Hdav HD?C5S4 Manual de usuario



HDMIAudio&VideoSingle

CAT5/RJ45ExtenderKit

UserManual

(HD‐C5S4)



[MustbeusedwithSolidCAT5eorCAT6Cable]



Allinformationissubjecttochangewithoutnotice.

Allnames&trademarksarepropertyoftheirrespectiveowners.

Rev.1108



MadeinTaiwan

SafetyandNotice

TheHD‐C5S4HDMIAudio&VideoSingleCAT5/RJ45ExtenderKithasbeentestedforconformanceto

safetyregulationsandrequirements,andhasbeencertifiedforinternationaluse.However,likeall

electronicequipments,theHD‐C5S4shouldbeusedwithcare.Pleasereadandfollowthesafety

instructionstoprotectyourselffrompossibleinjuryandtominimizetheriskofdamagetotheunit.



zFollowallinstructionsandwarningsmarkedonthisunit.

zDonotattempttoservicethisunityourself,exceptwhereexplainedinthismanual.

zProvideproperventilationandaircirculationanddonotusenearwater.

zKeepobjectsthatmightdamagethedeviceandassurethattheplacementofthisunitisonastable

surface.

zUseonlythepoweradapterandpowercordsandconnectioncablesdesignedforthisunit.

zDonotuseliquidoraerosolcleanerstocleanthisunit.Alwaysunplugthepowertothedevicebefore

cleaning.

TableofContents

◇ INTRODUCTION……………………………..………………..…………………………………………………..p.2

◇ PANELDESCRIPTION………………………..…………………………….…………………………………..p.4

◇ HARDWAREINSTALLATION………………………….……………………………………………………..p.6

◇ EDIDLEARNING………………………….……………………..……………………..………………………..p.6

◇ CONNECTIONDIAGRAM…………..…………………….…………………………………………………..p.7

◇ PINDEFINITION…………………………………………….………….…………………………………………p.8

◇ NOTICE……………………………………………………………………………………………………………….p.9

INTRODUCTION

TheHD‐C5S4HDMIAudio&VideoSingleCAT5/RJ45ExtenderKitboostsupyourvideo/audio

transmissiondistanceupto60m(200ft)inHDTV1080iformat,40m(130ft)inHDTV1080pformat,and

20m(65ft)inHDTV1080pwith36‐bitcolordepth.HD‐C5S4alsosupportsthemostadvanced3Dvideo

formatcomplaintwithHDMIandthereforeguaranteesthehighest3Dvideocompatibilityonthemarket.

WithonlyonecosteffectiveCat.5/5e/6cable,userscanreadilyextendHDTVsourcesfromDVDplayers,

Blu‐rayDiscplayer,PS3,PC,andanyotherkindsofsourcescompliantwithTMDStodistantdisplay

monitorsincludingHDMIorDVIenabledTVsetsorLCDPCmonitors.Withtheadvanceddesignforthe

latestHDMItechnology,deepcolorvideo,DTS‐HDMasterAudioorDolbyTrueHDaudio,andHDCP

supportsandcompatibilityareallfurtherinsured.ThisflexibilitymakesHDCPcompliantDVDplayersorPS3

transmitutmosthighqualityvideoandaudiowithagreaterdistanceattheminimalcost,whenintegrating

severalcomponentsapart.Inaddition,HD‐C5S4isalsoequippedwithbi‐directionalIRpass‐throughpath.

ThisbonusfeatureallowsuserstoboostIRcontroldistanceupto100m(330ft)andmakesIRcontrol

possiblethroughonlysingleCat.5/5e/6cableincludingHDMIsignals.

TheHD‐C5S4includestwounits:transmittingunitofHD‐C5S4andreceivingunitofHD‐C5S4.The

transmittingunitisusedtocapturetheinputHDMI/DVIsignalswithIRcontrolpacketsandcarrythe

signalsviaonecosteffectiveCat.5/5e/6cable.Thereceivingunitisresponsibleforequalizingthe

transmittedHDMIsignalandreconstructingIRsignals.Thetransmissiondistancebetweenthesendingand

receivingunitscanbeupto60m(200ft)atHD720por1080i;or40m(130ft)atFullHD1080p.Withan

8‐levelequalizationrotarycontrolonthereceivingunit,userscanadjusttheequalizationstrengthtothe

receivedHDMIsignalsaccordingly,andthereforeoptimizethetransmissiondistancebetweensourceand

destination.



