User Manual

Models covered in this user manual:

K304 - Secure 4-port KM Switch w/audio

K304E - Secure 4-port KM Switch w/audio and DPP

K308 –Secure 8-port KM Switch w/audio

Rev: 2.9 Doc No: HDC06147

K304x-K308 Secure KM Switch User Manual

4 & 8 port Secure KM Switch User Manual

Table of Content

Introduction ....................................................................................... 2

What is KM?....................................................................................... 2

Package Contents............................................................................... 2

Security Features ............................................................................... 3

Operational Features ......................................................................... 4

What is Virtual Display Technology (VDT)?........................................ 5

Equipment Requirements .................................................................. 6

Safety Precautions ............................................................................. 7

Front Panel Features.......................................................................... 8

Rear Panel Features –K304E ............................................................. 9

Tamper Evident Labels..................................................................... 10

Before Installation............................................................................ 13

Installation ....................................................................................... 14

Typical System Sketch –K304E ........................................................ 16

Driver Installation............................................................................. 20

Operation......................................................................................... 21

DPP Operation.................................................................................. 22

Troubleshooting Guide .................................................................... 24

Record of Revisions

Rev

Date

Description of changes

2.4

June 19, 2012

Added K308 device

2.5

July 9, 2012

Web based configuration, function keys

2.6

Sept 19, 2012

Web based configuration process and

default settings updated

2.7

Oct 14, 2012

Changed pre-config. shortcuts (added

F11)

2.8

April 4, 2013

Removed PS/2 from K308

2.9

July 31, 2015

Images and text updated

4 & 8 port Secure KM Switch User Manual

Introduction

Thank you for purchasing this HSL Secure KM Switch. This KM Switch

is designed for use in secure defense and intelligence environments

across wide security gaps. This 3rd Generation Secure KM Switch

offers optical data diode per channel. Optical data diodes are used to

prevent data transfer between connected computers running at

different security levels even if these computers attempts to attack

the KM. This product provides the highest security safeguards and

features that meet today’s and will meet future cyber prevention

requirements.

This User Manual provides all the details you’ll need to install and

operate your new product, in addition to troubleshooting guidance—

in the unlikely event of a problem.

What is KM?

There are many cases where one computer user needs to work

simultaneously with few computers. In some cases users are having

multiple displays attached to these multiple computers. The

challenge is how a single user can interact with multiple computers

having multiple displays. KMs would not do a good job for these users

as they were designed to switch displays as well.

KM switch is a device that switches a single set of keyboard and

mouse between multiple computers. KM switch is essentially a KM

switch without the video switching - all displays are continuously

connected to their respective computers.

Package Contents

Inside product packaging you will find the following:

HSL Secure KM Switch unit

12V 1.5 A wall-mounted power Supply (K304x models) or

AC power cable (K308 model)

Important: This product is equipped with always-on active

anti-tampering system. Any attempt to open the product

enclosure will activate the anti-tamper triggers and render the

unit inoperable.

If the unit’s enclosure appears disrupted or if all the channel-

select LEDs flash continuously, please remove product from

service immediately and contact HSL Technical Support.

4 & 8 port Secure KM Switch User Manual

Security Features

HSL Secure KM Switch is the most advanced and secure commercially

available KM Switch available today. Below is a summary of some of

the security features incorporated into the product.

Unidirectional Data Paths

Optical diodes used to enforce unidirectional data flow from the

peripheral devices to computers preventing potential leakage paths

between computers even in the severe threat of two infected

computers attacking the KM.

No Shared Resources

This KM Switch designed to securely operate even when peripheral

devices are vulnerable to signaling attacks. This KM Switch does not

allow computer access to any shared resource and does not share

controllable power sources.

Dedicated Processors for Emulation

The Switch features a dedicated processor per computer port to

emulate peripheral devices. This keeps each computer running on

different security levels physically separated and secure at all times,

and prevents any unintended data leakage between computers.

Non-Reprogrammable Firmware

The Switch features custom firmware that is not reprogrammable,

preventing the ability to remotely attack the KM control logic.

USB Ports Protection

Console USB ports are protected from the use of storage and other

unsafe USB devices through strong filtering (independent of

computer protection means). Unqualified devices are rejected when

connected to the Switch. Only mouse and keyboard data are passed

through.

Heavy-duty Steel Enclosure

HSL Secure KM Switches uses thick steel components to protect the

product from physical tampering and to minimize radiated

electromagnetic emissions that can be snooped or intercepted.

