Hathaway NG2015 Manual de usuario

8' HOT SHOT ARCADE BALL TABLE

ASSEMBLY INSTRUCTIONS

NG2015

Please Do Not Hesitate to

Contact Our Consumer Hotline

at 800-759-0977

with Any Questions That May

Arise During Assembly or

Use of This Product!

Ver. 1116

THANK YOU!

Thank you for purchasing this product. We work around the clock and around the globe to ensure

that our products maintain the highest possible quality. However, in the rare case of issues during

assembly or use of this product, please contact our Consumer Hotline at 800-759-0977 for immediate

assistance before contacting your retailer. Please read the warranty information at the back of these

assembly instructions for further details.

CARE AND USE

1. This product is intended for INDOOR use only.

2. Do NOT drag thetable when moving it, as this will damage thelegs.

ASSEMBLY TIPS

1. Find a clean, level surface to begin the assembly of your game table. We recommend that two adults

work together to assemble this game. You may want to carefully cut or tear the four corners of the box

so that the bottom of the box can be used as your work surface.

2. Remove all of the contents from box and verify that you have all of the parts shown on the Parts

List before you begin assembly. Note: Some parts may be pre-installed or pre-assembled.

3. Some figures or drawings may not look exactly like product.

4. When installing parts that have more than one screw or bolt, hand tighten all screws or bolts

in place before final tightening with screwdriver or wrench.

5. Electric screwdrivers may be helpful during assembly; however, please set a low torque and use

extreme caution because screws may be stripped or overtightened, resulting in damaged parts, if the

electric screwdriver’s torque is set too high.

WARNINGS!

READ AND FOLLOW ALL ASSEMBLY, OPERATION AND SAFETYINSTRUCTIONS CAREFULLY.

CHOKE HAZARD - THIS ITEM MAY CONTAIN SMALL BALLS AND PARTS

NOT SUITABLE FOR CHILDREN UNDER 3 YEARS OF AGE.

IMPORTANT! PLEASE READ THESE ASSEMBLY INSTRUCTIONS

IN ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT.

8’ HOT SHOT ARCADE BALL TABLE - NG2015

Parts List

PARTS

P1L NGP5856 P1R NGP5857 P2L NGP5858 P2R NGP5859 P3L NGP5860 P3R NGP5861 P4 NGP5862

P5 NGP5863 P6L NGP5864 P6R NGP5865 P7L NGP58661 P7R NGP58671 P8 NGP5868

FRONT END

APRION

P9 NGP5870

P10 NGP5871 P11 NGP5872 P12 NGP5873 P13 NGP5874

BACK UPPER

PANEL

LEFT FRONT LEG RIGHT BACK

LEG

FRONT BOTTOM

PANEL

LEFT BACK LEG SPREADER

LEFT FRONT

SIDE APRON

LEFT BACK

SIDE APRON

RIGHT BACK

SIDE APRON CROSSBEAM

NET FRAME

FRONT

FRONT TOP

PANEL

CONNECT HINGE

SET

BACK BOTTOM

PANEL

P16 NGP5877

TARGET BOARD

P14 NGP5875

BACKBOARD

P15 NGP5876

ELECTRONIC

SCORER

7/15

P17 NGP5878 P18 NGP5879 P19 NGP5880 P20 NGP5881

NET NET FRAME

BACK

P21 NGP5882

NET SPACER

BAR

RIGHT FRONT

LEG

LEFT MIDDLE

LEG

RIGHT MIDDLE

LEG

RIGHT FRONT

SIDE APRON

P23 NGP58831P22 NGP5884

SUPPORT PANEL

BALL

“L” SUPPORT

PANEL

P24 NGP58851 A1 NGP5886

P13

P17

P15

P7R

P6R

P6L

P24

P3L

P2L

P1L

P11

P1R

P16

P4 P10

P2R

P3R

P14 P20

P18

P19

P23

RESET SWITCH

NGP5888

RUBBER

GEAR HINGE

NGP5890

REAR APRON

TRIANGULAR

INSERT

P7L

NGP58761*

TARGET BOARD

WIRING HARNESS

NGP58762*

TARGET BOARD

FLIP SWITCH

*Pre-assembled on Target Board

P25 NGP5885

COVER PANEL

Illustrations Not to Scale

For replacement parts please call 800-759-0977.

