Hirschmann MACH1040 Manual de usuario

Installation MACH1040

Release

03/2021

Technical support

https://hirschmann-support.belden.com

User Manual

Installation

Industrial Ethernet Ruggedized Switch

MACH1040 family Full Gigabit

Aufkleber MAC-Adresse

V.24USB

FAULT

Sb R1

MAR1040

Aufkleber MAC-Adresse

V.24USB

FAULT

Sb R1

MAR1040

Aufkleber MAC-Adresse

V.24USB

FAULT

Sb R1

MAR1142

Aufkleber MAC-Adresse

V.24USB

FAULT

Sb R1

MAR1140

MAR1040

MAR1042

MAR1140

MAR1142

MAR1140, MAR1142

FAULT

RM Stand by

R1 R2

16 ETHERNET Service Port

Relay

26.03.2021 Installation MACH1040

Release

03/2021

The naming of copyrighted trademarks in this manual, even when not specially indicated, should

not be taken to mean that these names may be considered as free in the sense of the trademark

and tradename protection law and hence that they may be freely used by anyone.

translation, conversion into any electronic medium or machine scannable form is not permitted,

either in whole or in part. An exception is the preparation of a backup copy of the software for

your own use.

The performance features described here are binding only if they have been expressly agreed

when the contract was made. This document was produced by Hirschmann Automation and

Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right

to change the contents of this document without prior notice. Hirschmann can give no guarantee

in respect of the correctness or accuracy of the information in this document.

Hirschmann can accept no responsibility for damages, resulting from the use of the network

components or the associated operating software. In addition, we refer to the conditions of use

specified in the license contract.

You can get the latest version of this manual on the Internet at the Hirschmann product site

(www.hirschmann.com).

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Installation MACH1040

Release

03/2021 3

Contents

Important information 5

Safety instructions 7

About this Manual 15

Key 16

1 Description 17

1.1 General device description 17

1.2 Combination options 18

1.3 Description of the device variants 19

1.3.1 Support of PoE 23

1.4 Gigabit combo port 24

1.4.1 10/100/1000 Mbit/s twisted pair port 24

1.4.2 100/1000 Mbit/s F/O port 25

1.4.3 Pin assignments 25

1.5 Display elements 25

1.5.1 Device state 26

1.5.2 LED display elements port status 28

1.6 Management interfaces 30

1.6.1 V.24 interface (external management) 30

1.6.2 USB interface 30

1.7 Signal contact 31

2 Installation 32

2.1 Checking the package contents 32

2.2 Installing an SFP transceiver (optional) 32

2.3 Wiring of the terminal blocks for supply voltage and signal

contact 33

2.3.1 Connecting the supply voltage 34

2.3.2 Wiring the signal contact 35

2.4 Installing and grounding the device 36

2.4.1 Mounting in a switch cabinet 36

2.4.2 Vertical mounting on the wall 38

4Installation MACH1040

Release

03/2021

2.4.3 Grounding the device 38

2.5 Operating the device 39

2.6 Connecting data cables 39

2.6.1 Twisted Pair ports 39

2.6.2 Optical fiber ports 39

3 Making basic settings 40

3.1 First login (Password change) 41

4 Monitoring the ambient air temperature 42

5 Maintenance and service 43

6Disassembly 44

6.1 Removing the device 44

6.2 Removing an SFP transceiver (optional) 44

7 Technical data 45

7.1 General technical data 45

7.2 Dimension drawings 47

7.3 EMC and immunity 49

7.4 Network range 51

7.4.1 10/100/1000 Mbit/s twisted pair port 51

7.4.2 Fast Ethernet SFP transceiver 51

7.4.3 Bidirectional Fast Ethernet SFP transceiver 52

7.4.4 Gigabit Ethernet SFP transceiver 53

7.4.5 Bidirectional Gigabit Ethernet SFP transceiver 54

7.5 Power consumption/power output 56

7.6 Scope of delivery 56

7.7 Order numbers/product description 57

7.8 Accessories 57

7.9 Underlying technical standards 60

A Further support 61

Installation MACH1040

Release

03/2021 5

Important information

Note: Read these instructions carefully, and familiarize yourself with the

device before trying to install, operate, or maintain it. The following notes may

appear throughout this documentation or on the device. These notes warn of

potential hazards or call attention to information that clarifies or simplifies a

procedure.