Active Always-On Anti-Tamper

Active chassis anti-tamper system prevents the KM electronic

circuitry from being accessed and tampered with by permanently

disabling the product once tampering is detected.

Holographic Tamper-Evident Labels

Four serially numbered holographic security tamper-evident labels

are placed on the enclosure surface to provide a visual indication if

the Switch has been opened or compromised.

Dedicated Peripheral Port (K304E)

HSL patented Dedicated Peripheral Ports enables secure use of CAC

or smart-card readers leveraging security.

Common Criteria Listing

The Switch is listed by the Common Criteria organization.

4 & 8 port Secure KM Switch User Manual

Operational Features

The HSL Secure KM Switch was designed with the user in mind for

today’s IT environment. Below is a summary of some of the features

incorporated into the Product.

Virtual Display Technology (VDT)

VDT allows the KM to switch automatically between computers once

mouse cursor crosses display borders. Seamless switching between

multiple computers with cusrsor movement.

Support for multiple head

Product can be easily configured to support dual, triple and up to 16

head computers through signed software driver. Note that single

head installation does not need any software installation.

Extensive administrator setup options

Administrator mode provides many customized settings from display

arrangement, size to cursor speed and acceleration.

Dedicate Peripheral Port (K304E only)

HSL K304E Secure KM Switch products supports parallel switching of

wide set of user authentication devices including CAC, smart-card

and biometric readers.

Audio Support

The KM Switch support audio out switching. Microphone switching

not supported to prevent analog leakages through audio ports.

KM Extenders Support

HSL Secure KM Switch supports most copper and fiber KM extenders

connected to the console port.

4 & 8 port Secure KM Switch User Manual

What is Virtual Display Technology (VDT)?

Virtual Display Technology (VDT) is implemented in HSL Secure KM

switches series to enable seamless cursor and keyboard switching

between multiple displays. VDT allows administrators to configure

any desired displays configuration with same or different size and

resolution. User simply moves mouse cursor across neighboring

displays to switch between connected computers.

Refer to the example in the figure at the right side. Assume that

computer #1 is connected to the left display, computer #2 is

connected to the top display, computer #3 is connected to the center

bottom display and computer #4 is connected to the display at the

right side. In this example all four displays are identical. VDT allows

the user to move the mouse cursor across the four displays while

automatically switch the shared peripherals based on the current

cusrsor location. For example when the user moves the cursor from

the left display to the center bottom display, the KM identifies the

display boarder crossing between these two displays and switches

the KM to computer #3.

HSL VDT is now further enhanced with the inclusion of pointing

device drivers to support dual, triple and up to 16 head computers.

With this technology user workstation may be integrated with any

combination of single, dual, triple and quad head computers.

VDT Configurator software enables the user administrator to easily

configure any set of display sizes, resolutions, geometry and physical

arrangements.

4 & 8 port Secure KM Switch User Manual

Equipment Requirements

Cables

It is highly recommended to use HSL Cable Kits for product to ensure

optimal security and performance.

One Cable Kit is required per connected computer.

Operating Systems

Product is compatible with devices running on the following

operating systems:

• Microsoft® Windows®

• Red Hat®, Ubuntu® and other Linux® platforms

• Mac OS® X v10.3 and higher.

USB Keyboard console port

The product console USB keyboard port is compatible with Standard

USB keyboards.

Notes:

a. For security reasons products do not support wireless

keyboards. In any case do not connect wireless keyboard to

product.

b. Non-standard keyboards, such as keyboards with integrated

USB hubs and other USB-integrated devices, may not be fully

supported due to security policy. If they are supported, only

classical keyboard (HID) operation will be functional. It is

recommended to use standard USB keyboards.

USB Mouse console port

The product console USB mouse port is compatible with standard

USB mice.

Notes:

a. Console USB keyboard and mouse ports are switchable, i.e.

you can connect keyboard to mouse port and vice versa.

However, for optimal operation it is recommended to

connect USB keyboard to console USB keyboard port and

USB mouse to console USB mouse port.

b. Console USB mouse port supports Standard KVM Extender

composite device having a keyboard/mouse functions.

c. For security reasons products do not support wireless mice.

In any case do not connect wireless mouse to product.

PS/2 Mouse and Keyboard console ports

The product console PS/2 keyboard and mouse ports are compatible

with standard PS/2 keyboards and mice.

User Audio Devices

Product is compatible with the following types of user audio

devices:

Stereo headphones;

Amplified stereo speakers.

Note: In any case do not connect a microphone to product audio

output port including headsets.

