HIK VISION DS-7600NI-E1/A Manual de usuario

All-in-One Network Video Recorder User Manual

All-in-One Network Video Recorder

User Manual

UD.6L0202D2084A01

User Manual of All-in-One Network Video Recorder

User Manual

Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou

Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user

manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed,

partially or wholly, by any means, without the prior written permission of Hikvision. Unless otherwise stipulated,

Hikvision does not make any warranties, guarantees or representations, express or implied, regarding to the

Manual.

About this Manual

This Manual is applicable to All-in-One NVR (Network Video Recorder).

The Manual includes instructions for using and managing the product. Pictures, charts, images and all other

information hereinafter are for description and explanation only. The information contained in the Manual is

subject to change, without notice, due to firmware updates or other reasons. Please find the latest version in the

company website (http://overseas.hikvision.com/en/).

Please use this user manual under the guidance of professionals.

Trademarks Acknowledgement

and other Hikvision’s trademarks and logos are the properties of Hikvision in various

jurisdictions. Other trademarks and logos mentioned below are the properties of their respective owners.

Legal Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH

ITS HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND

ERRORS, AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT

LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR

PURPOSE, AND NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS

DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL,

CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS,

DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR

DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS

BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE

WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITES FOR

ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER

ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS;

HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.

SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR

JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS

THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS

USED WITH ILLEGITIMATE PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE

LATER PREVAILS.

User Manual of All-in-One Network Video Recorder

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and comply

therefore with the applicable harmonized European standards listed under the EMC Directive

2004/108/EC, the RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper recycling, return this product to your local

supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection

points. For more information see: www.recyclethis.info

2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted

municipal waste in the European Union. See the product documentation for specific battery

information. The battery is marked with this symbol, which may include lettering to indicate

cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a

designated collection point. For more information see: www.recyclethis.info

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.

User Manual of All-in-One Network Video Recorder

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.

The precaution measure is divided into “Warnings” and “Cautions”

Warnings: Serious injury or death may occur if any of the warnings are neglected.

Cautions: Injury or equipment damage may occur if any of the cautions are neglected.

Warnings

●Proper configuration of all passwords and other security settings is the responsibility of the installer and/or

end-user.

●In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation

and region. Please refer to technical specifications for detailed information.

●Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with

100~240 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to technical specifications for

detailed information.

●Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire

hazard.

●Please make sure that the plug is firmly connected to the power socket.

●If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then

please contact the service center.

Warnings Follow these

safeguards to prevent serious

injury or death.

Cautions Follow these

precautions to prevent

potential injury or material

damage.

User Manual of All-in-One Network Video Recorder

●Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer.

The figures in the manual are for reference only.

This manual is applicable to the model: DS-7600NI-E1/A.

Preventive and Cautionary Tips

Before connecting and operating your device, please be advised of the following tips:

•Ensure unit is installed in a well-ventilated, dust-free environment.

•Unit is designed for indoor use only.

•Keep all liquids away from the device.

•Ensure environmental conditions meet factory specifications.

•Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping it

may cause damage to the sensitive electronics within the unit.

•Use the device in conjunction with an UPS.

•Power down the unit before connecting and disconnecting accessories and peripherals.

•Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or

equivalent type only. Dispose of used batteries according to the instructions provided by the manufacturer.

User Manual of All-in-One Network Video Recorder

Product Key Features

General

Connectable to network cameras, network dome and encoders.

Connectable to the third-party network cameras like ACTI, Arecont, AXIS, Bosch, Brickcom, Canon,

PANASONIC, Pelco, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO, and cameras that adopt ONVIF

or PSIA protocol.

Connectable to the smart IP cameras.

PAL/NTSC adaptive video inputs.

Each channel supports dual-stream.

Up to 8 network cameras can be connected.

Independent configuration for each channel, including resolution, frame rate, bit rate, image quality, etc.

The quality of the input and output record is configurable.

Local Monitoring

Simultaneous HDMITM and VGA outputs.

HDMITM and VGA outputs at up to 1920×1080 resolution.

Importing and previewing advertising videos, audios and pictures.

Multiple screen display in live view is supported, and the display sequence of channels is adjustable.

Live view screen can be switched in group, and manual switch and automatic cycle live view are also

provided, and the interval of automatic cycle can be adjusted.

Quick setting menu is provided for live view.

Motion detection, video tampering, VCA (Video Content Analysis) alarm, video exception alert and video

loss alert functions.

Privacy mask.

Multiple PTZ protocols supported; PTZ preset, patrol and pattern.

Zooming in by clicking the mouse and PTZ tracing by dragging mouse.

The NVR can server as a displayer. NVR, HDMI and VGAsignal source can be connected and displayed.

Advertising

One-touch advertising.

Video, audio and picture advertising files are supported.

Multiple formats are selectable when importing the advertising files.

Advertising files can be imported via USB storage device and web server.

Imported advertising files can be managed.

Support configuring preview sequence of advertising files.

HDD Management

One HDD is installed when delivery.

HDD capacity of 500 GB and 1 TB is selectable.

8 network disks (8 NAS disks, or 7 NAS disks+1 IP SAN disk) can be connected.

