Blender Safety

You will be killed or seriously injured if

you don’t follow instructions.

You can be killed or seriously injured if

you don’t follow instructions.

Your safety and the safety of others is very important.

We have provided many important safety messages in this manual and on your appliance.

Always read and obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to hazards that can kill or hurt you and others.

All safety messages will be preceded by the safety alert symbol and the word

“DANGER” or “WARNING.” These words mean:

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and

tell you what can happen if the instructions are not followed.

wDANGER

wWARNING

IMPORTANT: This operation manual should be reviewed with all equipment operators as

part of your operator training.

840080600env03 10/24/01 10:07 AM Page 2

Blender safety

•Read the Operation Manual before using

blender. Keep this manual handy.

•Plug into a grounded 3 prong outlet.

•Do not remove ground prong.

•Do not use an adapter.

•Do not use an extension cord.

•To reduce risk of personal injury, unplug

cord from outlet when not in use, and

before putting on or taking off parts.

•Do not store utensils or other objects in

the container since the blender would be

damaged if inadvertently turned On.

•To prevent possibility of serious

personal injury, keep hands and

utensils out of blender container while

operating blender.

•Inspect container and cutter assembly

daily. Check cutter assembly for wear,

nicks, and broken or loose blades.

•If cutter assembly blades are loose,

discontinue use immediately and replace

cutter assembly. Do not attempt to repair

or tighten cutter assembly.

•Replace container and cutter assembly

at least every 12 months or sooner if

cutter assembly blade appears worn

or damaged.

•Always operate blender with container,

cover, and filler cap in place.

•Do not move or reposition base while unit

is On or operating.

•Do not use outdoors.

•Do not use with non-foods.

•To reduce risk of personal injury and to

prevent damage to blender or container

and cutter assembly, DO NOT insert

utensils into blender container while

operating blender.

•To prevent damage to blender, container,

or cutter assembly, DO NOT move or

shake blender while in operation. If

blending action stops during operation,

turn blender Off, remove container from

base, remove container cover, and use

a thin rubber spatula to push mixture

towards cutters.

•Do not submerge or wash the blender

base in a dishwasher.

•Do not place blender in or near water

while in operation.

•Do not spray the blender base with a

high-pressure spray gun.

•Disconnect power before cleaning.

•Disconnect power before servicing.

•Do not fill the container to a level higher

than the highest graduation marking.

•To prevent burns from hot liquids

splashing out of the container, always

remove filler cap from container cover

when blending.

•Never exceed recommended volume

when blending hot contents.

•Only authorized service/repair specialists

should repair the blender or open the

blender housing.

•Do not operate any appliance with a

damaged cord or plug or after the

appliance malfunctions, or is dropped

or damaged in any manner.

•NOTE: Only use the Hamilton-Beach

91300 blender container (part number

6126-91300, as provided with the unit).

– SAVE THESE INSTRUCTIONS –

IMPORTANT SAFETY INSTRUCTIONS

WARNING – When using electrical appliances basic safety precautions should be

followed, including the following:

840080600env03 10/24/01 10:07 AM Page 3

Parts and Features

The parts and features for the Tango Series Blenders are shown on this page. Become familiar

with all parts and features before using your blender. Page references are included

next to some features. Refer to those pages for more information about the feature.

Your Tango Series blender is designed for blending and mixing beverages.

Note: The Blender is not designed to crush ice. Ice cubes made in most icemakers may be

added to liquid ingredients in the blender to make daiquiris or similar drinks.

Cover

(p. 5, 6)

Container

(p. 5, 6, 7, 8)

Removable

Filler Cap

(p. 5, 6, 7, 8)

Model 91300

On (I)/Off (O)/

Pulse

Switch

(p. 5)

Model 91350

Timer Dial

(p. 6)

On/Off

Switch

(p. 6)

Gasket

(p. 5, 6)

Blades

(p. 5, 6, 7) Blender Base

(p. 5, 6, 7)

Collar

(p. 5, 6)

Model 91350 Model 91300

(Base Only Shown)

Low/Hi

Switch

(p. 5)

Cutter

Assembly

(p. 5, 6, 7)

840080600env03 10/24/01 10:07 AM Page 4

Operation

Controls

Two separate switches on the front panel

allow you to control the blender for precise

blending requirements:

•The On/Off switch will turn the blender

On for continuous operation or Off.

