RL170D4BC2

Safety for children and others

who are vulnerable people

For your safety and correct

usage, before installing and

first using the appliance, read

this user manual carefully,

including its hints and

warnings. To avoid

unnecessary mistakes and

accidents, it is important to

make sure that all people

using the appliance are

thoroughly familiar with its

operation and safety

features. Save these

instructions and be sure that

they remain with the

appliance if it is moved or

sold, so that anyone using it

throughout its life, will be

properly informed on its

usage and safety notices.

For the safety of life and

property, keep the

precautions of these user's

instructions as the

manufacturer is not

responsible for damages

caused by omission.

This appliance can be used

by children aged from 8 years

and above and persons with

reduced physical, sensory or

mental capabilities or lack of

experience and knowledge if

they have been given

supervision or instruction

concerning use of the

appliance in a safe way and

understand the hazards

involved. Children shall not

play with the appliance.

Cleaning and user

maintenance shall not be

made by children without

supervision.

Keep all packaging away

and 2014/30/EU and 2009/125/EC and EC.643/2009 and 2002/96/EC

This appliance is in accordance with the following EU guidelines: 2014/35/EU

Safety and warning information........2

Description of the appliance ............7

Control panel....................................7

First use an installation.....................8

Daily use...........................................10

Helpful hints and tips........................11

Cleaning and care............................12

What to do if... .................................13

Reversing the door...........................14

Installing the door handle.................15

Disposal of the appliance.................16

from children as there is risk

of suffocation.

If you are discarding the

appliance, pull the plug out of

the socket, cut the

connection cable (as close to

the appliance as you can)

and remove the door to

prevent children playing from

suffering an electric shock or

from closing themselves

inside it.

If this appliance, featuring a

magnetic door seals, is to

replace an older appliance

having a spring lock (latch)

on the door or lid, be sure to

make the spring lock

unusable before you discard

the old appliance. This will

prevent it from becoming a

death trap for a child

General safety

This

appliance is intended

WARNING —

to be used in

and similar applications

such as

household

-staff kitchen areas in

shops, offices and other

working environments;

-farm houses and by clients

in hotels, motels and other

residential type

environments;

-bed and breakfast type

environments;

-catering and similar non-

retail applications

WARNING — Do not store

explosive substances such

as aerosol cans with a

flammable propellant in

this appliance.

WARNING — If the supply

cord is damaged, it must be

replaced by the

manufacturer, its service

agent or similarly qualified

persons in order to avoid a

hazard.

WARNING — Keep

ventilation openings, in the

appliance enclosure or in

the built-in structure, clear

of obstruction.

WARNING — Do not use

mechanical devices or

other means to accelerate

the defrosting process,

other than those

recommended by the

manufacturer.

WARNING — Do not

damage the refrigerant

circuit.

WARNING — Do not use

electrical appliances inside

the food storage

compartments of the

appliance, unless they are

of the type recommended

by the manufacturer.

WARNING — The

refrigerant and insulation

be lengthened.

2. Make sure that the power

plug is not or

damaged. A or

damaged power plug may

overheat and cause a fire.

3. Make sure that you can

plug of the

appliance.

4. Do not pull the main

cable.

5. If the power plug socket

is loose, do not insert the

power plug. There is a risk

of electric shock or fire.

6.You must not operate

theappliance without the

interior lighting lamp cover.

7.The fridge is only applied

with power supply of single

phase alternating current of

220~240V/50Hz. If

fluctuation of voltage in the

district of user is so large

that the voltage exceeds the

above scope, for safety

sake, be sure to apply A.C.

Automatic voltage regulator

of more than 350W to the

fridge. The fridge must

employ a special power

The power cord must not

crushed

access the main

Electrical safety

blowing gas are

flammable. When

disposing of the appliance,

do so only at an authorized

waste disposal centre. Do

not expose to flame.

The refrigerant isobutene

(R600a) is contained within

the refrigerant circuit of the

appliance, a natural gas

with a high level of

environmental

compatibility, which is

nevertheless flammable.

During transportation and

installation of the

appliance, ensure that

none of the components of

the refrigerant circuit

becomes damaged.

The refrigerant (R600a) is

flammable.

Refrigerant

If the refrigerant circuit

should be damaged:

-Avoid opening flames and

sources of ignition.

-Thoroughly ventilate the

room in which the

appliance is situated.

It is dangerous to alter the

specifications or modify

this product in any way.

Any damage to the cord

may cause a shortcircuit,

Caution:risk of fire

fire, and/or electric shock.

Do not store flammable

gass or liquids in the

appliance,There is a risk

of an explosion.

