Heatmiser NeoX Manual de usuario

The Heatmiser neoX is designed to extend the communication distance

between neoStats.

The neoX needs to be connected to your system and you do this via the free

App that can be downloaded from the Apple App Store, Google Play Store,

Amazon App Store or Windows Phone Store .

To add the neoX to your system, select Manage Zones > Add repeater from the

global menu in the App.

To remove the neoX from your network press and hold the Connect button

for 10 seconds. The Link and Radio Signal LEDs will go out indicating it has been

removed from your network.

Introduction

Factory Reset

Twitter: heatmiseruk Facebook: facebook.com/thermostats

Want More Information?

Call our support team on: +44 (0)1254 669090

Or view technical specifications directly on our website:

www.heatmiser.com

PDF FAQ

The Heatmiser neoX is designed to extend the communication distance

between neoStats.

The neoX needs to be connected to your system and you do this via the free

App that can be downloaded from the Apple App Store, Google Play Store,

Amazon App Store or Windows Phone Store .

To add the neoX to your system, select Manage Zones > Add repeater from the

global menu in the App.

To remove the neoX from your network press and hold the Connect button

for 10 seconds. The Link and Radio Signal LEDs will go out indicating it has been

removed from your network.

Introduction

Factory Reset

Rev 1.0

Twitter: heatmiseruk Facebook: facebook.com/thermostats

Want More Information?

Call our support team on: +44 (0)1254 669090

Or view technical specications directly on our website:

www.heatmiser.com

PDF FAQ

Rev 2.0

The Heatmiser neoX is designed to extend the communication distance

between neoStats.

The neoX needs to be connected to your system and you do this via the free

App that can be downloaded from the Apple App Store, Google Play Store,

Amazon App Store or Windows Phone Store .

To add the neoX to your system, select Manage Zones > Add repeater from the

global menu in the App.

To remove the neoX from your network press and hold the Connect button

for 10 seconds. The Link and Radio Signal LEDs will go out indicating it has been

removed from your network.

Introduction

Factory Reset

Twitter: heatmiseruk Facebook: facebook.com/thermostats

Want More Information?

Call our support team on: +44 (0)1254 669090

Or view technical specications directly on our website:

www.heatmiser.com

PDF FAQ

1 2

3 4

Installation Procedure

Please read the instructions fully so you get the best from our product.

LED Status Wiring Diagram - NeoX

Power Switch

Connect Button

There are 3 LEDs in use on the neoX

Power LED Permanently on when the neoX is powered.

Link LED Permanently on once the neoX has been paired to the network.

Radio Signal LED Permanently on whilst the neoX is in range of the network.

Power LED

Link LED

Radio Signal LED

Stylish Thermostats For Modern Living

N L

Neutral

Live

230VAC

Mains Supply In

Recommendations

Max Cable Size - 1.5mm

Back Box Depth - 35mm

The neoX is designed to be flush mounted and requires a back box of 35mm

(minimum depth) to be sunk into the wall prior to installation.

Step 1

Carefully separate the front half of the neoX from the back plate by placing

a small flat head terminal driver into the slots on the bottom face of the neoX.

Step 2

Place the neoX front somewhere safe.

Terminate the neoX as shown in the wiring diagram.

Step 3

Screw the neoX back plate securely into the back box.

Step 4

Clip the front of the neoX back onto the neoX back plate.
