Haier WNA600TX Guía del usuario
AUTOMATIC DRUM
WAS HING MACHINE
INSTRUCTIONS FOR
INSTALLATION AND
OPERATION
Dear customers, congratulations. You have once again made a wise and
sensible purchase. By choosing our Washing machine you not only found
the best in advanced technology, but above all you have found a faithful,
untiring and reliable friend.
Your machine is strong, reliable and long lasting. All those qualities which
have made the our trademark famous the world over.
From today, these qualities are at your disposal to help you resolve your
daily household problems.
Your machine is easy to use. Read this owner's manual carefully since
contains all the instructions for safe installation, use and maintenance.
Remember to keep your owner's manual in a safe place so that you can
refer to it whenever you need to.
FUNCTION INTRODUCTION............................ ..3-4
INSTALLATION....... .................................5-7
CLOSE UP.................................. ..........8-10
USING INSTRUCTIONS..................... .............11-15
MAINTENANCE................................. ........16
SOLUTION TO PROBLEMS............. ..............17-18
ATTACHED CHART:
GUIDE FOR SELECTING PROGRAMME.......... ..................19
.......................
...................................
.....................................
........................
..................................
......................
.......
WARNING....................................................................................20
FUNCTION INTRODUCTION
FUNCTION COMPARING TABLE
FUNCTION
MODEL
Washing capacity
Power switch
ON/OFF
WNA600TX
5kg
16
600r/min
330W
650W
74kg
850X550X595mm
HxDxW
Weight
Power(Spin)
Power(Wash)
Door-locking device
Plustic tub
Rinse
Spin speed
No soak
Economic wash button
Cold wash button
Thermostat ajustable(0-90 C)
Wool
Synthetic
Cotton
Programmes
Power(Heating)1950W
FUNCTION INTRODUCTION
European andAsiaAesthetic design, elegant and beautiful.
Three types of wash: rinse, beat and rain effect.
Changeable washing function: cold wash and hot wash,No soak
Three types of laundry: cotton, synthetic and wool, with 16 cycles.
Alarge washing capacity: 5 kg.
Stainless steel drum; painted cabinet with three layers of
cataphresis, phosphorus and paint.
Rinse with anti-crease system, care for clothes.
Super anti-shock design.
Self-lock device for the door.
Characteristics of WNA600TX
Remove the package and check that the machine is
undamaged.
If you have any doubts, do not use the machine and call on a
qualified technician. Keep all packing parts (plastic bag,
foam rubber, screws etc.) out of the reach of children since
they could be dangerous.
The inside of the washing machine which
consists of a floating unit, is fixed with screws at the back of
the cabinet (Fig.1) during transport. Before starting the
machine remember to release the floating unit by removing
the above screws . To prevent water spray from entering the
machine, remember to close the holes left open by the
screws with the plastic caps provided in the packet
containing the owner's manual. And rescrew the holes
where the iron piece is taken down with the former two
screws.Attention:keep the packing screws and plastic caps
in a safe place for later use. It is important for the machine to
be perfectly level (the angle of inclination on the work surface
must not be more than 2 degrees). For this reason the
machine is fitted with adjustable feet used for levelling the
machine before use (Fig.2). In the case of flooring with
carpeting, remember to check that the ventilation in the
support area is not plugged.
Important:
Fig.1
Unpacking
levelling and
positioning
Installation
Fig.2
Connect the plug to a socket provided with efficient earthing.
Or use the spare earthing wire supplied together with the
machine and the earthing terminal located on the left-upper
corner of the back of your machine (Warning: this appliance
must be earthed as a safety measure according to the law).
Make sure that the voltage and frequency available
correspond with the values stated on the data plate located at
the back of the machine and that the electric system is
dimensioned to withstand the maximum current shown on the
data plate. If the socket the machine is connected to does not
correspond with the plug, replace the plug with a suitable one
and avoid using adaptors or shunts since they could cause
overheating and burn out.The spare eathing wire is
absolutely not allowed to be connected to water
pipe,heating pipe or other kinds of pipes.
Installation
Electric
connection
Connection
of tap and
Loading
Hose
Connect the inlet hose to a cold water tap with a 3/4 gas
threaded opening, and fit the filter and the rubber gasket
supplied with the washing machine. Check that it is tightly
screwed to the tap (Fig. 3).
If the water piping is new or has not been used for a long time,
before making the connection, let the water run until it is clear
and free from impurities.
This step is necessary to ensure that the incoming water
does not clog and possibly damage the machine.
Fig. 3
Installation
Connect the drain hose to a drain duct (with internal
diameter of at least 4 cm.) or place it for drainage into
a sink or a tub, ensuring that there are no kinks or
bends. The free end must be at a height of between
80 and 100 cm. Should it be necessary to fix the end
of the hose at a height of less than 80 cm from the
floor, the hose must be fixed in the appropriate hook
on the upper part of the back panel (Fig.4) or use the
supplied support to fix the drain hose.(Fig.5)
Connection of
the Drain Hose
Fig.4 Fig.5
Insert stainless steel screen washers into end of each
supply hose and attach that end of supply hose to
your 3/4" water tap spigot.Be sure that you match up
cold water to "C" .Note:Home Centers also have"Y"
connectors and "Couplings" which enable you to
connect the machine to your sinks faucet.
Connecting
WaterSupply
Close up
A
B
C
D
E
G
F
Close up
AProgramme selector Knob.
By turning this dial (clockwise only) you can
select from sixteen wash programmes the one
most suited for your washing.
1~7 cotton cycle
8~12 synthetic cycle
13~16 wool cycle
CPower Light
This light indicates whether the electricity is on or
off. The light comes on when button D is pressed
and goes off when button D is not pressed.
DON/OFF Button
ON/OFF button. Supplies electrical power to the
machine.
E Economic Wash Button.
It reduces water and power consumption when
rinsing if the machine does not have a full load.
(Less than 3kg)
C C