Features

zSupportHDMIDeepColor&full3D

zExtendthetransmissionupto60m(200ft)fromtheHDMIsourceatHD1080ior720p24‐bit

zExtendthetransmissionupto40m(130ft)fromtheHDMIsourceatFullHD1080p24‐bit

zExtendthetransmissionupto20m(65ft)fromtheHDMIsourceatFullHD1080p36‐bit

zHDCP1.1compliant

zMinimizethecableskewbyadjustable8‐levelequalizationcontrol

zPureunaltereduncompressed7.1chdigitalHDMIoverCat.5/5e/6cabletransmission

zDTS‐HDMasterAudioandDolbyTrueHDhighbitrateaudiosupport

zAllowscascading

zWallmountinghousingdesignforeasyandrobustinstallation

zPerfectlyintegratedwithotherHDMIoverCat.Xseriesproducts



Theclaimedtransmissiondistancehereissubjecttothegradeofinstalledcable(s),sourcedeviceand

display.

ForoverCAT.Xtransmission,thecable(s)hastobesolid,notstranded.Anykeystonejackalongthe

transmissionpathwillkillthetransmissionperformancesignificantly!

Specifications&PackageContents

ModelNameHD‐C5S4

Technical

RoleofusageTransmitter[TX] Receiver[RX]

HDMIcomplianceYes

HDCPcomplianceYes

VideobandwidthSingle‐link225MHz[6.75Gbps]

Videosupport480i/480p/720p/1080i/1080p60

HDMIoverUTP

transmission[24‐bit]

FullHD(1080p)‐40m(130ft)[CAT5e]/50m(165ft)[CAT6]

HD(720p/1080i)‐50m(165ft)[CAT5e]/60m(200ft)[CAT6]

AudiosupportSurroundsound(upto7.1ch)orstereodigitalaudio

SignalEqualization8‐leveldigitalcontrolatRX

InputTMDSsignal1.2Volts[pea

‐to‐peak]

InputDDCsignal5Volts[pea

‐to‐peak,TTL]

ESDprotection[1]Humanbodymodel—±19kV[ai

‐gapdischarge]&±12kV[contactdischarge]

[2]Corechipset—±8kV

PCBstac

‐up4‐layerboard[impedancecontrol—differential100Ω;single50Ω]

Input1xHDMI 1xRJ45

Output1xRJ45 1xHDMI

HDMIsourcecontrolControllableviaIRpass‐throughfromRXtoTXwithIRextenders

HDMIconnectorTypeA[19‐pinfemale]

RJ45connectorWE/SS8P8Cwith2LEDindicators

RotarycontrolswitchEDIDMode Signallevel

Mechanical

HousingMetalenclosure

DIMENSIONS

[LxWxH]

Model91x60x24mm[3.6"x2.4"x0.9"]

Package270x175x80mm[10.6"x6.9"x3.1"]

WeightModel198g[7oz] 194g[6.8oz]

Package780g[1.7lbs]

FixednessWall‐mountingcasewithscrews

Powersupply5V2ADC

Powerconsumption3Watts

Operationtemperature0~40°C[32~104°F]

Storagetemperature‐20~60°C[‐4~140°F]

Relativehumidity20~90%RH[nocondensation]

PackageContents

1xHD‐C5S4[TX&RX]

2xDC5V2Awallwart

1xUserManual

PANEL DESCRIPTION

InputPanel—HD‐C5S4Transmitter(TX)

MODE:0‐EDIDFull‐HD(1080p@60)‐24bit2Dvideo&7.1chaudio

1‐EDIDFull‐HD(1080p@60)‐24bit2Dvideo&2chaudio

2‐EDIDFull‐HD(1080p@60)‐36bit2Dvideo&7.1chaudio

3‐EDIDFull‐HD(1080p@60)‐36bit2Dvideo&2chaudio

4‐EDIDHD(1080p@30)(1080i@60)(720p@60)‐24bit2Dvideo&7.1chaudio

5‐EDIDHD(1080p@30)(1080i@60)(720p@60)‐24bit2Dvideo&2chaudio

6‐EDIDFull‐HD(1080p@60)‐36bit3Dvideo&2chaudio

7‐EDIDlearningmode

HDMIIN:ConnectstoaHDMIsourcewithaHDMImale‐malecable



OutputPanel—HD‐C5S4Transmitter(TX)



+5VDC:Connectto5VDCpowersupply.