H1 H2 H3 H4 H5 H6

5/16” BOLT 5/16” WASHER

1-1/4” SCREW

H8 ADDITIONAL EQUIPMENT

REQUIRED:

PHILLIPS HEAD

SCREWDRIVER

H11 T1

ALLEN WRENCH

1/4” FLAT

WASHER

1/4”X1-1/4” BOLT 1/4”X1” BOLT

1/4” FLAT

WASHER

3/4” SCREW 3/8” SCREW 3/4” FLAT

SCREW

HARDWARE PACK - NGP5887

T2 NGP58763

POWER

ADAPTER

H10

1-1/4” FLAT

SCREW

7/15 4

Illustrations Not to Scale

ASSEMBLY INSTRUCTIONS

Unfinished Side Up

Black Side Down

P10

P21

Figure 1

1. Find a clean, level place to begin the assembly of your game. We recommend building the unit on the shipping carton to

protect the parts during assembly. Note: The two main units are assembled upside down then turned over for final assembly.

2. Attach the SUPPORT PANEL, P21, to the FRONT BOTTOM PANEL, P10, using (3) SCREWS, H8, through the two

outer holes as shown in Figure 1. Note: The P10 panel and P21 support panel both have pre-drilled holes for screws.

3. Place the LEFT FRONT SIDE APRON, P6L, and RIGHT FRONT SIDE APRON, P6R, upside down and approx. 2 feet

apart, as shown in Figure 2.

4. Insert FRONT TOP PANEL, P9, with finished white side down, into lower grooves of SIDE APRONS, P6L and P6R.

Make sure the end of P9 with the cutouts is on the same end as gear hinge as shown in Figure 2. Slide P9 forward until

the end with cutouts is flush with SIDE APRON ends above gear hinges. With help from another adult, hold this assembly

firmly and attach pieces together using (2) SCREWS, H1, and pre-drilled holes on each side.

5. Attach FRONT END APRON, P5, with groove facing in, using (2) SCREWS, H1, and pre-drilled holes on each side.

Note: Don’t tighten screws all the way until you complete Step 6. This will make it easier to get P10 into P5 groove.

6. Insert FRONT BOTTOM PANEL, P10, with unfinished side up, into upper grooves of SIDE APRONS, P6L and P6R.

Slide P10 forward until the end is flush with SIDE APRON ends above gear hinges, even with panel P9. Tighten P5Screws.

Note: This unit is assembled

upside down.

P6L

Note: Location

of gear hinge

P6R

Note: Location

of gear hinge

Note: Location

of these cutouts

P10

Unfinished

Side Up Slide both

panels in grooves

White

Side Down

Figure 2

7. Attach CROSSBEAM, P8, with cutout opening facing down and to the left, using (2) SCREWS, H1, and pre-drilled

holes on each side, as shown in Figure 3.

8. Attach LEFT and RIGHT FRONT LEGS, P1L and P1R, using (2) BOLTS, H2, and (2) WASHERS, H3, on each leg, as

shown in Figure 3. Note: Hand tighten for now, and then do final tightening with ALLEN WRENCH, T1, once P4 Spreader

is attached in next step.

9. Attach SPREADER, P4, using (4) SCREWS, H1, as shown in figure 3. Note: Hand place screws in all four pre-drilled

holes to align panel before tightening.

CAUTION:

P4 SPREADER MUST BE CENTERED

CORRECTLY ONTO PRE-DRILLED HOLES

IN LEGS BEFORE ATTACHING WITH H1

SCREWS.

Figure 3

NOTE: Location

of gear hinge

P1L

P1R

ASSEMBLY INSTRUCTIONS (CONT.)

10. Attach the SUPPORT PANEL, P21, to the FRONT BOTTOM PANEL, P10, using (3) SCREW, H8, through the

three holes as shown in Figure 4. Note: The P12 panel and P21 support panel both have pre-drilled holes for screws.

Unfinished Side Up

Black Side Down

P12

P21

Figure 4

Figure 5

THANK YOU!ASSEMBLY INSTRUCTIONS (CONT.)

P7L

P7R

P23

11. Attach REAR APRON, P23,and CROSSBEAM, P8, to the LEFT BACK SIDE APROS,P7L, and RIGHT BACK SIDE

APROS, P7R using (4) SCREW, H1 as shown in Figure 5.

