HIK VISION DS-K1200 Series Guía de inicio rápido

Title:

DS-K1100 Series Card Readers Connect

to DS-K2600 Series Access Controllers

by RS-485

Version:

v1.0

Date:

6/21/2017

Product:

Access Control Device

Page:

1 of 5

DS-K1200 Series Fingerprint Card Readers Connect to DS-

K1T200 Series Access Controll Terminal

Preparation

Connecting fingerprint card reader to access controll is mainly applied to swiping card or fingerprints to

open the door for entering and exiting. The models of card reader and access controller in this guide are

as below:

Card Reader

Access Control Terminal

DS-K1200MF

DS-K1T200MF/MF-C

DS-K1200EF

DS-K1T200EF/EF-C

Note

If the model of access control terminal is DS-K1T105E/E-C or DS-K1T200EF/EF-C, we suggest

customers should match the following several card readers, such as DS-K1102E/EK, DS-K1107E/EK and

DS-K1108E/EK; you can find the same symbol ‘E’in the access control terminal and card reader model

name, that means both devices can recognize the EM Card.

The ‘M’access control terminal should be matched the ‘M’card reader either, and they can recognize the

Mifare1 Card.

Notice

1. Please cut off power supply before wiring;

2. DS-K1200 Series Fingerprint Card Readers support private RS485 protocol; the details about RS-485

interface of fingerprint card reader are as below:

3. Correspondingly, there are RS485 interfaces in DS-K1T200 series access control terminal; the details

about RS-485 interface of DS-K1T200 series access control terminal are as below:

Color

Description

Blue

RS-485 -

Yellow

RS-485 +

Red

PWR (DC +12V)

Black

GND (Power Grounding)

Black

GND (RS-485 Grounding)

Interface

Color

RS485

RS485+

Yellow

RS485-

Blue

GND

Black

Title:

DS-K1100 Series Card Readers Connect

to DS-K2600 Series Access Controllers

by RS-485

Version:

v1.0

Date:

6/21/2017

Product:

Access Control Device

Page:

2 of 3

4. Please check the rear panel of card reader and unscrew it, you could find DIP switch module;

The No. of DIP switch from left to right is 1~4:

For example, the binary value of the above status is 0011.

Step 1: DIP Switch

Please set the DIP switch firstly before connecting the card reader, the binary value of the card reader is

0100, please set as the following picture;

Step 2: RS-485 Wiring

We recommend that customers use external power supply to fingerprint card reader.

Please connect card reader to door station as following picture:

Icon

Description

Represent 1 in binary mode

Represent 0 in binary mode

Power Input

RS485

Interface

RS485+

RS485-

GND

RS485-/Blue

RS485+/Yellow

Power GND

12V/Red

External Power

Supply

RS485 GND

Title:

DS-K1100 Series Card Readers Connect

to DS-K2600 Series Access Controllers

by RS-485

Version:

v1.0

Date:

6/21/2017

Product:

Access Control Device

Page:

3 of 3