•The Pulse position on the On/Off

switch (Model 91300 only) turns on the

blender only when the switch is pressed.

When the switch is released, the blender

will stop. This will allow you to precisely

control the operation of the blender.

•The Hi/Low switch allows you to select

the following speeds:

Hi – 20,000 RPM Low – 18,500 RPM

Using the blender

Before you use the blender for the first

time, wash the container, cover, and

cutter unit assembly. Refer to “Cleaning

Instructions.” Do not put the cutter

assembly in the dishwasher.

To operate the blender, proceed as follows:

1.Place the blender on a clean, dry, level

surface, and set the On/Off switch to Off.

2.Place cutter unit in the threaded collar,

blades up. Slip the gasket OVER the

blades and onto the base of the

cutter assembly. Screw the completed

cutter assembly onto the container.

3.Plug the blender into an electric outlet.

4.Place the ingredients to be blended into

the container.

5.Place the container onto the base. Make

sure it rests securely on the base.

6.Place the cover and filler cap on the

container.

7.Set the Hi/Low switch to the desired

speed. See “Professional Blending

Techniques” for blending tips.

NOTE: If you want the blender to run for

short bursts, press the Pulse switch.

While you are pressing the Pulse switch,

the blender will run at the selected speed.

Release the Pulse switch to stop the blender.

wWARNING

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions

can result in death, fire, or

electrical shock.

wWARNING

Cut Hazard

Always place cover on container

before operating blender.

Do not put spoon or other utensils

in container when blending.

Failure to follow these instructions

can result in broken bones, cuts, or

other injuries.

Operating the Blender–

Model 91300

On (I) /

Off (O) /

Pulse

Switch Hi/Low

Switch

840080600env03 10/24/01 10:07 AM Page 5

Operation

Controls

Two separate switches on the front panel

allow you to control the blender for precise

blending requirements:

•The Timer dial (Model 91350 only)

allows you to select the blend time. Turn

the dial clockwise to the desired setting.

•The On/Off switch will turn the blender

on for continuous operation or off.

Using the blender

Before you use the blender for the first

time, wash the container, cover, and cutter

assembly. Refer to “Cleaning Instructions.”

Do not put the cutter assembly in the

dishwasher.

To operate the blender, proceed as follows:

1.Place the blender on a clean, dry, level

surface, set the On/Off switch to Off, and

turn the timer dial counterclockwise to the

off position.

2.Place cutter in the threaded collar, blades

up. Slip the gasket OVER the blades and

onto the base of the cutter assembly.

Screw the completed cutter assembly

onto the container.

3.Plug the blender into an electric outlet.

4.Place the ingredients to be blended into

the container.

5.Place the container onto the base.

Make sure it rests securely on the base.

6.Place the cover and filler cap on the

container.

7.Select the desired blend time.

8.Move the On/Off switch to the On position.

Release the switch; blending will stop

automatically after the desired time.

9.For manual operation, set the dial to

“manual”. Blender will need to be turned

on/off manually.

wWARNING

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions

can result in death, fire, or

electrical shock.

wWARNING

Cut Hazard

Always place cover on container

before operating blender.

Do not put spoon or other utensils

in container when blending.

Failure to follow these instructions

can result in broken bones, cuts, or

other injuries.

Operating the Blender–

Model 91350

Timer

Dial

On (I) /

Off (O)

Switch

840080600env03 10/24/01 10:07 AM Page 6

Professional Blending Techniques

Filling the container

When filling the container with ingredients,

follow these recommendations:

• Use sufficient amount of liquid to ensure

that the mixture is fluid and free-running

at all times. Pour the liquid into the

container FIRST.

• Cut solid ingredients into pieces that are

no bigger than a 1″cube.

• Add the ingredients to container in batches.

Do not blend maximum volume all at once.

• Do NOT overfill the container with product.

This may prevent the blender from

processing the product properly.

Process dense foods or thick mixtures

in small batches, and remember that the

volume of the product normally increases

during processing.

• Do not exceed 8 oz. of content when

blending hot product.

• Always place the cover and filler cap on

the container when blending. For blending

hot liquids, remove filler cap from

container cover before blending.

Blending techniques

Icy drinks – Do not use blender to crush

large ice cubes. The blender is not

designed for this. Small ice cubes or

crushed ice is recommended. Pour in

liquid, then add ice. Cover. Turn blender

On and process until desired consistency

is reached. Chunks of frozen fruit can be

added to milk or fruit juice to produce a

sherbet or slush.