Figure 6

ASSEMBLY INSTRUCTIONS (CONT.)

Slide both

panels in grooves

Note: Location

of gear hinge Note: Location

of these cutouts

P12

P11

12. Insert BACK BOTTOM PANEL, P12, with unfinished side down, into lower grooves of SIDE APRONS, P7L and P7R.

Slide P12 forward until the end is flush with SIDE APRON ends below gear hinges, as shown in Figure 6.

White side up

13. Insert BACK TOP PANEL, P11, with finished white side up, into upper grooves of SIDE APRONS, P7L and P7R.

Make sure the end of P11 with the cutouts is on the same end as gear hinge as shown in Figure 6. Slide P11 forward until

the end with cutout is flush with SIDE APRON ends above gear hinges. With help from another adult, hold this assembly

firmly and attach pieces together using (3) SCREWS, H1, and pre-drilled holes on each side.

P7L

P7R

ASSEMBLY INSTRUCTIONS (CONT.)

Figure 7

14. Assemble LEFT and RIGHT MIDDLE LEGS, P2L and P2R, together with SPREADER, P4, using (4) SCREWS, H1,

as shown in Figure 7. Note: Hand place screws in all four pre-drilled holes to align panel before tightening. Attach “L”

SUPPORT PANEL, P22, in same manner using (6) SCREWS, H10, as shown.

15. Attach Middle Leg Assembly between assembled sides, P7L and P7R, using (2) BOLTS, H2, and (2) WASHERS, H3,

on each leg, as shown in Figure 7.Note: Velcro will be used as wire harness in future step.

16. Attach LEFT and RIGHT BACK LEGS, P3L and P3R, using (2) BOLTS, H2, and (2) WASHERS, H3, on each leg, as

shown in Figure 7. Note: Hand tighten for now, and then do final tightening with ALLEN WRENCH, T1, once P4 Spreader

is attached in next step.

17. Attach SPREADER, P4, between Legs using (4) SCREWS, H1, as shown in Figure 7.

Note: Hand place screws in all four pre-drilled holes to align panel before tightening.

CAUTION:

P4 SPREADER MUST BE CENTERED

CORRECTLY ONTO PRE-DRILLED HOLES

IN LEGS BEFORE ATTACHING WITH H1

SCREWS.

P4 P3L

P3R

Note: Correct location

Velcro

P22

H2 H3

P2L

P2R

H10

P22

of Support Panel to Legs

ASSEMBLY INSTRUCTIONS (CONT.)

Figure 8

H5 Bolt

Washer

P15

Note: Hinge Gear Assemblies Must Mesh

Note: This Hinge is Threaded and Must Be on Inside

CAUTION:

Pinch Point

CAUTION:

Pinch Point

Reset Button

Reset

Button

No Gap

Ligature

Bundle of

White Wire

P16

Hinge Set

P16

Hinge Set

P7R

Back Side

Apron

P6R

Front Side

Apron

Note: This Hinge is NOT Threaded

and Must Be on Outside

Washer

18. With the help of another adult, set both completed assemblies upright and position so gears face each other as shown

in Figure 8. Using (2) HINGE SETS, P16, connect assemblies using BOLT, H5, and Washer, H7, as shown in Figure 8.

The bolts should be snug,but NOT over tightened as this is a pivot area.Note: Hinge gear assembliesmust mesh together,

perdiagram,and thereshould be no gapbetweenplayfields. Also, only one hinge plate persetisthreaded andmust be

installed on the inside of eachplayfield side.

20. Place TARGET BOARD, P15, with red hole at the top, into position with the sides resting in the grooves of the braces

on the side panels and against the front of the ramp.

21. Attach the RESET BUTTON, with the long white wire, through the hole in the FRONT END APRON, P5, by removing

the washer and nut on the back of the Reset Button, feeding the Reset Button and wire through the hole from the front and

re-attaching the washer and nut. Note: Be careful not to damage or break wire connections while attaching Reset Button.

Reset Button -

(this ships

pre-wired to

Target Board)

P24

19. Attach TRIANGULAR PATCH, P24, on each side aprons using (2) BOLTS, H4, and (2) WASHERS, H6, on each patch,

as shown in Figure 8.

H4H6
