Hisense RT286N4ABN Instrucciones de montaje

RT276N4ABN

RT286N4ABN

Contents

Safety and warning information...........2

Installing your new appliance...............8

Description of the appliance.............10

Control panel...................................11

Using your appliance.........................12

Cleaning and care..............................13

Helpful hints and tips.........................15

Troubleshooting...............................16

Disposal of the appliance...................18

Safety and warning information

For your safety and correct usage, before installing and

first using the appliance,read this user manual carefully,

including its hints and warnings.To avoid unnecessary

mistakes and accidents,it is important to make sure that all

people using the appliance are thoroughly familiar with its

operation and safety features. Save these instructions and

be sure that they remain with the appliance if it is moved or

sold,so that anyone using it throughout its life,will be

properly informed on its usage and safety notices.

For the safety of life and property,keep the precautions of

these user's instructions as the manufacturer is not

responsible for damages caused by omission.

Safety for children and others who are vulnerable people

● According to EN standard

This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved.Children shall not play with the

appliance.Cleaning and user maintenance shall not be

made by children without supervision.

● According to IEC standard

This appliance is not intended for use by persons

(including children) with reduced physical,sensory or

mental capabilities,or lack of experience and knowledge,

unless they have been given supervision or instruction

concerning use of the appliance by a person being

responsible for their safety.

● Keep all packaging away from children as there is a risk

of suffocation.

● If you are discarding the appliance,pull the plug out of the

socket,cut the connection cable (as close to the appliance

as you can) and remove the door to prevent children

playing from suffering an electric shock or from closing

themselves inside it.

● If this appliance, featuring a magnetic door seals,is to

replace an older appliance having a spring lock (latch) on

the door or lid,be sure to make the spring lock unusable

before you discard the old appliance.This will prevent it

from becoming a death trap for a child.

General safety

● WARNING —This appliance is intended to be used

in household and similar applications such as

-staff kitchen areas in shops,offices and other working

environments;

-farm houses and hotels, motels and other residential type

environments;

-bed and breakfast type environments;

-catering and similar non-retail applications.

● WARNING — Do not store explosive substances such as

aerosol cans with a flammable propellant in this appliance.

● WARNING — If the supply cord is damaged,it must be

replaced by the manufacturer,its service agent or similarly

qualified persons in order to avoid a hazard.

● WARNING — Keep ventilation openings,in the appliance

enclosure or in the built-in structure,clear of obstruction.

● WARNING — Do not use mechanical devices or other

means to accelerate the defrosting process,other than

those recommended by the manufacturer.

● WARNING — Do not damage the refrigerant circuit.

● WARNING — Do not use electrical appliances inside the

food storage compartments of the appliance,unless they

are of the type recommended by the manufacturer.

● WARNING — The refrigerant and insulation blowing gas

are flammable. When disposing of the appliance,do so only

at an authorized waste disposal centre.Do not expose to

flame.

● WARNING —When positioning the appliance,ensure the

supply cord is not trapped or damaged.

● WARNING —Do not locate multiple portable socket-outlets

or portable power supplies at the rear of the appliance.

Replacing the illuminating lamps

● WARNING—The illuminating lamps must not be

replaced by the user! If the illuminating lamps is

damaged,contact the customer helpline for assistance.

This warning is only for refrigerators that contain

illuminating lamps.

Refrigerant

The refrigerant isobutene (R600a) is contained within the

refrigerant circuit of the appliance,a natural gas with a high

level of environmental compatibility,which is nevertheless

flammable.During transportation and installation of the

appliance,ensure that none of the components of the

refrigerant circuit becomes damaged.

The refrigerant (R600a) is flammable.

● WARNING — Refrigerators contain refrigerant and

gases in the insulation.Refrigerant and gases must be

disposed of professionally as they may cause eye injuries

or ignition. Ensure that tubing of the refrigerant circuit is not

damage prior to proper disposal.

WARNING : Risk of fire / flammable materials

If the refrigerant circuit should be damaged:

-Avoid opening flames and sources of ignition.

-Thoroughly ventilate the room in which the appliance is

situated.

a Gas Work

this appliance.

It is hazardous for

involve removal of covers.

Authorization for hydrocarbon refrigerants

Authorized Queensland the

or repairs which

to carry out servicing

to service

anyone other than an Authorized Service Person

MUST hold

Service Person

a Gas Work

this appliance.

It is hazardous for

involve removal of covers.

Authorization for hydrocarbon refrigerants

Authorized Queensland the

or repairs which

to carry out servicing

to service

anyone other than an Authorized Service Person

MUST hold

Service Person

It is dangerous to alter the specifications or modify this

product in any way.

