Hakko Electronics FX-888D Manual de usuario
Soldering iron
•
Digital model in an analog-model price bracket
•
Features adjustment mode, preset mode, and password function
•
Separable tip/heater design provides excellent value for money
•
Supports the N
2
system.
Model No. FX888D
Power consumption 70W
Temperature range 200-480ºC
Temperature stability
±1ºC at idle temperature
・Station
Output voltage
AC 26V
Dimensions 100(W)×120(H)×120(D)mm
Weight 1.2kg
・Soldering Iron
Power consumption 65W (26V)
Tip to ground resistance
<2Ω
Tip to ground potential
<2mV
Standard tip Shape-B (No.T18-
B)
Heating element Ceramic heater
Cord length 1.2m
Total length 217mm (with B tip)
Weight 46g (with B tip)
* Length and weight (w/o cord)
Model No. Unit Color Iron Holder Color Packing list
No.FX888 Blue-Yellow Blue-Yellow
Soldering station (FX-888D), Soldering
iron (FX-8801 with soldering tip type B),
Iron holder (with cleaning wire, cleaning
sponge), Instruction Manual
*Rubber cleaner sold separately.
Reliable digital technology by HAKKO – Introducing the HAKKO FX-888D
Excellent thermal recovery
•
Heater output has been increased by 30% compared to that of the conventional models
HAKKO 936・937. Also FX-888D delivers excellent thermal recovery by using T18
series tips for their terrific heat conductivity.
This allows soldering at a lower set temperature and reducing the thermal impact on
components as well as tip oxidation that can shorten tip life.
•
Thermal recovery graph
Rise time to 350°C is 20 seconds faster and tip temperature drop is reduced during
continuous work.
•
HAKKO FX-888D performance comparison graph with conventional stations
Able to shorten the time required for the same work and improve work efficiency
significantly.
Designed to be User-Friendly
•
Small footprint
Compact station body requires a space of only 100 (W) x 120 (D) mm. What’s more,
points that come into contact with the floor are positioned as close to the outer edge of
the body as possible to improve stability and make the station difficult to fall over.
•
Simple and easy operation
With only two operation buttons of UP and ENTER in the center, operation is simple
and easy. Even if you’re not familiar with operation of machines, you can operate it
without difficulty.
•
Iron holder with full of functions
An iron holder of the same color of a soldering station comes as a set. The highly
functional iron holder not only improves ease of use, but also brings a sense of visual
consistency to the work environment.
Blue & yellow
Soldering station Iron holder
Strict temperature management
•
Digital display
The FX-888D’s digital display makes it easy to check the set temperature at a glance.
•
Password function
Settings can be locked using a password to prevent them from being changed
unexpectedly. Of course, it is possible to restrict all setting changes or prevent users
from switching to particular modes. It allows you to choose a style of usage best suited
for your worksite.
•
Preset mode
This feature is very convenient when you want to change the set temperature to suit a
particular workpiece, component, or tip shape. Simply select the desired temperature
from a selection of preset temperatures registered in advance. (Up to 5 preset
temperatures can be registered.) Preset mode can save your trouble and improve
workability.
•
Adjustment mode
Temperature adjustment* is an essential part of any strict quality control system. With
adjustment mode, what used to be a troublesome procedure is now as simple as
entering the measured tip temperature to FX-888D.
*Adjust the tip temperature to match the set temperature in case that there is a
difference between those temperatures due to tip shape, heater replacement, or other
factors.
Measuring tip temperature with a tip thermometer (HAKKO FG-100)
HAKKO FX-8802 N
2
(nitrogen) gas system
A space-saving N2 system. Anti-oxidation and
pre-heating significantly improve solderability.
—Example Configuration (N
2
System)
Soldering station, Iron holder, N2 gas generator, and N2 flowmeter must
be purchased separately.
HAKKO FX-8803 One-hand, manual-solder-feed iron
— Example Configuration (One-hand, Manual-Solder-Feed System)
Soldering station and Iron holder must be purchased separately.
HAKKO FX-8804 Hot tweezers
—Example Configuration (Hot Tweezer System)
Soldering station, cap, and Iron holder must be purchased separately.
How to remove the bottom plate.
1. Press the slide lock button inward.
Note Press it firmly from upward. It is easy to
open by the slide lock sloping inward.
2. Open the iron holder base while pressing the
slide lock.
3. Remove the solder waste in the bottom plate.
T18 Series
Shape BC/C
T18-C05 Shape-0.5C
T18-C08 Shape-0.8C
T18-C1 Shape-1C
T18-C2 Shape-2C
T18-C3 Shape-3C
T18-C4 Shape-4C
T18-C5 Shape-5C
T18-CF1 Shape-1CF
Tinned cut surface only
T18-CF15 Shape-1.5CF
Tinned cut surface only
T18-CF2 Shape-2CF
Tinned cut surface only
T18-CF3 Shape-3CF
Tinned cut surface only
T18-CF4 Shape-4CF
Tinned cut surface only
T18-CSF25 Shape-2.5CSF
This type has good heat transfer with short tip end design, tinned cut surface ony.
T18-S6 Shape-S6
Shape B
T18-B Shape-B
T18-BL Shape-BL
T18-S4 Shape-S4
T18-SB Shape-SB
Shape D
T18-D08 Shape-0.8D
T18-D12 Shape-1.2D
T18-D16 Shape-1.6D
T18-D24 Shape-2.4D
T18-D32 Shape-3.2D
T18-DL12 Shape-1.2DL
T18-DL2 Shape-2DL