Do not operate any

electrical appliances

inthe

appliance(e.g.electric ice

cream makers,mixers

etc.).

When unplugging always

pull the plug from the

mains socket,do not pull

on the cable.

Do not place hot items

near the plastic

components of this

appliance.

Store pre-packed frozen

food in accordance with

the frozen food

manufacture’s

instructions.

The appliances

manufactures storage

recommendations should

be strictly adhered

to.Refer to relrelevant

instructions for storage.

Daily use

Frozen food can cause

frost burns if consumed

straight from the freezer

compartment.

Do not place the appliance

in direct sunlight.

Keep buring candles,lamps

and other items with naked

flames away from the

appliance so that do not set

the appliance on fire.

The appliance is intended

for keeping food stuff

and/or beverages in

normal household as

explained in this

instruction booklet.

The appliance is

heavy.Care should be

taken when moving it.

Do not remove nor touch

items from the freezer

comartment if your hands

are damp/wet,as this could

cause skin abrasions or

frost/freezer burns.

Never use the base,

drawers, doors etc. to

stand on or as supports.

To avoid items falling and

causing injury or damage

to the appliance, do not

overload the door racks or

put too much food in the

crisper drawers.

socket instead of common

one with other electric

appliances. Its plug must

match the socket with ground

wire.

For electrical connection

carefully, follow the

instructions given in this

manual.

Unpack the appliance and

check if there are damages

on it. Do not connect the

appliance if it is damaged.

Report possible damages

immediately to the place you

bought it. In this case retain

packing.

It is advisable to wait at least

four hours before connecting

the appliance to allow the oil

to flow back in the

compressor.

Adequate air circulation

should be around the

appliance, lacking this leads

to overheating. To achieve

Do not clean the appliance

with metal objects, steam

cleaner, ethereal oils, organic

solvents or abrasive

cleansers.

Do not use sharp objects to

remove frost from the

appliance. Use a plastic

scraper.

Installation Important!

caution!

Care and cleaning

Before maintenance, switch

off the appliance and

disconnect the mains plug

from the mains socket.

sufficient ventilation, follow

the instructions relevant to

installation.

Wherever possible the back

of the product should not be

too close to a wall to avoid

touching or catching warm

parts (compressor,

condenser) to prevent the

risk of a fire, follow the

instructions relevant to

installation.

The appliance must not be

locate close to radiators or

cookers.

Service

Any electrical work required

to do the servicing of the

appliance should be carried

out by qualified electrician or

competent person.

This product must be

serviced by an authorized

Service Center, and only

genuine spare parts must be

used.

Make sure that the mains

plug is accessible after the

installation of the appliance.

1)If the appliance is Frost

Free.

2)If the appliance contains

freezer compartment.

Description of the appliance

1. decorative board(some models have)

2. Storage shelf

3. Bulb & temperature regulator

4. Crisper cover

5. Crisper

6. Adjustable feet

7. Egg tray

8. Door handle(some models have)

9. Upper door rack

10. Door

11. Lower door rack

View of the appliance

Control panel

Note: Due to continual modification of our products, your refrigerator may be slightly different

from this instruction Manual, but its functions and usage methods remain the same.

Starting up and temperature regulation

Insert the plug of the connection lead into

the plug socket with a protective grounding

contact. When the refrigerator compartment

door is opened, the internal lighting is

switched on.

The temperature selector knob is located on

the left side of the refrigerator compartment.

Setting “0” means

off.

Turning in a clockwise direction the

refrigeration unit turns on, it will then operate

automatically.

Setting “1” means

Highest temperature, warmest setting.

Setting “7” (end-stop) means

Lowest temperature, coldest setting.

Important!

Important! High ambient temperatures (e.g.

on hot summer days) and a cold setting

(position 6 to 7) may cause the compressor

to run continuously or even non-stop!

Reason: When the ambient temperature is

high, the compressor must run continuously

to maintain the low temperature in the

appliance.

Changing the light bulb

Warning!

Before changing the light bulb,

switch off the appliance and unplug it, or pull

the fuse or the circuit breaker.

If the light bulb can’t work, please contact

your specialist dealer or your local

Customer Service Center to change it.

Thermostat knob

Bulb(inside)

Lampshade

First use an installation

lo wer base cover

Maximum performance and safety are

guaranteed by maintaining the correct

indoor temperature for the class of unit

concerned, as specified on the rating plate.

This appliance performs well from N to T.

The appliance may not work properly if it is

left for a longer period at a temperature

above or below the indicated range.

