Herschel T-MKW Manual de usuario
T-MKW Mains powered WiFi thermostat -White
Installation and Operating Instructions
Herschel Infrared Ltd declares that the radio equipment type T-MKW Wireless Thermostat is
in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at:
https://www.herschel-infrared-technology-center.com/compliance/
English
Safety
For indoor use only. Keep your device completely dry. This
product must be installed by a competent person and in
accordance with all the EU and national regulations.
Always isolate the AC mains supply before
installing or working on any components that
require 230V AC 50 Hz mains.
This appliance is rated IPX0 and must be installed outside of
the splash zones in bathrooms. Use the supplied external
thermostat sensor if necessary to allow temperature
sensing in damp locations while keeping the thermostat
unit dry.
English
Technical Information
Frequency: WiFi 2.4 GHz
Power Supply: 100-240V AC, 50/60Hz
Current: 16 Amps
Setpoint range: 5-45°C
Accuracy: +/- 1°C
Sensor: NTC10kB 25/50: 3950K
Housing: PC+ABS (Fire retardant)
English
Home Screen Quick Reference
White button functions:
Quick press: Switch mode
Long press: Power on/off
1
Corner buttons:
Quick press: Increase temperature
Quick press: Decrease temperature
Long press: Enter pairing mode
Mode Setting: Sleep / Home / Away / Auto
If there is no any mode icon displayed,
the thermostat is in manual mode.
Auto mode is only set up in the app
Network state: Connected to WiFi
The heater is switched on.
Temperatures:
a. Current temperature: without icon
displays the room temperature
b. Setpoint temperature: with icon displays
the setpoint temperature
English
Installation
1. Ensure mains power is off
2. Gently open the T-MKW at points (marked ‘A’ on image) using a flat-headed
screw driver.
3. Connect clamps 1 & 4 to the heater
4. Connect clamp 2 to Mains in: Live
5. Connect clamp 3 to Mains in: Neutral
6. If using in damp rooms (e.g. bathrooms), connect the external sensor and
remember to select “Sensor External” in the app, once paired.
7. The T-MKW is a Class II electrical appliance and does not require an Earth
connection. However, the heater is a Class I appliance and must still be earthed.
Connect the heater earth lead to the mains earth separate from the thermostat
(connection not supplied).
8. Fix the thermostat to the back box via points (marked ‘B’ on image)
9. Replace the front of the thermostat. Switch mains on.
English
Connect to the Internet
a. Download and Install the Smartlife app App from the App Store or Google Play.
b. Click the bottom right corner button for 3s, will flash quickly.
c. In SmartLife, click ‘+’ in the top right to add a device. Select Small Home Appliances
and scroll to find Thermostat (Wifi).
d. Input the SSID and password, confirm the symbol is flashing quickly and let the
pairing process complete.
Voice Control
Click ‘ ’ on the right bottom corner of the ‘All Devices’ home page. Then enter ‘Third
Party Voice Services’ to integrate to third-party services like Alexa, Google Assistant,
etc. Then follow the steps as shown.
English
Advanced Settings
With the thermostat switched on, long press the right and left buttons
simultaneously to enter the advanced settings. Change settings using either the
right or left button and select the next function by pressing the white button.
1. Open Window: Set ‘01’ to enable Open Window. Set ‘00’ to switch it off.
2. Adaptive Start: Set ‘01’ to enable Adaptive Start. Set ‘00’ to switch it off.
3. Sensor type: Default is: 00, Internal: 00, External: 01, Internal and External: 02.
4. High temperature protection: 20 -90°C. Default is 65°C.
5. Controller Lag (Hysteresis): 1 - 9°C. Default is 2°C.
6. Temp calibration: -9°C -+9°C. Default is 0°C.
7. Highest target temperature: 35 -90°C. Default is 35°C.
8. Lowest target temperature: 0 -30°C. Default is 5°C.
9. Home mode target temperature: Default is 22°C.
a. Sleep mode target temperature: Default is 20°C.
b. Away mode target temperature: Default is 15°C.
c. System restart: Press left or right corner buttons to switch the ‘ - -‘ to ‘==’ and
wait for 5s.
d. Factory Setting: Press left or right corner buttons to switch the ‘- -‘ to ‘==’ and
wait for 5s.
English
Other Operations
a. Temperature protection warning:
If the High Temperature limit (set in Advanced Settings step 4) is ever
exceeded, ‘…’ will flash and the heater will stop working. Lower the
setpoint temperature to cancel.
b. If the WiFi icon ‘ ’ flashes slowly, the wifi connection has failed.
c. Open Window:
The Open Window function will switch off the heating for 15 minutes if the
temperature drops 3˚C in 1 minute. You can switch the Open Window function
on and off in the Advanced settings.
d. Adaptive Start:
In Smart mode, the heating switches on in advance of the next period
to ensure the next target temperature is reached by the start of that
period. You can switch Adaptive Start on and off in the Advanced
settings.
e. Specialist High Temperature setting (e.g. Hot Yoga).
For specialist high temperature uses such as hot yoga, you must override
the high temperature setting (default is 35°C) in the advanced settings (8).
The SmartLife app is a 3rd party app that is constantly evolving and future versions
may have some differences to these printed instructions which were correct at time
of printing.
English
2 Year Warranty
Register your product at the Helpful Resources section of your local Herschel
website.
Within two years from date of purchase Herschel will repair or replace the T-MKW
where the fault is due to defects in materials or workmanship. This warranty is for
standard domestic use only and excludes commercial uses. In the event of a
warranty claim please visit the Herschel Website and use the Contact Us form to get
in touch with Customer Services. You will need proof of purchase.
Note your serial number here:
250522