HDMISignalOUT:PluginaCat‐5/5 e /6 cablethatneedstobelinkedtothetransmitting

unitofHD‐C5S4.



InputPanel—HD‐C5S4Receiver(RX)

+5VDC:Connectto5VDCpowersupply.

HDMISignalIN:PluginaCat‐5/5 e /6 cablethatneedstobelinkedtothereceivingunitofHD‐C5S4.



OutputPanel—HD‐C5S4Receiver(RX)

SignalLevel:Adjustthe8‐levelequalizationcontroltothereceivedHDMIsignals.TheHDMIsignallevel

variesfrom0(strongest)to7(weakest)forrespectivetransmissionlengthfromlongestpossiblerange

toshortdistance.Pleaseadjustthesignallevelfrom7to0andstopturningtherotaryswitch

whenevertheaudio/videoisplayingnormally.Inappropriatesignallevelsettingmaycause

overpoweringissuethatwouldshortentheproductlifesignificantly!

HDMIOUT:ConnecttoaHDMIdisplaywithaHDMImale‐malecable.

HARDWARE INSTALLATION

1.ConnectaHDMIorDVIsource(suchasaBlu‐rayDiscplayer)tothetransmittingunitofHD‐C5S4.

2.ConnectaHDMIorDVIdisplay(suchasaLCDTV)tothereceivingunitofHD‐C5S4.

3.ConnectIRBlaster/ReceivertobothTXandRXunits.

4.ConnectaCat‐5/5 e /6 cablebetweenthetransmittingandreceivingunits.

5.MakesurethisCat‐5/5 e /6 cableistightlyconnectedandnotloose.

6.Plugin5VDCpowersupplyunittothepowerjackofthereceivingunitofHD‐C5S4.

7.Plugin5VDCpowersupplyunittothepowerjackofthetransmittingunitofHD‐C5S4.

8.Ifyouseeflickeringorblinkingimageonthedisplay,pleaseadjusttherotarycontrolswitchtoimprove

thecableskew.0standsforthestrongestHDMIsignallevelforlongestpossibletransmissionlength

while7standsfortheweakestHDMIsignallevelforshorttransmissionlength.Pleaseadjustthesignal

levelfrom7to0andstopturningtherotaryswitchwhenevertheaudio/videoisplayingnormally.

Inappropriatesignallevelsettingmaycauseoverpoweringissuethatwouldshortentheproductlife

significantly!



EDID LEARNING

1. TurnofftransmittingunitofHD‐C5S4anddisconnecttheCat.5/5e/6betweentransmittingand

receivingunits.

2. ConnecttheHDMIdisplayto"HDMIIN"onthetransmittingunitwithaHDMIcable.

3. Set"MODE"onthetransmittingunitat7.

4. Turnonthetransmittingunit.

5. TheLEDontheRJ45oftransmittingunitwilldimandlightagain,whichindicatestheEDIDlearning

procedureiscomplete.

6. UnplugtheHDMIcablefromthedisplayandfollowtheinstructionin[HardwareInstallation]tosetup

theHD‐C5S4andenjoytheexperience.



CONNECTION DIAGRAM



PIN DEFINITION

HDMI

TypeA(Receptacle)HDMI

Pin1TMDSData2+Pin11TMDSClockShield

Pin2TMDSData2ShieldPin12TMDSClock–

Pin3TMDSData2–Pin13NC

Pin4TMDSData1+Pin14Reserved(N.C.ondevice)

Pin5TMDSData1ShieldPin15SCL

Pin6TMDSData1–Pin16SDA

Pin7TMDSData0+Pin17DDC/CECGround

Pin8TMDSData0ShieldPin18+5VPower

Pin9TMDSData0–Pin19HotPlugDetect

Pin10TMDSClock+

CAT5 [RJ45]



NOTICE

1.Whenadjustingthesignallevelonthereceiverunit,pleasedialtherotarycontrolswitchfrom7to0

andstopturningtherotaryswitchwhenevertheaudio/videoisplayingnormally.Inappropriatesignal

levelsettingmaycauseoverpoweringissuethatwouldshortentheproductlifesignificantly!

