HIK VISION DS-k1106 Manual de usuario

DS-K1106 Series Card Reader

Installation Manual

UD.6L0206D1146A01

User Manual

Any and all information, including, among others, wordings, pictures, graphs

are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its

subsidiaries (hereinafter referred to be “Hikvision”). This user manual

(hereinafter referred to be “the Manual”) cannot be reproduced, changed,

translated, or distributed, partially or wholly, by any means, without the

prior written permission of Hikvision. Unless otherwise stipulated, Hikvision

does not make any warranties, guarantees or representations, express or

implied, regarding to the Manual.

About this Manual

This Manual is applicable to Card Reader

Series

Models

Description

DS-K1101

Series

DS-K1101M

MIFARE card reader (without keypad)

DS-K1101MK

MIFARE card reader (with a keypad)

DS-K1101C

CPU card reader (without keypad)

DS-K1101CK

CPU card reader (with a keypad)

DS-K1102

Series

DS-K1102M

MIFARE card reader (without keypad)

DS-K1102MK

MIFARE card reader (with a keypad)

DS-K1102C

CPU card reader (without keypad)

DS-K1102CK

CPU card reader (with a keypad)

DS-K1102E

EM card reader (without keypad)

DS-K1102 EK

EM card reader (with a keypad)

DS-K1102 EM

Dual-band card reader(without keypad)

DS-K1102 EMK

Dual-band card reader(with a keypad)

DS-K1103

Series

DS-K1103M

MIFARE card reader (without keypad)

DS-K1103MK

MIFARE card reader (with a keypad)

DS-K1103C

CPU card reader (without keypad)

DS-K1103CK

CPU card reader (with a keypad)

DS-K1104

Series

DS-K1104M

MIFARE card reader (without keypad)

DS-K1104MK

MIFARE card reader (with a keypad)

DS-K1104C

CPU card reader (without keypad)

Series

Models

Description

DS-K1104CK

CPU card reader (with a keypad)

DS-K11046

Series

DS-K1106M

MIFARE card reader（without keypad）

DS-K1106C

CPU card reader (without keypad)

DS-K1106S

ID card reader (without keypad)

The Manual includes instructions for using and managing the product.

Pictures, charts, images and all other information hereinafter are for

description and explanation only. The information contained in the Manual

is subject to change, without notice, due to firmware updates or other

reasons. Please find the latest version in the company website

(http://overseas.hikvision.com/en/).

Please use this user manual under the guidance of professionals.

Trademarks Acknowledgement

and other Hikvision’s trademarks and logos are the properties of Hikvision in

various jurisdictions. Other trademarks and logos mentioned below are the

properties of their respective owners.

Legal Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT

DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, IS

PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS, AND HIKVISION MAKES

NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,

MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR

PURPOSE, AND NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL

HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE

TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT

DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS

PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION,

IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS

BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF

iii

PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL NOT

TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE

OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK,

VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER,

HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.

SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT

LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO

ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION

SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH

ILLEGITIMATE PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE

APPLICABLE LAW, THE LATER PREVAILS.

0101011060112

Content

CHAPTER 1 PREVENTIVE AND CAUTIONARY TIPS ................... 2

CHAPTER 2 INTRODUCTION................................................... 3

2.1 FRONT VIEW .................................................................3

2.2 REAR VIEW ...................................................................4

2.3 SIDE VIEW ..................................... 错误!未定义书签。

CHAPTER 3 INSTALLATION ..................................................... 4

3.1 INSTALLING PSAM CARD .................................................4

3.2 INTRODUCTION FOR DIP SWITCH.......................................5

3.3 DEFINITION OF CABLE .....................................................6

3.4 WIRING CABLES.............................................................7

3.5 INSTALLING CARD READER................................................9

CHAPTER 4 SOUND PROMPT AND INDICATOR...................... 10

Chapter 1 Preventive and Cautionary

Tips

To guarantee the card reader works properly, please read and

obey the notes below.

If the card reader is powered by the controller, the power

supply distance is recommended to be no longer than 100m.

If the distance is longer than 100m, you are advised to power

the card reader by external 12V (range: -%10 ~ +%10) DC

power supply, which is nonswitched and linear.

To guarantee the communication between the controller and

the card reader, you must use RVVP cable above 0.5 to

connect them.

If the card reader is installed outside or in environment easy

to permeable, it is advisable to install a waterproof shield.

If you need to install several card readers, the distance

among them must over 30cm.

To reduce the noise in long distance transmission, the shield

of cable should connect to the GND of both controller and

card reader terminal.

Chapter 2 Introduction

DS-K1106 series card reader is a kind of high-performance

product, with a 32 bit high-speed processor. It communicates with

access controller via either RS-485 protocol or Wiegand protocol.

And a build-in tamper-proof module helps to protect card reader

from malicious damage. As to the physical appearance, the

PC+ABS material makes water proof and dust proof possible in

poor environment.

2.1 Front View

Figure 2-1 DS-K1106M/DS-K1106C/DS-K1106S

2.2 Rear View

Figure 2-2 Rear View of DS-K1106 Series

No.

Name

PSAM Card Slot (available for CPU card reader)

DIP Switch

Cable Interface of RS-485, Power, LED Control, etc.

Serial Port

Chapter 3 Installation

3.1 Installing PSAM Card

PSAM card slot is only available for CPU card reader.

Insert the PSAM card into the slot according to the direction

shown below.

Figure 3-1 PSAM Card Slot

3.2 Introduction for DIP Switch

The DIP switch module is shown below. The No. of DIP switch

from left to right is 1 ~ 8.

Figure 3-2 DIP Switch Module

Table 3-1 Description of DIP Switch

Icon

Description

Represent 1 in binary mode

Represent 0 in binary mode

For example, binary value of the following status is: 0000 1100.

Figure 3-3 DIP Switch Module

Table 3-2 Description of DIP Switch

No.

Description

DIP Switch Status

1 ~ 4

Address of RS-485

1: 1

No.

Description

DIP Switch Status

0: 0

Read card No. or file in card.

(Only available for CPU card

reader.)

1: read card No;

0: read file in card.

Wiegand protocol or RS-485

protocol.

1: Wiegand protocol;

0: RS-485 protocol.

Wiegand Protocol

(available when No. 6 is 1)

1: Wiegand protocol

of 26-bit;

0: Wiegand protocol

of 34-bit.

Matched Resistance

(available for RS-485 protocol)

1: Enable;

0: Disable.

3.3 Definition of Cable

The description of 10 cables is shown below.

Table 3-3 Description of Cable

Color

Description

Yellow

RS-485+

Brown

Blue LED Control (available for Wiegand Protocol)

Blue

RS-485-

Purple

Beep Control (available for Wiegand Protocol)

Gray

Case Sensor (available for Wiegand Protocol)

Green

Wiegand W0 (available for Wiegand Protocol)

White

Wiegand W1 (available for Wiegand Protocol)

Black

GND

Orange

Red LED Control (available for Wiegand Protocol)

Red

PWR (DC +12V)
