Hasselblad 503CW Manual de usuario

503CWOMS.EPS

960807

ANDERS ENGSTRÖM, ILLUSTRATÖR

Östra vägen 46

430 91 HÖNÖ

tel/fax 031-96 84 64

[email protected]

Victor Hasselblad AB

Göteborg Sweden

Service Manual

in retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopy, recording, or

otherwise, without the prior written permission of the Company.

October 1996

10.

11.

12.

13.

14.

15.

16.

17.

18.

19.

Camera body 503CW

Contents list

Revision 1 May 1997

General

Camera body 501C

Camera body 503CXi

Camera body 503CX

Camera body 500C/M (Classic)

Exploded view: Winding crank

Exploded view: Left hand wall and electronics

Exploded view: Right hand wall

Exploded view: Front bayonet plate

Exploded view: Auxiliary shutter and mirror assembly

Exploded view: Mechanism plate

Exploded view: Gear housing

Exploded view: Shell

Sub-assembly: Front bayonet plate and auxiliary shutter with mirror

Adjustment, final assembly and calibration of the flash meter

Reassembly

Disassembly

Tools

Camera body 501CM

Related Service Infos

Revision 4 January 2001

503CW - 501C - 503CX/CXi - 500C/M - 501CM

20/93 Flash metering circuit redesigned - 503CX

04/94 New camera - 501C

05/94 Exploded views and spare part specifications - 501C and 503CXi

06/94 Spare part No. changed - 500C/M and 503CX

12/94 Pin fitted in bayonet plate - 501C

04/95 Tripod foot modified - 501C and 503CXi

09/95 New tool - 503CXi

10/95 Updated pages - 503CXi

02/96 Signal arm shortened - 501C and 503CXi

14/96 New Service Manual - 503CW

14/97 New camera body - 501CM

15/97 Modifications - 501C and 503CW

28/97 Camera body in black finish - 501CM

12/98 New film speed range - 503CW

02/99

10/99 Discontinued parts - 501C, 503CXi, 503CX and 500C/M

Stray-light - 503CW, 501CM, 501C, 503CX/CXi and 500C/M

08/00

New CD-ROM - Version 1.3

09/00 Washer added in the gear box - 501CM and 503CW

01/00 New CD-ROM - Version 1.2

14/00 Discontinued parts - 500 series cameras

12/96 Tripod foot adapter/kits

17/93 Fitted with wrong spacers - 503C/M and 503CX

01/01 Modified magazine hook - 501CM and 503CW

Related Service Infos

Revision 4 January 2001

503CW - 501C - 503CX/CXi - 500C/M - 501CM 2.

New CD-ROM - Version 2.0

04/01

June 1998

Camera body 503CW General description

1:1

Revision 1

Camera type: Single lens reflex camera with 6 x 6 (2 1/4 x 2 1/4 in) max.

film size. Interchangeable lenses, film magazines, viewfinders

and focusing screens.

Weight: 610 g.

Lens mount: Hasselblad bayonet mount for CF and C lenses.

External

dimensions: 91L x 114W x 110H (3 9/16 x 4 1/2 x 4 11/32 in).

*Acute-Matte D designed by Minolta

Design: Mechanical, with an aluminium alloy camera body shell cast in

one piece.

Viewfinders: Folding focusing hood interchangeable with reflex viewfinder,

prism viewfinders with or without built-in exposure meter or

magnifying hoods.

Film advance: Manual advance or motor driven with Winder CW.

Simultaneous shutter cocking.

Winder CW winding time: 1.05 sec, approx. 0.8 frames/sec

in continuous mode.

Flash control: TTL/OTF-metering. ISO 16 - 1000 with flash adaptors

SCA390 or SCA590 for connection with flash units from the

SCA300 or SCA500 systems respectively. Metering area within

40 mm diameter in the centre of the image area.

Note! From camera serial No. 19ER18271 the ISO range is

changed to 64 - 4000.

Tripod coupling: 1/4 in and 3/8 in socket threads and base plate for quick

coupling attachments.

Focusing screen: Hasselblad Acute-Matte D* focusing screen.

Sales code No. 42204.

