection cable (as close to the appliance as

you can) and remove the door to prevent children playing

from suffering an electric shock or from closing themselves

inside it.

If this appliance, featuring a magnetic door seals, is to replace

an older appliance having a spring lock (latch) on the door or

lid, be sure to make the spring lock unusable before you

discard the old appliance. This will prevent it from becoming a

death trap for a child.

General safety

WARNING —This appliance is intended to be used in

household and similar applications such as

-staff kitchen areas in shops, offices and other working

environments;

-farm houses and by clients in hotels, motels and other

residential type environments;

-bed and breakfast type environments;

-catering and similar non-retail applications.

WARNING —Connect to potable water supply only.

WARNING — Do not store explosive substances such as

aerosol cans with a flammable propellant in this appliance.

WARNING — If the supply cord is damaged, it must be

replaced by the manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard.

WARNING — Keep ventilation openings, in the appliance

enclosure or in the built-in structure, clear of obstruction.

WARNING — Do not use mechanical devices or other means

to accelerate the defrosting process, other than those

recommended by the manufacturer.

WARNING — Do not damage the refrigerant circuit.

WARNING — Do not use electrical appliances inside the food

storage compartments of the appliance, unless they are of the

type recommended by the manufacturer.

WARNING — The refrigerant and insulation blowing gas are

flammable. When disposing of the appliance, do so only at an

authorized waste disposal centre. Do not expose to flame.

WARNING —When positioning the appliance, ensure the

supply cord is not trapped or damaged.

WARNING —Do not locate multiple portable socket-outlets

Replacing the LED

WARNING—The LED light must not be replaced by the user!

If the LED light is damaged, contact the customer helpline for

assistance.

Refrigerant

The refrigerant isobutene (R6 a) is contained within the

refrigerant circuit of the appliance, a natural gas with a high

level of environmental compatibility, which is nevertheless

flammable. During transportation and installation of the

appliance, ensure that none of the components of the

refrigerant circuit becomes damaged.

The refrigerant (R6 a) is flammable.

WARNING — Refrigerators contain refrigerant and gases in

the insulation. Refrigerant and gases must be disposed of

professionally as they may cause eye injuries or ignition.

Ensure that tubing of the refrigerant circuit is not damage prior

to proper disposal.

Caution: risk of fire /flammable materials

If the refrigerant circuit should be damaged:

-Avoid opening flames and sources of ignition.

-Thoroughly ventilate the room in which the appliance is

situated.

It is dangerous to alter the specifications or modify this product

in any way.

Any damage to the cord may cause a shortcircuit, fire, and/or

electric shock.

Electrical safety

1. The power cord must not be lengthened.

2. Make sure that the power plug is not crushed or damaged. A

crushed or damaged power plug may overheat and cause a

fire.

3. Make sure that you can access the main plug of the

appliance.

4. Do not pull the main cable.

5. If the power plug socket is loose, do not insert the power

plug. There is a risk of electric shock or fire.

6. You must not operate the appliance without the interior

lighting lamp cover.

7. The fridge is only applied with power supply of single phase

alternating current of 22 ~24 V/5 Hz. If fluctuation of voltage

in the district of user is so large that the voltage exceeds the

above scope, for safety sake, be sure to apply A.C. Automatic

voltage regulator of more than 35 W to the fridge. The fridge

must employ a special power socket instead of common one

with other electric appliances. Its plug must match the socket

with ground wire.

Daily use

Do not store flammable gass or liquids in the appliance.

There is a risk of an explosion.

Do not operate any electrical appliances in the appliance

(e.g.electric ice cream makers, mixers etc.).

When unplugging always pull the plug from the mains socket,

do not pull on the cable.

Do not place hot items near the plastic components of this

appliance.

Do not place food products directly against the air outlet on

the rear wall.

Store pre-packed frozen food in accordance with the frozen

food manufacture’s instructions.

The appliances manufactures storage recommendations

should be strictly adhered to. Refer to relrelevant instructions

for storage.

Do not place carbonated or fizzy drinks in the freeze

compartment as it creates pressure on the container, which

may cause it to explode, resulting in damage to the appliance.