Important! It is necessary to have good

ventilation around the fridge to allow for the

dissipation of heat.For this reason,sufficient

clear space should be available around the

appliance. It is advisable for there to be

75mm separating the back of the fridge to

the wall at least 100mm of space on its two

sides and a clear space in front to allow the

doors to open 160°.

Appliances must not be exposed to rain.

Sufficient air must be allowed to circulate

in the low rear section of the appliance, as

poor air circulation can affect performance.

Built-in appliances should be positioned

away from heat sources such as heaters

and direct sunlight.

screw provided in a plastic bag with your

appliance, you can install these

accessories according to the following

procedure.

Note:

There is no need to install these

accessories under normal usage.

Only under the extreme circumstances,

cabinet empty while load on door with total

mass of 15 kg and opening the door about

90 degree ,this refrigerator may take risk

of tipping. Then rubber supporting pad

should be fastened to the lower base

cover to steady this appliance.

Installing the rubber supporting

Before using the appliance for the first

time, wash the interior and all internal

accessories with lukewarm water and

meutral soap in order to remove the

typical smell of a brand new product, then

dry thoroughly.

Installation Positioning

Warning! Before installing, read the

instruction carefully for your safety

and the correct operation of appliance.

Position the appliance away from sources

of heat such as stoves, radiators, direct

sunlight, etc.

Cleaning before use

1.Tilt appliance to find screw hole on the

left of lower base cover.

cro ss

sc rewdr awe r

rubber supporting pad

scr ew

First use an installation

2.Put screw into the hole of rubber

supporting pad.

3.Make screw in alignment with the hole on

lower base cover . Fasten rubber supporting

pad to the base cover firmly by a cross

screw driver (self-provided).

The appliance should be level in order to

eliminate vibration. To make the appliance

level, it should be upright and both

adjusters should be in stable contact with

the floor. You can also adjust the level by

unscrewing the appropriate level

adjustment in the front (use your fingers or

a suitable spanner).

Leveling

Caution! Any electrical work required to

install this appliance should be carried out by

qualified or authorized personnel.

Warning! This appliance must be grounded.

The manufacturer declines any liability should

these safety measures not be observed.

Electrical connection

Installation door rack

invard-pressing

Crisper

For storing fruit and vegetables.

Refrigerator compartment 2)

For storing the food that does not need to

be frozen and different sections suitable

for different kinds of food.

1) If the appliance contains related accessories

and functions.

2) If the appliance contains a freezer compartment.

Daily use

Accessories 1)

Various glass, plastic storage shelves or

wire trays are included with your appliance

different models have different

combinations and different models have

different features.

The walls of the refrigerator are equipped

with a series of runner so that the shelves

can be positioned as desired.

Movable shelves/trays

Remove door rack

Hold the left side of the door rack, inward-

press the other side and lift this side until it

separated from the liner. Then you can take

out the door rack from the liner.

First, install the left of the door rack.

Second, inward-press the other side and

downward-press this side until installation

it.

Tabla de contenidos

Otros manuales de Refrigerador de Hisense

Hisense

Hisense RQ515N4AB1 Instrucciones de montaje

Hisense

Hisense RS-47WL Manual de usuario

Hisense

Hisense RIB291F4AWF Instrucciones de montaje

Hisense

Hisense H720FSB-WD Instrucciones de montaje

Hisense

Hisense FV306N4CW2 Instrucciones de montaje

Hisense

Hisense RR106D4CBF Instrucciones de montaje

Hisense

Hisense RF697N4ZS1 Instrucciones de montaje

Hisense

Hisense RB372N4ADE Instrucciones de montaje

Hisense

Hisense HR6TFF600SD Instrucciones de montaje

Hisense

Hisense RF632N4WFF Instrucciones de montaje

Hisense

Hisense RM672N4AJ1 Instrucciones de montaje

Hisense

Hisense RS700N4AWBUI Instrucciones de montaje

Hisense

Hisense RIB291F4AW1 Instrucciones de montaje

Hisense

Hisense RS-34WC4SIA Instrucciones de montaje

Hisense

Hisense RB403N4EW1 Instrucciones de operación

Hisense

Hisense H370BMI-WD Instrucciones de montaje

Hisense

Hisense FMN530WFI Instrucciones de montaje

Hisense

Hisense RT600N4WC2 Instrucciones de montaje

Hisense

Hisense H310US Instrucciones de montaje

Hisense

Hisense HRCD585BW Instrucciones de montaje

Hisense

Hisense RB292F4WB1 Instrucciones de operación

Hisense

Hisense RS818N4ICE Instrucciones de montaje

Hisense

Hisense RS723N4WCU Instrucciones de montaje

Hisense

Hisense RB403N4EW1 Instrucciones de montaje

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
