Haier PBFS21EDAP/S/E Manual de usuario

Order No.

Ref0910S006V0

◎2009(HAIER ELECTRICALAPPLIANCES COR. LTD)

SERVICE MANUAL

Haier Group

Refrigerator

MODEL:PBFS21EDAP/S/E

RBFS21TIAP/S/E

RBFS21SIAP/S/E

PRFS25EDAP/S/E

This service information is designed for experienced repair technicians only and is not designed for use by the general public. It

dose not contain warnings and cautions to advice non-technical individuals of potential dangers in attempting to service a product.

Product powered by electricity should by serviced or repaired only by experienced professional technicians. Any attempt to service

or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.

WARNING

CONTENTS PAGE

1. PARTS IDENTIFICATIONS--------------------------------------------------------------1

2. PARTS DISASSEMBLY -------------------------------------------------------------- 2-8

2.1 Door Removal----------------------------------------------------------------------------2

2.2 Freezer Drawer Removal--------------------------------------------------------------3

2.3 Dispenser Panel Label Removal-----------------------------------------------------4

2.4 Mullion and Mullion Heater Replacement----------------------------------------5-7

2.5 Freeze Sensor Replacement----------------------------------------------------------8

3. CONTROL AND DISPLAY SYSTEM---------------------------------------------9~15

4. REFRIGERATION PRINCIPLE-------------------------------------------------------16

System flow chart and scenograph------------------------------------------------------16

5. CIRCUIT DIAGRAM----------------------------------------------------------------17~22

5.1 Schematic----------------------------------------------------------------------------17~19

5.2 Connect diagram-------------------------------------------------------------------20~22

6. Sensor and Error code-----------------------------------------------------------------23

7. TROUBLESHOOTING-------------------------------------------------------------24~37

7.1 Common Troubles in Refrigerators and Remedies------------------------24~35

7.2 Sensor Replacement-------------------------------------------------------------------36

7.3 Instruction of Check Variable Speed Compressor------------------------------37

8. Other(Icemaker and defrost details)--- ------------------------------------------38

CONTENTS

Model Designations

Bottom Mount

21 - 25 cu ft Refrigerator / Freezer

Details:

PRODUCT CODE and SERIES INTRODUCTION

P B F S 21 E D A S

S: Stainless E: Black P: White

A: Production series

D: Dispenser and Icemaker I: Icemaker

E: Elite S: Supreme T: Plus

21：Capacity

S: Spill-proof shelving

F: Four doors

B: Bottom Mount Freezer

P: Phoenix series R: Standard series

PARTS IDENTIFICATIONS



Freezer

&KLOOFROGVWRUDJHÀRRGOLJKW

:DWHU¿OWHU

'LDU\IRRGER[

Diary foChill-cold

storageUDFNRGER[

Liquid rack

Slide rack

Fruits and

VHJHWDEOHVER[

Gallon

bottled seat

Cooked-

IRRGER[

Ice-making

drawer

Deepfreeze

refrigeration big

drawer

Deepfreeze

fridge

Ice spoon

Ice-maker

Ice-meeting

drawer

Drawer

clapboard

Deepfreeze

fridge big

drawer

For the application of this brochure to different models, the characteristics of the refrigerator you are

using may be different from the descriptions in this brochure.

Note

2.1 Right French Door Removal and Installation

1. Remove the screws on the top hinge cover,then set aside the top hinge cover and

lay it down for installing later;

2. Using a screwdriver,remove the top hinge screws.Remove the hinge,then take the

door off and place it aside;

3. Remove the middle hinge if necessary;

4. Install the door in reverse sequence.

Left French Door Removal and Installation

1. Firstly,remove the top hinge cover as above;

2. Disconnect the water pipe from back of cabinet(just for those models with Water

dispenser);

3. Remove the hinge screws by a screwdriver,and take off the hinge,then remove the

door and place it aside,Disconnect the wire cable connector,ground wire,then pull

out the water pipe(just for those models with Water dispenser);

4. Remove the middle hinge if necessary;

5. Install the door in reverse sequence.

Remark:If the refrigerator without water dispenser,just disconnect the all the wire

connectors.

DISASSEMBLY



2.2 Center Freezer Drawer Removal and Installation

1. Firstly,open the door as far as possible,and take off the drawer, then remove the

screws fixing slideway on each side of the drawer;

2. Pull the drawer body up and towards you,then place it aside;

3. Remove the screws fixing the slideway fixture on door;

4. Install the drawer in reverse sequence.

Remark:the removal and installation of bottom freezer drawer are the same as above.

DISASSEMBLY



2.3 Instruction of removal Dispenser Panel Label on BM21 series

(Only for those models with Water Dispenser)

Tools Required:

Knife or sharp screwdriver

Warning: Please do protect the refrigerator!

Instruction:

1. Insert the knife under the panel label to remove the label.

2. Unrip the label (with the knife) about 8cm,then it’s easy to remove the whole label.

3. Remove the screw under the label.

Remark: The label can be used for several times.

DISASSEMBLY



2.4 Instruction of Assembling Door Mullion on BM21/25 series

1. Install top axis of mullion through the heater;

2. Paste the heater onto mullion;

3. Fix the earth wire;

4. Install the reinforce metal and foam on the bottom cover;

5. Fix the bottom cover on the mullion,then fix the spring,bottom axis,foam airproof;

6. Fix the top axis and top cover;

7. Fix the 5 screws.Preinstall mullion is OK.

DISASSEMBLY



Instruction of Replacing Door Mullion heater on BM21/25 series

1. Remove the screws on mullion;

2. Disconnect the earth wire and connector;

3. Remove the screws on mullion;

4. Remove the upper cover,seal and bottom cover;

5. Remove the screw fixing earth wire;

6. Tear off the heater and replace a new one.Then Install it according to the steps above.

Notice:

1. Be careful:the distortion of clip will cause gap between the bottom cover and mullion.

2. After reassembly mullion,run 5-10 minutes,feel surface of the mullion.If it’s not warm,check

the connection,and reconnect if necessary.

DISASSEMBLY



Instruction of Replacing Horizontal Mullion heater

1. Remove the screws fixing horizontal mullion;

2. Dismantle the horizontal mullion and foam airproof;

3. Disconnect the linking clip and mullion heater;

4. Remove the screw fixing earth wire of heater,then tear off the heater;

5. Install the horizontal mullion according to the above steps.

Notice: Be careful:the distortion of clip will cause gap between the airproof and horizontal

mullion

DISASSEMBLY