Symbol explanation

This is a general warning symbol. This symbol alerts you to

potential personal injury hazards. Observe all safety notes that

follow this symbol to avoid possible injury or death.

If this symbol is displayed in addition to a safety instruction of the

type “Danger” or “Warning”, it means that there is a danger of

electric shock and failure to observe the instructions will

inevitably result in injury.

This symbol indicates the danger of hot surfaces on the device.

In connection with safety instructions, non-observance of the

instructions will inevitably result in injuries.

DANGER

DANGER draws attention to an immediately dangerous situation, which will

inevitably result in a serious or fatal accident if not observed.

WARNING

WARNING indicates a potentially hazardous situation which, if not avoided,

could result in death or serious injury.

CAUTION

CAUTION indicates a possible danger which, if not avoided, may result in

minor injuries.

6Installation MACH1040

Release

03/2021

NOTICE

NOTE provides information about procedures that do not involve the risk of

injury.

Installation MACH1040

Release

03/2021 7

Safety instructions

General safety instructions

You operate this device with electricity. Improper usage of the device

entails the risk of physical injury or significant property damage. The

proper and safe operation of this device depends on proper handling

during transportation, proper storage and installation, and careful

operation and maintenance procedures.

Before connecting any cable, read this document, and the safety

instructions and warnings.

Operate the device with undamaged components exclusively.

The device is free of any service components. In case of a damaged

or malfunctioning device, turn off the supply voltage and return the

device to Hirschmann for inspection.

Certified usage

Use the product only for the application cases described in the

Hirschmann product information, including this manual.

Operate the product only according to the technical specifications.

See “Technical data” on page 45.

Connect to the product only components suitable for the requirements

of the specific application case.

Installation site requirements

Install this device only in a switch cabinet or in an operating site with

restricted access, to which maintenance staff have exclusive access.

Mount the device horizontally in a cabinet or vertically on a flat surface.

Operating the device as a table unit is inadmissible.

See “General technical data” on page 45.

Install the device in a fire protected shell if you are mounting it

vertically.

WARNING

UNCONTROLLED MACHINE ACTIONS

To avoid uncontrolled machine actions caused by data loss, configure all

the data transmission devices individually.

Before you start any machine which is controlled via data transmission, be

sure to complete the configuration of all data transmission devices.

Failure to follow these instructions can result in death, serious injury,

or equipment damage.

8Installation MACH1040

Release

03/2021

If you are operating the device in a 19" switch cabinet: install sliding/

mounting rails for supporting the weight of the device.

When you are selecting the installation location, make sure you

observe the climatic threshold values specified in the technical data.

Use the device in an environment with a maximum pollution degree

that complies with the specifications in the technical data.

Strain relief

Note: If the strain relief is insufficient, there is a risk of torsion, contact

problems and creeping interruptions.

Relieve the connection points of cables and lines from mechanical

stress.

Design strain relieves in such a way that they prevent any mechanical

damage to cables, wires or conductors caused by external influences

or their own weight.

To prevent damage to device connections, connectors and cables,

follow the instructions for proper installation in accordance with DIN

VDE 0100-520:2013-06, sections 522.6, 522.7 and 522.13.

Device casing

Only technicians authorized by the manufacturer are permitted to open

the casing.

Make sure there is at least 3.94 in (10 cm) of space in front of the

ventilation slits of the casing.

See “General technical data” on page 45.

Never insert pointed objects (narrow screwdrivers, wires, etc.) into the

device or into the connection terminals for electric conductors. Do not

touch the connection terminals.

Do not touch the housing during operation or shortly after switching off

the device. Hot surfaces can cause injury.

Operating the device in the maximum surrounding air temperature and

stacking devices: When installing the device, make sure there is at

least 1 free rack space (approx. 5 cm) above the device, because heat

is discharged via the housing of the device.

Qualification requirements for personnel

Only allow qualified personnel to work on the device.

Qualified personnel have the following characteristics:

Qualified personnel are properly trained. Training as well as practical

knowledge and experience make up their qualifications. This is the

prerequisite for grounding and labeling circuits, devices, and systems

in accordance with current standards in safety technology.

Qualified personnel are aware of the dangers that exist in their work.

Installation MACH1040

Release

03/2021 9

Qualified personnel are familiar with appropriate measures against

these hazards in order to reduce the risk for themselves and others.

Qualified personnel receive training on a regular basis.

National and international safety regulations

Verify that the electrical installation meets local or nationally applicable

safety regulations.