Blending hot mixtures

IMPORTANT: To minimize the possibility

of scalding, the following precautions MUST

be observed:

•Do not exceed 8 oz. of content when

blending hot product. Remember that the

volume of the product normally increases

during processing.

•Always place the cover on the container

and remove the filler cap from container

cover when blending hot liquids to prevent

the build up of pressure.

•Never stand with your face directly over

the container when operating the blender

where steam may be released.

Filler Cap

Use the filler cap to add liquids to the

container while the unit is running.

wWARNING

Burn Hazard

Always use caution when blending

hot contents.

Failure to follow these instructions

can result in burns.

840080600env03 10/24/01 10:07 AM Page 7

Caring for the Blender

Cleaning Instructions

General cleaning

The jar should be cleaned immediately

AFTER EACH USE. The jar can be

cleaned in the following manner:

1.Fill the jar half full with warm water,

122° F (50° C).

2.Add a drop of liquid detergent or

1/2teaspoon of detergent powder.

3.Place the cover/filler cap on the jar and

blend for 30 seconds.

4.Turn the blender off, and then rinse

the jar and wipe down to dry. Do not

disassemble the cutter assembly.

5.Wash the jar cover/filler cap in warm,

soapy water. Rinse and let dry.

6.Unplug the blender.

7.Wipe down the blender base with a

damp cloth.

Sanitizing

If the blender will not be used again

within 1 hour, sanitize the container

in the following manner:

1.After washing the jar, fill it with a cold

chlorine-based sanitizing solution that

has a minimum chlorine concentration

of 100 parts per million.

See recommended solution below.

2.Place the cover/filler cap on the jar and

blend for a minimum of 2 minutes.

3.Empty the jar but do not rinse.

4.Dry the jar by placing it with its

cover on the blender base and turn the

blender On for 2 seconds.

5.Immerse the cover and filler cap in

sanitizing solution for 2 minutes.

Recommended Sanitizing Solution:

The sanitizing solution should consist of

1 tablespoon of household bleach per 1

gallon of clean, cool water (60° F, 16° C)

mixed according to the instructions on

the bleach. When using a sanitizing

solution other than that recommended,

the sanitizing solution concentration

should be tested using commercially

available test strips and should indicate a

concentration between 100 and 200 parts

per million of bleach to water.

wWARNING

Cut Hazard

Always place cover on container

before operating blender.

Do not put spoon or other utensils

in jar when blending.

Failure to follow these instructions

can result in broken bones, cuts, or

other injuries.

wWARNING

Electrical Shock Hazard

Disconnect power before cleaning.

Replace all parts before operating.

Do not immerse base in water or

other liquid.

Failure to do so can result in death

or electrical shock.

840080600env03 10/24/01 10:07 AM Page 8

Troubleshooting Guide

Replacement Parts

Problem . . . Solution . . .

Blender fails to start

or stops while it is

running and cannot

be restarted

• Check to see if unit is securely plugged into an electric outlet.

• Check to see if the fuse for the electric outlet has blown or if a

circuit breaker has tripped.

Maintenance

Unplug the blender and remove the container from the base, and then inspect the

container and cutter unit assembly for wear, nicks, and broken or loose blades.

Replace if necessary. If the blades are loose, discontinue use immediately and

replace the blades. Do not attempt to repair or tighten the cutter assembly. See

“Replacement Parts” below.

Unplug the blender, and then inspect the power cord insulation and power plug for

cracks. Refer to “Requesting Assistance or Service” for repair or replacement.

Replace the container and cutter assembly at least once a year. See “Replacement

Parts” below.

91300/91350 1 container 6126-91300

91300/91350 Cutter assembly 99200

Model Part Description Part Number

Inspect the blender and its various parts and replace as follows:

Daily

Weekly

Yearly

Ingredients will not mix

properly • Check to see if enough liquid has been added to the ingredients.

Mixture should be fluid and free-running at all times.

• Solid pieces are too large. Pieces should not exceed 1"cubes.

• Container is too full. Do not fill past highest graduation marking.

• Cutter unit blades are not sharp or are damaged. Inspect

container and cutter assembly daily. Replace container and

cutter assembly at least every 12 months or sooner if cutter

assembly appears worn or damaged.

• Check to see if cutter assembly is installed properly.

