INSTRUCTION MANUAL
For...は専用機種。複数の場合は「/」で区切る。
不要の場合はとる。
形名を入力。 複数の場合は「/」で区切る。
3638-20
品名を入力。
LEAK LOGGER
Contents
Introduction i
Inspection i
Safety Notes ii
Notes on Use v
Measurement Flow Chart and Reference Guide viii
Chapter 1 Product Outline 1
1.1 Name and Functions of Parts 2
1.2 Interval and Maximum Recording Time 3
1.3 Measurement Value Recording Modes 5
1.4 Leak Current Measurement 6
1.5 Load current measurement 8
Chapter 2 Set Up 9
2.1 Replacing the Battery 9
2.2 Power Save Function 11
2.3 Setting Current Time 12
2.4 Connecting Sensor Cable 12
Chapter 3 Settings 15
3.1 Setting Items 15
3.2 Manual Setting 20
3.3 Setting by COMMUNICATION BASE 22
Chapter 4 Specifications 25
Chapter 5 Maintenance and Service 27
i
_____________________________________________________________________
Inspection
______________________________________________________________
NOTE Testing monitor batteries installed in the unit may possibly be
weak. Replace batteries before extended measurement usage.
Before using the product, make sure that the insulation on the
sensor cables is undamaged and that no bare conductors are
improperly exposed. Using the product in such conditions could
cause an electric shock, so contact your dealer or Hioki
representative for repair.
Introduction
Ins
p
ection
Thank you for purchasing the Hioki 3638-20 LEAK
LOGGER. To obtain maximum performance from the
instrument, please read this manual first, and keep it handy
for future reference.
When you receive the instrument, inspect it carefully to
ensure that no damage occurred during shipping. If damage
is evident, or if it fails to operate according to the
specifications, contact your dealer or Hioki representative.
Accessories
9632 CONNECTION CABLE
Instruction Manual
LR03 alkaline battery X4
(built into this unit, for monitor)
Before using the product the first time, verify that it
operates normally to ensure that the no damage occurred
during storage or shipping. If you find any damage, contact
your dealer or Hioki representative.
ii
_____________________________________________________________________
Safety Notes
______________________________________________________________
DANGE
R
This instrument is designed to conform to IEC 61010
Safety Standards, and has been thoroughly tested for
safety prior to shipment. However, mishandling
during use could result in injury or death, as well as
damage to the instrument. Be certain that you
understand the instructions and precautions in the
manual before use. We disclaim any responsibility for
accidents or injuries not resulting directly from
product defects.
Safety Symbols
The symbol printed on the instrument indicates that
the user should refer to a corresponding topic in the
manual (marked with the symbol) before using the
relevant function.
In the manual, the symbol indicates particularly
important information that the user should read before
using the instrument.
Indicates DC (Direct Current).
Safet
y
Notes
This manual contains information and warnings essential
for safe operation of the instrument and for maintaining it
in safe operating condition. Before using the instrument,
be sure to carefully read the following safety notes.
iii
_____________________________________________________________________
Safety Notes
______________________________________________________________
DANGE
R
Indicates that incorrect operation presents an extreme
hazard that could result in serious injury or death to
the user.
WARNING
Indicates that incorrect operation presents a
significant hazard that could result in serious injury or
death to the user.
CAUTION Indicates that incorrect operation presents a
possibility of injury to the user or damage to the
instrument.
NOTE Advisory items related to performance or correct
operation of the instrument.
f.s. (maximum display or scale value, or length of scale)
Signifies the maximum display (scale) value or the length
of the scale (in cases where the scale consists of unequal
increments or where the maximum value cannot be
defined).
In general, this is the range value (the value written on
the range selector or equivalent) currently in use.
rdg. (displayed or indicated value)
This signifies the value actually being measured, i.e., the
value that is currently indicated or displayed by the
measuring instrument.
dgt. (resolution)
Signifies the smallest display unit on a digital measuring
instrument, i.e., the value displayed when the last digit on
the digital display is "1".