Frozen food can cause frost burns if consumed straight from

the freezer compartment.

Do not place the appliance in direct sunlight.

Keep buring candles, lamps and other items with naked

flames away from the appliance so that do not set the

appliance on fire.

The appliance is intended for keeping food stuff and/or

beverages in normal household as explained in this

instruction booklet The appliance is heavy. Care should be

taken when moving it.

Do not remove nor touch items from the freezer compartment

if your hands are damp/wet, as this could cause skin

abrasions or frost/freezer burns.

Never use the base, drawers, doors etc. to stand on or as

supports.

Frozen food must not be refrozen once it has been thawed

out.

Do not consume ice popsicles or ice cubes straight from the

freezer as this can cause freezer burn to the mouth

and lips.

To avoid items falling and causing injury or damage to the

appliance, do not overload the door racks or put too much

food in the crisper drawers.

caution!

Care and cleaning

This refrigerating appliance is not intended to be

used as a built-in appliance.



Before maintenance, switch off the appliance and disconnect

the mains plug from the mains socket.

Do not clean the appliance with metal objects, steam cleaner,

ethereal oils, organic solvents or abrasive cleansers.

Do not use sharp objects to remove frost from the appliance.

Use a plastic scraper.

Installation Important!

For electrical connection carefully, follow the instructions

given in this manual.

Unpack the appliance and check if there are damages on it.

Do not connect the appliance if it is damaged. Report possible

damages immediately to the place you bought it. In this case

retain packing.

It is advisable to wait at least four hours before connecting the

appliance to allow the oil to flow back in the compressor.

Adequate air circulation should be around the appliance,

lacking this leads to overheating. To achieve sufficient

ventilation, follow the instructions relevant to installation.

Wherever possible the back of the product should not be too

close to a wall to avoid touching or catching warm parts

(compressor, condenser) to prevent the risk of a fire, follow

the instructions relevant to installation.

The appliance must not be located close to radiators or

cookers.

Make sure that the mains plug is accessible after the

installation of the appliance.

Ser ice

Any electrical work required to do the servicing of the

appliance should be carried out by qualified electrician or

competent person.

This product must be serviced by an authorized Service

Center, and only genuine spare parts must be used.

1) If the appliance is Frost Free.

2) If the appliance contains freezer compartment

Installing your new appliance

Before using the appliance for the first

time, you should be informed of the

following tips.

Warning!

For proper installation, this refrigerator

must be placed on a level surface of hard

material that is the same height as the rest

of the flooring. This surface should be

strong enough to support a fully loaded

refrigerator.

The rollers, which are not castors, should

be only used for forward or backward

movement. Moving the refrigerator

sideways may damage your floor and the

rollers.

Ventilation of appliance

Install the appliance in a plane

and stable surface. Assure

good ventilation.

We recommend letting a space at least:

- 5 -7 mm from the back to the wall

- 1 mm from the top to the wall

- 1 mm from its side to the wall

Enough space must be provided in the

front of the appliance to allow the doors to

open as shown in follow diagrams.

Note:



Climate class Ambient temperature

SN +1 °C to +32°C

N +16°C to +32°C

ST +16°C to +38°C

T +16°C to +43°C



Stand your appliance in a dry place to

avoid high moisture.



Keep the appliance out of direct sunlight,

rain or frost. Stand the appliance away

from heat sources such as stoves, fires or

heaters.

Le eling of appliance

For sufficient leveling and air circulating

in the lower rear section of the appliance,

This appliance performs well from N to ST.

The appliance may not work properly if it is left for

a longer period at a temperature above or below

the indicated range.

the bottom feet may need to be adjusted.

You can adjust them manually by hand or

by using a suitable spanner.

To allow the doors to self-close, tilt the

top backwards by 1 -15 mm.

Whenever you want to move the

appliance, remember to turn the feet back

up, so that the appliance can roll freely.

Reinstall the appliance when relocating.

Doors remo al

In case when your access door is too

narrow for the refrigerator to pass through,

remove the refrigerator door and drawers.