2. IftheDVIorHDMIdevicerequirestheEDIDinformation,pleaseuseEDIDReader/Writertoretrieve

andprovideDVIorHDMIdisplayEDIDinformation.

3.AllHDMIoverCAT5transmissiondistancesaremeasuredusingBelden1583ACAT5e125MHzUTP

cableandASTRODESIGNVideoSignalGeneratorVG‐859C&VG‐870B.

4. ThetransmissionlengthislargelyaffectedbythetypeofCat‐5/5 e /6 cables,thetypeofHDMIsources,

andthetypeofHDMIdisplay.ThetestingresultshowssolidUTPcables(usuallyintheformof300m

[1,000ft]bulkcables)cantransmitalotlongersignalsthanstrandedUTPcables(usuallyintheformof

fixedlengthpatchcords).ShieldedSTPcablesarebettersuitedthanunshieldedUTPcables.Asolid

UTPCat‐5ecableshowslongertransmissionrangethanstrandedSTPCat‐6cable.Forlongextension

applications,solidUTP/STPcablesaretheonlyviablechoice.

5. EIA/TIA‐568‐Btermination(T568B)forCat‐5/5 e /6 cablesisrecommendedforbetterperformance.

6. ToreducetheinterferenceamongtheunshieldedtwistedpairsofwiresinCat‐5/5 e /6 cable,onecan

useshieldedSTPcablestoimproveEMIproblems,whichisworseninlongtransmission.

7. BecausethequalityoftheCAT5/6cableshasthemajoreffectonhowlongthetransmissionlimitcan

achieveandhowgoodisthereceivedpicturequality,theactualtransmissionrangeissubjecttoone's

choiceofCat‐5/5 e /6 cables.Fordesiredresolutionsgreaterthan1080ior1280x1024,aCat‐6cableis

recommended.

8. IfyourHDMIdisplayhasmultipleHDMIinputs,itisfoundthatthefirstHDMIinput[HDMIinput#1]

generallycanproducebettertransmissionperformanceamongallHDMIinputs.



PerformanceGuideforVGAoverRJ‐45/CAT5CableTransmission

PerformanceratingTypeofcategorycable

WiringShieldingCAT5CAT5eCAT6

Solid

Unshielded(UTP)

Shielded(STP)

Stranded

Unshielded(UTP)

Shielded(STP)

TerminationPleaseuseEIA/TIA‐568‐Btermination(T568B)atanytime



Tabla de contenidos

Otros manuales de Extensor de Hdav

Hdav

Hdav HDMI-C5IRB Manual de usuario

Hdav

Hdav HD4?C6E Manual de usuario

Hdav

Hdav HDMI-C5S4IR Manual de usuario

Hdav

Hdav HD-C5S4P Manual de usuario

Hdav

Hdav HD-C5 Manual de usuario

Manuales populares de Extensor de otras marcas

SY HDBT-60T Manual de usuario

Appsys ProAudio

Appsys ProAudio ADX-16 Manual de usuario

Atlona

Atlona RS232 Manual de usuario

IDK

IDK OPF-TH1000-A Manual de usuario

Enable-IT

Enable-IT 824WP Manual de usuario

Worx

Worx Landroid RadioLink WA0864 Hoja de especificaciones

TP-Link

TP-Link TL-WA730RE Manual de usuario

Camplex

Camplex CMX-HDMI-SFPL Manual de usuario

SC&T

SC&T HE03-4K Manual de usuario

Marmitek

Marmitek MegaView70 Manual de usuario

Samsung

Samsung SCS-26UC4 Manual de usuario

Foxun

Foxun SX-GES24 Manual de usuario

MuxLab

MuxLab 500771 Manual de usuario

foxunhd

foxunhd SX-AEX01 Manual de usuario

TERK Technologies

TERK Technologies LFIRX2 Manual de usuario

Devolo

Devolo Audio Extender Manual

Edimax

Edimax EW-7438RPn V2 Manual de usuario

Shinybow USA

Shinybow USA SB-6335T5 Manual de usuario