The following symbols in this manual indicate the relative
importance of cautions and warnings.
Accuracy
The specifications in this manual include figures for
"measurement accuracy" when referring to digital
measuring instruments, and for "measurement tolerance"
when referring to analog instruments.
iv
_____________________________________________________________________
Safety Notes
______________________________________________________________
CAT I Secondary electrical circuits connected to an AC
electrical outlet through a transformer or similar
device.
CAT II Primary electrical circuits in equipment connected
to an AC electrical outlet by a power cord (portable
tools, household appliances, etc.)
CAT III Primary electrical circuits of heavy equipment
(fixed installations) connected directly to the
distribution panel, and feeders from the distribution
panel to outlets.
CAT IV The circuit from the service drop to the service
entrance, and to the power meter and primary
overcurrent protection device (distribution panel).
Measurement categories (Overvoltage categories)
To ensure safe operation of measurement product, IEC
61010 establishes safety standards for various electrical
environments, categorized as CAT I to CAT IV, and called
measurement categories. These are defined as follows.
Higher-numbered categories correspond to electrical
environments with greater momentary energy. So a
measurement device designed for CAT III environments can
endure greater momentary energy than a device designed for
CAT II. Using a measurement product in an environment
designated with a higher-numbered category than that for
which the product is rated could result in a severe accident,
and must be carefully avoided.
Never use a CAT I measuring product in CAT II, III, or IV
environments. The measurement categories comply with the
Overvoltage Categories of the IEC60664 Standards.
v
_____________________________________________________________________
Notes on Use
______________________________________________________________
DANGE
R
This product cannot be used on following voltage lines.
If the voltage exceeds, there will be a short-circuit
accident or electrocution accident will result.
CAT III, AC300 Vrms for 9657
CAT III, AC150 Vrms for 9658
To avoid short circuits and potentially life-threatening
hazards, never attach the clamp-on leak sensor to a
circuit that operates at more than the following
maximum rated voltage to earth.
AC300 Vrms for 9657
AC150 Vrms for 9658
Clamp-on leak sensor should only be connected to the
secondary side of a breaker, so the breaker can prevent
an accident if a short circuit occurs. Connections
should never be made to the primary side of a breaker,
because unrestricted current flow could cause a
serious accident if a short circuit occurs.
For model 9657
When conductors being measured carry in excess of
the safe voltage level (SELV-E) and not more than 300
V, to prevent short circuits and electric shock while the
clamp core jaw is open, make sure that conductors to
be measured are insulated with material conforming to
(1) Measurement Category III, (2) Pollution Degree 2,
and (3) Basic Insulation Requirements for Working
Voltages of 300 V.
Notes on Use
Follow these precautions to ensure safe operation and to
obtain the full benefits of the various functions.
vi
_____________________________________________________________________
Notes on Use
______________________________________________________________
DANGE
R
For model 9658
When conductors being measured carry in excess of
the safe voltage level (SELV-E) and not more than 150
V, to prevent short circuits and electric shock while the
clamp core jaw is open, make sure that conductors to
be measured are insulated with material conforming to
(1) Measurement Category III, (2) Pollution Degree 2,
and (3) Basic Insulation Requirements for Working
Voltages of 150 V.
Refer to the following standards regarding the
meanings of underlined terms.
IEC61010-1
IEC61010-2-031
IEC61010-2-032
WARNING
To avoid electric shock, do not allow the product to
get wet, and do not use it when your hands are wet.
When measuring the ground conductor on a
transformer Class 2 connection site, be careful not to
approach high voltage devices or conductors. Also, if
close to high voltage charging devices or if
measurement is otherwise difficult, first change the
route of the grounding wire.
To avoid damage to the product, protect it from
vibration or shock during transport and handling, and
be especially careful to avoid dropping.
This is a precision instrument: do not clamp any
foreign objects in the end of the clamp core, or insert
anything in the core gap.
Do not exert excessive pressure on the clamp sensor
or attempt to wedge the sensor into a tight spot for
measurement.