Support S.M.A.R.T. and bad sector detection.

HDD quota management; different capacity can be assigned to different channel.

Recording and Playback

Holiday recording schedule configuration.

User Manual of All-in-One Network Video Recorder

Continuous and event video recording parameters.

Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm, and VCA.

8 recording time periods with separated recording types each day.

Pre-record and post-record for alarm, motion detection for recording, and pre-record time for schedule and

manual recording.

Searching record files by events (alarm input/motion detection/VCA).

Tag adding for record files, searching and playing back by tags.

Playback of video files by sub-periods.

Locking and unlocking record files.

Searching and playing back record files by camera No., recording type, start time, end time, etc.

Smart search for the selected area in the video.

Zooming in when playback.

Reverse playback of multi-channel.

Supports pause, play reverse, speed up, speed down, skip forward, and skip backward when playback, and

locating by dragging the mouse.

Up to 8-ch synchronous playback.

Backup

Export video data by USB device.

Export video clips when playback.

Multiple formats are selectable when exporting the files.

Management and maintenance of backup devices.

Alarm and Exception

Configurable arming time of alarm input/output.

Alarm for video loss, motion detection, VCA, video tampering, HDD full, HDD error, network

disconnected, IP confliction, illegal login, abnormal record, etc.

Alarm triggers full screen monitoring, audio alarm, notifying surveillance center, sending email and alarm

output.

Automatic restore when system is abnormal.

Other Local Functions

Three-level user management; admin user is allowed to create many operating accounts and define their

operating permission, which includes the limit to access any channel.

Operation, alarm, exceptions and log recording and searching.

Manually triggering and clearing alarms.

Import and export of device configuration information.

Network Functions

1 self-adaptive 10M/100M/1000M network interface is provided.

IPv6 is supported.

TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS and iSCSI are supported.

TCP, UDP and RTP for unicast.

Auto/Manual port mapping by UPnPTM.

Access by HiDDNS with default or custom global server configuration.

Support access by EZVIZ Cloud P2P.

Remote reverse playback via RTSP.

Support accessing by the platform via ONVIF.

Remote search, playback, download, locking and unlocking of the record files, and the breakpoint resume

User Manual of All-in-One Network Video Recorder

is supported for downloading files.

Remote parameters setup; remote import/export of device parameters.

Remote viewing of the device status, system logs and alarm status.

Remote HDD formatting and program upgrading.

Remote system restart and shutdown.

Alarm and exception information can be sent to the remote host

Remotely start/stop recording.

Remotely start/stop alarm output.

Remote PTZ control.

Voice broadcasting.

Embedded WEB server.

Development Scalability:

SDK for Windows and Linux system.

Source code of application software for demo.

Development support and training for application system.

All-in-One Network Video Recorder User Manual

TABLE OF CONTENTS

Product Key Features ......................................................................................................................................5

Chapter 1 Introduction........................................................................................................................12

1.1 Front View.....................................................................................................................................13

1.2 IR Remote Control Operations......................................................................................................14

1.3 USB Mouse Operation ..................................................................................................................17

1.4 Input Method Description..............................................................................................................18

1.5 Rear View......................................................................................................................................19

Chapter 2 Getting Started ...................................................................................................................20

2.1 Starting Up and Shutting Down the NVR......................................................................................21

2.2 Setting Admin Password................................................................................................................22

2.3 Using the Wizard for Basic Configuration.....................................................................................23

2.4 Login and Logout..........................................................................................................................28

2.4.1 User Login........................................................................................................................28

2.4.2 User Logout......................................................................................................................28

2.5 Operating LCD Menu....................................................................................................................30

2.5.1 Configuring Displayer Parameters....................................................................................30

2.5.2 Switching Input Source.....................................................................................................31

2.6 Adding and Connecting the IP Cameras........................................................................................32

2.6.1 Activating the IP Camera..................................................................................................32

2.6.1 Adding the Online IP Cameras .........................................................................................33

2.6.2 Editing the Connected IP Cameras and Configuring Customized Protocols.....................36

Chapter 3 Live View.............................................................................................................................39

3.1 Introduction of Live View .............................................................................................................40

3.2 Operations in Live View Mode......................................................................................................41

3.2.1 Using the Mouse in Live View .........................................................................................41

3.2.2 Quick Setting Toolbar in Live View Mode .......................................................................42

3.3 Adjusting Live View Settings........................................................................................................45

Chapter 4 Advertising Configuration.................................................................................................46

4.1 Importing Advertising Files...........................................................................................................47

4.2 Advertising Preview......................................................................................................................48

4.2.1 One-touch Advertising......................................................................................................48

4.2.2 General Advertising..........................................................................................................49

4.3 Advanced Configuration ...............................................................................................................49

4.4 Managing Advertising Files...........................................................................................................50

Chapter 5 PTZ Controls......................................................................................................................52

5.1 Configuring PTZ Settings..............................................................................................................53

5.2 Setting PTZ Presets, Patrols & Patterns.........................................................................................54

5.2.1 Customizing Presets..........................................................................................................54