DPP Port (K304E)

The product operates with authorized USB devices plugged into the

console DPP Port, such as USB smart-card reader or Common Access

Card (CAC) reader.

Programming Cable

In order to use HSL’s external configuration tool it is required to

purchase and use HSL USB Type-A to USB Type-A Programming

cable (1.8 m).

4 & 8 port Secure KM Switch User Manual

Safety Precautions

Please read the following safety precautions carefully before using

the product:

Before cleaning, disconnect the product from DC or

AC power.

Be sure not to expose the product to excessive

humidity.

Be sure to install the product on a clean secure

surface.

Do not place the DC/AC power cord in a path of foot

traffic.

If the product is not used for a long period of time,

remove the product’s wall-mount power supply from

the mains jack.

If one of the following situations occurs, get the

product checked by a qualified service technician:

The product’s power supply is overheated,

damaged, broken, causes smoke or shortens

the mains power socket.

Liquid penetrates the product’s case.

The product is exposed to excessive moisture

or water.

The product is not working well even after

carefully following the instructions in this

user’s manual.

The product has been dropped or is physically

damaged.

The product has obvious signs of breakage or

loose internal parts.

The product should be stored and used only in

temperature and humidity controlled environments

as defined in the product’s environmental

specifications.

The wall-mount power supply used with this product

should be the model supplied by the manufacturer

or an approved equivalent provided by HSL or an

authorized service provider. The use of improper

power source will void product warranty.

4 & 8 port Secure KM Switch User Manual

Front Panel Features

1 –Steel enclosure

2 –DPP (Dedicated Peripheral Port) Freeze push-button and Status LED

3 –DPP channel select LEDs

4 –Channel Select push-buttons and LEDs

5a-5b –Holographic Tamper Evident Labels

Note:

-K304 is identical except for not having DPP freeze LEDs & button

-K308 is identical except for having 8 channel select push buttons and not

having DPP freeze LEDs & button

4 & 8 port Secure KM Switch User Manual

Rear Panel Features –K304E

Console ports:

1 DPP port

2 Audio console output 3.5 mm stereo jack

3 USB Mouse & Keyboard jack

4 PS/2 Mouse & Keyboard jack

Computer group ports:

5 Computer Keyboard/Mouse USB jack

6 Computer audio input jack 3.5 mm stereo

7 Computer DPP (USB) port

8 Power port

9 Holographic Tamper Evident Labels

Note:

-K304 is identical except for not having DPP ports in console and computer areas

-K308 is identical except for having 8 computer areas and not having DPP ports in console and

computer areas nor PS/2 ports in console area

Otros manuales para K304

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de High Sec Labs

High Sec Labs

High Sec Labs SK81DU-3 Manual de usuario

High Sec Labs

High Sec Labs SK21 N Series Manual de usuario

High Sec Labs

High Sec Labs SK21PH-4 Manual de usuario

High Sec Labs

High Sec Labs Mini-Matrix SX42DU-3 Manual de usuario

High Sec Labs

High Sec Labs SK21D-3 Manual de usuario

High Sec Labs

High Sec Labs SC42PHU-4 Manual de usuario

High Sec Labs

High Sec Labs K304 Manual de usuario

High Sec Labs

High Sec Labs FV11D-M Manual de usuario

High Sec Labs

High Sec Labs Mini-Matrix SX22D-3 Manual de usuario

High Sec Labs

High Sec Labs SM20-4 Manual de usuario

High Sec Labs

High Sec Labs SM20N-3 Manual de usuario

High Sec Labs

High Sec Labs SM20N-3 Manual de usuario

High Sec Labs

High Sec Labs SX82PHU-4T Manual de usuario

High Sec Labs

High Sec Labs SM40N-4 Manual de usuario

High Sec Labs

High Sec Labs Mini-Matrix SX22D-3 Manual de usuario

High Sec Labs

High Sec Labs K204 Manual de usuario

High Sec Labs

High Sec Labs Mini-Matrix SX22D-3 Manual de usuario

High Sec Labs

High Sec Labs SC42PHU-N Manual de usuario

High Sec Labs

High Sec Labs DK22D-3 Manual de usuario

High Sec Labs

High Sec Labs SC21H-M Manual de usuario

High Sec Labs

High Sec Labs SK41 N Series Manual de usuario

High Sec Labs

High Sec Labs SX42 U-3 Series Manual de usuario

High Sec Labs

High Sec Labs K404F Manual de usuario

High Sec Labs

High Sec Labs K244E Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