Any damage to the cord may cause a short circuit,fire,

and/or electric shock.

Electrical safety

1.The power cord must not be lengthened.

2. Make sure that the power plug is not crushed or

damaged.

A crushed or damaged power plug may overheat and

cause a fire.

3.Make sure that you can access the main plug of the

appliance.

4. Do not pull the main cable.

5. If the power plug socket is loose, do not insert the power

plug. There is a risk of electric shock or fire.

6.You must not operate the appliance without the interior

lighting lamp cover.

7.The fridge is only applied with power supply of single

phase alternating current of 220~240V/50Hz. If fluctuation

of voltage in the district of user is so large that the voltage

exceeds the above scope,for safety sake, be sure to apply

A.C. Automatic voltage regulator of more than 350W to the

fridge.The fridge must employ a special power socket

instead of common one with other electric appliances. Its

plug must match the socket with ground wire.

Daily use

● Do not store flammable gas or liquids in the appliance,

there is a risk of an explosion.

● Do not operate any electrical appliances in the appliance

(e.g. electric ice cream makers,mixers etc.).

● When unplugging always pull the plug from the mains

socket,do not pull on the cable.

● Do not place hot items near the plastic components of

this appliance.

● Do not place food products directly against the air outlet

on the rear wall.

● Store pre-packed frozen food in accordance with the

frozen food manufacture’s instructions.

● The appliances manufactures storage recommendations

should be strictly adhered to.Refer to relevant instructions

for storage.

● Do not place carbonated or fizzy drinks in the freezer

compartment as it creates pressure on the container,which

may cause it to explode,resulting in damage to the

appliance.

● Frozen food can cause frost burns if consumed straight

from the freezer compartment.

● Do not place the appliance in direct sunlight.

● Keep burning candles,lamps and other items with naked

flames away from the appliance so that do not set the

appliance on fire.

● The appliance is intended for keeping food stuff and/or

beverages in normal household as explained in this

instruction booklet.You should take care when move it as

the appliance is heavy.

● Do not remove or touch items from the freezer

compartment if your hands are damp/wet, as this could

cause skin abrasions or frost/freezer burns.

● Never use the base,drawers,doors etc. to stand on or as

supports.

● Frozen food must not be refrozen once it has been

thawed out.

● Do not consume ice popsicles or ice cubes straight from

the freezer as this can cause freezer burn to the mouth and

lips.

● To avoid items falling and causing injury or damage to

the appliance,do not overload the door racks or put too

much food in the crisper drawers.

caution!

Care and cleaning

● Before maintenance,switch off the appliance and

disconnect the mains plug from the mains socket.

● Do not clean the appliance with metal objects,steam

cleaner,ethereal oils,organic solvents or abrasive cleansers.

● Do not use a sharp objects instead of a plastic scraper

to remove frost from the appliance.

Installation Important!

● For electrical connection carefully, follow the instructions

given in this manual.Unpack the appliance and check if

there are damages on it.

● Do not connect the appliance if it is damaged. Report

possible damages immediately to the place you bought

it.In this case retain packing.

● It is advisable to wait at least four hours before connecting

the appliance to allow the oil to flow back in the compressor.

● Adequate air circulation should be around the appliance,

lacking this leads to overheating. To achieve sufficient

ventilation, follow the instructions relevant to installation.

● Wherever possible the back of the product should not be

too close to a wall to avoid touching or catching warm parts

(compressor, ) to prevent the risk of a fire, follow

the instructions relevant to installation.

● The appliance must not be locate close to radiators or cookers.

● Make sure that the mains plug is accessible after the

installation of the appliance.

Service

● Any electrical work required to do the servicing of the

appliance should be carried out by qualified electrician or

competent person.

● This product must be serviced by an authorized Service

Center, and only genuine spare parts must be used.

1) If the appliance is Frost Free.

2) If the appliance contains freezer compartment.

Note: Children aged from 3 to 8 years are allowed to load

and unload refrigerating appliances.(This clause applies

only to the EU region.)

condenser

Climate class Ambient temperature

+16℃ to +32℃

+16℃ to +38℃

+16℃ to +43℃

Note:

●This appliance performs well within

the climate class showed in

the table below. It may not work

properly if being left at a temperature

above or below the indicated range for

a long period.

Installing your new appliance

Before using the appliance for the first

time, you should be informed of the

following tips.

Warning!

For proper installation, this refrigerator

must be placed on a level surface of

hard material that is the same height as

the rest of the flooring. This surface

should be strong enough to support a

fully loaded refrigerator.