• Select speed to create a fluid blend.

Refer to “Requesting Assistance or Service” to order parts below.

Caring for the Blender

Model 91350 fails to

start when switch is

depressed.

• Depress switch to the Off position, then release. Then turn blender

On according to the instructions.

840080600env03 10/24/01 10:07 AM Page 9

Call our toll-free customer service number

1-800-572-3331

www.commercial.hamiltonbeach.com

8 a.m. – 5:30 p.m. EST Monday – Thursday, 8 a.m. – 5:15 p.m. EST Friday

Requesting Assistance or Service

Before calling for assistance or service,

please check the “Troubleshooting Guide”

on page 8. If you still need help, follow the

instructions below.

Whenever you call to request assistance

or service, you need to know the complete

model number. You can find this

information on the label on the bottom of

your blender.

Please also record the purchase date of

your equipment and your dealer’s name,

address, and telephone number.

Model Number ______________________

Purchase Date ______________________

Dealer Name ________________________

Dealer Address______________________

Dealer Phone ______________________

You can also order replacement parts

by calling your nearest Hamilton Beach

Commercial Service Center or your local

dealer.

840080600env03 10/24/01 10:07 AM Page 10

Otros manuales para Tango Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Licuadora de Hamilton Beach

Hamilton Beach

Hamilton Beach HBF400 Manual de usuario

Hamilton Beach

Hamilton Beach Tango Series Manual de usuario

Hamilton Beach

Hamilton Beach Rio Series Manual de usuario

Hamilton Beach

Hamilton Beach HMI Series Manual de usuario

Hamilton Beach

Hamilton Beach 908 Series Manual de usuario

Hamilton Beach

Hamilton Beach HBH650 Manual de usuario

Hamilton Beach

Hamilton Beach 59766 Manual del propietario

Hamilton Beach

Hamilton Beach 908 Series Manual de usuario

Hamilton Beach

Hamilton Beach Personal Creations 51146 Manual de usuario

Hamilton Beach

Hamilton Beach 52300 Manual de usuario

Hamilton Beach

Hamilton Beach HBB908 - Bar Blender, 44 oz. Poly Top Manual de usuario

Hamilton Beach

Hamilton Beach 58143 Manual de usuario

Hamilton Beach

Hamilton Beach MultiBlend 53511 Manual del propietario

Hamilton Beach

Hamilton Beach 53514 Manual de usuario

Hamilton Beach

Hamilton Beach HBH450 Manual de usuario

Hamilton Beach

Hamilton Beach Tango Series Manual de usuario

Hamilton Beach

Hamilton Beach Summit HBH850 Manual de usuario

Hamilton Beach

Hamilton Beach 840141302 Manual de usuario

Hamilton Beach

Hamilton Beach Aguas Frescas 50162 Manual de usuario

Hamilton Beach

Hamilton Beach MultiBlend 58151-SC Manual de usuario

Hamilton Beach

Hamilton Beach 53620 Manual de usuario

Hamilton Beach

Hamilton Beach 50163 Manual del propietario

Hamilton Beach

Hamilton Beach 59205C Manual de usuario

Hamilton Beach

Hamilton Beach 58616 Manual del propietario

Manuales populares de Licuadora de otras marcas

ROTOR

ROTOR 1125.201 Manual de usuario

Braun

Braun Multiquick 5 Vario series Manual de usuario

ARENDO

ARENDO MIRA 305424 Manual de usuario

CHEF-BUILT

CHEF-BUILT CCB-3500 Manual de usuario

Viconte

Viconte VC-4406 Manual de usuario

Oster

Oster BLSTAB-CB0 Manual de usuario

HOFFEN

HOFFEN MC-3005 Manual de usuario

Black & Decker

Black & Decker BLC18750DM Manual de usuario

Sunbeam

Sunbeam 4182 Manual de usuario

Bialetti

Bialetti FMX35 Manual de usuario

Black & Decker

Black & Decker BL8000 Manual de usuario

Duronic

Duronic BL530 Manual de usuario

Exquisit

Exquisit MS 3002 wes Manual de usuario

Lumme

Lumme LU-KP1891A Manual de usuario

Binatone

Binatone HB-735 Manual de usuario

Moulinex

Moulinex LM936E10 Manual de usuario

Oster

Oster VERSA Manual de instalación y operación

Ninja

Ninja NN210Q Manual de usuario