Then pass the refrigerator laterally. If you

do not need to remove the appliance

doors, go to ‘Installing the water lines’ on

page 11.If you need to remove the doors,

continue below.

Warning!

When reversing the door, the appliance

must be unplugged.

The tools you will need (Not pro ided):

Allen Wrench(4mm)

Wrench(8mm)

Philips screwdriver

Disassembling the fridge door

Some models may be slightly different

from pictures. If some parts shown in the

picture cannot found in your appliance,

please ignore the relevant description.

1. With the door closed, remove the 3

screws holding the top cover (A) with

Philips (+) screwdriver, and then remove

the top cover carefully with the

entire-harnesses unattached.

2.Take out connectors and the water

coupler from the installation clip.

Remove the two wire connectors (press

the top of the connector (B) and separate

it from the other one) on the left side

door .To remove the water coupler from

the hinge, twist and pull the clips from the

coupler then remove the water line (C)

while pressing the movable part (D) of the

water line coupler.

3. Remove the 3 screws (B) fixed on the

hinges with a Wrench (8mm) and 1 ground

screws (C) attached to the hinge with

Philips (+) screwdriver. Remove the upper

left and right door hinges (D).

4. Use your both hands to open the door

more than 9

. Lift it up and take it off.

（

Be careful of racks while remove the

door.

）

5. Remove the 4 hex head bolts (E) with

an Allen wrench (4 mm). Remove the 2

screws with screwdriver. Then remove the

lower left and right door hinges (F).

Re-attaching the fridge doors

To reattach the fridge doors after you have

moved the appliance to its final location,

assemble the parts in reverse order.

1. To prevent water leaks, the water line

should be fully inserted into the center of

the coupler until the guide lines are

coincided exactly with the head of the

movable part.

Note

：

：：

：

Arrow on the water line coupler point to

the direction of the door.

2. Make sure the clips are properly

connected to the coupler.

Caution!

In case the fridge doors can’t be

self-closed, please make sure the door

opened more than 9

when you remove

or re-attaching the fridge doors.

Disassembling the freezer door

1. Pull out the freezer door and the upper

freezer drawer (A) to the final position.

Then take out the ice box (B) by lifting it up

in the direction of the arrow.

Otros manuales para RF702N4IS1

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Refrigerador de Hisense

Hisense

Hisense H720FSB-WD Instrucciones de montaje

Hisense

Hisense H420BMEI-WD Instrucciones de montaje

Hisense

Hisense RS694N4TC2 Instrucciones de montaje

Hisense

Hisense RQ758N4SAI1 Instrucciones de montaje

Hisense

Hisense BCD-203WYA/HC4 Instrucciones de montaje

Hisense

Hisense HRVF240 Instrucciones de montaje

Hisense

Hisense RT33D6AAE Manual de usuario

Hisense

Hisense RF749N4WFF Instrucciones de montaje

Hisense

Hisense RQ758N4SWSE Instrucciones de montaje

Hisense

Hisense RD-39DR4SAA/CPA1 Manual de usuario

Hisense

Hisense RB390N4BFC Instrucciones de montaje

Hisense

Hisense RF702N4IS1 Instrucciones de montaje

Hisense

Hisense BCD-543WPAZR/HC1(E) Manual de usuario

Hisense

Hisense RF489N4BC1 Instrucciones de montaje

Hisense

Hisense RF540N4WI1 Instrucciones de montaje

Hisense

Hisense RF632N4WFF Instrucciones de montaje

Hisense

Hisense RR197D4AGN Instrucciones de montaje

Hisense

Hisense RF225A3CSE Instrucciones de montaje

Hisense

Hisense RR130DAGS Instrucciones de montaje

Hisense

Hisense RM-53WC1SHAUVE -001 Manual de usuario

Hisense

Hisense HRCD609B Instrucciones de montaje

Hisense

Hisense RQ768N4ABU Instrucciones de montaje

Hisense

Hisense HRFD560SW Instrucciones de montaje

Hisense

Hisense RD-60WC1STA/USE-002 Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