Grounding the device

The device is grounded via the separate grounding screw on the back of

the device.

Use a wire diameter for the ground conductor that is no smaller than

the diameter of the supply voltage connection, however of at least

1.0 mm² (AWG16).

Ground the device before connecting any other cables.

Disconnect the grounding only after disconnecting all other cables.

Shielded ground

The shielded ground wire of the twisted pairs cables is connected to the

front panel as a conductor.

Beware of possible short circuits when connecting a cable section with

conductive shield braiding.

Supply voltage

The supply voltage is electrically isolated from the casing.

Exclusively connect a supply voltage that corresponds to the type plate of

your device.

Every time you connect the electrical conductors, make sure that the

following requirements are met:

The power supply conforms to overvoltage category I or II.

The power supply has an easily accessible disconnecting device

(for example a switch or a plug). This disconnecting device is

clearly identified. So in the case of an emergency, it is clear which

disconnecting device belongs to which power supply cable.

The electrical wires are voltage-free.

The ground screw on the back of the device is connected to the

protective conductor.

There is a fuse in the outer conductor (AC) or the positive

conductor (DC) of the voltage supply.

Regarding the properties of this fuse: See “General technical data”

on page 45.

Supply with DC voltage: the fuse is suitable for a DC voltage.

If the neutral conductor (AC) or the negative conductor (DC) is not

grounded: there is a fuse in each of the two wires.

The wire diameter of the power supply cable is at least 1 mm²

(North America: AWG16) on the supply voltage input.

10 Installation MACH1040

Release

03/2021

The cross-section of the protective conductor is the same size as

or bigger than the cross-section of the power supply cables.

The cables used are permitted for the temperature range of the

application case.

Relevant for North America:

The power supply lines are made up of copper wire.

Start connecting the electrical wires only if all the above safety

requirements are fulfilled.

Verify that the electrical installation meets locally or nationally

applicable safety regulations.

Use undamaged parts.

Internal fuses are triggered only in the case of a detected error in the

device. In case of damage or malfunction of the device, turn off the

supply voltage and return the device to the plant for inspection.

Only switch on the device when the housing is closed.

First connect the ground screw on the back of the device with the

protective conductor before you set up the other connections. When

removing the connections, you remove the protective conductor last.

For supply voltage connections with protective conductor connection:

First connect the protective conductor before connecting the wires for

the supply voltage.

If your device comprises a 2nd supply voltage connection of this type:

First connect the protective conductor before connecting the wires for

the supply voltages.

Tabla de contenidos

Otros manuales de Cambiar de Hirschmann

Hirschmann

Hirschmann CS30 Manual de usuario

Hirschmann

Hirschmann PowerMICE MS4128 Manual de usuario

Hirschmann

Hirschmann Power MICE Manual de usuario

Hirschmann

Hirschmann RS20 series Manual de usuario

Hirschmann

Hirschmann BATOne Manual de usuario

Hirschmann

Hirschmann GigaLION-24TP Manual de usuario

Hirschmann

Hirschmann MACH4000 Series Manual de usuario

Hirschmann

Hirschmann RSPM20-4Z64Z6 Series Manual de usuario

Hirschmann

Hirschmann ETHERNET IP67 Instrucciones de funcionamiento e instalación

Hirschmann

Hirschmann GECKO 4TX Manual de usuario

Hirschmann

Hirschmann RS2-5TX/FX Manual

Hirschmann

Hirschmann PowerMICE Manual de usuario

Hirschmann

Hirschmann OCTOPUS 8TX-EEC Manual de usuario

Hirschmann

Hirschmann MACH4000 Series Manual de usuario

Hirschmann

Hirschmann RS20 series Manual de usuario

Hirschmann

Hirschmann OCTOPUS 8M Series Manual de usuario

Hirschmann

Hirschmann MACH102 Series Manual de usuario

Hirschmann

Hirschmann RH1-CX+ Manual de usuario

Hirschmann

Hirschmann BRS20-0400 Series Manual de usuario

Hirschmann

Hirschmann RSP 25 Manual de usuario

Hirschmann

Hirschmann OCTOPUS 8M Series Manual de usuario

Hirschmann

Hirschmann SPIDER PL Manual de usuario

Hirschmann

Hirschmann GREYHOUND GRS1020 Manual de usuario

Hirschmann

Hirschmann MACH104-20TX-F Series Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
