Harman JBL QUANTUM Stream Manual de usuario

QUICK START GUIDE

Stream

Software requirements

PLATFORM: Windows 10 (64 bit only) / Windows 11

500 MB of free hard drive space for installation

*Always use the latest version of Windows 10 (64 bit) or Windows 11 for the most optimal experience on JBL QuantumENGINE

Download JBL QuantumENGINE to gain full access to features on your JBL Quantum Stream, such as EQ

settings, polar pattern selection and lighting customization. JBLquantum.com/engine

JBL QuantumENGINE

System compatibility

PC | Mac | PlaystationTM | Nintendo SwitchTM

USB power cable

QSG | WARRANTY CARD |

WARNING CARD

001 WHAT'S IN THE BOX

JBL Quantum Stream microphone

01 Touch button (Mic mute/unmute)

02 Volume knob

03 Polar pattern Indicators

04 USB-C port

05 3.5 mm headset port

06 Ring LED (RGB lighting + mute/unmute

indicator)

07 Rotary joint

08 Microphone stand

Note: Some controls may change with

firmware upgrade.

002 OVERVIEW

3.5 mm

2.5 mm

headset

PC | mac | PlayStation™ | Nintendo Switch™

* USB-C to USB-C cable is not included by-pack. Connectivity with USB-C may not

work with all models of said devices.

* 3.5 mm to 2.5 mm or 3.5 mm cable is not included by-pack.

PC | Mobile | LAPTOP | Nintendo Switch™

003 Connection

5a Connect the microphone to your PC via USB connection.

5b Go to “Sound Settings” -> “Sound Control Panel”.

5c Under “Playback” highlight “JBL Quantum Stream” and select

“Set Default” -> “Default Device”.

Note: By default, all sounds will be played through the JBL

Quantum Stream microphone and heard through a headphone

connected to it. To hear sound from the PC directly, select the

PC sound card as the default device.

5d Under “Recording” highlight “JBL Quantum Stream” and select

“Set Default” -> “Default Device”.

5e Follow the onscreen instructions to personalize your sound

settings.

004 First time setup

JBL Quantum Stream JBL Quantum Stream

>2S

Cardioid (Default)

Omnidirectional

005 Polar pattern

CARDIOID

Individual podcasts, gaming, streaming,

voiceovers, instruments etc.

Omnidirectional

Multi-person podcasts, conference calls,

streaming, voiceovers etc.

Recommended positioning Not recommended

006 Mute

>5S

× 1

mute

unmute

RGB lighting off

007 Volume

× 1 +

MICROPHONE

Power required/consumption: 5 V 500 mA

Sample rates: 44.1 kHz / 48 kHz / 96 kHz

Bit rate: 16 / 24 bit

Capsules: 14 mm Electret Condenser Microphone

Polar patterns: Cardioid & Omni-directional

Frequency response: 20 Hz - 20 kHz

Sensitivity: -37 ± 3 dB (1 kHz@1 Pa, 0 dB = 1 v/Pa)

Maximum SPL: 110 dB

HEADPHONE AMPLIFIER

Impedance: >16 ohms

Power output (RMS): 45 mWrms per channel (Load = 32 ohms)

THD: <0.5% (Load = 32 ohms)

Frequency response: 20 Hz - 20 kHz

Signal to noise: 90 dB (A weighted)

DIMENSIONS - MIC WITH STAND

Dimensions (L x W x H): 8 cm x 8 cm x 17.43 cm / 3.15" x 3.15" x 6.86"

Weight: 248 g / 0.547 lbs

008 TECH SPEC