The rollers, which are not castors,

should be only used for forward or

backward movement. Moving the

refrigerator sideways may damage

your floor and the rollers.

In order to improve efficiency of

the cooling system and save

energy, it is necessary to

maintain good ventilation around the

appliance for the dissipation of heat.For

this reason,sufficient clear space should

be available around the refrigerator.

Suggest: It is advisable for there to be

50 mm of space from the back to the

wall,at least 100mm from its top,at

Ventilation of appliance

1456mm

550mm

564mm

1065mm

937mm

135°

50mm50mm

SN +10℃ to +32℃

least 50 mm from its side to the wall

and a clear space in front to allow the

doors to open 135°. As shown in

following diagrams.

50mm

50mm 50mm

●Stand your appliance in a dry place to

avoid high moisture.

●Keep the appliance out of direct

sunlight, rain or frost. Stand the

appliance away from heat sources

such as stoves,fires or heaters.

Leveling of appliance

●For sufficient leveling and air

circulating in the lower rear section of

the appliance, the bottom feet may

need to be adjusted.You can adjust

them manually by hand or by using a

suitable spanner.

●To allow the doors to self-close, tilt

the top backwards by 10-15mm.

Note:

●If required you may lay the

refrigerator on its back in order to gain

access to the base, you should rest it

on soft foam packaging or similar

material to avoid damaging the

backboard of the refrigerator.

●There is no need to install these

accessories under normal usage.

Only under the extreme

circumstances,that is opening the door

about 90 degree,this refrigerator may

take risk of tipping.Then rubber

supporting pad should be fastened to

the lower base cover to steady this

appliance.

1. Tilt appliance to find screw hole on the

left of lower base cover.

2. Put screw into the hole of rubber

supporting pad.

3. Make screw in alignment with the hole

on lower base cover.Fasten rubber

supporting pad to the base cover firmly

by a cross screwdriver (self-provided).

lower base cover

rubber supporting pad

screw

adjustable bottom feet

cross screwdriver

10-15mm

Description of the appliance

Note!

Due to unceasing modification of our products,your refrigerator may be

slightly different from this instruction manual,but its functions and using

methods remain the same.

To get the best energy efficiency of this product,please place all shelves,

drawers and baskets on their original position as the illustration above.

●

14. Freezer door rack

15. Fridge door gasket

16. Upper door rack

17. Door switch

18. Lower door rack

19. Fridge door

1. Freezer wind channel

2. Freezer shelf

3. Freezer temp. control

4.Ice tray cover(optional)

5.Ice cube tray(optional)

6. Fridge temp. control

7. Fridge shelf

9. Crisper cover

10. Crisper

11. Adjustable bottom feet

12. Freezer door gasket

13. Freezer door

Fridge wind channel

View of the appliance

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Refrigerador de Hisense

Hisense

Hisense RF26N6AFE Manual de usuario

Hisense

Hisense RB335N4WB1 Instrucciones de montaje

Hisense

Hisense RL170D4BC21 Manual de usuario

Hisense

Hisense RS818N4TCE Instrucciones de montaje

Hisense

Hisense HRF254N6TSE Manual de usuario

Hisense

Hisense RT417N4DD1 Instrucciones de montaje

Hisense

Hisense RB14N1ASD Instrucciones de montaje

Hisense

Hisense HR6FDFF701SW Instrucciones de montaje

Hisense

Hisense H230RRE-WD Instrucciones de montaje

Hisense

Hisense RS840N4WBE Instrucciones de montaje

Hisense

Hisense RS818N4TCE Instrucciones de montaje

Hisense

Hisense KT 117 A +++ Instrucciones de montaje

Hisense

Hisense BCD-203WYA/HC4 Instrucciones de montaje

Hisense

Hisense RF208N6 Series Instrucciones de montaje

Hisense

Hisense HR6CDFF695GB Instrucciones de montaje

Hisense

Hisense RS840N4WCF Instrucciones de montaje

Hisense

Hisense HSC-192FLB Manual de usuario

Hisense

Hisense RL170D4BCE Instrucciones de montaje

Hisense

Hisense RB291D4CWF Instrucciones de montaje

Hisense

Hisense H310BIT Instrucciones de montaje

Hisense

Hisense FV14D6CWD Instrucciones de montaje

Hisense

Hisense RT600N4WC2 Instrucciones de montaje

Hisense

Hisense HRVF254 Instrucciones de montaje

Hisense

Hisense RB296F4AW1 Instrucciones de montaje

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