5.2.2 Calling Presets ..................................................................................................................54

5.2.3 Customizing Patrols..........................................................................................................55

5.2.4 Calling Patrols ..................................................................................................................56

5.2.5 Customizing Patterns........................................................................................................57

User Manual of All-in-One Network Video Recorder

5.2.6 Calling Patterns.................................................................................................................57

5.2.7 Customizing Linear Scan Limit........................................................................................58

5.2.8 Calling Linear Scan ..........................................................................................................59

5.2.9 One-touch Park.................................................................................................................59

5.3 PTZ Control Panel.........................................................................................................................61

Chapter 6 Recording Settings..............................................................................................................62

6.1 Configuring Parameters.................................................................................................................63

6.2 Configuring Recording Schedule ..................................................................................................65

6.3 Configuring Motion Detection Recording.....................................................................................68

6.4 Configuring Alarm Triggered Recording.......................................................................................70

6.5 Configuring VCA Triggered Recording.........................................................................................72

6.6 Manual Recording.........................................................................................................................74

6.7 Configuring Holiday Recording ....................................................................................................75

6.8 Files Protection..............................................................................................................................76

Chapter 7 Playback..............................................................................................................................77

7.1 Playing Back Record Files ............................................................................................................78

7.1.1 Instant Playback................................................................................................................78

7.1.2 Playing Back by Normal Search.......................................................................................78

7.1.3 Playing Back by Event Search..........................................................................................81

7.1.4 Playing Back by Tag.........................................................................................................83

7.1.5 Smart Playback.................................................................................................................85

7.1.6 Playing Back by System Logs ..........................................................................................87

7.1.7 Playing Back External File ...............................................................................................88

7.2 Auxiliary Functions of Playback ...................................................................................................90

7.2.1 Playing Back Frame by Frame..........................................................................................90

7.2.2 Digital Zoom.....................................................................................................................90

7.2.3 Playing Back by Sub-periods............................................................................................90

Chapter 8 Backup ................................................................................................................................92

8.1 Backing up Record Files ...............................................................................................................93

8.1.1 Quick Export.....................................................................................................................93

8.1.2 Backing up by Normal Video Search................................................................................95

8.1.3 Backing up by Event Search.............................................................................................97

8.1.4 Backing up Video Clips....................................................................................................98

8.2 Managing Backup Devices............................................................................................................99

Chapter 9 Alarm Settings..................................................................................................................100

9.1 Setting Motion Detection Alarm..................................................................................................101

9.2 Setting Sensor Alarms .................................................................................................................103

9.3 Detecting Video Loss Alarm........................................................................................................106

9.4 Detecting Video Tampering Alarm ..............................................................................................107

9.5 Handling Exceptions Alarm.........................................................................................................109

9.6 Setting Alarm Response Actions ................................................................................................. 110

9.7 Triggering or Clearing Alarm Output Manually .......................................................................... 113

Chapter 10 VCA Alarm....................................................................................................................... 114

10.1 Face Detection............................................................................................................................. 115

Otros manuales para DS-7600NI-E1/A

Tabla de contenidos

Otros manuales de Hardware de red de HIK VISION

HIK VISION

HIK VISION UD.6L0202B1986A01 Manual de usuario

HIK VISION

HIK VISION DS-7100NI-E1 Series Manual de usuario

HIK VISION

HIK VISION DS-96128NI-E16 Manual de usuario

HIK VISION

HIK VISION DS-76xxNI-Ex/xP Manual de usuario

HIK VISION

HIK VISION DeepinMind iDS-6700NXI-I/8F(B) Series Manual de usuario

HIK VISION

HIK VISION DS-7600NXI-K1 Series Manual de usuario

HIK VISION

HIK VISION HIK-7104NI Manual de usuario

HIK VISION

HIK VISION DS-MP7608HN Series Manual de usuario

HIK VISION

HIK VISION DS-9608NI-ST Series Manual de usuario

HIK VISION

HIK VISION S-7708NI-I4/8P Manual de usuario

HIK VISION

HIK VISION HWN-4116MH Manual de usuario

HIK VISION

HIK VISION NVST HNR Series Manual de usuario

HIK VISION

HIK VISION DS-7608NI-K2/8P/4G Manual de usuario

HIK VISION

HIK VISION DS-7108NI-E1/V/W Manual de usuario

HIK VISION

HIK VISION HiWatch Series Manual de usuario

HIK VISION

HIK VISION DS-7608NI-M2 Series Manual de usuario

HIK VISION

HIK VISION 7604NI-K1B Manual de usuario

HIK VISION

HIK VISION DS-76O4NI-K1 B Manual de usuario

HIK VISION

HIK VISION DS-7608NI-I2/8P Manual de usuario

HIK VISION

HIK VISION DS-7604NI-E1/4P Manual de usuario

HIK VISION

HIK VISION BCS-V-NVRXX02-4K Series Manual de usuario

HIK VISION

HIK VISION DS-7716NXI-I4/16P/4S Manual de usuario

HIK VISION

HIK VISION DS-7104NI-SL Manual de usuario

HIK VISION

HIK VISION HWN-2104H-4P Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario
