Hilti Pd-e Manual de usuario

PD-E

English 1

Français 17

Español 34

Português 51

PD-E

en English ............................................. 1

fr Français ........................................... 17

es Español ........................................... 34

pt Português ......................................... 51

*2068470* 2068470 English 1

English

1 Information about the operating instructions

1.1 About these operating instructions

• Read these operating instructions before the product is used or operated

for the first time. This is a prerequisite for safe, trouble-free handling and

use of the product.

• Observe the safety instructions and warnings in these operating instruc-

tions and on the product.

• Always keep the operating instructions with the product and make sure

that the product is accompanied by these operating instructions only,

when the product is given to other persons.

1.2 Explanation of symbols

1.2.1 Warnings

Warnings alert persons to hazards that occur when handling or using the

product. The following signal words are used:

DANGER

DANGER !

▶Draws attention to imminent danger that will lead to serious personal

injury or fatality.

WARNING

WARNING !

▶Draws attention to a potential threat of danger that can lead to serious

injury or fatality.

CAUTION

CAUTION !

▶Draws attention to a potentially dangerous situation that could lead to

personal injury or damage to the equipment or other property.

1.2.2 Symbols in the operating instructions

The following symbols are used in these operating instructions:

Comply with the operating instructions

Instructions for use and other useful information

Dealing with recyclable materials

Do not dispose of electric equipment and batteries as household

waste

2 English 2068470 *2068470*

1.2.3 Symbols in illustrations

The following symbols are used in illustrations:

These numbers refer to the illustrations at the beginning of these

operating instructions.

The numbers in illustrations refer to important work steps or to com-

ponents important for the work steps. In the text, the corresponding

numbers draw attention to these work steps or components, e.g. (3).

Item reference numbers are used in the overview illustration and

refer to the numbers used in the key in the product overview sec-

tion.

This symbol is intended to draw your special attention to certain

points for handling the product.

1.3 Product-dependent symbols

1.3.1 General symbols

Symbols used in relation to the product.

If applied on the product, the product has been certified by this cer-

tification body for the US and Canadian markets according to the

applicable standards.

KCCREM-HLTPD-E

On/off button

Measure button

Menu button

Delete (clear) button

Right arrow button

Left arrow button

1.4 Product information

products are designed for professional users and only trained,

authorized personnel are permitted to operate, service and maintain the

products. This personnel must be specifically informed about the possible

hazards. The product and its ancillary equipment can present hazards if

used incorrectly by untrained personnel or if used not in accordance with

the intended use.

The type designation and serial number are printed on the rating plate.

*2068470* 2068470 English 3

▶Write down the serial number in the table below. You will be required to

state the product details when contacting Hilti Service or your local Hilti

organization to inquire about the product.

Product information

Laser range meter PD-E

Generation 01

Serial no.

1.5 Laser information on the product

Laser information → page 3

Laser information

Laser Class 2 based on the IEC60825-1 / EN60825-

1:2007 standard in compliance with CFR 21 § 1040

(Laser Notice 50).

Laser Class 2: Do not stare into the beam. Do not di-

rect the beam toward other persons or toward areas in

which other persons, who are not involved in the work

with lasers, may be present.

Recycle waste material.

2 Safety

2.1 Safety instructions

2.1.1 Basic information concerning safety

In addition to the safety rules listed in the individual sections of these

operating instructions, the following rules must be strictly observed at

all times. The product and its ancillary equipment may present hazards

when used incorrectly by untrained personnel or when used not as directed.

▶Keep all safety instructions and information for future reference.

▶Stay alert, watch what you are doing and use common sense when

working with the product. Do not use the product while you are tired

or under the influence of drugs, alcohol or medication. A moment of

inattention while operating the product may result in serious personal

injury.

▶Do not render safety devices ineffective and do not remove information

and warning notices.

▶If the product is opened improperly, laser radiation in excess of Class 2

may be emitted. Have the product repaired only by Hilti Service.

▶Tampering with or modification of the product is not permitted.

▶Check that the product functions correctly each time before use.

4 English 2068470 *2068470*

▶Measurements taken through panes of glass or other objects may be

inaccurate.

▶The measurement may be incorrect if the conditions under which the

measurement is taken change rapidly, e.g. due to people walking through

the path of the laser beam.

▶Do not point the product toward the sun or other powerful light sources.

▶Take the influences of the surrounding area into account. Do not use the

tool where there is a risk of fire or explosion.

▶Observe the information printed in the operating instructions concerning

operation, care and maintenance.

2.1.2 General safety rules

▶Check the product for damage before use. Have the damage repaired

by Hilti Service.

▶Check the accuracy of the product after it has been dropped or subjected

to other mechanical stresses.

▶Although the product is designed for the tough conditions of jobsite use,

as with other measuring instruments it should be treated with care.

▶Products which are not in use must be stored in a dry, high place or

locked away out of reach of children.

▶The product is not intended for use by children.

▶Observe the national health and safety requirements.

2.1.3 Proper preparation of the working area

▶Avoid unfavorable body positions when working from ladders. Make

sure you have a safe stance and that you stay in balance at all times.

▶Secure the site at which you are taking measurements and take care to

avoid directing the laser beam toward other persons or toward yourself.

▶When the product is brought into a warm environment from very cold

conditions, or vice-versa, allow it to become acclimatized before use.

▶Use the product only within its specified limits.

▶Keep the laser exit window clean in order to avoid measurement errors.

▶Observe the accident prevention regulations applicable in your country.

2.1.4 Working safely with laser tools

▶Laser Class 2/Class II tools may be operated only by appropriately

trained persons.

▶Laser beams should not be projected at eye height.

▶Precautions must be taken to ensure that the laser beam does not

unintentionally strike highly reflective surfaces.

▶Precautions must be taken to ensure that persons do not stare directly

into the beam.

▶The laser beam must not be allowed to project beyond the controlled

area.

▶Switch the laser tool off when it is not in use.

*2068470* 2068470 English 5

▶Store laser tools, when not in use, in places to which unauthorized

persons have no access.

2.1.5 Electromagnetic compatibility

Although the device complies with the strict requirements of the applicable

directives, Hilti cannot entirely rule out the possibility of interference to the

device caused by powerful electromagnetic radiation, possibly leading to

incorrect operation. Check the accuracy of the device by taking measure-

ments by other means when working under such conditions or if you are

unsure. Likewise, Hilti cannot rule out the possibility of interference with

other devices (e.g. aircraft navigation equipment). The tool complies with

the requirements of class A; The possibility of interference occurring in a

domestic environment cannot be excluded.

Only for Korea: This laser range meter is suitable for commercial and

industrial use and for the electromagnetic radiation encountered in this field

(Class A). Users must pay attention to this point and make sure that this

laser range meter is not used in occupied living areas.

3 Description

3.1 Overview of the product 1

@Rear contact surface

;Reference indicator LED for

rear contact

=Left arrow button

%Menu button

&“Measure” button

(Graphic display

)Reference indicator LED for

front contact

+Side “Measure” button

§On/off button

/Right arrow button

:Hand strap attachment point

∙Delete (clear) button

$¹/₄ inch thread

£Folding spike

|Laser emitting and receiving

lens

¡Optical sight

Q¹/₄ inch thread

3.2 Intended use

The product described is a laser range meter. It is designed for taking indi-

vidual measurements as well as the continuous measurement of distances.

Distances can be measured from all stationary targets without a highly

reflective surface, i.e. concrete, stone, wood, plastic, paper, etc. The use of

prisms or other highly reflective targets is not permissible and, if attempted,

may falsify the results.

The product is approved for use with batteries of the type AAA.

6 English 2068470 *2068470*

3.3 Explanation of the display

Main menu

Select angle unit

Determine painter’s area

Single Pythagoras

Measure areas and volumes

Select special functions

Select trapezoid function

Select Pythagoras function

At least one right angle is required for horizontal and diagonal dis-

tances.

Select settings

Measure indirectly

No specific angle is required for measurements on non-moving ob-

jects such as walls.

Generally applicable symbols

Battery charge state

Measuring spike not folded out

Measuring spike folded out

Measure

Add distances

Subtract distances

Select

Do not select

Select measuring time

Select calculator

Angle units submenu

Inclination in percent

Metric units

Imperial units

Inclination in angular degrees

Otros manuales para pd-e

Tabla de contenidos

Idiomas:

Otros manuales de Instrumento de medición de Hilti

Hilti

Hilti PD 30 Manual de usuario

Hilti

Hilti PD 20 Manual de usuario

Hilti

Hilti PD-I Manual de usuario

Hilti

Hilti PRM 15 Manual de usuario

Hilti

Hilti pd-e Manual de usuario

Hilti

Hilti PM 2-L Manual de usuario

Hilti

Hilti PR 25 Manual de usuario

Hilti

Hilti PMC 46 Manual de usuario

Hilti

Hilti PD 38 Manual de usuario

Hilti

Hilti PL MG-IS Manual de usuario

Hilti

Hilti PD 40 Manual de usuario

Hilti

Hilti PR 30-HVS Manual de usuario

Hilti

Hilti PD 42 Manual de usuario

Hilti

Hilti pos 150 Manual de usuario

Hilti

Hilti PM 2-LG Manual de usuario

Hilti

Hilti PD-S Manual de usuario

Hilti

Hilti PD-S Manual de usuario

Hilti

Hilti PS 300 Manual de usuario

Hilti

Hilti PMP 42 Manual de usuario

Hilti

Hilti HILTI PD-C Manual de usuario

Hilti

Hilti PS 1000 X-Scan Manual de usuario

Hilti

Hilti PR 2-HS Manual de usuario

Hilti

Hilti pd-e Manual de usuario

Hilti

Hilti PD-I Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