0 319°

300

280

260

240

220

200

180

160

140

120

100

120

140

160

180

200

220

240

260

280

300

320

340

360°

503DGRM1

961018

ANDERS ENGSTRÖM, ILLUSTRATÖR

Östra vägen 46

430 91 HÖNÖ

tel/fax 031-96 84 64

[email protected]

October 1996

1:2

Camera body 503CW Camera release sequence

April 1998

Revision 0

Release sequence

Pre-

released

position

Variable

timing

interval

Key

position

Mirror

Auxiliary

shutter

Lens shutter

Aperture f 2.8 f 22

1/500 sec

Tools

Camera body 503CW

October 1996

Revision 0

Tool No. Description Used for

2:1

V-2200 Bender Signal arm adjustment

V-2201 Bender Mirror arm adjustment

V-2202 Bender S-arm adjustment

V-2203 Bender Release arm adjustment (aux. shutter)

V-2205 Bender Supporting tool when using V-2201

V-2206 Winding knob Substitutes regular winding crank during

repair work

V-2211 Pin driver Fitting the locating pin in the front plate

and the front gear bracket

V-2224 Bender Release arm adjustment

V-2229 Focal length gauge Adjustment of the focal length,

mirror 45ºangle and focusing screen

V-2236 Microscope Focusing screen adjustment

V-2354 Exposure gauge Release sequence control

V-4151/52 Focusing tester Focusing screen adjustment

V-4704 Key Focusing screen adjustment

V-4705 Focusing screen adapter Focusing screen adjustment

Tools

Camera body 503CW

October 1996

Revision 0

Tool No. Description Used for

2:2

V-5423 Riveting jig Replacement of aux. shutter flaps

V-5942 Exp. gauge Release mechanism adjustment

902474 Test box ELX/CX Calibration of the TTL flash meter

902658 Key angle gauge Adjustment of the front key angle

(V-2075)

904644 Bayonet plate Stop lever adjustment

970600 Service Test System Calibration of the TTL flash meter

905020 Screwdriver Screws in the mirror box

January 2001

Camera body 503CW Disassembly

3:1

Revision 1

Camera shell

Remove the lens, film magazine, view finder, focusing

screen and winding knob.

Remove the screw (830060), coupling (22767) and

washer (22799).

Remove the leather (13374), shim (22473), screw

(822701) and ISO selector knob (22495).

Do not damage the sliding contacts.

Remove the cap (22470) from the chassis connector and

peel back the leather covering two screws

(823335). Remove these screws and firmly push the

chassis connector into the body of the camera.

Remove the tripod foot (30763) held by six screws

(829755). Remove the two rear screws (829755) and

the two front screws (820781).

Fig. 1.

The chassis can now be separated from the camera shell.

Ensure that the lens release button (13139), release

button (22759), buffer (22367), teflon cone (103773)

and distance washers (810620) are not dislodged from

the camera shell and lost.

Fig. 2.

Operate the S-release on the camera by pressing the

S-arm (21167) towards the stop. Remove the front gear

cover (22876). Do not remove the side cover (22813)

unless it is absolutely necessary.

The side cover is held in position by the spring (30775)

secured with two screws (829425) and double sided

tape.

Note! If removed, a new cover must be used when the

camera is reassembled.

Fig. 1

Fig. 2

May 2000

Camera body 503CW Disassembly

Revision 2

Circuit board (22575) *22882

CAUTION! When handling the circuit board a

grounded bench mat and a wrist strap must be

used to prevent ESD damage.

Lift the chassis connector out of the hole in which it is seated

in the left hand wall. Remove the two screws (820325) that

secure the photodiode. Gently ease the photodiode through

the hole in the left wall.

Remove the two screws (820011) and the grounding

attachment (22453). Remove the screw (820011) and the

cable holder (12453). Remove the two screws (820015) and

separate the circuit board from the chassis.

Finally, remove the insulating plate (22746).

* Note! The circuit board (22882) is fixed to the wall by an

insulating double-sided tape, screws and attachment.

Fig. 3.

Front bayonet plate (30777)

Disconnect the spring (814512) from the push rod (22369).

Remove the release bar (30375) by gently lifting it with a

screwdriver so that it is freed from the front gear wheel and

then easing it forward.

Remove the front bayonet plate (30777) by removing two

screws (820015) in each of the right and left sides, two

(821017) in the view finder screen frame and two (823655)

in the bottom plate. Carefully draw the front plate forward.

Fig. 4.

Note! The drive spring should be held when the gear wheel

is released to prevent damage to the drive spring by

releasing the tension too quickly.

Rear plate (30300)

(including auxiliary shutter)

Disconnect the arm (22781) secured to the mirror frame by

a clip (817115). Remove the washer (810649) underneath

the arm. Remove two screws (821017) on top of the

focusing screen frame and six (820015) then partly withdraw

the rear plate. When partly removed, disconnect both the

upper and lower connecting rods. The rear plate can now be

removed completely.

Fig. 5.

3:2

Fig. 3

Fig. 4

Fig. 5

823655

820015

821017
